Joinery

Hundegger K2

Condition: good (used), Year of construction: 2005, functionality: fully functional, feed length X-axis: 22,000 mm, total length: 22,000 mm, saw blade diameter: 760 mm, working length: 22,000 mm, working width: 650 mm, Description: For sale: K2 650mm CNC machining centre, year 2005, 5-axis machine, ideal for industrial carpentry, timber framing, and woodworking applications. Machine fully serviced, operational, and in regular use. Key Features: • 5 axes • Automatic workpiece turnover system • Infeed 22 meters / Outfeed 20 meters • Integrated crosscut saw with pneumatic end-of-chain clamping • Saw blade Ø760 mm (360° rotation) Godpfeyimi Hsx Afaetu • Universal cutterhead Ø350 mm – thickness 80 mm • Universal cutterhead Ø350 mm – thickness 45 mm (additional) • Universal cutterhead Ø350 mm – thickness 100 mm (additional) • Universal cutterhead / router Ø40 mm • Universal cutterhead / dovetail milling (cutter Ø45/60 mm) • Vertical router (cutter Ø8 to 30 mm) • Inclined horizontal drilling unit (0 – 45° angle), max drill length 650 mm • Horizontal drilling unit, max drill length 650 mm • Vertical drilling unit, max drill length 460 mm Condition & Services: • Comprehensive overhaul completed in June 2024 • Industrial cabinet PC Pyramid with Windows 10 installed 18/11/2025 (invoice available) • New operator console as of 04/2022 • Machine in daily working condition • Option for dismantling and reassembly by manufacturer – estimated cost: €25,000 (includes installation and hotline support) If you have questions or require further information, please do not hesitate to contact us by message or phone.

Condition: excellent (used), Year of construction: 2015, Stravis sawmill line with Jabłoński automatic edger after complete renovation. Condition like new. The line consists of: 1. Log conveyor for 5m logs with a cascade feeder 2. Caterpillar-chain saw 110 + 90 kW 3. Multi-blade saw (2 x 75 kW) spindle diameter 80mm 4. Roller conveyor l- 6m with a mechanism for stopping the movement of the left prism 5. Crosscut saw from 0.8 m to 5m 6. Base conveyor 7. Roller conveyor l=3.5m 8. Driven roller conveyor 4.5m 9. Driven roller conveyor l=4.0 m with a board dumping mechanism 10. Transverse belt conveyor b=3m, l=5m 11. Transverse belt conveyor with a pick-up b=2m, l=5m 12. Longitudinal belt conveyor b=0.4m, l=5m 13. Automatic edger Jabłoński 14. Gooseneck Jabłoński 15. Cross feeder with a scanner measuring the width of the board 16. Centering for the edger 17 17. Edge separator Gsdpfxjv Iyhfs Afaetu 18. Crosscutter from 0.8 m to 3.0 m 19. Gooseneck 20. Automatic stacker Jabłoński 21. Non-regenerated crosscutter Jabłoński 22. Bruks chipper with control (you need to make a belt or vibrating gutter) Assembly and start-up at the customer's premises is possible. Possibility of sending videos of the working machine before renovation. Possibility of setting the line in a turn or along the length. Optionally, construction of a base for the line. OPPORTUNITY

Condition: ready for operation (used), Year of construction: 2002, This 4-axis HUNDEGGER K2 was manufactured in 2002, designed for efficient wood beam processing. It features a loading area with motorized chains, a maximum beam length of 13,500 mm, and a working section up to 440 mm × 240 mm. Includes a circular saw and universal milling unit, both with 4 axes, alongside versatile drilling units. Ideal for complex woodworking tasks. Contact us for more information about this machine. • CNC designed for wood beam processing • Maximum incoming beam length: 13,500 mm • Maximum outgoing beam length: 12,000 mm • Maximum working section: 440 mm × 240 mm • 2 independent clamps for transport and positioning (“two-hand” system) • Circular saw unit, Ø 750 mm, 4 axes • Universal milling unit with double output, 4 axes • Lower vertical drilling unit with multi-purpose support • Horizontal drilling unit with multi-purpose support, tilting • Long horizontal chain saw unit, 700 mm, with counter-support system • Includes tool change equipment • Independent control panel • CE compliant Gtedpfx Afjyaq Dxsaou Additional equipment • Loading area with 7 motorized transverse chains • Unloading area with 6 arms for parking and storage of parts

