Climate test chamber Environmental test

Espec PR-3KP

Condition: good (used), operating hours: 75,383 h, Espec PR-3KP Environmental test chamber -20 to +100 °C Features: Manufacturer: Espec Type: PR-3KP Kjdpfx Afswbz Hho Sofa Temperature range: -20 to +100 °C Humidity: 20 to 98 % rH Refrigerant R-404A:- CFC-free - ozone-friendly Operating hours: 75383 Dimensions: External dimensions: HxWxD= 1680 x 1050 x 1200 mm Chamber dimensions: HxWxD= 850 x 600 x 800 mm Further items in other sizes - new and used - can be found in our store! International shipping costs on request!

Condition: excellent (used), CTS Type: C-40/1000 CTS climatic test chamber Condenser chiller air-cooled Control: 32 bit controller LCD control panel Digital display of setpoints and actual values Numerical input of setpoints Error messages in plain text RS 232 interface Free switching channels for on-site test material control Temperature test: Temperature range: -40°C to +180°C Temperature change rate Heating speed 2.0 K/min Cooling rate 2.5 K/min Temperature deviation ± 0.1 to ± 0.3 K in time Heat radiation: approx. 2500 W at +20°C approx. 2500 W at ± 0°C approx. 1500 W at -20°C Climate Working range: Temperature range +10°C to +95°C Humidity range 10 to 98% r.h. Dew point range I +7 to +94°C Dew point range II -10 to +7°C Temperature deviation ± 0.1 to ± 0.3 K in time Humidity constancy I, temporal ± 0.5 to ± 1.5 % r.h. Humidity constancy II, temporal ± 1 to ± 3 % r.h. Kfsdpforu Dzujx Af Sea Panorama window 570 x 710 mm Test chamber dimensions Width 1000 mm Depth 1100 mm Height 900 mm External dimensions Width 1270 mm Depth 2220 mm Height 1950 mm Test chamber volume 1000 liters Pipe feed-throughs, ø 50 Electrical connection: 400 V +6/-10% 3/N, PE 50 Hz Connected load: 8.4 kW Rated current: 12.4 A Refrigerant: R-404A Weight: 800 kg The following information is for your safety as a buyer! The following points are carried out on our offered chambers in advance: 1. functional check and replacement of necessary components 2. if necessary, new filling with legally compliant refrigerant 3. leak test with certificate 4. after successful inspection, the chambers are subjected to a documented test run. Condition: used Scope of delivery: (see picture) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Year of construction: 2019, condition: good (used), Various climate chambers for testing a wide range of products. Kfedpfxsxgrz Rj Af Sea Example: Vötsch Type: VC 0018 Climate test chamber Air-cooled Test chamber dimensions: Width 580 x Depth 450 x Height 750 mm

Condition: good (used), Type: TS -70/1000-10 For sale is a CTS temperature test chamber Model: TS -70/1000-10 Cooling: water-cooled refrigeration unit Ksdpfxoxdi Ezo Af Ssfa Compressor has been replaced! Features: - Multi-touch control system - USB and Ethernet interfaces - Cable feedthroughs for test cables: 4 × Ø 125 mm - Safety temperature limiter Applications: - Environmental and longevity tests - Thermal cycling tests (stress screening) - Quality assurance and research & development - Electronics, automotive, materials testing Test chamber volume: 1,000 liters Test chamber dimensions: - Height: approx. 1,000 mm - Width: approx. 860 mm - Depth: approx. 1,100 mm External dimensions: - Height: approx. 1,950 mm - Width: approx. 1,270 mm - Depth: approx. 1,900 mm Temperature range: -70°C to +180°C Temperature deviation: ± 0.3 K over time Temperature change rate: up to approx. 10 K/min Electrical connection: 400V 3/N 50Hz Rated power: approx. 23.1 kW Rated current: approx. 40 A Refrigerant: R404A / R23 Weight: 1,000 kg For your peace of mind as a buyer, please note: The following inspections and services are performed on our offered chambers in advance: 1. Functional check and replacement of necessary components 2. Refilling with legally compliant refrigerant if required 3. Leak test with certificate 4. Following successful checks, chambers undergo a documented test run Condition: used Scope of delivery: (See pictures) (Specifications and technical data subject to change and errors excepted!) We are happy to answer further questions by phone.

