ER-USP 5

ENGEL

Condition: excellent (used), Year of construction: 2013, clamping force: 4,000 kN, Equipment: documentation/manual, Control: CC200 Year: 2013 Clamping force: 400 t Max daylight: 1450 mm Mould height min max: 450-1000mm Ejector stroke: 250 mm Screw diameter: 70 mm (S8 screw G1) Shot volume: 1501 cm3 Injection rate: 319cm3/sec Specific injection pressure: 2252 bar Max screw speed: 160 rpm Type: Horizontal Drive: Hydraulic 2 core pullers 16 mould heating zones 12 waterflow Kljdpfx Adjyctyzo Eer Euromap 67 ECODRIVE AIR VALVES

Condition: excellent (used), Year of construction: 2004, operating hours: 98,108 h, clamping force: 1,500 kN, screw diameter: 50 mm, injection weight: 354 g, Engel Victory 750/150 Tech injection molding machine (146) Number: 146 Availability: in stock Year of production: 2004 Producer: Engel Injection molding machine condition: used Screw diameter [mm]: 50 Injection weight [g]: 354 Injection pressure [bar]: 1427, 2500 Closing force [kN]: 1500 Column spacing [mm]: without columns Plate size [mm]: 750 x 850 Control type: CC 200 Tongue: german Installed power [kW]: 61 Working hours [h]: 98108 Weight [kg]: 9500 Dimensions [mm]: Kljdpey Ec D Nofx Ad Ejr 5700 x 2000 Feed hopper: NO Core string: Yes Robot socket: Yes

Condition: ready for operation (used), Year of construction: 2019, clamping force: 6,500 kN, screw diameter: 60 mm, overall weight: 6,500 kg, controller manufacturer: ENGEL, This Engel duo 2400/650 electrical injection moulding machine was manufactured in 2019. It features a screw diameter of 60/70/80 mm, a screw stroke of 315 mm, and a maximum injection capacity of 890 cm³. The clamping force reaches up to 6500 kN with a maximum mold weight of 11000 kg. Consider the opportunity to buy this Engel duo 2400/650 electrical injection moulding machine. Contact us for more information about this machine. Klodey D Npcopfx Ad Esr Additional equipment • Oil Reservoir Capacity - Injection Unit: 500 l • Maximum Cooling Power (32°C Water Inlet): 29.40 kWcool • Water Consumption (32°C): 4.80 m3/h Machine Benefits Qualitative Machine Benefits • The machine has electric water batteries (4 e-flomos with 8 circuits each). • The injection units are fitted with accumulators which enable a high injection pressure of up to 2400 bar with a 60 mm screw. Technical Machine Benefits • Maximum injection capacity: 890 cm³ • Screw torque: 2000 nm // maximum screw speed @ reduced torque: 275 min-1 • Reduced torque @ maximum screw speed: 1600 nm • Recovery rate (3-zone screw): 51 g/s // recovery rate (barrier screw): 67. 1 g/s • Injection rate: 353 cm³/s • Nozzle stroke: 950 mm • Ld ratio: 24. 0 • Heating zones incl. Nozzle: 8 // heating wattage: 27. 5 kwel • Opening force with pressure pad: 510 kn • Maximum distance between platens: 1750 mm Extra Information Dimensions & Weight • Drop Out Chute Width: 1100 mm • Weight of Clamping Unit: 20,000 kg • Maximum Mold Weight (Moving Platen): 7,330 kg • Maximum Mold Weight (Stationary Platen): 7,330 kg • Maximum Mold Weight (Total): 11,000 kgCycle Data (Euromap 6) • Stroke: 700 mm • Dry Cycle Time: 2.9 s Control System: Monocompute CC300 Main Features • 21.5” full HD touchscreen • USB interface / Ethernet connection • E-move control element • 3 keycards for user login • Graphic symbols for cycle control • Screen languages: German, English • Acoustic error signal / Signal light for error displayPrograms & Monitoring • Power Control: optimizes motor performance during dispensing • Mould parallelism measurement • IQ Weight Monitor: monitors shot weight & viscosity • IQ Weight Control: automatic injection parameter adjustment during fluctuations • Quality monitoring interface (injection time, dosing time, pressure, cycle time) • Continuous ejection possible when monitoring is deactivated Clamping Unit & Plates • Reinforced clamping plates (FAP & BAP +50 mm each) • Reduced min./max. tool height and panel distance (–100 mm due to reinforcement) • FAP: smallest possible platen opening, spherical calotte minimized • BAP: without ejector opening • Additional threads according to EUROMAP VOL1 • Centering grooves according to drawing • Plate ejector – Variant A (adapted to clamping pattern) • Safety interface for ejector Hydraulics & Core Pulls • Hydraulic core pull: • 1-fold on moving platen • 2-fold on fixed platen • 2-fold on moving platen with PQ proportional valve, volume measurement, pressure/speed adjustment • Interface for intermediate core pull position Mold Heating & Cooling • Mold heating: 16 circuits, max. 40 kW heat output (Euromap 14) • Temperature monitoring interface (moving & fixed platen) • 4-fold hydraulic mold nozzle control • Separate cooling water connection (tool & machine) • Temperature control unit interface: Engel protocol, 20 mA current loop • 4-way flow regulator (0–10 l/min) • Hose specification: max. 90 °C / 4 bar • Hoses for mold cooling

