Slotted bed for Weinig Unimat 23 6 shafts

Weinig

Condition: used, Year of construction: 2009, machine/vehicle number: 113680, functionality: limited functionality, working width: 230 mm, spindle diameter: 40 mm, spindle speed (max.): 6,000 rpm, working height: 120 mm, TECHNICAL DETAILS Working width: 20–230 mm Working height: 8–120 mm Infeed table length: 1,950 mm Feed rate: 6–12 m/min Number of spindles: 5 Spindle diameter: 40 mm Spindle speed: 6,000 rpm Max. tool diameter vertical spindle: 232 mm Max. tool diameter horizontal spindle (except for the first spindle): 200 mm Spindle arrangement and power 1. Spindle, bottom: 5.5 kW Fpedpfx Aozrmptohkek 2. Spindle, left: 7.5 kW 3. Spindle, right: 7.5 kW 4. Spindle, top: 11 kW 5. Spindle, bottom: 5.5 kW MACHINE DETAILS Connection voltage: 400 V Connection power: 32 kW Fuse rating: 64 A Dimensions & Weight Dimensions (L x W x H): 4,000 x 1,400 x 1,350 mm Weight: 2,500 kg EQUIPMENT 5-spindle version Four-sided machining Infeed table CE marking Note: The 5th spindle is defective.

Condition: ready for operation (used), Year of construction: 1998, working width: 230 mm, overall weight: 2,500 kg, spindle speed (max.): 6,000 rpm, This 5-spindles WEINIG DIMTER PROFIMAT 23 E was manufactured in 1998. It features a working width of 230 mm and a working height range of 8-120 mm. The machine operates at a spindle speed of 6000 rpm and has a feed rate of 5-24 m/min. If you are looking to get high-quality wood planning capabilities, consider the WEINIG DIMTER PROFIMAT 23 E machine we have for sale. Contact us for further details. • Condition note: Not rebuilt – without warranty Fjdpfx Aezt Dg Sehkepk • Working height: 8–120 mm • Number of spindles: 5 (top, right, left, bottom, top) • Feed rate: 5–24 m/min • Total power consumption: approx. 25 kW • Feed table length: approx. 2000 mm

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 3,000 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 142 mm, controller manufacturer: SIEMENS, controller model: WS 400-20, CNC processing center manufactured in 1997. This WEINIG / DIMTER Unicontrol 10 features a maximum workpiece length of 3,600 mm and a maximum workpiece height of 100 mm. It includes a powerful cross-cut saw with a spindle speed of up to 3,000 rpm and a tenoning spindle motor power of 15 kW. If you are looking to get high-quality CNC processing capabilities, consider the WEINIG / DIMTER Unicontrol 10 machine we have for sale. Contact us for further details. • Max. workpiece height: 100 mm • Min. workpiece height: 40 mm • Min. workpiece width: 40 mm • Max. workpiece width: 140 mm • Max. workpiece length with CNC stop: 3,500–3,600 mm • X-axis stroke: 3,000–3,500 mm (version dependent) • Cross-cut saw motor power: 3.7 kW • Cross-cut saw spindle speed: 2,800–3,000 rpm • Cross-cut saw max. tool diameter: 400 mm • Cross-cut saw spindle diameter: 40 mm Fpedszt Dfbjpfx Ahkjk • Tenoning/slotting spindle quantity: 2 pcs • Tenoning spindle diameter: 50 mm • Tenoning spindle clamping length: 400–640 mm • Tenoning spindle max. tool diameter: 400 mm • Tenoning spindle motor power 1: 11 kW • Tenoning spindle motor power 2: 15 kW • Tenoning spindle speed: 2,900–3,250 rpm • Profiling spindle quantity (vertical): 2–3 pcs • Profiling spindle diameter: 50 mm • Profiling spindle clamping length: 320–400 mm • Profiling spindle max. tool diameter (flight circle): 232 mm • Profiling spindle motor power: 11 kW (each) • Profiling spindle speed: 6,000 rpm • Horizontal profiling unit (top) motor power: 3 kW • Horizontal profiling unit spindle diameter: 40 mm • Horizontal profiling unit max. tool diameter: 130 mm • Horizontal profiling unit speed: 5,850 rpm

