Used switchgears & controls for sale (244)

Condition: used, functionality: fully functional, For sale is a complete electrical control system for an industrial rail processing machine, located in Thale. The system was installed and commissioned by ATG Automatisierung GmbH (Gronau). The system consists of multi-section Rittal enclosures with modern Siemens control technology (S7-1500 + PROFINET), Siemens SINAMICS V20 and Hitachi SJ1 frequency inverters, Pilz safety relays, and a Siemens SIMATIC HMI touch panel. Bdodpfezu Ivyex Ammeg

Condition: like new (used), Year of construction: 2004, functionality: fully functional, overall weight: 13,000 kg, type of input current: three-phase, input voltage: 400 V, input current: 1,250 A, Complete medium and low voltage system including three 1000KVA 20KV transformers Comprised of: 3x Pauwels transformer 1000KVA 20000V 1x Alstom medium voltage switchgear for incoming ring circuit, 20KV Alstom load disconnect switch tap-off Outgoing measurement, 3x fuse outgoing circuits for 3x transformers 1x Siemens Sikus low voltage switchgear, power supply from 3 transformers, incl. 3 coupling switches for busbar connection Various outgoing terminals NH00 NH1 NH2 For further questions, please contact by phone or email. More pictures and details, nameplates available on request. Top condition – almost as new – see pictures. Dismantling was performed by an electrical company. All busbar connectors and bolts are included. Internal wiring for power metering has been withdrawn and labeled. Bodpsy Hf Umofx Ammedg Volume: one complete truck, 13.6 ldm, approx. 13,000KG including transformers. Collection only by appointment in 75053 Gondelsheim. A forklift is available for loading. Shipping possible via freight carrier, please inquire with postal code.

Condition: used, overall weight: 37 kg, SIEMENS 3WN6 WITHDRAWABLE AIR CIRCUIT BREAKER – 1,000 A Manufacturer: Siemens Series: 3WN6 Type: 3WN6271-7FH58-1KA3-Z Version: withdrawable air circuit breaker Bdedpezw Tx Ejfx Ammsg Number of poles: 3 Frame size: I Rated current In: 1,000 A Frequency: 50/60 Hz Rated operational voltage Ue: 500/690 V AC Breaking capacity Ics = Icu: 65 kA at 500 V / 50 kA at 690 V Short-time withstand current Icw: 50 kA for 0.5 seconds Rated impulse withstand voltage Uimp: 8 kV Utilisation category: B Motor operating mechanism: 220–240 V AC / 220–250 V DC F1 shunt release: 220–240 V AC / 220–250 V DC Y1 closing coil: 220–240 V AC / 220–250 V DC Options stated on nameplate: F21, S22, S21 and S05 Standards: IEC/EN 60947-2 and DIN VDE 0660 T.101 Identity number: 3200904083 Estimated net weight: approximately 37 kg Made in Germany Siemens 3WN6 withdrawable air circuit breaker for switching and protecting industrial low-voltage power distribution systems. The breaker is equipped with an electrical motor operating mechanism, closing coil, shunt release and electronic overcurrent trip unit. Pre-owned unit. As the complete operating history is not known, the unit is offered as used. It has not recently been functionally or load tested by us in a switchgear installation. Inspection and testing by a qualified electrical specialist are required before commissioning. The photographs show the actual unit offered and the included scope of supply. Please verify the complete type number, control voltage, connections and compatibility with the existing switchgear before purchasing. Available from stock. Worldwide freight shipment can be arranged. 9 units available

