Used Mazak Laser Cutting Machine for sale (341)

Condition: excellent (used), Year of construction: 1989, I am selling a CNC lathe Mazak QuickTurn 20N. Lathe in bdb condition. Equipment: MAZATROL T-2, control MAZATROL CAM-T-2. Nsdpfxeu U R E Ae Aahewb

Condition: used, TECHNICAL DETAILS - Number of axes : 3 Njdpfx Asycxudoahjwb MILLING SPINDLE - Tool holder type : ISO40 - Spindle speeds : 12.000 [rpm] - Spindle power : 18,5 [kW] LINEAR AXES - Travels on X/Y/Z axes : 1050 / 530 / 510 [mm] - Rapid traverses rates (X/Y/Z) : 42 [m/min] - Cutting feed rates (X/Y/Z) : 1 - 8000 [mm/min] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 30 TABLE - Table dimensions : 1300 x 550 [mm] - Maximum weight upon table : 1200 [kg] - Distance table / spindle nose (min./max.) : 150 - 650 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 41.15 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.880 x 2.950 [mm] - Machine height : 2.808 [mm] - Machine weight : 6800 [kg] EQUIPMENT - CNC : MAZATROL MATRIX NEXUS 2 - Interface : PCMCIA / RS232 - Electronic handwheel - 3 colors status lamp - Coolant tank * with high-pressure pump - Coolant through spindle - Chips conveyor - Tool probe

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Equipment: chip conveyor, Options: Left side chip conveyor Coolant temperature control 15,000 rpm spindle High-torque spindle Linear scales on axes Losma extraction Automatic door Detachable handwheel 3-color signal lamp Renishaw RMP 600 Nedpfx Ajycr Nuoahjwb Continuous 5 axes ISO 5-axis function Performance package Memory extension Robot interface

Condition: used, Year of construction: 2019, MAZAK VTC 800/30SR Table size (clamping surface): 3,500 x 820 mm Nwedpfx Aajxqhxmohsb Travel X-axis: 3,000 mm Travel Y-axis: 800 mm Travel Z-axis: 720 mm Rapid traverse X/Y/Z: 50 m/min Max. spindle speed: 18,000 rpm Spindle taper: SK 40 Machine is equipped with: - CNC controller Mazatrol SmoothX - Tool magazine with 48 tool places - Through-spindle cooling - Preparation for Monitoring B-System RMP60 - NC rotary table - Chip conveyor

Condition: ready for operation (used), + Fully operational + See the video + Includes tailstock, documentation, and chip conveyor + Free loaded on truck 📋 Full technical specifications – Mazak Quick Turn 15N Performance / Capacity Swing over bed: Ø 440 mm Swing over cross slide: Ø 254 mm Centre distance: 644 mm Standard turning diameter: Ø 150 mm Max. turning diameter: Ø 254 mm Max. machining length (chucking work): 451 mm Max. machining length (shaft work): 433 mm Workpiece weight (chucking work): 100 kg Workpiece weight (shaft work): 150 kg Max. bar diameter (with hollow chuck): Ø 51 mm Axes X-axis Travel: 180 mm Rapid traverse: 30,000 mm/min Z-axis Travel: 510 mm Rapid traverse: 30,000 mm/min Spindle Speed range: 45 – 4,500 rpm Number of speed ranges: 1 Spindle nose: JIS A2-6 Spindle bore: Ø 62 mm Spindle bearing inner diameter: front Ø 100 / rear Ø 90 mm Spindle bore taper: Ø 70 (1/20) Spindle drive motor: 15 HP Torque: up to 28.6 kgm Direct command: automatic: 1 rpm manual: 10 rpm Turret Turret type: 8-station / 12-station / 16-station drum turret (depending on version) Tool stations: 8 / 12 / 16 Tool shank size (external): 25 mm Boring bar shank diameter: Ø 40 mm Turret indexing time: 1 step: 0.48 s Full step: 0.85 s Turret clamping force: 4,300 kg Coupling diameter: Ø 210 mm Turret indexing: possible Tailstock Taper: MT 4 (dead centre) Max. quill thrust: 700 kg Quill diameter: Ø 80 mm Quill stroke: 130 mm Motors / Supply Spindle motor: 15 / 11 kW Feed motor X: 1.0 kW Feed motor Z: 2.0 kW Hydraulic motor: 1.5 kW Coolant pump motor: 0.18 kW Electric power requirement: 41.3 kVA Compressed air pressure: 0.5 MPa Air flow: 100 Nl/min Machine dimensions Machine height: 1,790 mm Nwodpfsybcbrox Aahsb Footprint (W × L): 2,360 × 2,570 mm Machine weight (incl. control): 4,300 kg Bed type: horizontal Bed width: 340 mm Accuracies Positioning accuracy: X-axis: 0.008 mm Z-axis: 0.013 mm Repeatability: X-axis: ± 0.002 mm Z-axis: ± 0.003 mm

