Used stitching machines for sale (45)

Condition: excellent (used), Format: to SRA Iajdsy R U H Tspfx Af Uot

Condition: ready for operation (used), Nagel Foldnak 8 with 2 stitching heads Nagel SP Plus Square Press Nagel Trimmer with belt delivery Iajdpfxsy Rr Eas Af Uet

Condition: used, Year of construction: 2002, Stitching unit Heidelberg HM 400 Iaedpsy I Rn Ujfx Af Ujt Year: 2002 - Stitching heads: Excluded

Condition: excellent (used), Year of construction: 1968, Hohner Favorit stapling machine, year of manufacture 1968 Runs quietly and operates flawlessly Power connection: 380 V Iedpeuiznqofx Af Ujat Dimensions: W 70 cm x D 74 cm x H 146.5 cm, weight 280 kg

Condition: used, Year of construction: 2002, Single-head wire-stapling machine (“Klopfer”) for block, booklet and optional ring-eyelet stapling Quick changeover between block and saddle-stitch stapling Hohner’s signature wedge cut for optimal wire alignment. Technical specifications • Stapling capacity: up to 203 staples/minute • Number of stapling heads: 1 • Max. stapling thickness: 25 mm (folded), 40 mm (double-sided) • Ring-eyelet stapling: up to 3 mm (optional) • Round stapling wire: No. 21–30 (0.80–0.35 mm) • Flat staples: 0.70×0.35 to 0.96×0.78 mm • Stapling table size: 700 × 240 mm • Insertion depth: block stapling 95 mm, saddle stapling 290 mm Iajdpfxsyv Eyzo Af Uet • Working height: 880 mm • Motor power: 0.55 kW • Voltage: 230/400 V, 50 Hz • Overall height: 1540 mm • Footprint: 900 × 700 × 1540 mm • Weight: 200 kg (net), 240 kg (gross) • Noise emission: < 82 dB(A) Applications • Brochures • Pads • Calendars • Pads Available at short notice

Condition: used, Multinak S double-head stitching machine with electric drive for stapling brochures and pads up to 27 mm Good condition several stitchers currently in stock available at short notice Iasdpfx Afeygwdrs Uet

Condition: used, Year of construction: 2017, Year: 2017 (November) Condition: perfect Counter condition: only 1.5 M - Inspection possible - Available - immediatley Configuration: - 2 x Tower DSC 10/60 - 1 x stitching and folding unit DBM 600 - 1 x front trimmer DBM 600T - 1 x long delivery - 1 x jogger Technical Specification - Duplo DSC 10/60 (gathering towers) - Paper Size and Media - Minimum size: approx. 120 × 148 mm - Maximum size: approx. 350 × 500 mm - (up to 350 × 610 mm for some versions) - Paper weight: - standard: approx. 52–300 g/m² - coated paper: approx. 79–300 g/m² - Media types: loose sheets, folded sheets, cross-folded sheets Capacity and Performance - Bin capacity: approx. 60–65 mm per station - Collating speed: up to 9,000–10,000 sets/hour (depending on configuration) - Inline production speed: approx. 4,000–5,000 booklets/hour Feeding and Transport System - vacuum belt feeding with air separation (Air Management System) - Error detection: double sheet detection, missing sheet detection, paper jam detection Iodpfx Asyxf Nuef Ueat - Additional features: automatic calibration for different paper types Technical Specification - Duplo DBM-600 / DBM-600T (Stitching & Folding Unit – 600i Booklet System) - Paper Size and Media - Sheet size (min.): approx. 105 × 170 mm - Sheet size (max.): approx. 356 × 508 mm - (up to 230 × 610 mm for long sheets) - Supported formats: - A4, A3, B4, B5, Letter, Legal (various orientations) Capacity and Performance - Production speed: up to 5,200 booklets/hour - 2-up production speed: up to 9,000 booklets/hour (with trimmer) - Folding capacity: up to 30 sheets (80 gsm) - Stitching capacity: up to 50 sheets (80 gsm) - (approx. 5 mm thickness, depending on paper) - Maximum booklet thickness: approx. 6 mm (≈120 pages) Stitching System - Number of heads: 2 standard (optional 4 stitching heads – not included) - Stitch types: saddle stitching, side stitching, corner stitching - stitch & fold / fold only - Stitch head type: Hohner 43/6S - Stitch distance (1-up): approx. 60–320 mm Booklet Formats - Finished booklet size (1-up): - max: approx. 350 × 254 mm - min: approx. 120 × 75 mm - Untrimmed booklet size: - max: approx. 356 × 254 mm Trimming Unit - Duplo DBM-600T - Face trimming (standard): - adjustable trim range - head & foot trimming - 2-up processing capability - trim range: approx. 2–60 mm Folding System - Type: automatic roller folding system - Adjustment: fine tuning from approx. 0.1 mm Control and Automation - Control system: PC-controlled interface - graphical user interface (GUI) - Automation features: fully automatic setup, job memory and recall - quick changeover between jobs Electrical and Physical Data - Power supply: 220–240 V, 50/60 Hz - Power consumption: - DBM-600: approx. 465 W - DBM-600T: approx. 645 W - Dimensions (DBM-600): approx. 1848 × 929 × 1227 mm - Weight (DBM-600): approx. 377 kg