Condition: like new (used), Year of construction: 2003, functionality: fully functional, overall weight: 80 kg, total height: 2,000 mm, total width: 600 mm, type of input current: three-phase, input voltage: 400 V, control cabinet height: 1,900 mm, input current: 100 A, 1x Siemens Sikus 630 Power Distribution Cabinet Sub-distribution Panel Switch Cabinet Power Distributor Floor Distributor Dimensions: 200x85x22.5 cm incl. plinth Cabinet height without plinth: 190 cm + 10 cm plinth = total height Industrial quality, enclosure made of sheet steel, color 7035 light grey Fully wired with main switch, surge protection, fuses, relays, and outgoing terminals. Bodpfeynwx Sex Ammedg The distribution panels were in operation until recently and underwent annual inspection. Wiring diagram is included. 10 units available. Year of manufacture: 2003 For further data, please refer to the pictures. Very good condition – almost like new, see photos Collection by appointment only in 75053 Gondelsheim A forklift is available for loading Shipping by freight forwarder possible, please inquire with ZIP code

Condition: like new (used), Year of construction: 2004, functionality: fully functional, overall weight: 4,000 kg, total height: 2,100 mm, total width: 6,200 mm, type of input current: three-phase, input voltage: 400 V, control cabinet height: 1,800 mm, input current: 1,250 A, Siemens Sikus Type 3200 Power Distribution Panel Sub-distribution switch cabinet, distribution panel, power distribution board 400V 1250A (for further information, please refer to image 21) 9x single cabinets 600mm – 1x 800mm = total length 6200mm (contrary to the drawing: 10x 600mm!!) Bdedpjynv H Iofx Ammsg Cabinet dimensions approx. H210xW60/80xD60cm each, incl. plinth and lifting eyes Connection from transformer 1250A to circuit breaker (Siemens 3WN6361-DWA05-1KA1) with coupling switch etc. (images of the circuit diagrams are attached). Three identical Siemens circuit breakers are installed. Equipped with multiple transformer metering on the main switch and residual current monitoring Busbar rated up to max 1600A Outgoing circuits: circuit breakers – Neozed NH00, NH1 fuses, etc. Excellent condition – almost as new – see pictures The dismantling was carried out by a professional electrical company. All copper busbar connectors and screws are included. Internal wiring for energy metering is pulled back and labeled. The cabinets are dismantled and packed on 5 pallets. Weight approx. 4000kg Collection only by appointment in 75053 Gondelsheim Forklift available for loading Shipping by freight forwarder possible, please inquire with ZIP code

Condition: like new (used), Year of construction: 2013, Medium voltage switchgear - primary distribution - manufacturer SIEMENS, type NXAIR, 2500A 12kV 40kA - total of 12 bays operated at 6kV ( possible on 12kV ), ABB digital protection. Complete documentation, very good condition, single line diagram will be sent upon request. Bdjdpfx Amjzuvy Tomeg

Condition: like new (used), Year of construction: 2003, functionality: fully functional, overall weight: 80 kg, total height: 2,000 mm, total width: 600 mm, type of input current: three-phase, input voltage: 400 V, control cabinet height: 1,900 mm, input current: 100 A, 1x Siemens Sikus 630 Power Distribution Panel, Sub-Distribution Board, Control Cabinet, Distribution Box, Floor Distribution Cabinet Dimensions: 200x60x22.5 cm including distribution base Cabinet height without base: 190 cm + 10 cm base = total height Industrial quality, housing made from sheet steel, color RAL 7035 light grey Bdsdsynwxxopfx Ammeg Fully wired with main switch, surge protection, fuses, relays, and outgoing terminals. The distributors were in use until recently and had annual inspections. A wiring diagram is included. A total of 10 units available. Year of manufacture: 2003 For further data, please refer to the images. Very good condition – almost like new, see pictures. Collection only by appointment in 75053 Gondelsheim. Forklift available for loading Shipping by freight carrier possible, please inquire with your postal code.