Condition: good (used), Year of construction: 2009, Clamping force: 90 t Screw diameter: 30 mm Screw diameter 2: 25 mm Type: Multicomponent Kjdpfx Adey Duaae Eelr Drive: Hydraulic

Condition: excellent (used), Year of construction: 2016, Engel e-Motion 740/280 T WP with TecnoMatic Robot / All-Electric Machine / Operating hours: approx. in automatic mode Year of manufacture: 2016 Injection unit: Screw diameter: 50 mm Shot weight: approx. 360 g Injection pressure: 1900 bar Plasticizing volume: 393 ccm Clamping unit: Clamping force: 280 t Tie bar spacing: 780x780 mm Platen size: 1100x1100 mm Ejector: electric Clamping system: toggle lever Control: CC 300 touchscreen Additional equipment: Production line with TecnoMatic robot Machine in very good technical condition All-electric machine: energy-saving and very quiet Operating hours: approx. in automatic mode Euromap 67 Robot interface 5x air valve 4x hydraulic core pull Control with 64 hot runner zones Injection unit is wear- and corrosion-resistant Main drive - servomotor with inverter for energy savings Central lubrication Parallel movements Automatic mold height adjustment TecnoMatic Medium Robot Year of manufacture: 2020 6-axis robot: all axes (X, telescopic Y, Z, A, B, C) driven electrically by servomotors Touch control panel Robot safety package Robot equipped with adapter, conveyor belt, and protective casing Purchase of robot and conveyor belt at additional cost Klodpfoy Dqr Sox Ad Eor Dimensions: Weight: 17,200 kg LxWxH: 7.37x2.10x2.30 m All machines offered are powered up and tested by our service technicians prior to sale. A video of the technical tests of the selected machine can be provided, or you can participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2001, Engel ES 1350/275 HL with Engel ERC 53/1-E Robot / Machine in very good technical condition Year of manufacture: 2001 Injection unit: Screw diameter: 60 mm Shot weight: 547 g Injection pressure: 1834 bar Metering volume: 618 cm³ Clamping unit: Clamping force: 275 t Tie bar distance: 0x0 mm Platen size: 1050x900 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 100 Additional equipment: Machine in very good technical condition Operating hours: 35,819 h in automatic mode Tie-barless machine Hydraulic core pull x 3 Hot runner control x 16 Injection unit hardened - bimetallic Machine has been regularly serviced by authorized Engel service Dimensions: Weight: 20,000 kg Length/Width/Height: 7.10x2.15x2.30 m All offered machines are started and tested by our service technicians before sale. Ksdpfxoy Dqr Eo Ad Eelr You can request a video of the technical tests of the selected machine or participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2011, Engel Victory 1350/260 Tech Ecodrive with Engel Viper 20 Robot / Hybrid Machine Year of manufacture: 2011 Injection Unit: Screw diameter: 65 mm Shot weight: approx. 810 g Injection pressure: 1200 bar Dosage volume: 900 ccm Clamping Unit: Clamping force: 260 t Tie bar spacing: 0x0 mm Platens size: 1100x1000 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 200 - touchscreen Klodpfoy Dqrxsx Ad Esr Additional Equipment: Production line with Engel Viper 20 robot Machine in very good technical condition Tie-bar-less hybrid machine: energy-efficient and very quiet Air valves x 6 Hydraulic core pull x 2 on the fixed platen side Hydraulic core pull x 2 on the moving platen side Hot runner control x 18 Injection unit is wear-resistant and corrosion-proof Main motor – servo motor driven by inverter – energy-saving Proportional valve on injection unit – precise injection Engel Viper 20 Robot Year of manufacture: 2011 6-axis robot: 4 axes are driven by servo motors (electric): X, Y, Z, B (rotation); axes A and C – pneumatic Robot safety package Robot with adapter, conveyor belt, and Engel brand safety enclosure Purchase of the robot and conveyor belt available at extra cost Dimensions: Weight: 19,400 kg Length/Width/Height: 7.06x2.03x2.30 m All machines offered are put into operation by our service technicians prior to sale. It is possible to receive a video of the technical tests for the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2011, Engel Victory 1350/260 Tech Ecodrive with Engel Viper 20 Robot / Hybrid Machine Year of Manufacture: 2011 Injection Unit: Screw diameter: 55 mm Shot weight: approx. 