Condition: good (used), Hohner Economy 25/40 Wire Stitcher Very good condition. A reliable machine with legendary durability. Technical specifications: Capacity: 206 cycles/min Sewing thickness: 25mm (punching up to 40mm without closing the staple from the bottom) Iaedpfx Afjy Hgi Sj Ust Wire diameter: max. 1mm Power supply: 380V Weight: 240kg The machine has an adjustable table for block and booklet stitching.

Condition: good (used), Introma ZD-2 SR Wire Stitcher The machine is in very good condition and ready to use. This is the current production model. Technical specifications: Capacity: 180/min Sewing thickness: max. 25mm Wire diameter: max. 1mm Iedpjy Hgixefx Af Ueat Power supply: 230V Weight: 230kg The machine has an adjustable table for block and booklet stitching. Side and front margins. Instructions included.

Condition: ready for operation (used), Year of construction: 1971, functionality: fully functional, Application: Cutting and rewinding of films, laminates, paper. Speed: Typically from 300 m/min to 800 m/min. Working width: 10–1000 mm. Iajdpfey N S Tbjx Af Ust

Condition: excellent (used), machine/vehicle number: 1395, Further MACHINERY / SPARE PARTS & MACHINE COMPONENTS of this type are available in our warehouse. ON REQUEST Ijdpfx Afedtccho Ujat

Condition: excellent (used), Year of construction: 2010, machine/vehicle number: 060900759, WITH TRIMMER p/n: 2654000N Format: to SRA Isdsxcaphopfx Af Usat

Condition: excellent (used), machine/vehicle number: 61 988, Further MACHINERY / SPARE PARTS & MACHINE COMPONENTS of this type are available in our warehouse. ON REQUEST Iasdsp H Tkiepfx Af Ust

Condition: excellent (used), Year of construction: 2001, Paper format: min. 10 x 16 cm // max. 35 x 50 cm Brochure format: min. 8 x 5 cm // max. 35 x 25 cm Equipment / Additional information: Page circumference 80 gr./m2 up to 100 pages Work cycles max. 4000 per hour 4xHohner 48/5 stitching heads Easy adjustment option for head stitching Break-in sword fold with adjustable folding rollers Iasdpfx Aor Ti Nbef Ust Front cutting unit via upper and lower knives

Condition: used, Format: 55 x 28 cm (21 x 11 inch) Iaodpjxztxmefx Af Uot Equipment: Good condition without any damage two stitchings heads 52/8 Maximum staple thickness of 8 mm

Condition: used, Year of construction: 2008, Saddle stitcher Heidelberg Stitchmaster ST 450 Year: 2008 Operation / Control - Colour monitor - Semi automatic setting Feeders - Number of chain stations: 8 - Hand feeding station(s) - Horizontal signature feeders: 1 x DHU 450 - Vertical signature feeders: 4 x DVU 450 - Cover feeder: CHU 450 - Pump(s) Stitching unit Heidelberg Stitchmaster ST 450 - Thickness control - Stitching heads: 2 - Delivery to the left Iaodpfjh Ezmiex Af Uot - Reject gate, for incomplete products Trimmer Heidelberg TR 150 - Sets of knives: 2 Delivery Heidelberg CHA - Compensating stacker - Delivery to the left Technical specifications: Max. mechanical speed 14.000 cycles/hour Sizes (uncutted) Max. 320 x 480 mm Min. 85 x 128 mm Sizes (cutted) Max .315 x 475 mm Min. 80 x 120 mm Product thickness: max 12 mm

Condition: used, Wire Stitching Machine Polygraph 703/1T Drahtheftmaschine / Wire Stitching Machine Polygraph 703/1T 1-head wire stitcher for block- and saddle stapling. Year - Serial-No. 21/4 Iaedpfx Afsyywzxs Ujt Online-Video-Inspection by WhatsApp - MS Zoom - Telegram On Stock Emskirchen/Nürnberg - Available Immediately - Can be test

Condition: excellent (used), Overview The Single Head Wire Stitching Machine is a versatile and reliable solution for wire stitching applications, suitable for both pads and brochures. Designed for consistent performance in print finishing environments, it offers the flexibility to handle standard and loop stitching with ease. Built with a robust and durable construction, this machine is well suited to long production runs while maintaining accuracy and stability. The adjustable working table allows quick changeover between saddle stitching for brochures and flat stitching for pads, making it ideal for varied workloads. An advanced wire feed system ensures smooth and precise stitching, even when working with thicker or digitally printed materials, providing consistent results across a wide range of stock types. Optional loop stitching conversion parts are available, allowing the machine to be adapted quickly to suit different production requirements. Key Features Supports both standard and loop stitching for pads and brochures Heavy-duty construction for reliable, long-term operation 25mm stitch and 40mm stab capacities Iodpfxsyyb Rde Af Ujat Adjustable table for saddle or flat stitching configurations Maximum speed of up to 203 staples per minute Table size: 700 × 240 mm Patented wire feed and cutting system for accurate, consistent stitching Suitable for thicker and digitally printed materials Optional loop stitching conversion kit available for added flexibility Why Choose the Hohner Economy 25/40 Ideal for print shops requiring a flexible stitching solution for multiple applications Simple changeover between different stitching styles reduces downtime Capable of handling a wide range of materials, including heavier stocks Reliable and durable design suited to regular production use Cost-effective alternative to larger multi-head stitching systems Optional loop stitching capability adds value and expands service offering Specifications Manufacturer Hohner Model Hohner Economy 25/40 Condition Used Mechanic cycles per minute [staples] 203 Clinched staple 25mm Capacity Stabbed from both sides 40mm Capacity Stitching table size [mm] 700 x 240 Working height [mm] 880 Throat depth from clincher box to machine body [mm] for pad stitching 95 Throat depth from clincher box to machine body [mm] for saddle stitching 290 Maximum number of stitching heads 1 Crown width [mm] 14 Round wire (standard) No. 21 – 30 Flat wire 0,70 x 0,35 mm – 0,90 x 0,78 mm Electric requirement 230/400V Single or 3phase Net weight [kg] 200 Dimensions (L)900mm x (W)700mm x (H)1540mm

Condition: used, Year of construction: 2005, Saddle stitcher Heidelberg Stitchmaster ST 400 Year: 2005 Operation / Control - Colour monitor Feeders - Number of chain stations: 9 - Horizontal signature feeders: 2 x TAL 400 - Vertical signature feeders: 6 x TAS 400 - Cover feeder: UFA 400 - Excluding pump(s) Stitching unit Heidelberg Stitchmaster ST 400 - Thickness control - Stitching heads: 2 Iaodpfx Aeh E Ewdof Ujt - Delivery to the left - Reject gate, for incomplete products Trimmer Heidelberg TR 400 - Sets of knives: 2 Delivery Heidelberg CHA - Compensating stacker - Delivery to the left

Condition: used, Year of construction: 2015, Year: 2015 Condition: excellent Counter status: only – 640,000! - Machine inspection: possible - Availability: immediately Configuration: - 1 × DSF 6000 digital feeder - 1 × DBM 600 stitching and folding unit - 2 × Hohner stitching heads - 1 × DBM 600T face trimmer - 1 × long conveyor (delivery unit) Specifications: Feeder (DSF-6000) - Feeding speed: up to 600 sheets/min - Stack capacity: approx. 610 mm - Paper size: - Min: 120 × 210 mm - Max: 364 × 525 mm - Paper weight: 64 – 300 g/m² - Buffer: approx. 10 sheets - Technology: - Air Management separation system - Anti-static system - Optical + ultrasonic sensors (double feed detection) - Weight: approx. 300 kg Specifications Duplo 600i - Speed: 4,500 – 5,000 booklets/hour - Format: - Min: 120 × 148 mm - Max: 356 × 508 mm Iaodpfx Afjyyby Ee Uot - Paper weight: 52 – 300 g/m²

Condition: good (used), Year of construction: 2007, Format: max 340 x 260 mm; min 90 x 115 mm Format (without overfold): max 340 x 250 mm; min 90 x 115 mm Overfold: max 15 mm Final fold: min 6 mm Pre-fold: min 8 mm Stapling sheet formats: max 340 x 260 mm; min 210 x 155 mm Stitching thickness: max 6 mm Mechanical speed 1:1: max 25,000 t/h Mechanical speed 1:2: max 30,000 t/h Equipment Collecting chain & feeder - 8 stations Collecting chain - 8 Substructure simple - 6 Feeders 416 - Fabric gluer 423 Stapling station - Stitching station 430 - 15" inch chain pitch - Stitching wire unwinding device - Thickness control / Plus-Minus - 4 stitching heads Three-knife trimmer - Three-knife trimmer 426 Knife - 2 knives Delivery - Stacker Robusto Optional accessories: --- not included in the scope of delivery --- - Crane system Iasdpfx Afsqrqxke Uot - Bar feeder - Print roller feeder - Additional stations - card gluer - various transport lines - compensating stacker - automatic tying machines - Wrapping machines - palletizer

Year of construction: 2002, condition: good (used), Built in: 2002 Working hours: 10.688 thsd.h Size: max 365 x 305 mm min 105 x 115 mm Product thickness: max 15 mm min 6 mm Speed: max 9.000 c/h min 2.000 c/h Iajded R Sanopfx Af Uot Equipment: gathering chain & feeder • 10 station gathering track & chain • 10 automatic feeders • 1 cover folder feeder 1528 stitching unit • wire unwind device • stitch control • 2 stitching heads HK 75 three knife trimmer • three knife trimmer 1522 knives • 2 sets of knives

Year of construction: 2003, condition: used, Collector chain & feeder 6 stations 3 substructures double 5 feeder 416 Card gluer Isdpoca Dktsfx Af Ujat Stitching station Stapling station 410 transfer right Stitching wire unwinding device Semko Thickness control / Plus-Minus 3 stitching heads Three-knife trimmer Three-knife trimmer 304 Knives 2 carbide knives MONICS Inserting machine Transfer belt between trimmer and main product feeder Biliner inserting machine Inline main product feeder 6 insert feeder Delivery Rapido compensating stacker

Year of construction: 2004, condition: good (used), Built in: 2004 Rebuilt: 2017 Equipment: stitching unit for Ferag UniDrum Iasdpfxoc U Nf Rj Af Ujt

Year of construction: 1988, condition: used, 480 x 325mm; 14,000c/h; 7 stations 6 feeders 279 Card gluer 1 folder feeder 1529 Stapling station 300 Iaedpfxjbnczbo Af Uet Trimmer