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 760 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, table load: 400 kg, rotational speed (max.): 8,000 rpm, TECHNICAL DETAILS X-axis: 760 mm Y-axis: 400 mm Z-axis: 400 mm Table size: 1,020 x 410 mm Max. table load: 400 kg Spindle speed: 8,000 rpm Tool holder: CAT 40 / BT 40 Tool changer: 20 positions Accuracy Positioning accuracy: ±0.01 mm Repeatability: ±0.005 mm MACHINE DETAILS Control: MAZATROL M-PLUS EQUIPMENT Robust construction Fully hydraulic table Stable cast iron structure Suitable for aluminium, steel and plastics User-friendly programming Integrated simulation and diagnostic software Regularly serviced Nwodpfoya Dw Sex Aahob Coolant and lubrication systems intact

Condition: used, Year of construction: 1987, Technical details: x-travel: 760 mm y-travel: 450 mm z-travel: 500 mm control: Mazatrol CAM M-2 tool changer with: 30 tools (Kettenmagazin) Plätze spindle taper MT: ISO 40 Revolution per minute: 28 - 4500 U/min. feed speeds infinitely variable: X/Y/Z: max. 2.000 mm/min max. torque on the spindle: ca. 23 Nm rapid traverse:: X / Y: 24 m/min rapid traverse:: Z: 15 m/min. bore capacity in steel (diameter): Ø 40 mm table-size: 500 x 1150 mm table load capacity - central/maximum: 700 kp total power requirement: 11 kW (24,4 kVA) kW Weight approx.: 6,8 t Nsdpfjvc Avbox Aahowb dimension machine xH: 3,7 x 2,5 x 2,6 m chip conveyor: L: 3,7 x B: 0,75 x H: 1,35 m ATC tool magazine for 30 tools up to Ø 100mm x 330mm, SK40 Hinged belt chip conveyor Knoll-120S-1 with ejection height of 1130mm Coolant tank with pump, 200liter capacity, 30 l/min. Operation via control panel with boom 2000mm. accessories: cooling lubricant pump Base plates *

Condition: excellent (used), Year of construction: 2008, CNC Horizontal Machining Center MAZAK HCN 5000 II Year of manufacture: 2008/10 Tool magazine: 40 tools Spindle speed: 18,000 rpm NC rotary table (fourth axis / 0.001 x 360,000 positions) Technical Specifications: Max. workpiece diameter: 800 mm Max. workpiece height: 1,000 mm X-axis travel: 730 mm Nsdpex Hgh Iefx Aahjwb Y-axis travel: 730 mm Z-axis travel: 740 mm Distance from spindle center to pallet center, min.: 70 mm Distance from spindle center to pallet center, max.: 810 mm Distance from spindle center to pallet surface, min.: 100 mm Distance from spindle center to pallet surface, max.: 830 mm Tool holder: SK40 Tool magazine: 40 tools Spindle speed: 18,000 rpm Pallet working area: 500 x 500 mm NC rotary table (fourth axis / 0.001 x 360,000 positions)