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, working width: 450 mm, Equipment: safety light barrier, TECHNICAL DETAILS Working width: 450 mm (limited processing up to 520 mm possible) EQUIPMENT - Safety light barrier - Saw - Universal milling unit with roller cutter - Dovetail cutter - Finger joint cutter - Drilling units: 1x horizontal + 2x vertical Gtodpfjyfhi Nsx Afaou - Slotting device - Marker on stop side - Automatic beam turning station - Wood length is now processed in the feed up to 16m - Control computer with EKP program included

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, For sale on behalf of a customer is a Segem ERT 100. The machine was operational until removal. The rotor bearing was replaced in September 2023 (approx. 2000 hours). Gsdexhf N Dopfx Afaetu

Condition: used, Year of construction: 2008, functionality: fully functional, overall weight: 24,000 kg, Machine provisionally reserved. Within a week timeframe. Gtodpfxsxx T Rde Afaju For sale: Hundegger K2i carpentry centre from 2008. The machine is in very good condition and very well equipped, including: 13 m infeed table Beam holders with driven chains! 5-axis saw unit 5-axis milling unit Horizontal and vertical drilling Additional milling unit for underside rafter ends Slotting unit with complete set of 8 mm and 10 mm chains Note: The slotting unit is a rare feature. It is used for manufacturing trusses with concealed metal plates. The machine is in excellent technical condition, has been regularly serviced and well maintained, and is in continuous operation. We are selling because we have purchased a much newer machine. Note: Collection available end of February.

Year of construction: 2002, condition: used, functionality: fully functional, Used HUNDEGGER K2-625 for sale. For sale: Hundegger K2 CNC machine with 4 axes, designed for machining wooden beams up to 13m, featuring 2 independent work clamps for sections up to 625mm x 300mm. Equipped with a circular saw unit (800mm), universal milling unit with finger bit and Milano cutter, interchangeable vertical milling unit, horizontal chain saw for groove cutting, vertical drill and hydraulic unit for beam turning. Comes with compressor unit (ELGI EN11-9.5 2022) and air dryer (MKE 155 09/2022), ready for installation and use. CE compliant. Gtedpfx Afjycg Sqoaeu Machine is in fully operational condition. Sold with tooling and spare parts. Price upon request. Videos available upon request.

Condition: good (used), Year of construction: 2000, functionality: fully functional, Cambio 500 debarking line consisting of: Infeed centering. Gtjdpfx Afowxdimeaju Cambio 500: Rotor opening 495 mm. Minimum log diameter 90 mm. Drive motor 55 kW. Feed motor 11 kW. 80 m/min. Hydraulic rotor and feed rollers. Outfeed control unit. Tilting trough for long timber. Spare parts.

