Laminating machine

Komfi Amiga 52 A Feeding Head

Komfi Laminator Amiga 52A (Feeding Head)
New/Demo Unit, Manufactured 2022

Specifications:
Max. speed of lamination: 25 m/min
Max. output: 8000 sheets/h
Min. sheet dimensions: 200 × 250 mm
Max. sheet dimensions: 560 × 800 mm (or up to 1016 mm)
Paper weight: 115-600 g/m²
Paper thickness: Max 0.7 mm (with overlap > 0) / Max 1.4 mm (with overlap < 0)
Max. paper pile: 6 cm (depending on sheet length)
Thickness of laminating film: 24-50 μm; OPP, PET, Nylon
Sheet overlap accuracy: ± 1 mm

Feeder:
Komfi single action feeding head

Laminating Unit:
Teflon coated rubber roll
Adjustable distance stoppers for lamination unit to enable processing thick substrates
and windows lamination.
Dsdpfx Agezb A T Uspsch
”On-the-fly” side-adjustable unwinding shaft with adjustable brake force.
Height-adjustable and removable spread roller perfectly removes wrinkles from laminate.
IR heating for laminating cylinder. Temperature sensor inside the cylinder for precise regulation.
Rubber coated pressure roller.
The powerful pneumatic pressure system guarantees even nip pressure and perfect lamination results.

Separator & Delivery:
Decurling unit consisting of bar and roller with position control to move the snapping moment automatically when the position of decurler is changed.
Built-in film perforator to enable sheet separation.
Cam-driven separation roller with adjustable tearing action, delivery roller and sheet skewing wheel.
Fixed delivery desk with adjustable air nozzles.
