Temperature test chamber 1000 liters

CTS - 70°C bis +180°C TS -70/1000-10 bis ca.10 K/min

Year of construction: 2024, condition: new, machine/vehicle number: H3000-H5000TM, Universal testing machine H3000TM-H5000TM according to DIN EN ISO 7500 The universal testing machine of the H3000TM-H5000TM series is a single-spindle machine, a robust construction made of aluminum and V2a with ball screws, ball bushing guides and toothed belt drive. The bellows cover protects the spindle and guides. The testing machine is microprocessor controlled and has a membrane keypad. The 2-line LCD display shows the force and travel. The testing machine can be used as standalone or with a PC via USB interface. The displacement is measured by means of an encoder 0.01 mm visible resolution on LCD (internal 0.0001mm). The machine is manufactured with a standard load cell: 0.03% linearity and the corresponding calibration. Optionally it is possible to add a second channel for a second load cell or a displacement transducer. The universal testing machine is manufactured with two different travels, 500mm or 1200mm (without load cell and testing tool). Further scope of delivery: One load cell up to nominal load, 220 Volt cable, USB cable, description, CE declaration of conformity. For more information, please refer to the attached description. Load cell 3000N-5000N Measuring range: 5-5000N tension and compression, with nom. 2mV/V output signal, overload protection: +/- 1000%, linearity: +/- Fgsdpfx Aeiq Hxkjdujk 0.05%, hysteresis: +/- 0.03%, repeatability: +/- 0.02%, with, incl. 1.5m connection cable incl. calibration certificate Long travel extensometer HE 900mm measuring travel, measuring arms motorized, including electronics Accuracy class class 1 from 1mm travel according to DIN EN ISO 9513 Measuring principle optical incremental Measuring path 900 mm , minus measuring length Display error 6 µm or 2 Resolution 1 µm Actuating force 10 cN Standard initial device measuring length (Lo) 10-100 mm, in 5 mm steps Lo adjustment is manual Measuring arm opening and closing is motorized specimen diameter 0-30 mm specimen thickness 0-30 mm sample width 0-100 mm Weight approx. 32kg Scope of delivery strain gauge complete with electronics Cutting edges round: 1 set each carbide / rubber wear parts measuring blades optional rectangular cutting edges ATTENTION: When using optional cutting edges a readjustment of the lo a readjustment of the lo stop is necessary.

Condition: excellent (used), Here we offer you a Köhler salt spray chamber. Köhler Salt Spray Chamber Corrosion Chamber Fgedpfx Ajn Arqdjdujk Köhler Salt Spray Chamber HKT 500 Operation via touch panel Inner dimensions W x D x H (without hood) 1880 x 840 x 1210 mm Test chamber volume 500 l Temperature range chamber room temp. up to 50°C Mains supply 230V 1P/N/50Hz 3000W Type: HKT 500 WTG 400 Kg Condition: used / used Scope of delivery: (See picture) (Changes and errors in the technical data, specifications are reserved!) Further questions we can answer on the phone for you.

