Used machining centers for stone and marble for sale (8)

Condition: used, Year of construction: 2003, x-travel 660 mm y-travel 355 mm z-travel 455 mm table surface area 760 X 355 mm table load 1,5 t Bdodpfeyy A Ansx Abwja T-slots 3 T-slot - width 18 mm control ULTIMAX 4 tool change unit 16 max. tool diameter 90 mm max. tool length 200 mm max. tool weight 7 kg spindle turning speed range 10.000 U/min spindle drive 7,5 kW 16 St. tool adaptor SK 40 feed max 28 m/min rapid traverse 35/35/30 m/min dimensions of the machine ca. 1,8 x 1,9 x 2,4 m weight 3 t total power requirement 21 kW Used vertical machining centre with double-arm tool changer. HURO ULTIMAX 4 CONTROL 10,000 RPM

Condition: used, Year of construction: 2020, functionality: fully functional, operating hours: 2,500 h, THIBAUT TC 625 – 5‑Axis CNC Bridge Saw (Used Machine) Bodpeyuvhfsfx Abweda Description For sale is a THIBAUT TC 625 5-axis CNC bridge saw in very well-maintained condition. The machine is ideal for processing natural stone, quartz composite, ceramics, and similar materials, and is especially suited for kitchen countertop and interior fitting production. Technical Data Manufacturer: THIBAUT SAS (France) Model: TC 625 Machine Type: 5-axis CNC bridge saw Year of Commissioning: approx. 2020 Machine No.: 04.19 Voltage: 400 V / 50 Hz Spindle Power: approx. 13.2 kW Spindle Speed: 0 – 6,000 rpm Blade Diameter: 300 – 650 mm X-Axis Travel: approx. 3,970 mm Y-Axis Travel: approx. 2,300 mm Z-Axis Travel: approx. 500 mm Max. Material Thickness: approx. 200 mm Condition Machine powered – demonstration possible by arrangement Spindle hours: approx. 2,500 h Excellent technical and optical condition Regularly serviced Ready for immediate use Features 5-axis CNC control Tilting worktable 3,600 × 2,000 mm Table adjustment from 0° to 85° Additional unloading table 3,600 × 400 mm Digital camera for slab imaging Tool and material probing system Vacuum lifter up to 500 kg ACS plunge cutting system Tool water cooling Software T'CUT basic software Vacuum lifter manipulation module Vein matching module Contouring and trimming module CAD/CAM software eT'CAM Application Areas Kitchen countertops Bathrooms and washbasins Staircases Processing of natural stone and quartz composite Ceramics and similar materials Sales Information Price: on request Location: Germany Availability: by arrangement Inspection / Test Run: Machine is powered – test possible

Condition: excellent (used), Year of construction: 2015, machine/vehicle number: 03814V2200, functionality: fully functional, operating hours: 2,416 h, input voltage: 380 V, type of input current: three-phase, travel distance X-axis: 2,200 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 280 mm, number of slots in tool magazine: 1, total height: 2,400 mm, total length: 3,000 mm, total width: 1,200 mm, overall weight: 1,100 kg, table length: 2,200 mm, table width: 280 mm, coolant supply: 3 bar, feed length X-axis: 2,200 mm, feed length Y-axis: 1,200 mm, feed length Z-axis: 280 mm, feed rate X-axis: 7 m/min, feed rate Y-axis: 7 m/min, feed rate Z-axis: 6 m/min, spindle motor power: 4,500 W, number of spindles: 1, rapid traverse Z-axis: 6 m/min, rapid traverse X-axis: 7 m/min, rapid traverse Y-axis: 7 m/min, rotational speed (max.): 18,000 rpm, rotational speed (min.): 1,000 rpm, spindle speed (max.): 18,000 rpm, spindle speed (min.): 1,000 rpm, table height: 1,200 mm, Equipment: rotational speed infinitely variable, NUMERICALLY CONTROLLED PANTOGRAPH WITH VERTICAL PLANE MODEL "VERTICAL 2200 OPEN" WITH 3 INTERPOLATED AXES FOR WORKING MARBLE AND GRANITE basic assembly: - range: x-axis=2200 mm. y-axis=1200 mm. z-axis=300 mm; Bedpfjygxc Aox Abweda - work surface L. 2500 x H. 1250 mm; - heavy carpentry-made structure in processed and painted steel; - Side openings with loops, both on the left and on the right, for processing oversized blocks with support rolls; - slabs and carter support in inox steel; - highly deep workbench made with extruded aluminium profile ; - slab locking with n°2 clamps with mechanical blocking device; - three-phase electro spindle hp 5 1/2 gas connection with perforated shaft and rotating joint for water passage for internal and external tool refrigeration, and inverter for variation to maximum 18000 r.p.m .; - openable polycarbonate protection for electro-mandrel, with safety micro; - axes movement by means of runners and sliding blocks of balls recircle; - dust tents for total protection of all moving parts; - water cooling tool system with centralized drain, including pump, decanting tanks and locking electrovalve; - electronic panel with console comprising numeric control, pc and monitor. Windows software included ARTCAM INSIGNA: - carrying out of reliefed and engraved writing, using all "true Type" fonts; - cad for carrying out drillings, cuts, engravings, millings and inlays; - import of most common types of files as dxf and dwg to create writings, drawings and stamps, reliefed and engraved logos, showr trays, sinks, arcs and portals; - automatic drilling for inserting bronze letters; - carrying out single and multiple sculptures in high and bas-relief; automatic switch off; 3D PLAN LASER laser copyng system to import manufactured products and tree-dimansional figures (bas and hight - relief) with interface and software for required dimensions