Condition: excellent (used), CTS Climate test chamber C-55/1000 Li water-cooled Temperature range: -50°C to +100°C Humidity range: 5 to 95% RH Dew point range: 5°C to +78°C Rated voltage: 400V 3/N 50Hz Rated power: 9.5 kW Nominal current: 18 A Compressor: TFH2511Z / TFH2511Z Refrigerant R404A/R23 The type designation of the CTS cabinet series is composed as follows: z. e.g. type C -55/1000/Li 1) C means: climate 2) -55 means: lower temperature -55 °C 3) 1000 means: 1000 liter test chamber volume 4) Li means: special equipment for tests with lithium-ion accumulators Control: Kfodpfxjva Hi Hs Af Ssa 32 bit controller LCD control panel Digital display of set and actual values Numerical input of setpoints Error messages in plain text Ethernet interface RS 232 interface Free switching channels for on-site test material control Test room lighting: energy-efficient, high-intensity LED light strip mounted on the door Insert grid: Stainless steel, support surface 970 x 980 mm Load per shelf max. 35 kg Total load with max. grating load 100 kg 1a Feed-through NW50 1b Feed-through 2x NW125 1c Entry port 2x Rp 314° for Minimax Technical performance data: Temperature tests: Temperature range -50°C to +100°C Temperature deviation ≤ ±0.3 K in time Temperature change rate according to IEC 60068-3-5 Heating 2.5 K/min Cooling 2.5 K/min Heat compensation approx. 4000 W at +20°C approx. 2200 W at -40°C Climate tests: Temperature range +5 °C to +95 °C Humidity range 5% to 95% rel. humidity Dew point range +5°C to 78°C Temperature deviation ≤ ±1.0 K in time Humidity deviation ≤ ±3.0% relative humidity over time The technical data refers to an ambient temperature of +25 °C, rated voltage 400V, without test material, without heat compensation and without additional equipment. Options may influence the performance data. Dimensions: Test volume 1000 liters Test chamber dimensions Height, approx. 1000 mm, width, approx. 860 mm, depth, approx. 1100 mm External dimensions Height, approx. 1950 mm, width, approx. 1270 mm, depth, approx. 1900 mm Operating data: Electrical connection 400 V +6/-10 %, 3/N, 50 Hz Nominal current 18 A Rated power 9.5 kW Protection class IP 54 Sound pressure level < 58 dB(A) (according to DIN EN ISO 3744 measured at a distance of 1 m from the front) Mass approx. 1000 kg Heat output to the installation room 10.4 kW Cooling unit: water-cooled, low-noise, fully hermetic Infinitely variable output adjustment via electronic monitoring and control system, environmentally friendly refrigerant R404A/R23 The following information is for your safety as a buyer! The following points are carried out on our offered chambers in advance: 1. functional check and replacement of necessary components 2. if necessary, refilling with legally compliant refrigerant 3. leak test with certificate 4. after successful inspection, the chambers are subjected to a documented test run. Condition: used Scope of delivery: (see picture) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Condition: excellent (used), Espec Type: EGNX28-6CWL Espec climate test chamber water-cooled Climate test chamber N series Temperature range -70 to +180°C Temperature change rate Heating 10 °K/min Cooling 5.5 °K/min Humidity range 10 to 95% RH according to diagram Internal dimensions W x H x D in mm 1000 x 1000 x 800 External dimensions W x H x D in mm 1205 x 1930 x 1960 Usable space volume 800 liters Cooling capacity 3.6 kW at -50 °C Heating system 10 kW Refrigerant R-404A Refrigerant R- 508A Power supply: AC 400 V 3-phase 50/60Hz 38A Weight: approx. 695 kg For your safety as a buyer, the following information! The following points are carried out in advance on the chambers we offer: 1. Functional check and replacement of necessary components 2. If necessary, new filling with legally compliant refrigerant 3. Leak test with certificate 4. After successful inspection, the chambers are subjected to a documented test run. Condition: used Scope of delivery: (See picture) Kfjdpfx Afjv Duuxj Sja (Changes and errors in the technical data, information is subject to change!) We are happy to answer any further questions you may have over the phone.

Condition: good (used), Vötsch VCS 4100 Climatic Test Chamber -40°C to +180°C Manufacturer: Vötsch Type: VCS 4100 Kfodpfouuiygsx Af Sja Temp. Range: -40°C to +180°C Line Voltage: 400 V Rated Current: 17 A Rated Power: 11 kW Refrigerant: R404A KK-07 Find more items - new and used - in our shop! International shipping costs upon request!
