Bag forming and filling system

Gainsborough Engineering Co. GV5 Complete Packing System

Condition: good (used), Year of construction: 2014, Coffee Cartridge Filling and Packaging Machine Complete and in good working condition Overhead hopper feed. Automatic online depositor Dkjdjucf S Tjpfx Abrog Speed 300 packs / hour Complete with Simens Touch Screen Controller Hot melt carton gluer

Condition: used, Year of construction: 2016, Overview  This weighing and packaging line was built in 2016 by the Spanish manufacturer Volpak. The system is fully equipped, in very good technical condition and shows only minor wear. The system is still installed and connected and can therefore be viewed in person at any time. Technical details Output: 60 bags/minute Doypack/flat bag formats: 20/25g, 50g, 300g, 500g, 750g Possibility of micro-dosing powders Modern wide zipper/belt Scope of delivery  Doypack packaging machine | Volpak | SI-280 F1 Multi-head weigher | Ishida | CCW-RV-228-S/05-SS 4 raw material unloading stations Lindor mixer Cox & Plant feeder between the unloading stations and the mixer and multihead weigher Ishida X-ray unit with recoil, IX-GA-4075 Ishida dynamic check weigher with DACS-G-S0 recoil Installation for the injection of nitrogen or another inert gas, together with a measuring system Dust extraction system Euro slot Smooth welding system Dkedjtz H T Djpfx Abreg

Condition: used, Gainsborough bagger and All-Fill powder depositor. Dkjdovvpphepfx Abreg

Condition: ready for operation (used), Year of construction: 1996, Two Bosch vertical form fill and seal machines are available. 1) Bosch SVB 2501 A, year of manufacture: 1993, bag type: pillow bag, bag weight: 250g/500g, bag length range: 80mm-250mm, max. production output: 40 cycles/min, power consumption: 3kW, machine dimensions X/Y/Z: approx. 1300mm/2500mm/1700mm, weight: approx. 1100kg. Including clipping unit PS mako BS 600-CSP, year of manufacture: 2015. 2) Bosch SVB 3601 L, year of manufacture: 1996, bag type: pillow bag, bag weight: 250g/500g, max. bag length: 400mm, bag width range: 80mm-360mm, max. production speed: 40 cycles/min. Including clipping unit PS mako BS 600-CSP, year of construction: 2015, documentation available. On-site inspection is possible. Expected to be available from mid-January 2025. Djdeu Rc R Sspfx Abrskg

Condition: new, Year of construction: 2025, Automatic container/capsule filling and sealing machine. - Suitable for the filling of powdery products (coffee, coffee blends, chocolate, milk powder, etc.) in different sized capsule containers (e.g. Nespresso, K-Cup, Lavazza, Tassimo, Bellissimo, without filter, etc.) and subsequent sealing. Automatic dosing, filling by an auger filler. UV sterilization system, anti-static device and vacuum cleaning system for mould formats included. Automatic film feeding and double heat sealing of the capsule. - Specifications: max. speed of the machine in neutral: 55 cups/minute; filling range: 0-20g; filling accuracy: +/- 0.15g; capacity of hopper: 5L (approx. 3kg powder); power supply and consumption: 220V, 1.5kW; required compressed air and flow rate: 6-8 bar, approx. 300L/min; flow rate inert gas: approx. 200L/min; machine dimensions: L1900xW1118xH2524mm; weight: 800 kg. Specifications refer to Nespresso capsules, by use of other brands of capsules specifications may vary. Dodpfxjv Nkzxe Abrskg Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.

Condition: good (used), Year of construction: 2005, functionality: fully functional, packaging machine Dodpfxswpx Uxs Abrjkg

Year of construction: 2025, condition: new, Automatic container/capsule filling and sealing machine. - Suitable for the filling of powdery products (coffee, coffee blends, chocolate, milk powder, etc.) in different sized capsule containers (e.g. Nespresso, K-Cup, Lavazza, Tassimo, Bellissimo, without filter, etc.) and subsequent sealing. Automatic dosing, filling by an auger filler. UV sterilization system, anti-static device and vacuum cleaning system for mould formats included. Automatic film feeding and double heat sealing of the capsule. - Specifications: max. speed of the machine in neutral: 90 cups/minute; filling range: 0-20g; filling accuracy: +/- 0.15g; capacity of hopper: 10L (approx. 6kg powder); power supply and consumption: 220V, 7.5kW; required compressed air and flow rate: 6-8 bar, approx. 300L/min; flow rate inert gas: approx. 200L/min; machine dimensions: L3420xW2200xH2688mm; weight: 900 kg. Specifications refer to Nespresso capsules, by use of other brands of capsules specifications may vary. Dkodpfx Ajv Nkz Eobrog Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.