Condition: new, Year of construction: 2026, functionality: not functional, input voltage: 420 V, input frequency: 50 Hz, type of input current: three-phase, travel distance X-axis: 4,300 mm, travel distance Y-axis: 6,680 mm, number of axes: 9, number of slots in tool magazine: 15, total height: 4,100 mm, total length: 7,920 mm, total width: 9,000 mm, overall weight: 18,000 kg, Equipment: CE marking, documentation/manual, WatMachinery NHSB 3517 5-AXIS is a fully automated stone-processing production system engineered as a self-contained manufacturing cell. It integrates loading, multi-technology cutting, automatic part transfer, contouring, and finishing into one controlled process chain. By automating workpiece transport and positioning and executing machining operations in sequence, the NHSB 3517 increases throughput, improves repeatability, and reduces variability associated with manual handling and operator-dependent setups—delivering consistent quality shift after shift. Bdsdsylkf Tepfx Abwsa Built on a compact platform that combines a 5-axis sawjet and a 5-axis CNC contouring center, the machine supports diamond blade cutting for high-productivity straight and profile cuts, an independent 5-axis waterjet for internal geometries and tight radii, and hybrid strategies that use both technologies for optimized edge quality and process stability. The production cycle begins with ergonomic slab loading via a tilting table, followed by material alignment including vein-oriented positioning for visual matching. Primary cutting and separation are performed with automatic selection of blade, waterjet, or combined cutting. Parts are then transferred through an automated handling sequence using a vacuum manipulator system with eight vacuum cups (lifting capacity up to 500 kg / 1,100 lbs), enabling safe and stable slab and workpiece manipulation. A dedicated finishing workflow completes the process with automatic positioning on suction-cup fixtures, followed by unloading without manual intervention. The 5-axis head assembly is configured for multi-operation processing and includes a diamond cutting spindle, an independent 5-axis waterjet head, and multi-head edge-finishing units for efficient flat-edge polishing, supported by vacuum handling plates for secure, repeatable part manipulation. An integrated slab washing apparatus cleans the surface before vacuum operations to improve grip reliability and positioning stability. The machine can be supplied with an on-board camera (accuracy ±5 mm) to capture slab images for software-based nesting and defect avoidance, and probing systems such as a laser probe and stone perimeter probing to enhance dimensional accuracy and alignment. The industrial CNC controller features an operator-friendly HMI, supports DXF import and G-code execution, and also provides a manual mode for quick operations and simple cuts. Designed for manufacturers producing countertops, bathroom elements, stairs, and architectural stone components, the NHSB 3517 5-AXIS delivers higher automation, reduced manual labor dependency, and measurable gains in productivity and process consistency.

Condition: refurbished (used), functionality: fully functional, power: 30 kW (40.79 HP), input voltage: 400 V, input frequency: 500 Hz, workpiece length (max.): 3,400 mm, workpiece width (max.): 1,800 mm, workpiece height (max.): 200 mm, table length: 4,500 mm, table width: 2,300 mm, table height: 1,800 mm, table load: 500 kg, 5-Axis Waterjet Cutting Center equipped with: - integrated working tank - 4.200 bar full electric e-drive™ - 19” numerical control - abrasive pressurized tank - cutting head - watercad-cam software Bdedpfx Aboxbgvfewoa accessories included - 5 axis ±55° interpolating system and touchwave ce-ramic™ - loading and unloading system - light laser barriers Included expenses: - Installation of the machine(s) - Machine full-load start-up - Practical training to BUYER’S staff on the machine functions

Condition: used, Year of construction: 1995, x-travel 1700 mm y-travel 400 mm z-travel 400 mm Control Siemens 480 D Number of axles 4 St. table width 500 mm table length 2000 mm tooltaper DIN 2079 SK 60 SK 40 total power requirement 16,25 kW weight of the machine ca. 4750 kg dimensions of the machine ca. 3000x 2500x 2800 m Machine number 9599 Bodpfx Asvf Rhwobwjda - 4th axis / horizontal / diam. 315 mm - Chip conveyor - tool changer for 20 tools

Condition: new, Year of construction: 2026, For sale: versatile Eckert Opal Waterjet cutting system, ideal for processing stone (natural stone, marble, granite), but also suitable for a variety of other materials. Waterjet cutting is performed without thermal impact, enabling precise and clean cutting edges. Perfect for complex contours, inlays, cutouts, or demanding shapes in stone. Bsdpex A Tr Nsfx Abwjda 🛠 Technical Specifications & Equipment (Manufacturer Data) Working width: 1,000 – 6,000 mm Working length: 1,000 – 12,000 mm Cuttable material thickness (waterjet 2D): 0.5 – 250 mm Cuttable material thickness (waterjet 3D, optional): 0.5 – 150 mm Positioning speed: up to 25,000 mm/min Positioning accuracy: ± 0.025 mm Design: Gantry construction with closed steel profiles for maximum stability and durability. The cutting tank is statically decoupled and corrosion-protected. Control system: Modern CNC control with touch display (Corning® Gorilla® Glass) – intuitive to operate for efficient workflow. Cutting process: Pure water or abrasive waterjet cutting; optional 5-axis cutting head available for 3D/bevel cutting. Optional additional equipment (if available / to be specified): [e.g. “Pro-X 3D Cutting Head”, “Abrasive Cutting”, “Multiple Cutting Heads (e.g. 2-Head / 4-Head)”, “CAD/CAM Software”, “Water Softening System”, “Scraper Chain Conveyor”, “Wastewater / Filtration Unit”, etc.] 🎯 Ideal for: Stone and natural stone processing businesses, marble or natural stone design workshops. Companies requiring precise, heat-free cuts for contours, inlays, cutouts, or shaped stones. