Edge grinder

Felder

Condition: as good as new (ex-display), Exhibition Machine For sale is our Felder RL-200 clean air extraction unit from our showroom, with a maximum air flow of 4,000 m³/h. The extraction unit is in like-new condition and has been inspected and serviced by our professional staff. Technical Data: - H3 dust-tested - Extraction connection diameter: 200 mm - Extraction possible on both right and left sides - Automatic chip shaker - Steel impeller - Max. air flow 4,000 m³/h - Minimal space requirement: 1,775 x 898 x 2,005 mm (L x W x H) - Year of manufacture: 2022 - Machine No.: 31.04.114.22 The clean air unit is located in A-5431 Kuchl and can be inspected at any time during our opening hours. Subject to prior sale! Related terms: extraction, extraction unit, clean air unit, clean air, RL Nkodpfx Aaexdkzqjxot Reference: R-L0CE0

Condition: used, Year of construction: 2012, functionality: fully functional, milling spindle length: 130 mm, height adjustment type: mechanical, table length: 2,070 mm, type of input current: three-phase, spindle diameter: 30 mm, spindle speed (max.): 10,000 rpm, extraction connection diameter: 100 mm, input voltage: 400 V, rotational speed (min.): 3,500 rpm, rotational speed (max.): 10,000 rpm, working length of spindle: 130 mm, Equipment: motor brake, – Year of manufacture: 2012 – Austrian production – Spindle adjustable from 0° to 45° – Sliding table for tenoning operations – CE marking TECHNICAL SPECIFICATIONS: – Spindle diameter: 30 mm – Spindle height: 130 mm Nsdpfx Aasycqiyexskt – Maximum tool diameter (allows use of large milling tools): 230 mm – Maximum tool diameter at 45°: 125 mm – 4 spindle speeds: 3500 / 6500 / 8000 / 10000 rpm – Main motor power: 5.5 kW – Electric motor with brake – Table dimensions (L x W): 780 x 970 mm – Sliding table dimensions (L x W): 2070 x 350 mm – "x-Roll" sliding table – Manual height adjustment – Manual angle adjustment: 0° - 45° – Quick-change spindle system – Fence on carriage – Additional table on carriage – Right/left rotation – Extraction port diameters: 100 and 80 mm – Transport dimensions (L/W/H): 220 x 90 x 150 cm – Weight: approx. 350 kg

Condition: used, Year of construction: 2022, 0,4 - 5 mm Workingpiece thickness from to 10 - 45 mm Nkedoxpn Ufspfx Aaxjt Feed speed 8 m/min.

Condition: like new (used), For sale is a used Felder AF-12 extraction unit with a maximum air flow rate of 1,350 m³/h. The machine is in like-new condition and has been inspected and serviced by our qualified staff. Technical specifications: - Extraction capacity: 1,350 m³/h - Maximum negative pressure: 1,800 Pa - Chip collection volume: 100 liters - Extraction connection diameter: 120 mm - Motor power: 1.5 kW / 2 HP - Year of manufacture: 2025, like new Njdpfx Aasycdqwexekt The extraction unit is located in A-5431 Kuchl and can be inspected at any time during our opening hours. Subject to prior sale! Related terms: extraction unit, dust extraction Reference: R-H705E

Condition: like new (used), For sale is a used Felder AF-22 extraction unit with a maximum air flow rate of 3100 m³/h. The machine is in like-new condition, has been inspected and serviced by our qualified staff. Technical data: - Extraction capacity 3,100 m³/h - Max. negative pressure 2510 Pa Nodpfeycdbvjx Aaxekt - Chip container volume 2 x 200 litres - Extraction port Ø 160 mm - Motor power 3 kW / 4.1 HP - Year of manufacture 2025, as new The extraction unit is located in A-5431 Kuchl and can be inspected at any time during our business hours. Subject to prior sale! Related terms: extraction unit, dust extraction, wall-mounted extraction Reference: R-R04D8