Condition: excellent (used), CTS Type: C-40/1000 CTS climatic test chamber Condenser chiller air-cooled Control: 32 bit controller LCD control panel Digital display of setpoints and actual values Numerical input of setpoints Error messages in plain text RS 232 interface Free switching channels for on-site test material control Temperature test: Temperature range: -40°C to +180°C Temperature change rate Heating speed 2.0 K/min Cooling rate 2.5 K/min Temperature deviation ± 0.1 to ± 0.3 K in time Heat radiation: approx. 2500 W at +20°C approx. 2500 W at ± 0°C approx. 1500 W at -20°C Climate Working range: Temperature range +10°C to +95°C Humidity range 10 to 98% r.h. Dew point range I +7 to +94°C Dew point range II -10 to +7°C Temperature deviation ± 0.1 to ± 0.3 K in time Humidity constancy I, temporal ± 0.5 to ± 1.5 % r.h. Fgedpferu Dzusx Aduok Humidity constancy II, temporal ± 1 to ± 3 % r.h. Panorama window 570 x 710 mm Test chamber dimensions Width 1000 mm Depth 1100 mm Height 900 mm External dimensions Width 1270 mm Depth 2220 mm Height 1950 mm Test chamber volume 1000 liters Pipe feed-throughs, ø 50 Electrical connection: 400 V +6/-10% 3/N, PE 50 Hz Connected load: 8.4 kW Rated current: 12.4 A Refrigerant: R-404A Weight: 800 kg The following information is for your safety as a buyer! The following points are carried out on our offered chambers in advance: 1. functional check and replacement of necessary components 2. if necessary, new filling with legally compliant refrigerant 3. leak test with certificate 4. after successful inspection, the chambers are subjected to a documented test run. Condition: used Scope of delivery: (see picture) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Condition: excellent (used), Feutron Type: 3702/06 Water-cooled climatic test chamber Technical data: Test chamber nominal volume 2.0 m³ Dimensions: Test chamber exterior, with humidifier console Width 2970 mm Height 2370 mm Depth 1530 mm Rear wall Minimum insertion dimensions: Width 2970 mm Height 2390 mm Depth 1550 mm Test chamber: Width 2000 mm Height 1000 mm Depth 1000 mm Double-leaf door, clear width Width 2000 mm Height 1000 mm Heated viewing window, 2 pieces Width 500 mm Height 600 mm Feed-through opening, 1 side panel left ∅ 75 mm Temperature range: -40...100°C Fgodok E Hnqepfx Adusk Climatic range: 10...95°C Temperature difference, temporal ≤ ± 0.5...± 1.0 ΔN/K Change rates measured in the supply air without load Cooling up to 2.0 on average K/min Heating up to 2.0 on average K/min Humidity range: 10...95 %r. F. Humidity difference, temporal ≤ ± 3.0 %r. F. Dew point range, temporary down to -5... 95°C Refrigeration system: water-cooled semi-hermetic Bitzer system Refrigerant: R507 (Μ-Κ1) Air conditioning and dryer refrigeration system air-cooled /hermetic system Refrigerant: R134a (Μ.ΚΚ) Power supply: Electrical mains connection: 400V 3/N/PE.AC,50Hz Mains plug: CEE 5-роlig, 32 A, with 5.0 m cable Max. simultaneous power requirement 10.0 kW Supply line fuse: 3x 25, Char, C A Degree of protection IP20 Weight: 1300 kg Condition: used Scope of delivery: (see picture) (Subject to changes and errors in the technical data and specifications) We will be happy to answer any further questions you may have on the phone.

Condition: good (used), White Type: WK1-1000/70 Weiss climatic test chamber water-cooled (refrigerant converted to R-452A) Touch panel" control unit All control and operating commands can be triggered by simply touching the function icons on the all control and operating commands by simply touching the function icons. Feedthroughs The test chamber is equipped with feed-throughs on the right and left side. Measurement cables and test equipment can be routed into the test chamber through these. Feed-throughs: 1 feed-through ∅ 125 mm installed on the right Fedpfx Asrvx Ezjduogk 1 feed-through ∅ 50 mm installed on the left Volume 990 liters Test chamber dimensions: Test chamber: width 1100 mm, depth 950 mm, height 950 mm Housing: width 1385 mm, depth 1850 mm, 1980 mm Data for temperature tests: Minimum temperature -70 °C Maximum temperature +180 °C Temperature deviation, temporal ± 0.1 to ± 0.5 K Temperature homogeneity, spatial ± 0.5 to ± 2 K Temperature change rate, heating 4 K/min Temperature change rate, cooling 2.5 K/min Max. heat compensation 2750 W Data for climate tests: Temperature range +10°C to +95°C Humidity range 10 to 98% r.h. Temperature deviation, temporal ± 0.1 to ± 0.3 K Temperature homogeneity, spatial ± 0.5 to ± 1 K Humidity deviation, temporal ± 1 to ± 3% r.h. Data for operation: Rated voltage: 3/N/PE AC 400V ±10% 50Hz Nominal current: 29A Nominal power 19.8 kW Refrigerant: R-452A/ R23 Weight approx. 910kg The following information is for your safety as a buyer! The following points are carried out on our offered chambers in advance: 1. functional check and replacement of necessary components 2. if necessary, new filling with legally compliant refrigerant 3. leak test with certificate 4. after successful inspection, the chambers are subjected to a documented test run. Condition: used Scope of delivery: (see picture) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Condition: excellent (used), Here we offer you Thermotron environmental test chamber. Fsdpfemhfr Isx Adujgk Thermotron Environmental Test Chamber Water Cooled Working volume: 227 liters Temperature uniformity: All models 0.7°C Temperature range: -70°C to + 180°C Temperature control tolerance: All models 0.3°C Shipping weight: approx 400 kg Internal dimensions width 610 mm x depth 610 mm x height 610 mm Outer dimensions width 890 mm x depth 1240 mm x height 1850 mm Humidity range: All models 10% to 98% RH Humidity control: All models 2.5% RH Heating capacity in minutes -65º to 71ºC: 17 Heating power in minutes -65º to 180ºC: 43 Heating power in minutes -40º to 85ºC: 16 Electrical requirements in full load amplifiers 230/3/60: 19 Electrical requirements in full load amplifiers 230/1/60: 25 Electrical requirements in full power amplifiers 220/1/50: 27 Cooling capacity in minutes 85º to -40ºC: 32 Cooling capacity in minutes 71º to -65ºC: 54 Cooling capacity in minutes 180º to -65ºC: 72 Compressor size: (2) -2 Hp Operating voltage: 400V 16.7 A Type: SM-8-8200 Condition: used / used Scope of delivery: (See picture) (Changes and errors in the technical data, specifications are reserved!) Further questions we can answer on the phone for you.

