Multi Rip Saw

ARI DS-72+1

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 663015, Walter Helitronic Mini Power Production 5 Axis CNC Tool & Cutter Grinder Universal tool and cutter grinder (CNC controlled) Made by Walter, model Helitronic Mini Power Production, s/n663015, year 2000 Description: Suitable to manufacture and regrind metal and woodworking tools of all kinds. Run with 1 micron filtration system, so the machine is very clean. Specifications: • Longitudinal traverse (X-axis) 350 mm, • Vertical traverse (Y-axis) 200 mm, • Cross traverse (Z-axis) 470 mm, • Rotary table swiveling range (C-axis) +/- 200°, • Work head ISO 50, center height (with / without worktable) 145 / 190 mm, • Max. diameter of workpiece 100 mm • Max. length of workpiece 270 mm • Max. dia. of grinding wheel 150 mm • Peak performance 11,5 kW, grinding spindle motor 9kW,speed 0 - 9500 rpm, • Connected load approx. 25 kW (460 volts 3ph / 60 Hz), • Dimensions w x d x h = 2600 x 2550 x 1970 mm, weight approx. 3950 kg, color grey RAL 7035 / grey RAL 7043. Accessories: • Control HMC 500 Windows XP Upgrade • Includes: 2021 Ebbco Filtration & Chiller unit Model PMF-MWF5-623-P-40K capable of filtering & chilling up to 2 grinders. 40,000 BTU Chiller & filtration up to 1 Micron. • Booster Box Upgrade option along with a spare Booster Box as well that could be used as a backup or for up to 3 other Walter machines. Value of each booster box is $10,000 a piece. • Stepless speed control, probe, pneumatic workpiece clamping • Fire extinguishing system • Mist Extractor Bcodou Ez Huepfx Ac Neu • Oil collecting pan, 2 grinding wheel flanges • Complete set of Manuals Software: • Tool Studio Version 2.1 Standard & Steptools • WWM Software Condition: • New Y axis Motor & Ball screw Installed 2021 • New Spindle Installed 2021 • New Electrical cabinet air conditioner Installed 2021 • All new encoder & motor cables for A, C, X, Y & Z axis Installed 2021 • Currently in production producing very accurate & consistent tools. Can be viewed under power • We have all of the shipping bracket, so the machine will be safely secured for shipping. • We can load onto a flatdeck for shipping for $900. We can also provide shipping & crating quotes if you would like.

Year of construction: 1982, condition: used, In Good Condition Bcodpfxedq Ug Io Ac Nsu

Year of construction: 2003, condition: refurbished (used), machine/vehicle number: 50/140/03, GENERAL CHARACTERISTICS Ø Grinding Wheel Dimensions (OD x ID x width) 508 mm Regulating wheel width 254 mm Diamond dressing speed Ø508 x 254 mm Lubrication (Auto/Manual) centralizado automático / automatic lubrication Bodpfod Nw T Isx Ac Njcu CNC Brand FANUC CNC Model Series 18i - T CNC Axes Nº 8 Grinding wheel width 254 mm ELECTRICAL CHARACTERISTICS Total Power 25 kW Voltage 220/380 v DIMENSIONS AND WEIGHTS Long 2150 mm Width 2200 mm High 3400 mm Weight 8000 kg

Year of construction: 2005, condition: excellent (used), I sell the thin cutting mini frame saw gatter NEVA TR88 Orbit plus, year 2005. Configuration with top + bottom moulding heads 1,5 + 1,5 KW suitable for later lamellas gluing Main motor 15 KW Bcsdpfoiuc Scox Ac Nsu Working height 270mm Digital working height adjustment w. ELGO Electric Positioner Digital feedign speed adjustment w.MKS Total weight 2800kg. Lot extras, saw leafs, adjustment elements and frame adjustment device indluded. Very good condition. Fully working. Made in Czech republic.

Condition: good (used), Year of construction: 1982, functionality: fully functional, machine/vehicle number: 55453, ACIERA 23 CNC DRILLING MACHINE With Aciera ISO30 quick-change system Machine tested and 100% functional Excellent price-performance ratio WITH CNC HEIDENHAIN TNC 125 Technical data Drilling capacity in steel 23 mm Thread cutting in steel M18 Spindle speeds: infinitely variable from 45 rpm to 4000 rpm Spindle stroke 120 mm Table length 590 mm Table width 320 mm Distance between table and spindle min. 110 mm Distance between table and spindle max. 570 mm Working path lengthwise 500 mm Transverse travel 300 mm Feed rates 0.02-0.6 mm/min Connection 50 Hz 3x 380 Volt Power 4.0 kWA Machine weight approx. 2110 kg Machine dimensions: length 1700 mm, width 1400 mm, height 2100 mm Technical data not binding. ACIERA 23 CNC DRILLING MACHINE With Aciera ISO30 quick change system Machine tested and 100% functional Excellent price-performance ratio WITH CNC HEIDENHAIN TNC 125 Technical data Drilling capacity in steel 23 mm Bcsdsu Tn Raepfx Ac Nou Thread cutting in steel M18 Spindle speeds: continuously variable from 45 rpm to 4000 rpm Spindle stroke 120 mm Table length 590 mm Table width 320 mm Distance between table and spindle min. 110 mm Distance between table and spindle max. 570 mm Longitudinal travel 500 mm Working distance across 300 mm Feeds 0.02-0.6 mm/min Connection 50 Hz 3x 380 volts Power 4.0 kWA Machine weight approx. 2110 kg Dimensions machine: length 1700 mm, width 1400 mm, height 2100 mm Technical data non-binding.

Year of construction: 2019, condition: like new (used), Laser Welding Robotic system for welding steel, stainless steel. Scope of supply: 1 x YASKAWA 6-axis robot YASKAWA HP20D.(Payload: 20kg, H-Reach: 1717mm, Robot Mass: 280kg, 2009.01) Bcsdpfoh Aiy Sjx Ac Neu 1 x YASKAWA DX100 controller.( 2009.02 ) 1 x LASERLINE LDM 1200-60 Diode 1320W Laser.(2015.10) 1 x LASERLINE laser welding head OTS-5 with Crossjet and cam.(2017.12) 1 x Cooling water circulation 2 way system HYFRA Sigma7 for laser and optics.(2018) 1 x siegmund table 1200x800.(2019) Machine can be inspected. Very good condition. Connected, can be tested. Shipping to EU countries is our responsibility and the shipping cost is free.

Condition: new, Year of construction: 2025, operating hours: 1 h, functionality: fully functional, laser type: fiber laser, Model 2022 for Industry 4.0! Laser marking machine for: = ᐳ Mark = ᐳ tempering of metals = ᐳ labeling of many materials = ᐳ deep engraving Extremely detailed and high-contrast engravings thanks to the JPT-MOPA system fiber laser source (var.pulse width on request) Simple operation and handling! Iayabahok Our Exclusive XL laser marking system is characterized by: • Professional fiber laser source JPT MOPAfix 20 or 30W power • 1064nm, 20-400 kHz (for perfect starting engravings) • "New Generation ECO" scanner unit • 19 "PC control, no external card! • very large viewing window with certified laser safety glass • Scan area approx. 150 x 150 mm • electrical height adjustment • Full housing with 4 roles • Mark "weightless" lift gate for safe. EZCAD III software: • Barcode and QR code support • Serial number function • Batch scanning from an Excel file • Laser parameter finder per matrix over 2 parameters • TCP IP connectivity for external components • Industry 4.0 can be processed at any time using the TCP / IP protocol. • Inputs and outputs for direct communication • New look and feel and fresh design • Even clearer and more intuitive operation • 3D preview for rotary axis machining • Performance increase of up to 50% through 64bit • Improved stability through integrated control card • Optional up to 4 axis controls (integrated) • Optional DEEP engraving with Z axis • More powerful algorithms for fast hatching. • Completely redesigned galvo generation • 2-fold laser pointer for checking the focus position. • LED lighting of the marking area • Connection possibility for external suction • Start button and EMERGENCY STOP on the housing • USB and network connection for data access • Operating instructions and operating software in German • protective housing acc. Laser class 1 • incl. 4 hours of training in our training center (max. 2 people) Do you need individuality? With pleasure. Choose from our numerous accessories: = ᐳ Camera systems for object detection = ᐳ Fiber laser source in almost all variations = ᐳ motorized and automatic height adjustment Bcedpfx Acsd S I Smo Nsu = ᐳ Scanlab equipment = ᐳ Automation for assembly = ᐳ conveyor belts for inlet and outlet = ᐳ 3D marking and GRAVIER function. = ᐳ automatic focus adjustment = ᐳ turntable = ᐳ motorized sledge = ᐳ Interlock system for labeling WITHOUT protective housing, but only with PPE (personal protective equipment) for bulky parts Our engraving lasers of course allow individual wishes in terms of design and size! = ᐳ Made in Schweinfurt! Images can contain options! Laser engraving machine, laser marker, laser marking, laser marking, laser engraving, laser engraver, laser marking, laser marking, laser engraving, laser engraving machine, laser engraving machine, laser marking machine, laser marking system, laser marking system, laser marking system, laser marking system, marking laser, marking laser Laser engraving machine, laser marker, laser marking, laser marking, laser engraving, laser engraver, laser marking, laser marking, laser engraving, laser engraving machine, laser engraving machine, laser marking machine, laser marking system, laser marking system, laser marking system, laser marking system, marking laser, marking laser, marking laser, marking laser

