Used Foil processing machinery for sale (14)

Condition: excellent (used), Bystronic Type: ERMM180 Thermoplastic applicator Field of application The thermoplastic applicator applies a thermoplastic material to rectangular glass panes rectangular glass panes as part of a production line for solar modules. The plastic forms a seal to a second pane of glass, which is applied in a later step. applied in a later work step. The panes are fed, applied and removed on horizontally running belts/belt conveyors. belts/conveyors. The thermoplastic applicator is a highly technical machine that has to fulfill many requirements with great precision. For this reason, you should only use products (glass, sealant) that meet the specifications on the following pages. the following pages. This helps to achieve high-quality and safe production. production. Performance and connected loads Maximum transport speed: 18 m/min Height of the glass running surface: 1100 mm Height of the applied sealant line: 0.5 to 1.2 mm Maximum width of the applied sealant line: 12.0 mm Required constant pneumatic inlet pressure: 6.5 to 8.0 bar Pneumatic operating pressure: 6.0 bar Compressed air consumption in normal operation: 10 standard liters/min Compressed air consumption when changing barrels: 500 standard liters/min Average energy consumption per hour: 10 kWh Working temperature of the sealant: 110°C to 130°C Ambient conditions and emissions Minimum ambient temperature: +15°C Maximum ambient temperature: +35°C Maximum relative humidity:: 75% Noise level: less than 70 dB (A) Requirements for the drums for the sealant Design: Material lidded container D18 according to DIN 6644 - with base (F1) and smooth outer surface (jacket design, smooth). Capacity: 216 liters Inner diameter: 571.5 mm Height: 874 mm Minimum wall thickness: 1.25 mm Machinable glass panes Types of glass Glass panes with a smooth surface can be processed (float glass). Dimensions and weights Smallest dimensions Largest dimensions Geometry 1198 mm 1200 mm Length LS 498 mm 600 mm Width BS 1.8* mm 5.0* mm Thickness DS Thermoplastics based on poly-iso-butylene (butyl) can be processed. The plastic must be flowable in the range of approx. 110°C to 130°C and have a defined viscosity curve. viscosity curve. Only use materials that have proven themselves in practice and that have been approved by the manufacturers of these materials and by Bystronic. Be3Jzjyt8M by the manufacturers of these materials and by Bystronic for your intended use. intended use. For detailed product descriptions and information on handling, storage and disposal of the plastic disposal of the plastic used can be found in the information sheets and safety data sheets provided by the manufacturers of the plastics. Dimensions of gantry robot with glass conveyor Height x width x depth: 2800 x 1890 x 2735 mm Weight of the gantry robot: 850 kg Weight of the glass conveyor: 1400 kg Drum pump dimensions Height x width x depth: 3320 x 1060 x 1200 mm Weight (without drum): 850 kg Weight (with drum): 1100 kg Height H for drum pump FP1: 4400 mm Height H for drum pump FP2: 4000 mm Control cabinet dimensions Height x width x depth: 2200 x 1800 x 600 mm Weight: 450 kg The applicator was used with the material butyl. Condition: second-hand / used From test laboratory, as good as new condition, only a few operating hours for testing! Scope of delivery: (see picture) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Condition: ready for operation (used), Year of construction: 2020, A film cutting machine with a handling portal from Trapo is available. Electrical components of the machine are available. However, the controls and the gripper of the handling portal are not available. Dpdeuf

Condition: used, High frequency welding press KIEFEL type G 3500 Sb HF plastic welding machine No. 2407 / 472 Year of manufacture approx. 1980 Table size 600 x 375 mm Plunger size 550 x 350 mm Projection 300 mm Installation height approx. 70 mm (with the currently installed ALU mounting plates) Stroke approx. 25 mm High-frequency power 4 kW High frequency presumably 27.12 mHz Mains connection 380 Volt, 50 Hz, 0.75 Amp. - Press table and ram with ALU support plates - adjacent HF generator KIEFEL Cvyse9X8Ns Space requirement of the welding press L x W x H 3000 x 1100 x 1600 mm Dead weight of the welding press approx. 1500 kg Tare weight approx. 600 kg High-frequency generator KÖRTING Radio Werke Type G 3500 Sb No. 60 364 732 Year of manufacture approx. 1980 High frequency: 27.12 mHz High-frequency output: 4 HF-kW Mains connection: 380 Volt, 50 Hz, (15.5/27 Amp.) - Air cooling 8.5 cbm/min. by built-in fan Space requirement L x W x H 850 x 800 x 1300 mm Weight 280 kg Tare weight of the system approx. 880 kg Good condition

Condition: good (used), Year of construction: 2011, Functionality: fully functional, machine/vehicle number: BF 1500/01/11, total width: 3,000 mm, total length: 7,600 mm, total height: 2,500 mm, roll width: 1,500 mm, ambient temperature (min.): 20 °C, energy consumption: 70 kWh, input voltage: 400 V, input frequency: 50 Hz, type of input current: AC, Production of bubble wrap from PE granulate with a width of 1500mm. Zmjzhz2Gc

Condition: like new (used), Year of construction: 2021, operating hours: 250 h, Machine size 1500x1500x1700mm Package size 1700x1550x1300mm Capacity 130-160pcs/min Power 3.5kW Finished products size 400x160mm Czvpms7C30

Condition: good (used), Functionality: fully functional, Machine for flat welding of foils (PVC) by high frequency welding technology, power 4 KW. Two tables, automatic feed. Dimension of welding area 80 x 50 cm. Brsd9Akcxmc

Condition: good (used), Functionality: fully functional, The subject of sale is a line for the production of laminates by pouring foil onto the laminated material. The lamination process is carried out using an extruder (extruders because there are two pieces) equipped with slotted dies with adjustable outlet width, thanks to which laminates can be produced in widths from 1m to 1.6m. The thickness of the foil that can be produced is 60 microns to 200 microns. The machine is great for combining different materials with each other, you can create various types of technical products according to your predispositions. The line also includes a material accumulator with a welding gun that allows feeding the material without the need to stop the line. The line does not include elements that are marked in red in the photos. The machine can also produce bubble wrap for technical applications. If necessary, we can also start the line at the buyer's premises, for an additional fee. The line is fully functional, we recommend it for various laminates. Ju7Uivkjc Description of the laminate production line The sales technology is a laminate production line, using the method of casting a film onto another material. The lamination process is carried out using an extruder (there are two extruders) equipped with slotted T-dies with adjustable width, thanks to which it is possible to produce laminates with a width of 1 m to 1.6 m. The thickness of the labels, which can be available from 60 microns to 200 microns, the machine is perfect for dividing various materials that can be created in the type of technical products according to its characteristics. The line also includes an accumulator device with a welded device for feeding material without power to the line. The line does not contain elements that are marked in red in the photos. The machine can also produce bubble wrap for technical applications. If necessary, we can also launch the line at the buyer's premises for an additional fee. The line is fully functional, we recommend it for making laminates.

Condition: used, Year of construction: 1986, U 1100 pouch machine for side seam products from RHS Elektrotechnik (Stiegler) Servo technology conversion 2013 by RHS, Working width 300 mm - 1100 mm, Befsggu throughput max. 70 m/min, 20 - 200 cycles/min, 3 single hole bars/6 mm Feed 70 mm - 300 mm, single-lane unwinding

Condition: used, WIDMANN automatic film unwinder, film unwinder Rewinder and unwinder, unwinder, rewinder, winding machine, roll winding machine, roll unwinding machine Unwinder with deflection rollers and film guide system Unwinder with deflection rollers for constant strap tension Year of construction approx. 2000 Roll width - coil width max. 400 mm Material width max. 400 mm Deflection rollers Ø 80 mm Deflection roller width 430 mm Roll weight - coil weight max. 150 kg Cstglqci7E Expansion shaft for cardboard core with inner diameter Ø 76 mm (inner coil diameter) Roll outer diameter - coil outer diameter max. 600 mm Interference circle with rotation of the film reel max. Ø 800 mm Reel shaft speed approx. 70 rpm Motor power - drive of the film reel 0.37 kW Mains connection 400 Volt, 50 Hz - Constant belt tension, winding tension via film accumulator with deflection rollers and vacuum shaft - Pick-up shaft with chuck for large rolls with cardboard core inner Ø 76 mm - 8 deflection rollers for film accumulator with constant winding tension, bearing via precise linear guide - Gear motor LENZE with brake to drive the film roll (0.37 kW) - Electrical system not ready for operation, see pictures Space requirement L x W x H approx. 1000 x 1000 x 1900 mm net weight 360 kg good condition

