Technical data paper roll cutting machine. This machine can only be used for small residual rolls up to a maximum diameter of 400 mm in order to automatically unwind these residual rolls and cut the paper into strips so that it can be better pressed into bales.
Year of manufacture unknown
Dimensions feed table for rolls:
Width inside of rolls 2.195 mm
Height inside of castors 465 mm
Transport dimensions Feed table over all:
2,650 x 1,300 x 2,150 mm (W x H ...
KONGSBERG XL 22 PLOTTER CUTTER
Ready for Operational Inspection
Includes FlexiHead RIP Software
Located in italy
66" x 86" Work Area (1680 x 2190)
The table is operational and 100% fully functional.
Precision Blade Tool
Oscillating Blade Tool
Pen Tool, Drag Knife Tool, and Crease Wheel Tool
Also includes FPZ vacuum motor
Power-Head with 3 tools, Motorized Z-axis
MP HF Knife, vibrating knife
RigidKnife, non-oscillating knife with carbon blade
2 knives diamete...
cutting length 780 mm
insertion depth 780 mm
weight of the machine ca. 1300 kg
connection value 400 Volt
- Program control
- air table
- Light barrier
- Back table cover
- Spare knife
- Tools for blade change
- Machine documentation
Available from around the end of July
Specifications: / Type: APC-M61 / Max. paper length: 580 cm / Min. size: 20 mms / Max. size: 61 x 61 cms / Paper pile height: 100 mms / Table height (mm) : 850 / Safeties on the machines: shields, 2 hand operation etc. / Pressure adjustable 5 kN - 17 kN (for firm or weak papers) / Power requirement (KW) : 1,8 / Voltage (V) : 380 / Length x width x height: 1070.0 × 1480.0 × 1270.0 / Weight 630 kg Computer with digital display and controls, including programming of 6 programs with 54 steps, and...
KIMLA BlackBird 1520 CNC plotter with a Becker side-channel fan with a 7KW motor. The machine is manufactured by the well-known Polish company KIMLA from Częstochowa. The high-power Becker fan is used to hold the material under vacuum during cutting. The plotter is equipped with an oscillating knife, however, the design of the machine allows it to be easily equipped with other heads, e.g. a milling one. The work table has been made as a 2-function table: when using an oscillating head, a vacuum ...
Used machine CNC cutter/plotter Cutting area in X and Y: 3,500 x 2,100 mm.
Multifunctional CAM cutting system in CNC knife technology for 2D cutting of leather, fabric, technical textiles, foam and other flat, semi-flexible or rigid, non-metallic materials
Equipment of the used machine
• 1 cutting bridge and 1 multifunctional tool head
The machine is sold with one driven circular knife, electric oscillating knife and one Milling Head + exhaust
• Multifunctional tool head to hold max. 2 intercha...
Hanssen paper slitter with a width of 1700 mm (grammage from 40g to 500g/m²). New electrical cabinet and voltage control.
Maximum unwinding speed of 600 m/min without roller;
Maximum unwinding diameter: 1600 mm
Wichita air brakes
Tension control with strain gauge and diameter reading
Cutting block equipped with 12 pneumatic knives. minimum cut : 60 mm
2 steel banana rollers
Shaftless winding (70, 76, 100, 120 and 150 mm) with extensions
Max. winding diameter: 1350 mm
Spool ejection, l...
GOEBEL SLITTER REWINDER
MAXIMUM WIDTH 105 cm
15 PNEUMATIC KNIVES
MANY COUNTER KNIVES
150mm PNEUMATIC AIR CYLINDERS
NEW ELECTRIC CABINET
22KW WITH NEW INVERTER
SUITABLE FOR FOIL, PAPER, SYNTHETIC MATTERIALS
MIN SLIT 20mm
SPEED 100 mtrs/min
WORKABLE WITH LARGE DIAMETER ROLLS
MANY SPARE KNIVES
EDGE TRIM VACUUM TUNNEL WITH SHREDDER
Maximum web width 1350 mm
Maximum web width in the unwinder 1400 mm
Minimum track width 520mm
Maximum diameter of the spool unwinding 1000mm. Axleless (40")
Inner diameter spool unwinding 76'2 / 152'4 mm. (3" and 6")
Minimum-maximum web tension 3.5 / 35 kg
Max coil weight 1000kg (2200Ibs)
Maximum adjustment of the guide unit +/- 50mm
Sensitivity maximum speed 33 mm / sec
Actuator type servo-electric
Maximum spool diameter: 800 mm (31.11")
Inside diameter ...
WOHLENBERG 137 PTC Fully Automatic
Type: Cutting Line
Machine number: 3892-002
Year of manufacture : 2005
- PC programming with floppy disk drive
- Large LCD display
- Multilingual text information
- Up to 1,500 program memory locations
- Stainless steel coated central air table
- Air side tables left, right and rear
- 2 x HSS knives
- IR light protection
- Baumann specialist Flow-Line system
including stacking racks.
- With lift, vibrator and dow...
Working width: 3000mm, max. material thickness: 0-10mm, connected load: 7.5kW, length: 4010mm, width: 1850mm, weight: 3,5t, with 8 creasers top and bottom, 6 knives top and bottom, 6 creasers including counter body, min. creasing width: 70mm, including documentation and conveyor belt, was maintained regularly.
Super como electric paper/cartboard guilottine, in a good condition, functions perfectly. It cuts 30 cm of thick cartboard, 120 cm wide and 130 cm long sheets can enter. We can provide video of the machine while cutting the cartboard
Automation: Siemens S7 CPU 300
production speed: 60 m/min
Design speed: 70 m/min
Web tension rewind stations: 2000 N
Material thickness: 2,0 mm
Setup speed: 10 m/min
roll diameter: 1500 mm
Roll width: 1950 mm
Roll weight: 3000 kg
installation dimension: 12.400 x 5.800 mm
rated current: 630 A
Drive: SEW three-phase drive
Power winding station 1: 30 kW
Power winding station 2: 30 kW
Safety: emergency stop buttons/steps, light barri...
High Speed Roll Die Cutting & Creasing & Embossing Machine
An ideal and professional machine in die-cutting, creasing, embossing and full-stripping various PE coated paper, normal paper, corrugating paper and plastic material.
Ideal for: paper cup, paper box, medical package, wine package, food package.
The Speed : The working speed is 150-200 times per minute the level of the capacity in China is 120 times per minute. It has the ability to die-cutting, creasing and embossing for vario...
Fully variable air/belt cross cutter / sheeter with camera register mark for paper and film production
min. format length: 100mm
max. format length: 3500mm
max. web width: 100mm
max. web width: 2500mm
max. mech. speed: 700m/min
year of construction: 2015
variable in- / offline air and belt cross cutter for paper and film, with speeds up to 700m/min a.o. also with special options like multiple stacking stations, antistatic equipment, non-contact product transport and many more.
For paper and ...
In this offer you acquire a used two-side trimmer (front/side trim) "STR5302/BLT302" suitable For Xerox Color C75/J75 Press.
suitable among others for:
C75, J75, Versant 80/180/2100/3100
Total: Approx. 95,103 cuts
This is a used unit and may show signs of use (minor scratches or yellowing).
(minor scratches or yellowing).
The unit has been tested for function
A test cut can be seen in the photo
Packing and shipping:
You are welcome to ...
16-page cross cutter / sheeter as used machine or according to customer's request electromechanically overhauled / revamped with warranty.
cut-off length: 598,5mm, 620mm, 625mm or 630mm (to be specified)
max. web width: 1000mm
max. mech. speed: 40.000 cyl. rpm - 65.000 cyl. rpm
year of construction: 2003 (basic frame, single parts new or overhauled)
We can also offer you many other new and used variable in- and offline air- and belt cross cutters / sheeters for paper and film, with s...
