Used Compound units for sale (5)

Condition: excellent (used), Complete Ammonia Freezing Installation More photos available!!! Ammonia freezing installation is a key element of the industrial cooling system, ensuring effective maintenance of low temperatures in production processes and storage. The use of ammonia (NH3) as a refrigerant guarantees high energy efficiency and ecological neutrality. Consists of: 1. Screw compressors The refrigeration system is based on 6 screw compressors from YORK: 5 units (model 233L) - Temperature range: -42°C / +35°C - Cooling capacity: 314 kW - Absorbed power: 221 kW - Motor power: 280 kW 1 unit (model 1216) - Temperature range: -35°C / +35°C - Cooling capacity: 79.8 kW - Absorbed power: 46 kW - Motor power: 55 kW These compressors ensure stable operation of the refrigeration system. Drcuvf 2. Ammonia Heat Exchangers The system includes 3 Thermowave plate condensers, each with the following parameters: - Cooling capacity: 1400 kW - Primary medium: NH3 - Condensation temperature: +35°C - Secondary medium: MEG 30% - Inlet temperature: +27°C - Outlet temperature: +32°C - Flow: 250 m3/h These condensers provide efficient heat transfer and work in conjunction with cooling towers. 3. Glycol Pumps The system includes 4 glycol pumps responsible for the circulation of the MEG 30% mixture: - Cooling medium: MEG 30% - Motor power: 30 kW - Flow capacity: 250 m3/h These pumps play a key role in stabilizing the operation of the refrigeration system, improving the efficiency of heat exchange. 4. Cooling Towers The heat removal system consists of 6 cooling towers: 4 towers (VXC models): - Cooling capacity: 720-990 kW 2 Baltimore Aircoil International FXVE 1212C towers: - Cooling capacity: 2500 kW each - Temperature range: 27°C / 32°C These towers ensure optimal cooling of the medium and guarantee stable operation of the entire installation. 5. LP Ammonia Tank The installation has a low pressure tank (LP Receiver) with a capacity of 18,380 L, operating in the range of: - Ambient temperature max: +30°C - Operating temperature: -24°C - Working pressure: 0.35 bar - Pneumatic tightness test: 12 bar - Hydraulic pressure test: 24 bar This tank is an important element of the ammonia collection and distribution system in the system. 6. Main Spare Parts The system has main spare components, including: 2 screw compressor motors (After regeneration) 1 screw for ammonia compressor (After regeneration) 1 piston compressor motor (After regeneration) The ammonia refrigeration system is characterized by high cooling efficiency, solid components and ecological use of NH3. Integration with the glycol system and efficient cooling towers allow for stable operation in industrial conditions. Screw compressors and Thermowave condensers ensure energy efficiency and longevity of the system, making it a reliable element of the refrigeration infrastructure.

Condition: excellent (used), Year of construction: 2015, Complete system consisting of a heat exchanger and two industrial pumps by the renowned brand Grundfos. The system is from a previously used industrial setup and is in good technical condition. Technical Details: Heat Exchanger (VDL Delmas): Model: S21A-IS16-46 Year of Manufacture: 2015 Heat Exchange Area: 11.4 m² Heat Transfer Capacity: 622 kW Operating Pressure: 10 bar Flow Rate (Primary Side): 78 m³/h. Flow Rate (Secondary Side): 105.6 m³/h Weight: 532 kg Grundfos Pumps: Pump Specifications: Model: CRN90-2A-F-G-E-HQQE Pump Type: Vertical multistage centrifugal pump Material: High-grade stainless steel for durability and corrosion resistance Maximum Flow Rate: 42.5 m³/h Maximum Head (Hmax): 68.9 m Motor Specifications: Model: Grundfos MG160MD2-42FF300-H3 Power (P2): 15 kW Rated Speed: 2920 rpm Dqj2Y9 Protection Class: IP55 Insulation Class: F Weight: 100 kg We have one brand new surplus Grundfos pump for this system.

Condition: excellent (used), Cooling compressors set Bitzer -Type: 4VHC-10K-40P (x4) -Volume: 28.9 m3/h (x4) - Refrigerant: CO2 -Refrigerant tank and control panel in set -Cooling capacity for CO2: 328 kW at -25°C/40°C, 267 kW at -30°C/40°C -Dimensions: 3400 x 1600 x 2200 mm -Control panel dimensions: 2520 x 500 x 2270 mm -Items in magazine: 1 -Reference number: Z95 -Condition: Used in good condtion Dqnxez

Condition: excellent (used), We can offer Cold water installations consisting of : - 3x compressors Bitzer HSKC7451-70Y-40P, Each volume:192m3/h, each capacity : 110 kW at -10/40 for R407C - 1x compressors Bitzer CSH7563-80Y-40P, Volume:227m3/h, capacity : 112 kW at -10/40 for R407C - Compressor mounting frame with 4pcs original Plate exchanger Original Control Box panel B7Pyph3Nhe The system worked on R407C,is dismantled and ready for reinstallation.

Condition: excellent (used), Compressors Rack with Original condenser Compressors Rack: Producent Bitzer Compressors Model 3x HSK 6461-60-40P Volume [m3/h] 3 x 165 Cooling Capacity for R404A: 343 kW at -5°C/40°C R404A, 280 kW at -10°C/40°C R404A Original condenser:: Chfew39Tc0 Producent : Kobol Type : CSH-1209H AL 1C Coolling Capacity : 700 kW Dimensions : Lenght : 900 cm, Width : 230 cm, Height : 150 cm Weight : 2309 kg Very good condition