Condition: used, Year of construction: 2012, functionality: limited functionality, power: 45 kW (61.18 HP), Steam turbine Manufacturer: Siemens Type: AFA 2.5 Year of construction: 2012 Fresh steam pressure: 4.10 bar Fresh steam temperature: 153°C Fresh steam quantity: t/h Wheel chamber pressure: bar Wheel chamber temperature: °C Exhaust pressure: 0.90 bar Exhaust temperature: 140°C Electrical power: 45 kW Rated speed: 3,000 rpm Quick stop speed: 3,600 rpm Steam turbine with generator and vacuum condenser with pumps, without inspection, as is, without overhaul at current location. Bodpfx Aex H Rwyommodg bps Consulting GmbH CONSULTING | PLANNING | SERVICE Steam turbines | Power plant systems and components info(at)bps-energie.de

Condition: excellent (used), Capacity: 2.5 tons Year of manufacture: 2017 Operating pressure: 150 bar Weight: 1100 kg Dimensions: 1800 × 1800 × 2200 mm Transport wheels included Bedpfxjw U Aure Ammsdg Tools not included in delivery

Condition: ready for operation (used), Year of construction: 2012, Rated voltage: 12 kV, length: 4430 mm, height: 1700 mm, including documentation. An on-site inspection is possible. Bdedpfx Aszqfxkemmeg

Condition: good (used), Year of construction: 2010, Horlemann HR10U-S Switchgear 12 kV HR 10U: the universal switchgear for industry and utilities Modular medium-voltage switchgear for solar power distribution Switchgear: Manufacturer: Horlemann Circuit: KKÜHTTT Type: HR10U-S Rated voltage: 12 kV Rated current: 630 A Short-circuit capacity: 20 kA/1s Height: 2060 mm Width: 1300 mm Depth: 800 mm Cell width: 7 x 650 mm Busbar: AL 50 x 10 mm Weight: approx. 620 kg Rated data HR10U: Ur: 12 kV Ir: 630 A Up: 75 kV Ik: 20 kA (1s) Ud: 28 kV IP: 50 kA Fr: 50 Hz IAC: AFL 25 kA (1 s) IP: IP4X According to IEC-62271-200 (VDE 0671-200); 2003-11 TMC Cast Resin Transformer: Design: Cast Resin High Voltage: 10 kV Low Voltage: 400-230 V Circuit: Dyn5 Year of Construction: 2010 Height: 1740 mm Width: 1300 mm Depth: 900 mm Weight: 1.8 t The switchgear is pressure-relieved via a pressure-relief chamber in the lower part of the switchgear panel. Documents: Test Report Circuit Diagram Financing through our bank is also possible. Bedjnfu Dyepfx Ammedg komplett-konzept.leasingo.de You can find more items - new and used - in our shop! International shipping costs on request!

Condition: like new (used), Year of construction: 2020, functionality: fully functional, Busbar set complete 2 pcs end feed BD2A-250-EE-BD2A 7 pcs busbar distributor BD2A-3-250-SB-3 Bdodpfjwuknnex Ammog 9 pcs feeder box BD2-AK02X/S18 12 pcs suspension bracket BD2-400-BB

Condition: like new (used), Rittal Thermostat SK 3110 Like-new control cabinet thermostat for temperature control in control cabinets and enclosures. Suitable for controlling fans, heaters, or heat exchangers. Manufacturer: Rittal Type: Control cabinet thermostat Model: SK 3110 Mounting type: DIN rail Application area: Control cabinet air conditioning Switching contact: Temperature-dependent Application: Fan control Application: Heater control Bjdpfx Ajzdnk Asmmsdg Housing color: Gray Location: Kusel Quantity: 142 units available

Condition: used, Siemens SIRIUS motor protection circuit breaker 3RV2031-4PA10 with auxiliary switch 3RV2901-1A Siemens SIRIUS motor protection circuit breaker with mounted auxiliary switch 3RV2901-1A for overload and short-circuit protection of motors. Manufacturer: Siemens Product series: SIRIUS Type: 3RV2031-4PA10 Device type: Motor protection circuit breaker Series: 3RV2 Number of poles: 3-pole Overload release setting range: 28–36 A Short-circuit release: 520 A Bdedpozupbwofx Ammog Release class: CLASS 10 Rated operating voltage: up to 690 V AC Operating temperature: -20 to +60 °C Main circuit connection: Screw connection Additional component: Auxiliary switch Type of auxiliary switch: Siemens 3RV2901-1A Rated insulation voltage of auxiliary switch: 690 V Rated impulse withstand voltage of auxiliary switch: 6 kV AC-12 at 230 V: 10 A AC-12 at 690 V: 10 A AC-15 at 230 V: 4 A AC-15 at 690 V: 1 A DC-13 at 24 V: 2 A DC-13 at 230 V: 0.25 A Scope of supply: Motor protection circuit breaker 3RV2031-4PA10 with mounted auxiliary switch 3RV2901-1A Available quantity: 2 pieces

Condition: good (used), Year of construction: 2011, Power converter, power supply, power supply unit, switched-mode power supply, medium-voltage switchgear, switching device, medium-voltage switchgear, switchgear block, secondary switchgear -Manufacturer: Ormazabal, Switchgear block type GAE630 1M5-9 -Rated voltage: up to 24 kV Bsdpfx Ashgw Srommedg -Rated current: up to 630 A -Technical data: see photo of the nameplate -Individual components: see photos -Quantity: 2 switchgear blocks available -Price: per piece -Dimensions: 850/755/H1995 mm -Weight: 414 kg

Condition: used, functionality: fully functional, Available quantity: 5 units Functionality tested; item originates from the dismantling of equipment from an automotive supplier. Manufacturer: Rittal GmbH & Co. KG Model: SK 3304540 Type: TopTherm Blue e wall-mounted cooling unit Bodpozgf H Tefx Ammodg Cooling capacity: 0.3 – 4.0 kW Voltage: 230 V AC Energy efficiency: Blue e technology with EC fans Mounting: Wall-mounted Function: Control cabinet cooling for temperature stabilization Refrigerant: R134a

Condition: used, Rittal TopTherm Air/Water Heat Exchanger SK 3209500 Rittal air/water heat exchanger for switchgear cabinet climate control. Unit manufactured in 2019. A total of 3 units are available. Manufacturer: Rittal Series: TopTherm Type: SK 3209500 Device type: Air/water heat exchanger Condition: used Supply voltage: 230 V AC Frequency: 50/60 Hz Phases: 1~ Rated current: 0.40 A at 50 Hz Rated current: 0.48 A at 60 Hz Power consumption: 0.095 kW at 50 Hz Power consumption: 0.110 kW at 60 Hz Useful cooling capacity: 2.50 kW Cooling capacity measurement point: L35 / W10 Coolant flow rate: 400 l/h Bdodpozdafgefx Ammog Operating temperature range: 1 °C to 70 °C Coolant: Water Maximum coolant temperature: 30 °C Operating pressure: 0.1 to 1.0 MPa Operating pressure: 14.5 to 145 psi Protection class: IP55 Weight: 23.5 kg

Condition: excellent (used), 3-phase follow-up controller for asymmetrical load (current controller for constant voltage) Additional data: see photos of the nameplates Bsdextu Tispfx Ammodg

Condition: good (used), Year of construction: 2018, Metal clad medium voltage switchgear - producer Efacec Portugal, type Normafix 24, configuration - metering panel ( incommer ) + 2 x outlet disconnector fuse switch for transformer 24kV 630A 16kA, metering panel do not include voltage and current instrumental transformers, posssible to fill them for reaquest for additional payment. Bdjdpfxsv Erz Ee Ammjg

Condition: ready for operation (used), Year of construction: 2015, Rated current: 2250A, rated impulse current: 75kA/125kA, degree of protection cabinet/floor: IP20/IP00, protection class: SK1, cable entry: bottom, main lines: 400V/230C AC, control lines: 110V DC, signal lines: 110V DC, number of panels: 7, panel equipment: panel 1: 4x NH00, panel 2: 2x NH1, panel 3: 2x NH2, panel 4: 2x NH3, panel 5-6: Siemens WLII 2000S+ETU25B, panel 7: Siemens BR6000 compensation. Documentation available. On-site inspection is possible. Bdodpfxsuanrko Ammeg

