Transport system

WEINIG RF 15

Condition: reconditioned (used), Number of spindles 5 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. Control Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ----- This machine is currently being refurbished at our facility! Pictures taken before dismantling and currently during the processing phase! Brief Summary: ----- - 5 spindles with 8,000 rpm - 4 x HSK/Powerlock - Axially and radial CNC adjustments of the spindles via control - CNC-controlled adjustment and positioning of the feed - Table tops with guide blades at spindles 2 and 3. - Includes Weinig/Neumann RF 15 return conveyor system Detailed Description: ----- Technical Data: Working width: 20-230 mm Working height: 8-120 mm 1st tool holder - bottom ----- Motor with brake: 5.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter: 93 - 145 mm Axially travel: 5 mm Folding device MarathonCoatin for table insert in front of 1st lower Tool Holder 2nd Tool Holder - PowerLock - Right ----- Motor with brake: 7.5 kW Shared motor with left tool holder Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter 40 mm below table level: 93 - 200 mm Tool swing diameter 55 mm below table level: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. tool diameter behind stop plane: 180 mm Max. groove depth: 35 mm Axially travel: 55 mm Spindle: CNC controlled axially Tedpfx Aaoyy A Iqo Toc Table tops with guide blades 3rd Tool Holder - PowerLock - Left ----- Motor with brake: Shared motor with the 2nd spindle Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter 40 mm below table level: 93 - 180 mm Table surface: 93 - 200 mm Tool swing diameter 55 mm below table surface: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. groove depth: 35 mm Axially travel: 55 mm Spindle axially and radially CNC controlled Table tops with guide blades 4. Tool holder - PowerLock - top ----- Motor with brake: 7.5 kW Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter: 93 - 200 mm Tool swing diameter for straight cutter heads max.: 180 mm Max. groove depth: 35 mm Axially travel: 40 mm Split pressure shoe in front of upper tool holder, adjustable and pivoting away from the tool, spring-loaded. Pressure shoe in front of, and discharge after, the upper tool holder with electronic digital displays, integrated into memory functions CNC-controlled radial spindle 5. Tool holder - PowerLock - bottom ----- Motor with brake: 7.5 kW Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter: 93 - 200 mm Max. throat depth: 15 mm Axially travel: 35 mm Feed system ----- Frequency-controlled feed, infinitely variable with brake: 4 kW, 5 - 30 m/min Infeed roller in front of the first lower tool, pneumatically controlled up/down. Durofer pointed tooth rollers (Weinig patent) wi...

Condition: good (used), Weinig add-on feed gearbox for short pieces. Suitable for Weinig Unimat, Profimat, Hydromat, Powermat. Used condition. Tjdpfx Ajzal Skja Tsc

Condition: reconditioned (used), Number of spindles 8 St. Working width 230 mm Working height 120 mm Weinig Planing and moulding line ----- Consisting of the following individual machines: Tedpfxoxpn Tus Aa Tjc Item 1: Weinig Profimat 23 E, four-side planer, stock number: 2803 5 spindles + glazing bead saw Item 2: Weinig Uniplan 23, stock number: 2804 Fine and hydroplaner with 2 horizontal spindles Item 3: Weinig RF 15, stock number: 2805 Longitudinal-cross-longitudinal conveyor with workpiece return to the operator Detailed descriptions of the machines can be found under the mentioned stock numbers. (Technical specifications according to the manufacturer, without guarantee!)

Condition: used, Coating chain composed of chain, rails and drive motor, approximate length 300 m. Used Tjdpfxjy Ud S Te Aa Tsc