Condition: excellent (used), Year of construction: 1999, CNC Lathe MAZAK SQT 200 MS Year of manufacture: 1999 Including indicated tools and sub-spindle Control: Mazatrol PC Fusion CNC 640T Technical specifications: Max. swing diameter: 525 mm Max. swing diameter over saddle: 350 mm Max. turning diameter: 300 mm Bar work up to max. diameter: 51 mm Main spindle: Speed range: 35 – 4,000 rpm Main drive power: 15 kW Max. torque: 350 Nm Spindle nose: A2 – 6 inch Spindle bore: 61 mm Spindle positioning C-axis: 0° - 360°/0.001° Second spindle: Speed range: 35 – 5,000 rpm Drive power: 7.5 kW Max. torque: 57 Nm Indexing: 72 positions/5° Tool turret: Number of tool stations: 12 (freely configurable with stationary and driven tools) Turret indexing time – 1st station: approx. 0.2 s Driven tools: Drive power: 3.7 kW Max. torque: 35 Nm Speed range: 25 – 4,500 rpm Nodpfjx Hgl Hsx Aahowb Travel: Turret travel: X-axis: 190 mm Z-axis: 575 mm B-axis: 585 mm Rapid traverse: X-axis: 30 m/min Z-axis: 30 m/min B-axis: 18 m/min Feed range: X/Z-axis: 0 – 5,000 mm/min C-axis: 1 – 2,000°/min

Condition: excellent (used), Year of construction: 2000, CNC Lathe MAZAK SUPER QUICK TURN 200 Year of manufacture: 2000 Working area: Max. swing diameter: 525 mm Max. turning diameter: 350 mm Max. turning length: 514 mm Bar work up to max. diameter: 51 mm Main spindle: Speed range: 35 – 5,000 rpm Main drive power: 18.5 kW Constant torque: 333 Nm Spindle nose: A2 – 6 inch Spindle bore: 61 mm Turret: Standard version: 12 stations Travel: Turret travel: X-axis: 190 mm Z-axis: 535 mm Njdsxvb E Dspfx Aahewb

Condition: ready for operation (used), Year of construction: 2018, Control Unit Brand MAZATROL Model SMOOTH X Main Drive Number of spindles 2 Spindle speed range 1 - 3300 rpm Spindle bore ø112 mm (ø4.41 inches) Number of axis 5 Nsdsx Stk Tjpfx Aahjwb Movement X-Axis Movement 615 mm X-Axis Rapid Traverse 50 m/min Y-Axis Movement 260 mm Y-Axis Rapid Traverse 40 m/min Z-Axis Movement 2563 mm Z-Axis Rapid Traverse 40 m/min W-Axis Rapid Traverse 30 m/min Tools Number of index 72 Max weight 12 kg Max tool diameter 90 mm Type of tool holder HSK-A63 (T63) This 5-axis Mazak Integrex i-400S-2500U was manufactured in 2018, featuring Mazatrol SMOOTH X Control and a Hydrafeed MSV110 Barfeed. It offers a maximum machining diameter of ø658 mm and a length of 2,497 mm. Equipped with a milling spindle speed of 12,000 rpm and a tool storage capacity of 72 tools, this turn-mill centre is ideal for complex machining tasks. If you are looking to get high-quality turning and milling capabilities, consider the Mazak Integrex i-400S-2500U machine we have for sale. Contact us for more information. Application Types Turning

Condition: ready for operation (used), Year of construction: 2013, Movement Y-Axis Movement 510 mm Z-Axis Movement 580 mm This 5-axis Mazak Variaxis i-600 was manufactured in 2013. It features a Siemens 840D control system, a table size of 600mm, and a spindle speed of 18000 RPM with a power of 35 kW. The machine offers a tool capacity of 40 and has spindle run hours of 1900. If you are looking to get high-quality milling capabilities, consider the Mazak Variaxis i-600 machine we have for sale. Contact us for more information about this machine. Application Types Milling Nwedpfex R E Ihjx Aahsb