Condition: ready for operation (used), Year of construction: 2018, Optimizing Cross-Cut Saw manufactured in 2018. This WEINIG DIMTER Opticut S90 features a saw blade diameter of 500 mm and a maximum cutting height of 120 mm. It accommodates input lengths from 400 to 6,300 mm and widths from 20 to 300 mm. If you are looking to get high-quality cutting capabilities, consider the WEINIG DIMTER Opticut S90 machine we have for sale. Contact us for further details. • Saw blade • Diameter: 500 mm Fpodpezt A Sgofx Ahkok • Bore: 30 mm • Adjustable saw blade speed: 40–100% via frequency converter • Workpiece capacity • Input length (min/max): 400–6,300 mm • Width (min/max): 20–300 mm • Thickness (min/max): 10–120 mm • Maximum cutting height: 120 mm • Minimum cross-section: 20 x 10 mm • Maximum cross-section 1: 215 x 120 mm • Maximum cross-section 2: 300 x 40 mm • Permissible timber curvature: max 2 mm/m or 8 mm over entire length • Table inclination: 10° • Motion and accuracy • Positioning speed (reverse stroke): max approx. 180 m/min • Positioning speed (forward stroke): max approx. 60 m/min • Positioning accuracy: +/- 0.1 mm • Motors and power • Pusher motor power: 5.1 kW • Saw motor power: 7.5 kW • Total electrical load: approx. 15 kW • Control and interface • Control unit: OptiCom Pro with 18.5" touch screen • Screen resolution: 1366 x 768 pixels • Protection class (front): IP65 • Interface: USB port and Ethernet network connection • Data format: CSV (ASCII) for import/export • Utilities and environment • Voltage: 400 V / 50 Hz • Operating pressure: 6–8 bar (min.) • Air consumption: approx. 250 NL/min • Extraction connection: diameter 125 mm • Required extraction performance: speed approx. 30 m/s; volume approx. 1,300 m³/h • Noise level (idling): ≤ 85 dBA

Year of construction: 1998, condition: ready for operation (used), spindle motor power: 11,000 W, spindle speed (max.): 6,000 rpm, This Weinig Unicontrol 10-5 was manufactured in 1998. A robust used window manufacturing machine, it features a working width of 40-220 mm and motor powers up to 15 kW for various machining units. It includes advanced features like a synchronization device, electronic height adjustment, and an automatic turning system for efficient one-man operation. If you are looking to get high-quality milling capabilities, consider the Weinig Unicontrol 10-5 machine we have for sale. Contact us for more information. • Capacities • Working width: 40–220 mm • Working height (longitudinal machining): 40–100 mm • Working height (cross machining): 40–100 mm (counter wood height 80 mm) • Workpiece length (longitudinal): min. 220 mm + 2 x tenon length • Workpiece length (cross): min. 275 mm + 1 x tenon length with 320 mm tool diameter • Feed (cross machining) • Motor power: 0.3 kW • Feed speed: 3–25 m/min • Workpiece clamping: 2 clamping claws • Length stop: with scale and reading magnifier for frame or sash outer dimensions • Counter: pneumatically clocked, 4 positions (not for studio windows), up to wood height max. 80 mm • Double part package: single or double part feeding, with cross separation and retention system • 1st piece (lying on the stop) wood width: 55–90 mm • 2nd piece wood width: 130 mm • Feed (longitudinal machining) • Motor power: 2.2 kW • Feed speed: 4–18 m/min (infinitely variable via frequency converter) • Feed roller spacing: 100/120 mm • Feed roller width: 30/50 mm • Feed roller diameter: 95 mm • Machining units • Crosscut saw • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 2800 rpm • Tool swing: max. 400 mm • Axial adjustment: pneumatic against 4-fold turret • 1st spindle with tenon and slot • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 3250 rpm • Tool swing: max. 320 mm • Tool clamping length: 320 mm • Axial adjustment range: 240 mm Fsdpfx Ahozt A Diskepk • Number of tools: 4 x 80 mm • Axial adjustment: hydraulic • 1st profiling spindle • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 6000 rpm • Tool diameter: max. 232 mm • Tool zero swing circle: 130–140 mm • Tool clamping length: 320 mm • Axial/radial adjustment range: 240/80 mm • Number of tool positions: 4 x 80 mm • Axial adjustment: hydraulic • 2nd profiling spindle • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 6000 rpm • Tool diameter: max. 232 mm • Tool zero circle: 130–140 mm • Tool clamping length: 320 mm • Axial/radial adjustment range: 240/80 mm • Number of tool positions: 4 x 80 mm • Axial adjustment: hydraulic • Mechanical spindle brakes • For profiling spindle(s) • For crosscut saw and profiling/sawing units • Profile milling unit (horizontal, top; in front of last profiling spindle) • Radially indexed: 2 positions • Axially indexed: 2 positions • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 5850 rpm • Tool swing: 130 mm • Tool clamping length: 40 mm • Axial adjustment range: 52 mm • Radial adjustment range: 125 mm • Profile milling unit (vertical, right; at end of machine) • Radially indexed: 2 positions • Axially indexed: 2 positions • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 5850 rpm • Tool swing: 210 mm • Tool clamping length: 160 mm • Axial adjustment range: 90 mm • Radial adjustment range: 100 mm • Length tenoning and slotting spindle (640 mm tool clamping length, instead of 320 mm spindle) • Motor power: 15 kW • Spindle speed: 2925 rpm • Number of tool positions: 8 x 80 mm