Condition: excellent (used), Hundegger K2 Industry 5-Axis CNC Timber Joinery Machine 5-axis machining capabilities – Maximum machining section: 300 x 620 mm Machining operations: Section probe detector, section measurement – Cutting: All straight cuts and any angle, horizontal and vertical, birdsmouth, valley and hip rafters, rebates, half-lap joints, chamfering, groove, straight and angled birdsmouth groove, web notch – Milling with aggregate head (hogging head) and other milling cutters, mortise and tenon, mortises, notches, scarf joints, dovetail joints (straight and angled), Gerber scarf – Drilling: straight and angled, deep-hole drilling – 1x side drill and 1x underside drill. Gedpfex U Ti Uex Afaetu Ink marking system – Piece identification labelling Control console and software: The control system allows importing data from CAD software and automates the calculation of complex machining operations. Work is currently performed with CADWORK software (not included in the sale of the machine). The machine features a pit designed for the elimination of wood waste and sawdust. This HUNDEGGER K2 CNC is fully upgraded and refurbished! Dimensions: - Machine: Length 22,900 mm x Depth 5500 mm x Max. height 2550 mm (on the floor) - Waste pit: approx. Length 12,000 x Width 2,400 x Depth 950 mm - Timber feeding length: 13,000 mm - Max. timber output length: 13,000 mm - Transverse infeed conveyor: 5 chains, 2,200 mm - Extendable timber support table - AQF feed chain with shaft extension, 2,900 mm - Under-table pivoting crosscut saw - Right-hand safety flap Waste evacuation system located below – Control for waste extraction system – Universal 5-axis milling unit with profiling tool, dovetail cutter, multiple finger joint cutter, combined vertical tool holder, drilling unit, finger joint cutter, combined horizontal tool holder, rebate unit / Drilling unit 1 and 2 – Marking device – Pneumatic beam turn-over station – Outfeed table with 7 arms Year of manufacture: 2003 Purchased by current owner in 2020. Machine was fully reconditioned in 2020: electrical, mechanical, pneumatic, tooling, and IT systems (dismantling parts and motors, replacement of bearings, hoses, cables, guideways, IT update and EKP data export, cleaning, new tooling in 2020) The machine is in very good technical and visual condition.

Condition: excellent (used), Year of construction: 2013, feed length X-axis: 13,000 mm, saw blade diameter: 800 mm, working length: 13,000 mm, Equipment: safety light barrier, We are offering this very well-maintained Hundegger K2i-625 (UF5) joinery machine, year of manufacture 2013. Fully automatic wood infeed with feed roller conveyor and loading & infeed transporters Under-table swiveling crosscut saw 11 kW Universal 4-axis milling unit (UF4) Combined support for vertically operating tools Gedpex Trllefx Afaetu Drilling unit 2.2 kW – drilling direction vertical Combined support for horizontally operating tools Drilling unit 2.2 kW – drilling direction horizontal Fully automatic hydraulic beam turning station Transport and positioning system "two-hand operation" incl. machine frame Electronic control with EKP software Refined machine surface Extension of the cross conveyor and feed roller conveyor for timber lengths up to 13 m 5-axis universal milling unit – UF5 (surcharge for 4-axis) Drilling unit 2.2 kW – drilling direction horizontal Front marking unit (operator side) InkJet 4 HP system on the stop side Remote maintenance (incl. portable video camera) Control unit for waste removal with operating buttons Extension of roller conveyor on the output side Spare saw blade 800 mm Dovetail cutter 60x3 Bx16, 5 mm (with reversible blades) If you have any questions or require further information, please feel free to send us a message or call us.

Condition: refurbished (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 223A011643003, warranty duration: 12 months, frame height: 600 mm, frame width: 600 mm, Equipment: documentation/manual, Arch Size: 600 x 600 mm Strap width: 5-12 mm Year: 2016 Machine-No.: 223A011643003 Condition: Refurbished Features: ⦁ ASLF Anti-Strap-Loss-Function Permanent strap control ⦁ Automatic strap feed ⦁ Strap width 5 - 12 mm, optional ⦁ DAT Direct-Access-Technology Torque-controlled retraction force, adjustable ⦁ Adjustable transport speed ⦁ Machine mobile ⦁ Table height continuously adjustable ⦁ Package flow monitoring Gjdpfx Asukvgrefaetu Special features: • Right machine (viewed in the direction of conveyance) • EMERGENCY STOP button in the Easy Control control unit • Signal exchange: 2 x mating connector with tool • Additional light barrier for attachment to the front or rear conveyor • Signal exchange: Do not strap the package. To the front-running machine • External button: Do not strap the package • Strap tension dependent on the package height (laser sensor) • Pneumatic package press (600x600) • Double press beam 600 • Feed protection on the table top, inlet side

Condition: used, Year of construction: 2003, functionality: fully functional, machine/vehicle number: 11441, At the moment we are working with the following version: Gedpfx Ajwvih Aofajtu 9.23.12.102733-12 The equipment of the K2: a 4-axis universal milling machine 2 drilling rigs a finger cutter below a slotter Hydraulic beam turning station Machine is fully working, can be visiited upon agreed time. avaible from 30/11/2025 Disassembly from our company and loading to truck, and is included in the price. Sale is as a used machine with exclusion of any warranty.