Condition: repair required (used), Year of construction: 2002, operating hours: 6,000 h, functionality: not functional, machine/vehicle number: 158187, travel distance X-axis: 1,740 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 840 mm, controller manufacturer: Fusion 640M, number of spindles: 1, number of slots in tool magazine: 30, Machine: Mazak VTC-300-C II Nodpfex U A Elox Aahewb Year of manufacture: 2002, Total spindle hours according to spindle monitor: 47,961 hours. A new spindle was installed, which now has 4,770 hours. Control: Fusion 640 M Travel distances: X-axis = 1,740mm, Y-axis = 760mm, Z-axis = 840mm Spindle: SK-40, 12,000 rpm Tool magazine with 30 positions Equipped with Renishaw probe Machine dimensions: Length = 4,150mm + 1,260mm chip conveyor, Width = 3,300mm, Height = 3,100mm Individual components can also be purchased (such as spindle, control cabinet, control unit, etc.). The machine is currently defective and is suitable either for repair (costs approx. €4,500) or for dismantling for parts. For further questions, please feel free to call or send an email.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, MAZAK VCN 410A Nikken 5AX-201 rotary table, 5-axis in continuous mode except tilt, which is managed via the Nikken x21 remote control Table diameter: 200 mm Nsdpoxvra Sofx Aahewb Travels: 560 x 410 x 510 mm Table size: 900 x 410 mm 30-tool magazine Spindle: 12,000 rpm Chip conveyor

Year of construction: 1999, condition: ready for operation (used), Main Drive Spindle motor power 22 kW Number of axis 3 Movement X-Axis Rapid Traverse 30500 mm/min Z-Axis Rapid Traverse 33000 mm/min Nsdpfx Ajx Nr S Djahowb Turret Number of turrets 2 Number of tool slots 12 This 3-axis Mazak Multiplex 6200 was manufactured in 1999 and features dual spindles with a maximum speed of 5,000 rpm and a drive power of 22/15 kW each. It includes an ABB robot and turrets on both the right and left with 12 tools each. Rapid traverse rates are 30.5 m/min for the X-axis and 33 m/min for the Z-axis. If you are looking to get high-quality turning capabilities consider the Mazak Multiplex 6200 machine we have for sale. Contact us for more information. Application Types Turning

Condition: ready for operation (used), Year of construction: 2016, operating hours: 16,000 h, travel distance X-axis: 3,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 720 mm, total height: 3,376 mm, table load: 2,500 kg, overall weight: 16,300 kg, spindle speed (max.): 18,000 rpm, spindle motor power: 33,000 W, tool weight: 8,000 g, product length (max.): 5,480 mm, number of axes: 5, This 4-axis Mazak VTC 800/30 SR was manufactured in 2016, featuring a robust vertical machining center with a table width of 3,500 mm and length of 820 mm. It boasts a maximum speed of 18,000 rpm and rapid traverse speeds of 50 m/min on all X, Y, and Z axes. The machine includes a 30-position tool changer and can handle a maximum tool weight of 8 kgf. Consider the opportunity to buy this Mazak VTC 800/30 SR vertical machining center. Contact us for more information. • Travels • Table size: 3,500 x 820 mm • B-axis: +110 degrees • Min. distance spindle nose to table top: 140 mm • Max. distance spindle nose to table top: 860 mm • Work spindle • Steep taper tool holder (40° taper not included when ordering 155 HSK tools) • Feed rates • Rapid traverse speed X/Y/Z: 50 m/min • Worktable • T-slot width: 18 mm • Number of T-slots: 7 • T-slot spacing: 100 mm • Table height from floor: 870 mm • Tool changer • Tool positions: 30 (standard) / 48 (optional) • Tool selection: shortest path • Tool shank: steep taper 40° • With adjacent positions occupied: 80 mm • With adjacent positions free: 130 mm • Total weight of all magazine tools: 150 kgf • Chip-to-chip time: 4.7 s • Utilities • Connection voltage: 380/400/415 V +10% • Connection frequency: 50/60 +1 Hz • Air pressure: 5–9 bar • Air flow rate: 260 l/min • Tank capacity: 500 L Additional equipment • AirFresh FMN V12 extraction system (installed on both sides and connected to a door sensor) • Mounting bracket for vertical operation of the rotary table • 2x Renishaw TS27R integrated tool presetting devices • Spare parts: • Y-axis motor for tool magazine • Linear axis shifter motor • Rotary axis shifter motor Nwsdex Nkp Uopfx Aahjb • Cylinder for swivel unit

