CNC for Flexible Drilling

BIESSE SKIPPER 130

Condition: used, machine/vehicle number: 008563, X axis working area: 3000 mm Y axis working area: 1300 mm Main Electrospindle power: 4.5 KW Number of controlled axes: 3 axes Fsdpfszruxvjx Ahdjpn Total number of drilling spindles: 82

Condition: used, Year of construction: 2008, We offer this used BIESSE SKIPPER 130 throughfeed machining center, year of construction 2008. Manufacturer: BIESSE Model: SKIPPER 130 Year of construction: 2008 Condition: used Category ID: 2074 Type ID: 151 Type: throughfeed machining center Fpedpfx Aoz H Sf Tshden If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), C.N.C. WORKING CENTER with 3 axes (X-Y-Z) - Goose-neck type Movable panel (workpiece), static working head, Horizontal position of the panel (workpiece) Numerical Control with Software BiesseWorks (Separate electric and command cabinet) Safety cabin (enclosure) of the working head, Front emergency carpets In-feeding working table (panel support) No. 2 Workpieces fixing clamps (for the panels introduction in the working area) Out-feeding table (with motorized belts) Minimum workpieces dimensions (X - Y - Z) mm 90 x 70 x 8 (ca.) Maximum workpieces dimensions (X - Y - Z) mm 3000 x 1300 x 60 (ca.) Two panels that can be processed simultaneously (on the Z-axis) Automatic panel dimension detection system (on the X and Y axes) BOTTOM WORKING UNITS (BH41): No. 31 Independent vertical boring spindles (No.) 31 No. 10 (8 X + 2 Y) Independent horizontal boring spindles No. 1 Circular Grooving Saw (on X axis) dia. (mm) 160 (N° 1 x kw 5) No. 1 Vertical electro-spindle ISO 30 (N° 1 x kw 6,5) No. 1 Horizontal electro-spindle (N° 1) on the Y axis TOP WORKING UNITS (BH41): No. 31 Independent vertical boring spindles (No.) 31 No. 10 (8 X + 2 Y) Independent horizontal boring spindles No. 1 Circular Grooving Saw (on X axis) dia. (mm) 160 (N° 1 x kw 5) Fjdozyalkepfx Ahdepn No. 1 Vertical electro-spindle ISO 30 (N° 1 x kw 6,5) No. 1 Horizontal electro-spindle (N° 1) on the Y axis

Condition: used, Year of construction: 2012, power: 20 kW (27.19 HP), working width: 1,300 mm, number of spindles: 82, plate height: 90 mm, working length: 3,000 mm, The pick-up deadlines specified in the General Terms and Conditions apply. The absolute latest pick-up date is August 31, 2026! TECHNICAL DETAILS Working area, X-axis: 3,000 mm Working area, Y-axis: 1,300 mm Maximum panel thickness: 90 mm Total number of drilling spindles: 82 Fpodpfx Ahjzf Ibdedon Drilling units, Unit 1 (top) Spindles for vertical drilling: 31 Spindles for horizontal drilling in the X direction: 8 Spindles for horizontal drilling in the Y direction: 2 Drilling units, Unit 2 (bottom) Spindles for vertical drilling: 31 Spindles for horizontal drilling in the X direction: 8 Spindles for horizontal drilling in the Y direction: 2 Milling spindles Number of milling spindles: 2 Milling spindles, Unit 1 (top) Number of controlled axes: 3 Motor power: 4.5 kW Milling spindles, Unit 2 (bottom) Number of controlled axes: 3 Motor power: 4.5 kW Grooving units Number of grooving units: 2 Grooving units, Unit 1 (top) Unit: Fixed for creating channels in the X direction Max. tool diameter: 160 mm Motor power: 3.5 kW Grooving units, Unit 2 (bottom) Unit: Fixed for creating channels in the X direction Max. tool diameter: 160 mm Motor power: 3.5 kW MACHINE DETAILS Total installed power: 20 kW Machine programming software: BIESSEWORKS EQUIPMENT Automatic panel stacking system with motorized transfer Barcode scanner (manufacturer: SICK) CE marking Protective grating Safety mats The machine is sold and delivered in its actual and legal condition (“as is, where is”) based on photographic documentation and technical/commercial documents with a descriptive nature. The buyer has the right to inspect the goods before pick-up and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 8565

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, Digital automatic drilling machine BIESSE SKIPPER 130 Working condition. Fpjdporkm R Hjfx Ahdon Free for loading.