590 g Injection pressure: 2183 bar Dosage volume: 618 ccm Clamping Unit: Clamping force: 260 t Tie-bar spacing: 0x0 mm Platen size: 1100x1000 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 200 - Touchscreen Kjdpfxey Dqrlj Ad Ejlr Additional Equipment: Production line with Engel Viper 20 Robot Machine in very good technical condition Tie-barless hybrid machine: energy-saving and very quiet 8x air valve on the fixed platen side 2x hydraulic core pull on the fixed platen side 2x hydraulic core pull on the moving platen side 18 hot runner control zones Injection unit is wear-resistant and corrosion-proof Main drive motor – servo motor with inverter – energy-saving Proportional valve on injection unit – precise injection Engel Viper 20 Robot Year of Manufacture: 2011 6-axis robot: 4 axes (X, Y, Z, B - rotation) driven electrically by servo motors; axes A and C – pneumatic Robot safety package Robot with adapter, conveyor belt, and Engel brand safety enclosure Purchase of robot and conveyor belt available at extra cost Dimensions: Weight: 19,400 kg Length/Width/Height: 7.06x2.03x2.30 m All offered machines are started and tested by our service technicians before sale. A video of the technical tests of the selected machine can be provided, or you can attend live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2011, Engel Victory 1050/220 Tech Ecodrive with Engel Viper 20 Robot / Hybrid Machine Year of manufacture: 2011 Injection unit: Screw diameter: 55 mm Shot weight: approx. 480 g Injection pressure: 2,053 bar Shot volume: 511 cm³ Clamping unit: Clamping force: 220 t Tie bar distance: 0x0 mm Platen size: 880x830 mm Ejector: hydraulic Clamping system: hydraulic Control system: CC 200 - Touchscreen Additional equipment: Production line with Engel Viper 20 robot Machine in very good technical condition Kjdpsy Dqpqofx Ad Eelr Operating hours: 38,188 h in automatic mode Tie-bar-less, hybrid machine: energy-saving and very quiet 4 air valves on the fixed platen side 2 hydraulic core pulls on the fixed platen side 2 hydraulic core pulls on the moving platen side Hot runner control with 12 zones Injection unit is wear-resistant and corrosion-proof Main drive motor: servo motor with inverter for energy saving Proportional valve on the injection unit – precise injection Engel Viper 20 robot Year of manufacture: 2011 6-axis robot: 4 axes driven by servo motors (electric): X, Y, Z, B (rotation); axes A and C – pneumatic Robot safety package Robot with Engel-brand adapter, conveyor belt, and safety enclosure Purchase of the robot and conveyor belt at additional cost Dimensions: Weight: 12,200 kg Length/Width/Height: 5.66 x 1.88 x 2.30 m All offered machines are started and tested by our service technicians prior to sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical demonstrations at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2021, Engel Victory 2460/260 Tech Ecodrive with Engel Viper 20 Robot / Hybrid Injection Molding Machine / Operating hours: approx. 10,000 h in automatic mode Year of manufacture: 2021 Injection unit: Screw diameter: 70 mm Shot weight: approx. 1,100 g Injection pressure: 2,000 bar Dosing volume: 1,212 cc Clamping unit: Clamping force: 260 t Klodpfoy Dqpkex Ad Eer Tie bar distance: 0x0 mm Platen size: 1,100 x 1,000 mm Ejector: hydraulic Clamping unit: hydraulic Control system: CC 300 – Touchscreen Additional equipment: Production line with Engel Viper 20 robot Machine in perfect technical condition Tie-barless hybrid machine: energy-efficient and very quiet Operating hours: approx. 10,000 in automatic mode Air valves x 5 Hydraulic core pull x 2 on the moving platen side Hydraulic core pull x 2 on the fixed platen side Injection unit is wear-resistant and corrosion-resistant Main drive of the machine: servo motor with inverter – energy saving Proportional valve on the injection unit – precise injection Kistler sensor – mold pressure control Engel Viper 20 Robot Year of manufacture: 2021 6-axis robot: all 6 axes driven by electric servo motors: X, Y, Z, B, C Touch control panel Robot safety package Robot with adapter, conveyor belt, and safety enclosure Purchase of robot and conveyor belt available at extra cost Dimensions: Weight: 21,000 kg Length/Width/Height: 7.35 x 2.06 x 2.37 m All offered machines are started up by our service technicians before sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request