Condition: reconditioned (used), Year of construction: 2006, MAZAK QUICK TURN NEXUS 200-II MY Max. machining diameter: 380 mm Max. machining length: 538 mm Max. milling speed: 4,500 rpm Max. spindle speed: 5,000 rpm Max. bar diameter: 65 mm Machine is equipped with: - CNC control Mazatrol Matrix - KITAGAWA three-jaw chuck BB-208, diameter 210 mm Nwedexlzp Ispfx Aaheb - Tool Eye - C-axis - Y-axis - Interface for bar feeder - Automatic parts catcher - NC tailstock - Reinforced coolant pump - MAYFRAN chip conveyor - 8 fixed tool holders - 2 driven tool holders

Condition: good (used), Year of construction: 2005, Tool holder BT 40, 12.000 rpm, 60 tool places in tool changer, 70 bar IKZ, Njdpjwbaqljfx Aahowb laser Renishaw OMI-2. Parts shown by hand not come.

Condition: ready for operation (used), Year of construction: 2006, operating hours: 32,790 h, functionality: fully functional, travel distance X-axis: 2,032 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 750 mm, table load: 3,000 kg, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel X-axis: 2,032 mm Travel Y-axis: 750 mm Travel Z-axis: 750 mm Max. workpiece height: 870 mm Max. table/workpiece load: 3,000 kg Table width: 800 mm Table length: 2,240 mm Spindle speed: 40 – 6,000 rpm Spindle taper: SK 50 Standard spindle power: 18.5 kW Standard torque: 759 Nm Spindle power (optional): 26 kW Torque (optional): 1,067 Nm MACHINE DETAILS Control unit: MAZATROL Dimensions & Weight Dimensions (L x W x H): 5,685 mm x 4,096 mm Weight: 14,000 kg Operating hours: 32,790 h Nodpfx Aaex Ng Nwshjwb

Condition: good (used), Year of construction: 2018, operating hours: 7,819 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 720 mm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, STANDARD TECHNICAL SPECIFICATION – MAZAK CAPABILITIES Table work surface (length): 2,500 mm Table work surface (width): 820 mm Longitudinal (crosswise) X-axis travel: 2,000 mm Column (crosswise) Y-axis travel: 800 mm Spindle head (vertical movement) Z-axis: 720 mm Minimum distance from spindle nose to top of table: 140 mm Maximum distance from spindle nose to top of table: 860 mm Table load capacity (uniform load): 1,700 kgf Spindle head rotation (B-axis): ± 110° SPINDLE HEAD Spindle taper: 7/24 taper, No. 40 Maximum spindle speed (standard): 18,000 min⁻¹ Minimum spindle speed (standard): 35 min⁻¹ Main spindle motor output (continuous rating): 26.0 kW FEED RATES Rapid traverse (X-axis): 50 m/min Rapid traverse (Y-axis): 50 m/min Rapid traverse (Z-axis): 50 m/min TABLE Table length: 2,500 mm Table width: 820 mm T-slot width: 18 mm Number of T-slots: 7 Distance between T-slot centers: 100 mm Height from machine base to table surface: 870 mm AUTOMATIC TOOL CHANGER Tool storage capacity (standard): 30 Tool storage capacity (optional): 48 Tool selection: Mazatrol memory random access type Tool shank: CAT-40 / MAS BT-40 Max. tool diameter with adjacent tools: 80 mm Max. tool diameter without adjacent tools: 130 mm Max. tool weight (with holder & taper pin): 8 kgf Max. total tool magazine weight: 150 kgf Max. tool length (from gauge line): 350 mm Tool change time (chip-to-chip): 4.7 s MACHINE DIMENSIONS Machine height (from floor): 3,355 mm Machine width: 4,250 mm Machine depth: 4,046 mm Machine weight: 14,000 kg OTHER Power supply voltage: AC380/400/415V ±10% Power supply frequency: 50/60 Hz ±1 Compressed air pressure: 0.5–0.9 MPa Compressed air capacity: 260 l/min Coolant tank capacity: 450 L STANDARD MACHINE EQUIPMENT – MAZAK GENERAL MACHINE OPTIONS Foundation kit (base bolts & plates) One set of adjusting tools Work area lighting Power transformer for European market USB I/F (1 port) MANUALS, DOCUMENTATION One set of documentation (CD) SPINDLE SPEED Spindle speed: 18,000 rpm (#40) MACHINE FRAME COLOR Mazak standard color (F white / S black) SAFETY, HEALTH Global safety measures Work area door interlock with locking switch Full machine enclosure Full-cover chip and coolant protection TOOL MAGAZINE 30-position tool magazine COOLING SYSTEMS Complete cooling system HIGH PERFORMANCE/HIGH PRESSURE COOLANT Through-spindle coolant (5 bar, 71 PSI) PRODUCTION AUTOMATION SYSTEMS Automatic ON/OFF + warm-up MEASURING SYSTEMS Automatic tool length measurement & tool breakage detection POSITIONING SYSTEM Absolute positioning system CHIP CONVEYOR Preparation for chip conveyor (left side) NC CONTROL UNIT – 15 Functions 19" color LCD (touch screen) 3-D coordinate conversion Position sensor B) Shape compensation for rotary axes EIA/ISO code input function (standard) Background tool path check LAN connection High smoothing control Mazak 2D software (shape compensation) Mazak 3D high-speed software package Mazak thread tapping / pre-tapping Tornado (Mazatrol) Mazatrol SmoothX CNC Movable control panel SD memory I/F (1 slot) + USB I/F (1 slot) Smooth standard software Nwjdpfx Aoya Hngoahob