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, A Weeke Vantage 200/510 including extraction, vacuum pumps and tools is for sale. The machine currently has 120 working hours and is in very good condition. Technical data: Travel path X axis: 4160 mm Y axis: 2440 mm Z axis: 325/ 185 mm Support table Length: 3130 mm Width: 1550 mm Workpiece thickness: 100 mm Total electrical connection value: 26.5 KW Weight: approx. 5100 KG Bcedpfjv Hd A Dex Ac Neu

Condition: ready for operation (used), Year of construction: 2007, Brand: Holz Her Model: PRO-MASTER 7123K Serial no: 527/0-705 5010147 Year of manufacture: 2007 - 2 HSK cones included + various drills for drill box - Comes with a number of suction cups and some spare parts Tech. info: 4-axis (c-axis) 6 beams Motor-controlled adjustment of beams Number of vertical boring bits: 24 Number of vertical boring bits in X axis: 10 Number of vertical boring bits in Y axis: 8 Centres distance: 32 mm Horizontal double spindle in X axis: 2 Horizontal double spindle in Y axis: 1 Centres distance: 64 mm Working area: 3200x1260 mm Maximum travel path: X= 3866 mm Y= 1650 mm Z= 325 mm Workpeice pass height for tool change spindle with HSK 63F tool connection: 345 mm Bedpfxjrz Irrj Ac Njcu Max. machining thickness/ feed-in height (rear stop): 175 mm Max. workpiece size for vertical bores: X=3730R/ 3460L mm Y=1570 mm Max. workpiece size for horizontal bores X: X=3450R/ 3370L mm Y= 1315 mm Max. workpiece size for horizontal bores Y: X=4760R/ 3300L mm Y= 1385 mm Max. workpiece size for edge milling, less cutter radius (tool 25 mmdiameter x 125 mm, HSK): X=3510R/ 3525L mm Y=1445 mm Z=280 mm Max. workpiece size for grooving in X (dim. centre grooving tool approx. 120 mm): X=3300R/ 3760L mm Y=1585 mm Max. workpiece size for grooving in Y (dim. centre grooving tool approx. 120 mm): X=3200R/3860L mm Y=1485 mm Max. travel speed X axis: 100 m/min Max. travel speed Y axis: 100 m/min Max. travel speed Z axis: 25 m/min Max. travel speed C axis: 60 m/min Motor power of boring unit: 3 kW Motor power of saw: 1,5 kW Motor power of electro spindle unit with clamping system: 6 kW Speed electro spindle 1000-18000rpm Power: 22 kW, 50 Hz, 400 V, 3-phase Compressed air: operating pressure 6,0 bar permissible limit pressure 8,0 bar Air requirement: 300 l/min Extraction capacity: approx. 5300 m3/h Dust nozzle diameter: 250 mm Size: Length with control cabinet: 6420 mm Overall width: 3760 mm Height with extractor hood: 2475 mm Weight: 4200 kg Program Campus NC-HOPS Operating system Microsoft Windows Graphic variants system with HOP and CAD/CAM properties For the creation of parts variants with macro technology Program operation Windows-conform surface configuration and operator guidance Macro / variant programming Indication and simulation modes Export and import facility to the various branch programs Interaction possibilities with a variety of branch programs Stock no: 2002061BXA with reservation for incorrectly presented technical data

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 18355, Area: Measuring plate:7,38m (L) x 3,06m (B) x 0,63m (H) Required area (room):7,80m (L) x 8,15m (B) x 3,70m (H) maschine data PRO T 1: -Zeiss Pro-T-Select Serial number: 181355 -Range: X7000, Y1600, Z2100 -System: Zeiss CSC with probe or optional Eagle Eye Navigator -Max. speed: axial < 150mm/s, 3D < 260mm/s tactile mode Software: Holos / Caligo (version 3.2.4 - 64Bit) maschine data PRO T 2: -Zeiss Pro-T-compact Bjdpfx Aceuiyl Uj Njcu Serial number: 181354 -Range: X7000, Y1600, Z2100 -Sensor: Zeiss RDS-CAA without Eagle Eye option -Max. speed: axial < 150mm/s, 3D < 260mm/s tactile mode Software: Holos / Caligo (version 3.2.4 - 64Bit)