Year of construction: 2023, condition: new, Semi-automatic auger filler for 100-5000g. Suitable for dosing and filling powdery products. Stand-alone version including screw conveyor and storage container. Also included are: horizontal screw conveyor to prevent undesired trickling, dust removal preparation, PLC control and touch monitor, weighing sensor (works automatically with each dose), bag clip mechanism, screw conveyor for 500 and 2000g doses, lid for screw conveyor so it is closed. Suitable for filling into bags, cans, glasses, other containers. - Specifications auger filler: hopper volume: 50 litres; filling weight: 10-5000g (change of dosing screws required); stainless steel version AISI 304; servo motor; packaging accuracy: 1-2% (depending on product and total weight); max. speed of the machine in neutral: 50/minute; current: 1.5kW, 3P, 380V; machine dimensions: L600xW800xH1000mm; weight: 100kg. The screw conveyor has a stainless steel AISI 304 body with stainless steel pipe. The feed hopper holds 230 litres and is equipped with a vibration motor for uniform product flow. - Specifications screw conveyor: Conveying capacity depending on product: up to 3 m³/h; standard angle: 45° (can be customized 30-60°); pipe diameter: 141mm; power: 1P, 380V, 3kW; machine dimensions: size depends on the customized end system (hopper, conveying length and angle can be adjusted); weight: approx. 150kg. The drawing just shows the auger filler. Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty. Dsdpfx Absgzp Ekorskg

Year of construction: 2018, condition: excellent (used), Complete powder packing system for manufacturing and filling bags up to 10kg. The plant was purchased in 2017/2018 and has only been used very lightly (approx. 60 tonnes in 2024). The system comprises of the following equipment: 1 x Entecon stainless-steel powder sieve fitted to stainless-steel frame. Overall dimensions - 1100mm x 930mm x 2200mm high. 1 x Entecon AMC blower conveyor with control box. 1 x Busch vacuum lifting system. Model - SB 0310 D 0H0 UH XX. 1 x Fluidiser with high and low level probes. 1 x All-Fill powder auger filler with agitator and outfeed tube. Model - S10. Dkodpfxswa Ilhe Abreg 1 x Gainsborough Engineering Co. GV4 vertical form, fill and seal bagging machine (2018) fitted with Markem Imaje Smart-Date X60 thermal printer. Sealing bars - 430mm (horizontal) and 600mm (vertical). Current film - 840mm wide. Used to produce 400mm wide bags. 1 x Gainsborough Engineering Co. mobile outfeed conveyor. Infeed - 200mm. Outfeed - 1000mm. 1 x OCS Checkweighers GmbH HC check weigher (2017) to weigh up to 30kg. Type - HC. Weigh table dimensions - 800mm long x 60mm wide. 1 x Declined roller conveyor on height adjustable feet, all stainless steel. Roller bed width - 800mm. Overall dimensions - 1210mm long x 880mm wide x 870mm high (+130mm max). *Please note - if you require a metal detector for this line then please enquire with us, we can supply a suitable unit* Please contact for more details and to arrange a viewing.

Condition: new, Year of construction: 2025, Complete vertical packaging system for dosing coffee beans AND ground coffee and packaging in coffee stand-up pouches with aroma valve. The system is equipped with two separate dosing systems (auger filler for powder, volumetric cup dosing unit for granules) and also has a Z-conveyor, screw conveyor, outfeed conveyor and an AMTEC PRO P60L as VFFS packaging machine. A hot stamping printer for date, batch number (optional: thermal transfer printer on request), an anti-static module, stand-up pouch module (gusset device) and flat-bottom module (bottom seam is applied tightly to bottom, depending on the film material) are also part of the equipment. - Specifications VFFS: Stable film pulling by vacuum; MITSUBISHI/SIEMENS PLC, WEINVIEW touch screen operator interface; mark sensor registration control; quick change former assembly, pneumatic sealing unit; servo motor film pulling; bag size: L(100-300)xW(80-240)mm; max. speed of the machine in neutral: 60 cycles/minute; stainless steel; 220V/3.5kW; 6bar, 0.36m³/min; machine dimensions: L1550xW1160xH1480mm; weight: 600/700kg. - Specifications volumetric dosing unit: 4 cups; perfect for free flowing granulate like products (rice, salt, sugar, etc.); stainless steel; dosing range: 80-2.000ml; max. speed of the machine in neutral: 60 cycles/minute; - Specifications: stainless steel; filling system with rotating screw; Servo motor; filling weight: 10-2000g; 50 liter filling hopper; accuracy: 0.5-2%; max. speed of the machine in neutral: 60 cycles/minute; airproof; damp pressure, side opening hopper, including dust collector. Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty. Dsdpfx Aov Nmh Iebrekg