Condition: used, Year of construction: 2016, The Mazak VTC 800 series is a line of powerful, large-format 5-axis turning centers for large workpieces, known for their high precision and rigidity, ideal for aerospace, energy and heavy machinery, with functions such as integrated spindles, fast tool change, and for efficient complete processing. Accessories/Options: Tool magazine for 30 tools Tool length measurement, tool breakage detection Factory-installed preparation for chip conveyor (left) Magazine (HSK) for 155 tools Air blower at the workpiece Signal light (end of machining: yellow) Additional: Work area lighting Coolant gun Air blower through the spindle 70 bar preparation, including interface for high-pressure system Automatic opening/closing of the operator door Mazak Monitoring System B RMP 60 (only/H/V) Collision monitoring by Brankamp 2 Renishaw TS27R tool presetting devices NC rotary table Holding device for vertical use of the NC rotary table Table center partition for pendulum machining 3D model of the work area in STEP format 5-axis milling technology Knoll compact filter KF400/2300 (filtration capacity 400 l/min, tank volume 2300 l/min) 1) High-pressure cooling 70 bar, 7 pressure stages Chip conveyor, hinged belt design Additional M-codes: 1 set = 2 M-codes Preparation for dual extraction system (mechanical nozzle) 0.198 mm Transformer for the European market 1 set of manuals in electronic form on CD 1 set of adjustment tools Foundation set (anchor bolts + plates) MAZAK standard paint Work area lighting Additional items: AirFresh FMN V12 extraction system (installed on both sides and coupled with a door sensor) Holding device for vertical operation of the rotary table 2 x Renishaw TS27R integrated tool presetting devices Spare parts: Y-axis motor, tool magazine Nodpfsx Idwiox Aahowb Linear axis shifter motor Rotary axis shifter motor Cylinder for swivel unit width: 3500 mm length: 820 mm X-axis travel range: 3000 mm Y-axis travel range: 800 mm Traversal range Z-axis: 720 mm min. distance spindle nose to table top: 140 mm max. distance from spindle nose to table top: 860 mm max. table load: 2500 kgf B-axis: ± 110 degrees Working spindle steep taper mount: Steep taper 40 collapses under load 155 tools HSK Max speed: 18,000 RPM Min. Drehzahl: 35 min-1 Rated power: ( 100 % continuous operation) 33,0 kW Emergency travel speed X-Y & Z axis: 50 m/min Working table width: 3500 mm Worktable length: 820 mm Width of T-slots: 18 mm Number of T-slots: 7 Distance of T-slots: 100 mm Table height from the floor: 870 mm Tool changer number of tool places (Standard): 30 Number of tool stations (optional): 48 Tool selection method: shortest path tool shank: Steep cone 40 With occupied side positions: 80 mm With available spaces: 130 mm max. tool weight: 8kgf Total weight of all magazine tools: 150 kgf max. tool length: 350 mm Tool change time: (Span-to-Span) 4.7 s Connected load: 400 V / 50/60 Hz Air pressure: 5 – 9 bar Air volume: 260 l/min Tank capacity: 500 l Dimensions (Height x Length x Width): 3376 x 5480 x 4051 mm Weight approx: 16300 kg colour: Gray / Black

