PVB production line

LISEC PVB Lamination Line

Condition: used, Year of construction: 1989, Grinding and polishing Maximum dimensions of the glass pane: 3000 x 3000 mm, Minimum dimensions of the glass pane: 40 x 80 mm, Working height: 820 mm, Dimension: Length: 7300 mm, width: 830 mm, Laodpfx Amjnzkwme Tjc height: 2730 mm. Weight: 3650 kg.

Year of construction: 1996, condition: good (used), machine/vehicle number: 9182, Offer 23168 Technical data: - Notching possibilities + miters in 3 planes Lodemb U E Aepfx Am Toac - right-angled, one-sided + two-sided + three-sided oblique . - Can be used as a shift cut crosscut saw - Pneumatic profile clamping Machining with semi-automatic sawing units - Saw blade dimensions - vertical 500 x 3,5 x 40 mm positive - horizontal 500 x 3,5 x 40 mm negative - notching width / notching height at 90° 300 / 285 mm - vertical saw blade 60° - 90° - 25° mot. positioning with digital display - Swiveling range saw blade horiz. with vert. saw blade Saw blade - 45° - 90° - 45° mot. positioning with digital displays - Notching height adjustment with digital displays - profile stop shoulder manually tiltable 30° - 90° - 45° - pneumatic coolant check device - air connection 6 bar - drive 400 V / 2 x 3 kW - space requirement approx. W 2400 x H 2000 / D 1400 mm - weight approx. 1200 kg

Condition: good (used), Year of construction: 1993, Washing height: 2700 mm. Washing machine with infeed conveyor and outfeed conveyor. Dimensions of the goods: Total length: approx. 11400 mm. Max. height: 3920 mm. Lajdjxl Ul Nspfx Am Tsc Weight: approx. 4000 kg. Condition: good, second-hand

Year of construction: 1995, condition: used, Max. sawing length: 5,000 mm Max. saw blade diameter: 500 mm Automatic positioning via diamond control of length and angles Angles can be swiveled inwards and outwards (20-135°) Moving roller conveyor Soundproof cabin Laedpfx Amjv Ip T De Toc Minimum quantity spray device chip conveyor belt Weight: approx. 2,800 kg
