plate thickness: mm
work piece width: mm
height over floor: 930 mm
machine weight approx.: 75 +( 27kg Untergestell) kg
dimensions L x W x H: 0,6 x 0,48 x 0,43 m
EDGE CHAMFERING MILLING MACHINE
Application: For chamfering
Machine table: WxD: 600 x 240mm
with limit stop bar LxH: 400 x 25mm
built-in tool: cutter approx. 50mm with 45° milling form
Chamfering width approx. 6mm
voltage: 380 V
with ON/OFF switch
table length mm
table width mm
max. workpiece weight 450 kg
table height 900 mm
U-axis +-60 mm
V-axis 60 mm
x-axis 450 mm
y-axis 300 mm
z-axis 350 mm
wire diameter - min. 0,2 mm
wire diameter - max. 0,3 mm
rapid traverse +-60 m/min
weight of the machine ca. 2,5 t t
dimensions of the machine ca. 2,9x3,5 m
1 Right hand feeding system
1 Eccentricpress 250 kN
4 Standard slide unit
1 Narrow slide unit
wire diameter range: up to 6,0 mm
stripmetal width: up to 80 mm
feeding length: up to 520 mm
output: 10 - 250/min
turning diameter 540 mm
turning length 535 mm
control SIEMENS Sinumerik
number of spindle speeds 75-5000
spindle bore 63 mm
total power requirement 28 kW
weight of the machine ca. 4,8 t
dimensions of the machine ca. 2,7 x 1,7 x 2,12 m
EVG COMPLETE MESH WELDING LINE - Type G7/126PV
Technical Details :
1. Mesh welding line EVG G7/126PV
Machine is manufactured in 1981.
- Max. Width mesh - 2.400 mm
- Max. Length mesh - 6.000
- Wire diameter range – 4 mm - 12 mm
- Max. speed - 70 strokes / min.
-Longitudinal wire spacings 100 mm, 150 mm, 200 mm
-Cross wire spacings 100 mm, 150 mm, 200 mm
-Longitudinal and cross wiress are from piece.
-The line is complete and still in working condition served by one man.
shaft length: max. 30 mm
capacity: 600 ST/min
wire diameter max.: 5 mm
working dimensions: 30 mm
dimensions electric cabinet LxWxH: 1,45x0,55x2,1 m
dimensions of machine: 2,95x1,5x2,15 m
dimensions of coil: 1,15x1,15x1,15 m
Orbital Cold Forming Machine! - Not not suitable for screw production!!!!!
- mechanic cold flow press / machine is unused!!!!
- Steel core bullets
- Rivets (almost all types: flat rivets, punch rivets, precision rivets, flat head rivets, etc. -----à not for manufac...
1 Feeding system right hand side
3 press units of 180 kN/each = total press capacity 540 kN
wire diameter range: up to 10 mm
stripmetal width: up to 100 mm
feeding length: up to 250 mm
output: up to 135/min
Macsoft - F413
CNC Wire Straightening 3D Bending and Cutting Machine 4 - 13 mm
MACH - ID 6851
Please Note: The information on this page has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We
wire diameter - max.: mm
wire diameter - min.: mm
wire length: mm
wire diameter - min.: 4 mm
wire diameter - max.: 12 mm
wire length: variable mm
total power requirement: ca. 10 kW
Weight approx.: 4,0 t
dimension machine xH: 1,9 x 4,2 x 2,0 m
transport measurements machine: 4,2 x 2,0 x 2,0 m
transport dimensions LxWxH: Haspel: 2,2 x 1,5 x 1,5 m
transport dimensions LxWxH: Bedienpult: 0,7 x 0,8 x 2,0 m
WIRE STRAIGHTENING AND CUTTING MACHINE with coil
The machine is currently pre-...
Max. workpiece size workpiece size: 850 x 500 x 400 mm. X/Y/Z travels 400mm x 250 mm.Maximum workpiece weight 100kg. UV travel 400 x 250 mm. Programmable Z-stroke 0 to 400 mm. Collision protection X Y Z U V. Taper angle +/- 30 degrees. Table movement 0 to 900 mm/min. Programmable wire feed speed 0.2 to 15 m/min. Programmable wire tension 3 to 30 N. Standard diamond wire guide 0.25 mm. Automatic wire threading. Automatic wire renewal. Max. Thread height 400 mm.
Machine dimensions LxWxH...
Macsoft - F412
CNC Wire Straightening 3D Bending and Cutting Machine 4 - 12 mm
MACH - ID 6850
US Standard Metric
Please Note: The information on this page has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its ac...
*Maschine is been refurbished by BIHLER in 1992*
1 Feeding system right hand side
1 Eccentricpress 250 kN
4 Standard-slide units
1 Narrow-slide unit
wire diameter range: 0,5 - 5,0 mm
stripmetal width: max. 40 (70) mm
feeding length: max. 320 mm
output: max. 132/min
LINE FOR CUTTING AND STRAIGHTENING RE-BAR/REBAR.
Automatic line is designed for straightening and cutting of smooth re-bar diameter from Ø6mm to Ø16mm and ribbed re-bar from Ø5mm to Ø12mm, depending on machine type.
Except straightening, machine cleans re-bar from dirt and rust.
Complete line set consists of wheel for re-bar pulley, machine for straightening and reception desk for straightened re-bar.
Machine operates by principle of „flying bushes“ (rings).
Instructions for use lin...
1 pce. Feeding system right hand side
1 pce. Cam press 25 kN
4 pcs. Slide units
wire diameter range: 0,5 - 2,5 mm
stripmetal width: max. 32 mm
feeding length: max. 170 mm
output: max. 225/min.
Richard Johnson and Nephew Barbed Wire Machine.
Complete with pay off
Refurbished machine and little used since.
Condition is the same as in the video when it was reconditioned by Century Steels.
Comes with wiring diagram, instruction Documents and wooden formers.
Link to video can be sent.
The machine was made by Johnson and Nephew of Manchester England. It is a very robust machine and many of these machines have been exported. The year of manufacture is 1977
The machine was refurbis...
Coil winding machine make VEB Koepen type FDW 5000
machine. # 87013
mx. bobbin diameter 200 mm
max. spool width 125 mm
The wire gauge is not recognizable, at the machine there is
at present a wire reel with 2,0 mm thickness
drive power 125 kw
dimensions 830 x 400 x 250 mm
- foot control
- discharge stand
used out of a factory liquidation, in good condition
- dimensions: 4600×1250×2120 mm
- weight 3400 kg - motors (26 kW total)
- 2D bending - bending from two coils simultaneously (from Ø5 to Ø8 mm), from one coil (from Ø10 to Ø12 mm)
- 3D bending - bending from one coil at a time (from Ø5 to Ø12 mm)
- maximum bending angle 180 degrees (2D and 3D)
- maximum workpiece length up to 2300 mm
- minimum workpiece length 100 mm
- Maximum material speed up to 110 m/min
- Maximum bending speed up to 1050 degrees/second
Two sets of United Wunderlich Model 60 Bonnell Spring coilers with heat treatment, wire pay offs, Books and wiring diagrams and some spares. Photos are of one set. Two sets available. Price is for one set.
