Complete sawmill (stationary)

LINCK

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, Log handling line, LINCK sawmill line, lumber sorting line with stacking system Log handling line: - Infeed - Cut-to-length - Turner - Emergency outfeed channel, possibility of log discharge - Root flare reducer (butt reducer) - Valon Kone debarker - Metal detector - Hellak DLV 720 - Log sorting line - 32 boxes LINCK sawmill line: LINCK Canter V40, year 1997 • Max. roundwood diameter: 650 mm • Min. roundwood diameter: 100 mm • Max. log length: 6 m • Min. log length: 3 m • Feed speed (30-80Hz): 25-70 m/min • Cutter head drive power: 90/132 kW • Number of knives: 3 • Cutting depth: 160/200 mm LINCK Multi-rip saw CSMK 375-A3/B3, year 1997 • Min. timber length: 3.00 m • Min. cutting thickness: 50 mm • Max. cutting thickness: 375 mm • Feed speed (frequency controlled): 25-70 m/min • Saw diameter: 648 mm • 648x5.7/3.5/6.8x160 Left • 648x5.7/3.5/6.8x160 Right • 648x5.7/3.5/x165 Plate • Shaft speed: 2500 rpm • Drive power per saw shaft: 110 kW • Weight (with motors): 18800 kg LINCK Turner DV 55, year 1996 • Feed speed: 36.2 m/min • Max. log diameter: 550 mm LINCK Canter V30, year 1996 • Max. roundwood diameter: 500 mm • Min. roundwood diameter: 100 mm • Max. log length: 6 m • Min. log length: 3 m • Feed speed (30-80Hz): 25-70 m/min • Cutter head drive power: 90/132 kW • Number of knives: 2 • Cutting depth: 160 mm LINCK Milling unit VP34 • Min. timber length: 3 m • Max. timber length: 4900 mm • Max. milling depth: 50 mm • Max. cutting height: 120 mm • Min. board width: 60 mm • Feed speed (50Hz): 41.7 m/min LINCK Saws S2 VS 66 S • Min. timber length: 3 m • Cutting height with inner saw: 280 mm • Cutting height with outer saw: 280 mm • Feed speed: 36 m/min • Saw diameter: • 505x5.2/3.6/6.8x120 mm Left • 505x5.2/3.6/6.8x120 mm Right LINCK Multi-rip saw S3 VSV 80-A, year 1988 • Min. timber length: 2.50 m • Cutting height: 280 mm Bjdpjyyd Tnofx Abwjda • Feed speed: 40 m/min • Saw diameter: • 510x5.2/3.6/6.8x120 mm Right • 510x5.2/3.6/x120 Plates LINCK Horizontal saw KH1, year 1985 • Min. timber length: 3 m • Min. cutting height: 60 mm • Max. cutting height: 140 mm • Max. cutting depth, right saw: 140 mm • Max. cutting depth, left saw: 140 mm • Min. cutting depth: 130 mm • Feed speed: 40 m/min • Saw diameter: 520x5.8/4.0x150 mm Lumber sorting: Lumber sorting by length, width and thickness 32 boxes for lumber Stacking and bundling system for lumber packs The offered line has a real capacity of approximately 70,000 m3 per year in one-shift operation. Huge spare parts inventory. Sharpening room. We offer complete service from sale to installation and commissioning in the new location. For an additional fee, professional dismantling, loading and commissioning in the new location are possible.

Condition: new, New manufactured sawline with chipper canters and circular saws. Suitable for producing for example sawn wood for pallet production. Bdedewzklajpfx Abwea Capacity per one shift approx 70 to 90 m3 ready sawn wood. Min log diameters 12 cm Max log diameters 38 cm Log length from 2 to 4 meters

Year of construction: 1999, condition: excellent (used), 1. Linck FWK Quick Clamp Carriage Gauge: 900 mm Travel speed forward/reverse: 80/180 m/min Clamp opening: 750 mm Log length: 2.5–13.5 m Log diameter: 150–700 mm 2. Linck CV1/SE 600 Full Frame Saw with Variable Width Adjustment Passage width: 760 mm Passage height: 710 mm Saw stroke: 600 mm 3. Removal Device Bm 1/Mbh 4. Side Material Cross-Cut Saw Linck KA 1/ACF Year of manufacture: 1998. Commissioned: 2000 Various tools Bdjdpfoxtwv Tjx Abwja Sale by customer order.

Year of construction: 2018, condition: ready for operation (used), This LINCK VZM & CSMA was manufactured in 2018. It includes a CSMA pull-out device and a VZM centering device, both designed for high-performance in automated production lines. The CSMA offers flexible material guidance with a feed speed of 85 m/min, while the VZM provides precise centering at 84 m/min. Both units feature robust designs for demanding conditions and minimal use, ensuring excellent condition. Contact us for more information about this machine. Machine Benefits Technical Machine Benefits • The csma pull-out device offers powerful and flexible material guidance in automated production lines, designed for variable workpiece sizes and ensures continuous material transport. • The vzm centering device is designed for precise centering tasks at high feed speeds, with a robust design suitable for demanding industrial conditions. • Drive power of csma pull-out device: 4 x 4 kw Bsdpfx Aoyabdpjbwsda • Drive power of vzm centering device: 2 x 7. 5 kw • Csma pull-out device feed speed: 85 m/min • Vzm centering device feed speed: 84 m/min Extra Information The machines were used exclusively for testing. Due to their minimal operating time, the machines are in mint condition and function perfectly.