Condition: used, Year of construction: 2015, height adjustment type: mechanical, - Year of manufacture: 2015 - Single owner. EQUIPMENT: Electrical Equipment - Supply voltage: 3x 400 V - Supply frequency: 50 Hz Workpiece Dimensions - Edgeband thickness: 0.4 - 3.0 mm - Workpiece thickness: 10 - 45 mm - Minimum workpiece width: 70 mm - Minimum workpiece length: 210 mm Nksdpfx Asya Ethsaxet Units - Edgeband feeding from a reel via a feed plate - Edgeband feeding thickness from 0.4–3 mm, manual feeding of single strips - Guillotine shears for trimming edgeband from the reel up to 3 mm thickness - Gluing unit for granulated hot-melt adhesive, Teflon-coated glue pot - Spring-loaded pressure unit, 1 straight pressure roller and 1 pressing/fixing roller - Saw trimming unit, 9,000 rpm, 0.18 kW, HW saw blades Z= 16, Ø 80 mm - Multifunctional milling unit, 12,000 rpm, 0.22 kW, radius machining, straight milling, chamfering - Radius scraper unit, mechanically engaged, for R= 2 mm - Flat scraper unit, mechanically engaged Operation: - Control panel with LCD display and keyboard - Quick, tool-free unit adjustment system (Quick system) Feed: - Edged workpiece transport by chain with track - Feed speed: 8 m/min - Extendable support General data: - Extraction connection Ø 120 mm Overall dimensions: - Length: 2000 mm - Width: 800 mm - Height: 1500 mm - Weight: 360 kg On customer request: - The machine is suitable for processing PVC and ABS edgebanding 0.5 - 3 mm - Edgebanding speed approx. 7 m/min - Milling top and bottom with chamfer or R2 radius - Flat scraper - 1.2 kg Teflon glue tank - Pre-cut guillotine - Edgeband trimming with two saw units - Quick machine calibration system by placing a piece of edgeband in the dedicated clamp - The machine has been regularly serviced, lubricated, and cleaned, ensuring its excellent technical condition. - An ideal solution for demanding carpentry workshops and manufacturing plants.

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, Dismantling and loading can be handled by the seller! MACHINE DETAILS Electrical Data Voltage: 400 V Phases: 3N Frequency: 50 Hz Motor power: 15 kW Current consumption: 32 A Nksdpfx Aaoyddqmoxet

Condition: new, Year of construction: 2007, functionality: fully functional, machine/vehicle number: 0711ST0619, feed rate X-axis: 13 m/min, rotational speed (max.): 12,000 rpm, The disassembly and loading can be carried out by the seller! Auction of an unused Format 4 Felder Perfect 40! TECHNICAL DETAILS Feed rate: 13 m/min Maximum material thickness: 3 mm Main saw motor power: 0.5 kW Main saw motor speed: 12,000 rpm Trimmer and profiling unit motor power: 0.68 kW Trimmer and profiling unit motor speed: 12,000 rpm Nkedpoyddmnofx Aaxet Polishing unit motor speed: 1,400 rpm MACHINE DETAILS Electrical data Voltage: 400 V Phases: 3N Frequency: 50 Hz Power: 8 kW EQUIPMENT Guillotine for edging material up to 3 mm Teflon-coated glue pot for 3 kg EVA granulate Audio signal generator Glue roller with quick-change system Pneumatic pressure unit, 1 driven and 2 conical pressure rollers End trim saws with carbide-tipped blades Z = 24, d-100 x 20 x 3.2 mm Trimmer and profiling unit with folding option up to 15° Guillotine for R = 2 mm Polishing unit with 2 motors

Condition: new, Year of construction: 2008, functionality: fully functional, machine/vehicle number: 08.807.248, feed rate X-axis: 9 m/min, workpiece height (max.): 60 mm, overall weight: 750 kg, rotational speed (max.): 12,000 rpm, Dismantling and loading can be carried out by the seller! Auction of an unused Felder G 500! TECHNICAL DETAILS Edge thickness: 0.4-5 mm Workpiece height: 8-60 mm Feed speed: 9 m/min Spindle unit speed: 12,000 rpm Min. workpiece width: 70 mm Nkodpfx Ajyddgzsaxst Min. workpiece length: 140 mm Radius scraper unit: R = 2 mm Polishing unit: 2 motors at 1,400 rpm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,200 x 1,100 x 1,550 mm Weight: 750 kg EQUIPMENT High-performance chain feed Support for coiled edge material Guillotine blades for cutting coiled edges up to 3 mm Glue application roller for EVA granulate from the Teflon-coated glue pot Spring-loaded pressure unit with 1 rubber pressure roller and 2 drive rollers Milling unit 0.27 kW, 100-tooth, 24-tooth saw blade Flush and radius milling unit a = 15, R = 2 mm Polishing unit with 2 motors at 1,400 rpm

Condition: new, functionality: fully functional, total length: 2,100 mm, total width: 900 mm, edge thickness (max.): 2 mm, total height: 1,250 mm, plate height: 45 mm, Dismantling and loading can be handled by the seller! Auction of an unused Felder G 200! TECHNICAL DETAILS Edge thickness: 0.4 - 2.0 mm Panel height: 10 - 45 mm Feed speed: 5 m/min MACHINE DETAILS Dimensions (L x W x H): 2,100 x 900 x 1,250 mm Required compressed air: 6 bar EQUIPMENT Pneumatic end-cutting guillotine Flush and radius trimming module (a = 15°, R = 2 mm) Nkjdpfx Aaeydc Uwoxet Teflon glue pot Electric temperature control (20 - 250 °C)