Condition: like new (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 12762, cutting height (max.): 300 mm, Fully automatic wood infeed Infeed roller conveyor Infeed and loading cross conveyor Under-table pivot cross-cut saw 11 kW 5-axis universal milling unit – UF5 Combination support for vertically operating tools Drilling unit 2.2 kW – vertical drilling direction Combination support for horizontally operating tools Reinforced drilling unit (3.0 kW) horizontal drilling direction Slotting unit 7.5 kW Rear marking device (on the stop side) Fully automatic beam turning station, hydraulic Transport and positioning device "two-hand system" Electronic control with Hundegger production software Roller conveyor for wood outfeed with ejector 5-arm timber rack Safety devices and guards Refined machine surface Extension for infeed cross conveyor Infeed roller conveyor for timber length 13 m 5-axis universal milling unit – UF5 Revolver milling unit – vertical from above Remote maintenance possible Control cabinet special arrangement Control unit for extraction with operating buttons Gtodpfx Asxxa Dwefaju Extension roller conveyor 7.10 m without drive Raising and lowering safety baffle plate

Condition: good (used), Year of construction: 2007, functionality: fully functional, Equipment: cabin, crane, Baljer & Zembrod Gjdpjv Tk I Hefx Afajtu OBX IV Reach 13.30m Load capacity 2500kg at 13.0m

Condition: like new (used), Year of construction: 2015, I sell the automatic CNC working centre for wooden constructions Hundegger K2i. Almost new machine. Year 2011. Gjdpfx Afsxtxkxjaotu Under-table rotary saw with saw blade from 750 mm to 800 mm, 360 degree rotation, servohydraulic tilting 0 – 65 degrees universal 5-axis unit equipped with cylindrical milling cutter, end mill and end mill, milling head diameter 350 mm x 100 mm end mill combi support for at least 5 tools with horizontal drilling device up to power from 2.5 to 3.0 kW, drilling diameter max 24 mm, drill length min 460 mm, machining depth min 300 mm combi support for at least 5 tools with horizontal drilling device up to power from 2.5 to 3.0 kW, drilling diameter max 24 mm, drill length min. 460 mm, machining depth min. 300 mm positioning and gripping of the material using arms, which, while the material is measured, transported to the desired location, the arms keep the processed element as close as possible to the tool that processes it for stability. the processed material can be rotated automatically tolerance +/- 2 mm at a length of 13 m Fully automatic wood input with input roller track and input and sliding cross conveyor K2i: Under-table tilting cross-cut saw K2i: Universal milling unit – 4-axis (UF4) K2i: Kombisupport for vertically working tools K2i: Drilling device (2.2 kW) – vertical drilling direction K2i: Kombisupport for horizontally working tools K2i: Drilling device (2.2 kW) – horizontal drilling direction K2i: Marking tool (rear or on the user side) K2i: Fully automatic element rotation – hydraulic K2i: Transport and positioning system “two-hand system” K2i: Electronic connection K2i: Roller track for removal wooden elements with a pusher K2i: 5-arm storage table K2i: Safety device K2i: Higher quality upper surface of the machine K2i: Extension of the K2i frame to 13.56 m K2i: 5-axis universal milling unit - UF5 (increase to 4-axis) K2i: Remote maintenance (including portable video camera) K2i: Dovetail milling machine (with rotating knives) 60x28x16.5 Suitable for wooden house constructions! Available immediately.