Condition: used, Year of construction: 1996, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 825 mm, controller model: Mazatrol M Plus, table width: 630 mm, table length: 630 mm, overall weight: 19,800 kg, spindle speed (max.): 10,000 rpm, Mazak FH 680 X Nwodpfjyan Diex Aahsb • X axis 1100 mm • Y axis 800 mm • Z axis 825 mm • Rotary table 360° – 1° indexing • 2 pallets • Table size 630x630 mm • 10,000 rpm, BT 50 • Through-spindle coolant (IKZ) • Year of manufacture: 1996 • 19,800 kg Can be inspected under power.

Condition: used, Year of construction: 1998, functionality: fully functional, machine/vehicle number: 136722, travel distance X-axis: 560 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: Mazatrol M Plus, table width: 400 mm, table length: 400 mm, overall weight: 9,500 kg, spindle speed (max.): 10,000 rpm, Mazak H415 • X 560 mm • Y 510 mm • Z 510 mm • Rotary table 360° - 1° indexing • 6-pallet magazine • 120-tool magazine • SK 40 • Through spindle coolant (IKZ) • Year of manufacture: 1998 • 9,150 kg Can be inspected under power. Njdpfxoyan Axe Aahewb

Condition: used, Year of construction: 2005, functionality: fully functional, machine/vehicle number: 175849, travel distance X-axis: 1,740 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 840 mm, controller model: PC Fusion 640 M, total height: 4,450 mm, total length: 3,300 mm, total width: 2,900 mm, overall weight: 11,500 kg, spindle speed (max.): 12,000 rpm, 3-Axis Machining Center MAZAK - VTC 300C-II Manufacturer: MAZAK Model: VTC 300C-II Control: PC Fusion 640M Year of manufacture: 2005 Internal coolant supply (IKZ): 15 bar Table length: 2000 mm Table width: 760 mm Feed rate X-axis: 36,000 mm/min Feed rate Y-axis: 36,000 mm/min Feed rate Z-axis: 36,000 mm/min Tool holder: SK 40 Spindle power: 15 kW Spindle speed: 12,000 rpm Tool changer: 30 positions Internal coolant: Yes Number of controlled axes: 3 Nodpfxjyanuho Aahjwb Chip conveyor: Yes Cooling unit: Yes Length: 4450 mm Width: 3300 mm Height: 2900 mm Can be inspected under power.

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 1,050 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, controller manufacturer: SMOOTH TECNOLOGY, table width: 1,100 mm, table length: 600 mm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 20,800 h, spindle nose: SK40, number of spindles: 1, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, Type: Vertical machining center Vertical Brand: MAZAK Model: SMART 530C Year: 2016 C.N.C: SMOOTH TECNOLOGY Table dimensions: 1100x600 mm Longitudinal X-travel: 1050 mm Cross Y-travel: 530 mm Vertical Z-travel: 510 mm Spindle nose: SK40 ISO Spindle speed: 12000 rpm. Njdjx Ttr Tspfx Aahewb Motor power: 18,5 Kw Rapid X,Y,Z axis: 40000 mm/min Tool Stations: 30 no.