Year of construction: 2019, condition: good (used), Various climate chambers for testing a wide range of products. Fjdpfexgrz Rox Adusgk Example: Vötsch Type: VC 0018 Climate test chamber Air-cooled Test chamber dimensions: Width 580 x Depth 450 x Height 750 mm

Condition: excellent (used), LDS Type: V895-440 HBT900C with amplifier SPA50K Technical data: Fitting Dimensions: 440 mm Sinusoidal force vector 55.6 kN (peak) Rausch force vector 55.6 kN (effective) Half sine force vector 166.8 kN (peak) Frequency range 0 to 2100 Hz Sinusoidal acceleration max. 981 m/s² Noise Acceleration max. 490 m/s² Speed max. 1.6 m/s Deflection ± 63.5 mm Oscillator mass 55 kg Max. load 700 kg Amplifier dimensions : WxHxD mm : 537mm x 1905mm x 895mm Weight 622 kg Sliding table: Work surface: 900 mm * 900 mm Thickness of the top : 50 mm Weight of the top: 80.4 kg Max load : 7250kg Effective frequency range 5-2000 Hz Condition : gebraucht / used Fgodpfx Aeuy H I Teduok Total weight (table + shaker): approx. 7000 kg Shaker + table dimensions: LxHxW approx. 2700 x 1500 x 1800 mm Scope of delivery: (see pictures) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Condition: excellent (used), Here we offer Vötsch shock test chamber. Temperature shock test chamber water cooled Two-chamber design Warm chamber: The temperature control of the warm chamber ranges from +50°C to +220°C Temperature deviation in time in the center of the chamber ± 1 K Temperature deviation spatially ± 2 K Temperature change rate heating 11 K/min cold chamber: the cold chamber from -80°C to +70°C Temperature deviation temporally in useful space center ± 1 K temperature deviation spatially ± 2 K Temperature change rate heating 2 K/min cooling 3 K/min Test chamber volume 125 liters Temperature range hot chamber +50°C to +220°C Temperature range cold chamber -80°C to +70°C Test chamber dimensions Width 470 mm Depth 650 mm Height 410 mm External dimensions Width 930 mm Depth 2115 mm Height 1970 mm Feedthrough ∅ 67mm Rated power 10 kW Rated current 25 A Voltage: 3/N/PE AC 400V ±10% 50Hz Refrigerant R404A / R23 Weight: 1000 kg For you as a buyer for safety the following information! The following points are carried out on our offered chambers in advance: 1. functional check and replacement of necessary components 2. new filling with legally compliant refrigerant 3. leak test with certificate Fsdpsn Arc Aofx Aduegk 4. after successful inspection, the chambers are subjected to a test run, which is monitored with calibrated equipment. Type: VT 7012 S2 Condition: used / used Scope of delivery: (See picture) (Changes and errors in the technical data, specifications are reserved!) Further questions we can answer on the phone for you.

Condition: excellent (used), Here we offer Vötsch shock test chamber. Temperature shock test chamber water cooled Two-chamber design Warm chamber: The temperature control of the warm chamber ranges from +50°C to +220°C Temperature deviation in time in the center of the chamber ± 1 K Temperature deviation spatially ± 2 K Temperature change rate heating 11 K/min cold chamber: the cold chamber from -80°C to +70°C Temperature deviation temporally in useful space center ± 1 K temperature deviation spatially ± 2 K Temperature change rate heating 2 K/min cooling 3 K/min Test chamber volume 125 liters Temperature range hot chamber +50°C to +220°C Temperature range cold chamber -80°C to +70°C Test chamber dimensions width 470mm depth 650mm height 410mm Outer dimensions width 930mm depth 2115mm height 1970+mm Feedthrough ∅ 67mm Rated power 10 kW Rated current 25 A Fgsdpfx Adoigg Hnjuok Voltage: 3/N/PE AC 400V +6/-10% 50Hz Refrigerant R404A / R23 Weight: 1000 kg For you as a buyer for safety the following information! The following points are carried out on our offered chambers in advance: 1. functional check and replacement of necessary components 2. new filling with legally compliant refrigerant 3. leak test with certificate 4. after successful inspection, the chambers are subjected to a test run, which is monitored with calibrated equipment. Type: VT 7012 S2 Condition: used / used Scope of delivery: (See picture) (Changes and errors in the technical data, specifications are reserved!) Further questions we can answer on the phone for you.