Condition: used, functionality: fully functional, Raimann KR 320 multi-blade saw Track width: 340 mm Cutting width: 310 mm Fjdpfxoztztpj Ahkepk Cutting height: 110 mm Spindle diameter: 65 mm Bushing diameter: 80 mm Blade size: 250-360 mm Feed rate: 4-48 m/min Main motor power: 37 kW Material receiver with side discharge Material return to the operator

Condition: excellent (used), CATALOG NUMBER: 6575 TECHNICAL DATA - max. width of workpiece: 230mm - max. height of workpiece: 170mm - 7 spindles: 1) horizontal, lower, 230mm, 11kW 2) vertical, right, 170mm 3) vertical, left, 170mm (2 and 3 spindles), 11kW 4) horizontal, right, 170mm, 5.5kW Fjdpeztzflefx Ahkjpk 5) horizontal, upper, 230mm, 11kW 6) horizontal, lower, 230mm, 7.5kW 7) universal, 230mm, adjustable at 360°, 7.5kW - all spindles adjustable up/down, left/right - spindles 3 and 5 are electrically adjustable - ATS (Automatic Thickness Setting) - spindle diameter: 40mm - electric brakes - 4 top infeed rollers, toothed, including 1 double roller - top infeed roller, rubber, double - top outfeed roller, rubber, double - 2 bottom metal rollers, smooth - bottom infeed roller, rubber, double - feed on Cardan shafts - rollers pneumatically pressed - stepless feed speed adjustment: 6-24m/min - feed motor: 5.5kW - electric adjustment of cutting depth - body lifting motor: 0.55kW - central lubrication of the table - diameter of dust extraction nozzles: 7x140mm - dimensions (L/W/H): 5800x2050x1850mm - weight approx. 4500kg ADVANTAGES – German production, WEINIG brand – with 7 heads – universal spindle – with ATS - for wet and dry wood – used planer, very good condition Net price: 126900 PLN Net price: 30200 EUR Net price calculated based on an exchange rate of 4.2 PLN/EUR (price may change in case of larger exchange rate fluctuations)

Condition: used, Weinig UNISTACK 811 stacking machine Fpodpfx Ajztzffjhkjk Package length: 500 mm to 3100 mm Package height: 1200 mm Package width: 1200 mm

Condition: used, For profiling and routing windows doors individual components and similar items with all-round profiles, including mechanisms for single-person operation Units: Fodpfx Aheztv Eaekepk Technical data: - 1. Profiling spindle, motor: 11 kW, spindle diameter: 50 mm, clamping length: 320 mm, stroke: 4×80, hydraulic, synchronisation device - 2. Profiling spindle, motor: 11 kW, spindle diameter: 50 mm, clamping length: 320 mm, stroke: 4×80, hydraulic,

Condition: used, A range of second-hand spare parts or complete units, control systems and switchboards for Weinig Univar (and others) are always in stock. Fjdpfeztv D Nox Ahkopk Please contact us. Sample images. 1/2 Marek repair panel [AO2R1] New distribution: Univar NWP incl. order: €6,000 Technical data: - Mechanisation NWP including ordering: €10,000 - [AO6R4]NWP 05/03/24: 17,900 - [AO12R10]NWP 05/03/24: €70,500