Condition: new, table length 2200 mm Bsdpfx Ajupxwkobwoda table width 1500 mm stroke height 1850 mm weight max. in kg 2000 kg 260 mm total power requirement 1,5 kW stroke speed - idle stroke upwards 40 sek. stroke speed - idle stroke downwards 30 sek. connected load frequency 400 V weight of the machine ca. 0,45 t dimensions of the machine ca. 2,2 x 1,5 x 0,26 m The hydraulic lifting tables are electrically driven and operated. Have a contact strip for safe lowering operation. Wide applicability for workshops, assembly departments, loading pits, etc.

Year of construction: 1999, condition: excellent (used), 1. Block conveyor 2. Transverse conveyor 3. Linck FWK quick-release carriage Track gauge: 900 mm Travel speed (forward/reverse): 80/180 m/min Clamp opening: 750 mm Log length: 2.5–13.5 m 4. Sawing unit Linck KCSU-6 Round timber diameter: 120–650 mm Drive per side: 160 kW Max. cutting height (triple): 405 mm Residual: 370 mm Log length: 2.5–13.5 m Max. feed-through width: 750 mm Cutting width min/max: 18–720 mm Split wedge opening: 560 mm Saw blade diameter: 620 mm Bdodpfxsxtwwko Abwea Edger distance: 370 mm Net weight approx.: 15,000 kg Stepless feed rate adjustment: 10–35 m/min 3. Timber removal device BM 1/MBH 4. Edger cross-cut saw Linck KA 1/ACF 5. Complete hydraulic system 6. Complete electrical/control system 7. Complete circulating conveyor technology 8. Discharge mechanisation 9. Waste removal underneath KCSU Year of manufacture: 1998. Commissioned in 2000 Various tools Sale according to customer order.

Condition: excellent (used), functionality: fully functional, Linck High-Performance Frame Saw Type DS 71 Frame opening 710 x 710 mm. Stroke 500 mm. Speed 320 rpm. Hydraulic roller lift with adjustable roller pressure. Hydraulic feed continuously adjustable from 0 to 13 m/min. Automatic overhang adjustment of the saw frame. Electromagnetic remote control. Bodpfxouqmu Ho Abwsda Jansen hydraulic saw blade tensioner with blade mount. 55 kW motor with gearbox. Hydraulic clamping carriage with hydraulic auxiliary carriage. Electrical switch cabinet with control and operator's panel. Dismantled and loaded free on truck. A video showing the saw in operation can be provided on request.

Condition: ready for operation (used), Logintake with butt end reducer and debarker. Below parts included: - Log deck with log unscrambler and log singulator - Butt-end reducer type Bruks RR1000 - Debarker type cambio 70-66 - Out-feed log conveyor with logkicker Bodpfx Abotrd Hfoweda

Condition: refurbished (used), 2 pieces 125 mm Ø x 170 mm Ø x 173 mm long 1 piece 140 mm Ø x 190 mm Ø x 173 mm long Bdjdpfx Abongz N Iowsa

Condition: ready for operation (used), Year of construction: 1990, functionality: unexamined, Log turning device Linck DV 35, not height-adjustable. Feed rollers are electrically driven. Price is as stated; a general overhaul can be offered on request. Bedpsymlm Iefx Abwjda

Condition: good (used), Year of construction: 2000, functionality: fully functional, Holtec Bruks long log intake system with root reducer, consisting of: Cross infeed conveyor with 6 chain strands, split drive. Holtec hydraulic step feeder with split drive. Bdsdpfx Ajwxck Asbwoa Bruks root reducer type RR 1200 for long logs – milling length 1200 mm. Holtec heavy-duty conveyor belt for round timber. Scraper conveyor for waste removal and distributor auger.

Condition: refurbished (used), Year of construction: 1990, functionality: unexamined, Pattern turning device with height adjustment and electric feed motors. Height adjustment is electric. The price is for the machine as is. Optionally, we can also offer a complete overhaul. Bsdpfx Ajx E Dbcobwjda

Condition: refurbished (used), Complete Cutting Machine Group from LINCK: 1.Pre-cut feed table Linck EV20 (condition:good) 2.Chipper canter LinckV18 (condition: good) Bedpervh Tmsfx Abwoda 5.Boad separator unit Linck SE (condition: refurbished) 1. EV20- Pre-cut feed table Linck EV20 for smaller logs. Hydraulic unit is included. 2. Chipper canter LinckV18. 2x85 KW motor with direct drive. Completely refurbished set. We can also offer full electrical installation and assembly of line on site.

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, Log feeder, chain log infeed, and chain log conveyor – 20 m Minimum log length: 5 m Bdedpfx Aswlaxkobwsa Maximum log length: 14 m Holtec ES 120 – Cross-cut saw (Year of manufacture: 1995) For cutting and trimming wood in industrial applications Chain log conveyor – 4 m Cassel Metal Shark® Octa – Metal detector Outfeed roller conveyor + transfer table – 7 m Control cabin Hydraulic operation Condition: perfect Manufacturer: Holtec Type: ES120 Year of manufacture: 1995

Condition: excellent (used), Pneumatic holding and clamping device from Linck. Bsdpsrdvggsfx Abwjda
