Complete sawmill (stationary)

HewSaw R115

Condition: reconditioned (used), functionality: fully functional, empty load weight: 2,400 kg, Compact sawing machine with mechanical centering infeed, el.motors 2x75 kW and 2x90 kW, machine can be equipped with edging block and electric-operating cabinet with frequency converters TECHNICAL DETAILS Top diameter: 80-230 mm Maximum log diameter: 350 mm Minimum log length: 2.4 m Cant height in Chipper Canter: 60-232 mm Cant width in Chipper Canter: 70-210 mm Line speed: 70-150 m/min Ljdpfx Adexfrmwj Njag Chip length: 20-30 mm

Condition: new, Year of construction: 2024, Padeves trepe. Stepfeeder. For log feeding and separation Height from 1.0 m. Width from 1.8 - 6 m For material diameters from 5 - 20 cm Speed up to 20 pieces/minute Hydraulic Automatic feed Ljdpfoudzycjx Ad Noag

Year of construction: 2004, condition: good (used), Build in 2004 - Type of strapping: single & double - max speed for single strap: 36 bundles/min - max speed for parallel (double) strap: 19 bundles/min - min bundle dimensions (w x l): ~200 x 170 mm - max bundle dimensions (w x l): ~560 x 560 mm - min bundle (package) height: ~10 mm - max bundle (package) height: ~440 mm - max weight bundle/package: 25 kg - Infeed / outfeed (conveying) height: ~800-930 mm - Continuously adjustable conveyor speed - Metric input of strapping position - Type of sealing: heat-weld sealing - Strapping material: Polypropylen (PP) - No of strap coil dispenser: single - Strap coil dispenser - core diameter: 200 mm - Strap coil dispenser - core width: 190 mm - Equipped with back stop (package stop) - Equipped with hold-down device - Equipped with interface to up-/downstream equipment - Over all length equipment: ~736 mm - Over all width equipment: ~1360 mm - Over all height equipment: ~1915 mm - Input Power: 1,5 kVA - Voltage: 400V, 50/60 Hz, 3Ph, N Ljdpfjh Iy Skox Ad Noag - Air requirement: 330l/min freie Luft 6 bar - Weight: ~550 kg - Equipment at Helmstedt, airports: Hannover (~1 hr), Berlin (~2 hrs) - Condition: cleaned & in working conditions - Machine available: upon request Description: Automatic single, double or multiple strapping of e.g. bundles behind a press stacker or a bindery stacker. Normally integrated into a complete packaging line for bundles/packages.

Condition: used, A Linck chipper canter line for continuous chipping, turning, profiling and sawing of round timber as well as for the production of main products and side boards is offered. 1) LINCK V30 chipper canter, feed speed: 50m/min/70m/min, drive power: 2 × 132kW, min. log diameter: 80mm, max. log diameter: 360mm, cutter heads: 18 chipping knives and 18 finishing knives, max. output: 1000fm/24h, 2) Linck DVN 55 turning device, function: turning and positioning of the preprocessed round timber between the chipper canter stages, 3) Linck V25 chipper canter, max. feed speed: 70m/min, drive power: 2 × 132kW, cutter heads: 18 chipping knives and 18 finishing knives, 4) Linck VPP 34 profiling unit, three-phase motors: 4, power: 32kW/50kW, speed: 1000rpm/1500rpm, feed: 4 geared motors, feed motor power: 1.3kW/2kW, max. feed motor speed: 66rpm, function: profiling of the side boards before the sawing process, 5) Linck VS 66 saw unit, three-phase motors: 4, power: 66kW/motor, speed: 3000rpm, fixed saw spacing: 24mm for 4 side boards. The chipper canter line will be available from January 2027. An on-site inspection is possible. Ljdpfozvy Eiex Ad Njag

Condition: excellent (used), max diameter of machined parts: 140 mm min diameter of machined parts: 40 mm 2-knife cutterhead any length of machined parts motor: 2.2 kW Lsdpfew Twkrex Ad Neag extraction port diameter: 120 mm dimensions (L/W/H): 950x520x1100 mm weight: 95 kg

Condition: used, Year of construction: 2003, operating hours: 39,500 h, functionality: fully functional, machine/vehicle number: 1663, arm reach: 15,300 mm, load capacity: 2,000 kg, track width: 10,000 mm, Used gantry crane 10 meter track gauge Crane type: OBX IV 15.3 meters Lifting capacity: 2,000 kg at 15 meters without grab Grab: included Crane arrangement: central Cab side: left Power supply: conductor rail Power: 45 kW !! Sale on behalf of customer !! Ledsyyldzjpfx Ad Noag Available from summer 2026

Condition: good (used), Wood router bit, router head, router tool, wood router bit, profile router bit -Outer diameter: 200 mm -Number: 5 milling cutters -2x: left -3x: right Price: complete Ljdpfob A Sqdex Ad Nsag -Weight: 6 kg/piece

Year of construction: 2013, condition: excellent (used), HewSaw SRC200/250 Lsdpfx Adozwnbho Neag