Year of construction: 2020, Condition: new, A fully automated film rewinding machine according to GMP guidelines. Foil rewinding machine type FUM-900 CP This film rewinding machine is used to rewind film rolls that have run in large systems or are not wound with the correct winding tension, and thus to prepare them for further processing. It was designed according to the special pharmaceutical guidelines and for the processing of PVC film. Advantage of our machine: with two separate drives, we can guarantee both right and left winding. Technical details: Width: 1,600 mm Blrvm0W0Ab Depth: 850 mm Height: 1,100 mm Materials: In contact with the product: 1.4301 / acrylic Performance: up to 120 m / s Speed: infinitely variable Ø film rolls: max. 450 mm Connection: 230 V / 50 Hz Drive: direct current 0.25 kW

Condition: like new (used), Year of construction: 2021, operating hours: 150 h, Functionality: fully functional, Model DH-001 Package 3900x820x820x1550mm Capacity 180-210pcs/min Power 5kW Dqqutx

Condition: reconditioned (used), Year of construction: 2018, Functionality: fully functional, Material joining machine - for the production of double-sided adhesive tapes and other material joints The semi-automatic cutting machine is suitable for winding various types of coupled tapes - single-sided adhesive materials, foam and aluminum on plastic or cardboard cores Unwinding unit: Separate from the machine, with an intermediate aluminum platform for operator inspection. TECHNICAL DETAILS Width of the cylinder: 2600 mm Ccbtvks Maximum material width: 2500 mm Diameter of the unwind shaft: 3" Maximum jumbo diameter: 1000 mm Diameter of the rewind shaft: 3" Maximum winding speed: 100 m/min Maximum winding diameter: 400 mm Brake: 4-caliper disk brake MACHINE DETAILS Overall dimensions: 4000 x 2000 x 400 mm Electrical connection: 400V 3P+N+T, 63A Connected load: 20 kW Compressed air: 6 bar, 5 l/min EQUIPMENT - Proportional brake for adjusting the winding tension - Winding turret with push-button rotation 2 pneumatic 3" winding shafts - 1 AC drive motor - 1 AC winding motor - Regulation of tension and line speed - Manual filling/emptying of the winding shafts - Preselection of meter counting with slowdown and stop

Condition: used, Year of construction: 1974, TS 800 pouch machine for side seam products from RHS Elektrotechnik (Stiegler) Zf9K7Gx8 Conversion of servo technology 2017/2018 by RHS Working width 150 mm - 750 mm Throughput max. 50 m/min, 50 - 150 cycles/min. 2 single hole bars/6 mm Feed 70 mm - 250 mm, single-lane unwinding

Condition: used, WIDMANN automatic film unwinder, film unwinder Rewinder and unwinder, unwinder, rewinder, winding machine, roll winding machine, roll unwinding machine Unwinder with deflection rollers and film guide system Unwinder with deflection rollers for constant strap tension Year of construction approx. 2000 Roll width - coil width max. 400 mm Cw7Ct8Cn Material width max. 400 mm Deflection rollers Ø 80 mm Deflection roller width 430 mm Roll weight - coil weight max. 150 kg Expansion shaft for cardboard core with inner diameter Ø 76 mm (inner coil diameter) Roll outer diameter - coil outer diameter max. 600 mm Interference circle with rotation of the film reel max. Ø 800 mm Reel shaft speed approx. 70 rpm Motor power - drive of the film roll 0.37 kW Motor power - drive of the flat film into the vacuum shaft 0.25 kW Mains connection 400 Volt, 50 Hz - Constant belt tension, winding tension via film accumulator with deflection rollers and vacuum shaft - Pick-up shaft with chuck for large rolls with cardboard core inner Ø 76 mm - 8 deflection rollers for film accumulator with constant winding tension, bearing via precise linear guide - LENZE geared motor with brake to drive the film roll (0.37 kW) - LENZE geared motor with brake to drive the flat film into the vacuum shaft (0.25 kW) Space requirement L x W x H 1900 x 1300 x 1900 mm net weight 580 kg Good condition