Condition: used, functionality: fully functional, Available quantity: 4 units Bodpfozhnv Tjx Ammjdg “Functionally tested; item originates from the dismantling of equipment from an automotive supplier” Manufacturer: Rittal GmbH & Co. KG Model: SK 3383500 Type: TopTherm Blue e roof-mounted cooling unit Total cooling capacity: 0.50 – 4.00 kW Energy efficiency: Blue e technology with EC fans Voltage: 230 V AC Control: Electronic thermostat and touch display Mounting: Control cabinet roof mounting Function: Temperature control for industrial control cabinets Refrigerant: R134a

Condition: used, Rittal air/water heat exchanger for the climate control of control cabinets and automation technology. Manufacturer: Rittal Series: TopTherm Bjdpfx Amezdafmemedg Type: SK 3210100 Device type: Air/water heat exchanger Condition: used Supply voltage: 230 V AC Frequency: 50/60 Hz Phases: 1~ Rated current: 0.44 A at 50 Hz Rated current: 0.50 A at 60 Hz Power consumption: 0.100 kW at 50 Hz Power consumption: 0.120 kW at 60 Hz Useful cooling capacity: 4.00 kW Measuring point for cooling capacity: L35 / W10 Flow rate of cooling medium: 400 l/h Operating temperature range: 1 °C to 70 °C Cooling medium: Water Maximum cooling medium temperature: 30 °C Operating pressure: 0.1 to 1.0 MPa Operating pressure: 14.5 to 145 psi Protection class: IP55 Weight: 25.5 kg Location: Kusel

Condition: used, functionality: unexamined, “functionally tested; item originates from the dismantling of equipment from an automotive supplier” Bdjdpfx Amjzhnyromog More than 10 units available Manufacturer: Siemens Model: 3TC5617-0A Type: Power contactor Rated voltage: 230 V AC Rated operating current: 40 A Frequency: 50/60 Hz Contacts: 3-pole (3 normally closed) Mounting type: Screw or DIN rail mounting Function: Switching of motors, heaters, or industrial loads Series: Sirius

Condition: excellent (used), Available quantity: 10 units. High-quality control cabinet cooler from Rittal, part of the TopTherm series, in very good condition (used). This unit is suitable for reliable air conditioning and cooling of control cabinets and industrial equipment. Robust industrial design with a high degree of protection and powerful cooling technology. Manufacturer: Rittal Model: TopTherm SK 3304540 Device type: Control cabinet cooler Condition: very good, used Date of manufacture: 10/2018 Serial number: 2018K000166679 Voltage: 400 V / 50 Hz / 3~ Alternative voltage: 460 V / 60 Hz / 3~ Rated current: 2.2 A Starting current: 11.5 A Circuit breaker: 6.3 – 10 A Power consumption: 0.64 kW Total cooling capacity DIN EN 14511: 1.10 kW Sensible cooling capacity DIN EN 14511: 0.94 kW EER L35 L35: 1.72 Refrigerant: R134a Refrigerant charge: 325 g GWP R134a: 1430 CO2e: 0.46 t Operating temperature range: 10 °C to 55 °C Degree of protection internal circuit: IP54 Degree of protection external circuit: IP34 Weight: 40 kg Bsdpfjzgf Hasx Ammedg Hermetically sealed: Yes Leakage tested according to EN-378-2

Condition: new, Year of construction: 2012, Electric power transmission cabinet, Electrical distribution cabinet, Electrical cabinet 180.5 kW, AEG Thyristor, AEG Thyro-A, 2A 400-350 HFRL1, Thyristor converter, Power controller, Electric power transmission cabinet for furnace, Used machine Manufacturer: Amarc srl Type: 120254; 3057 Year: 2012 Dimensions: 1020 x 530 x 2130 mm Weight: 200 kg Cabinet: 400 V; 3-phase; 50 Hz; 262 A; 180.5 kW Power transmission system AEG Thyro-A 2A 400-350 HFRL1 (Thyristor) AEG Thyro-A: Thyristor 400 V 350 A Cooled Power regulator Bdjdorbzygopfx Ammsg Load supervision on analog outputs
