Condition: used, Stack cutting machine, guillotine cutter, guillotine SCHNEIDER Type Senator 155 Rubber, paper and veneer shear, plastic shear, fabric shear Guillotine for paper, cardboard, rubber, wood, and veneer Paper shear, rubber shear, plastic shear, paper and veneer shear Machine no. 60178 Year of manufacture: 1968 Cutting length: 1550 mm Cutting height: approx. 125 mm Working height: 140 mm Back gauge: max. 1550 mm Motor power (blade drive): 5.5 kW Power supply: 380 Volt, 50 Hz - Two-hand operation for blade activation - Automatic pressing device holds the paper stack on the table - Manual clamp and blade activation via foot switch (operational) - Back gauge adjustment up to 1550 mm (can be adjusted manually via handwheel) - Retrofitted electric control not functional, without wiring diagrams, without user manual - Back gauge adjustment via servo motor (servo motor, controller, and control present, not functioning) Required space (L x W x H): 325 x 270 x 165 cm Space requirement for transport without disassembly: Length 330 cm x Width 270 cm x Height 175 cm Space requirement for transport with disassembly: Length 550 cm x Width 220 cm x Height 175 cm (machine + table separately) Machine dimensions: Length 270 cm x Width 190 cm x Height 175 cm Back gauge table: Length 240 cm x Width 170 cm x Height 120 cm Weight of assembled machine: approx. 5000 kg (without transport steel plate) Good condition Pgedpsdzqnyofx Al Hjk Ideal for cutting paper, cardboard, leather, cork, rubber, or fabric-reinforced rubber Sales price does not include the 20 mm steel plate on which the machine is placed in storage. (Price for the steel plate: EUR 900 net)

Condition: like new (used), Year of construction: 2013, functionality: fully functional, Vertical piston compressor with sound insulation hood DK 600Eco UNM STS 660-10-270 Pedpoypkr Uefx Al Hogk - Year of manufacture: 2013 - With integrated refrigeration dryer, 660 l suction capacity, 520 l output volume - 10 bar - Weight: 245 kg - Sound-damping hood - Condensate drain 4 kW, 400 Volt - Width: 960 mm, Depth: 740 mm, Height: 1905 mm - Noise level: 69 dB (A) - Barely any operating hours - IN ABSOLUTELY AS-NEW CONDITION Transport possible at extra cost!

Condition: ready for operation (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 51585, cutting width (max.): 1,320 mm, insertion depth: 1,320 mm, insertion height: 140 mm, stack height: 140 mm, overall weight: 4,000 kg, type of input current: AC, front table length: 680 mm, total width: 2,333 mm, input current: 13 A, total height: 1,560 mm, working width: 1,320 mm, total length: 2,570 mm, input voltage: 380 V, space requirement height: 1,560 mm, space requirement width: 2,333 mm, Equipment: documentation/manual, safety light barrier, For sale: Used cutting machine Schneider Senator 132 / MC2, year of manufacture 1985. The machine offers a cutting width of 132 cm and is ideally suited for use in print shops, bookbinderies, and finishing operations. Pedpfx Aey Hi Rljl Hjgk Robust construction, proven technology, and reliable performance make this machine a solid solution for precise cutting tasks. Inspection by appointment is gladly possible.

Condition: new, Year of construction: 2023, functionality: fully functional, machine/vehicle number: RM6 NE IIDI, type of input current: three-phase, input voltage: 11,000 V, input frequency: 50 Hz, control voltage: 230 V, Equipment: CE marking, medium voltage switchgear left over from an order, new, unused Psdpfsy Hir Ajx Al Hsgk

Year of construction: 2006, condition: excellent (used), machine/vehicle number: 1107, P/N: 190.101 Pgodpfoihvl Isx Al Hek Further MACHINERY / SPARE PARTS & MACHINE COMPONENTS of this type are available in our warehouse. ON REQUEST

Condition: excellent (used), machine/vehicle number: 783, P/N: 190.101 Pjdpfx Aoiiv Dnel Hegk Further MACHINERY / SPARE PARTS & MACHINE COMPONENTS of this type are available in our warehouse. ON REQUEST

Condition: excellent (used), P/N: 190.101 // Fabrik No.: 616 Pgodpfxegnlb As Al Hek Further MACHINERY / SPARE PARTS & MACHINE COMPONENTS of this type are available in our warehouse. ON REQUEST

Condition: excellent (used), CATALOG NUMBER 7617 TECHNICAL DATA - Wheel diameter: 610 mm - Table dimensions: 670x640 mm - Table tilts, angle adjustable - Motor: 2.2 kW - Brake - Max. cutting height: 380 mm - Throat distance (blade to frame): 550 mm - Extraction port diameter: 100 mm - Dimensions (L/W/H): 1150x800x2200 mm - Weight: 360 kg ADVANTAGES – German-made – Not repainted – In very good condition – Used saw Net price: 7900 PLN Net price: 1880 EUR based on a rate of 4.2 EUR (Prices may fluctuate with significant exchange rate changes) Pgjdsyg I Axepfx Al Hsk

Condition: used, Linear unit, linear axis, gantry axis with servo drive, synchronous servo motor, electric slide, loading unit, linear guide with servo motor and pneumatic gripper SCHNEIDER ELECTRIC / FESTO type PAS43SBG1800 / BMH1002T07F2A Pgsdpfx Alsw Uc T Ie Hjk Year of manufacture: 2012 Vertical stroke via Schneider Electric linear axis PAS43SBG1800 Travel: 1800 mm Travel per revolution: 20 mm Maximum speed: 1 m/s Drive element: ball screw Guide type: recirculating ball linear guide size 20 Payload: 60 kg Maximum speed, ball screw: 3000 rpm Motor type: Schneider Electric BMH1002T07F2A Rated voltage: 240 Vrms Rated power: 1.912 kW Rated speed: 3500 rpm Max. current draw: 29.4 A Horizontal travel: 670 mm via Festo pneumatic cylinder Gripper opening: 600 - 670 mm - Pneumatic gripper on guide carriage - Gripper jaws open pneumatically - Unit mounted on welded square tube frame Total weight: approx. 380 kg Overall dimensions (W x H x D): 1280 x 2950 x 1150 mm Very good condition Nearly identical linear unit under stock number 59700 Drive controller 61488 = suitable for linear units 59702 + 59700

Condition: good (used), Year of construction: 2013, power: 4 kW (5.44 HP), operating pressure: 10 bar, Equipment: refrigerant dryer, Schneider Unimaster Piston Compressor UNM STS 660-10-500 XSDK 2 cylinders, soundproofed, Intake capacity 660 L/min, Delivery rate 520 L/min, 10 bar, Motor 4 kW, 380 Volt, 50 Hz, Tank volume 500 liters, Pedsy E Iz Tspfx Al Hjgk complete with: Refrigeration dryer DK 600 ECO, Oil/water separator ÖWAMAT 10, ECOMAT condensate drain, Pre- and fine filter, as inspected, ex location Seevetal, subject to prior sale.
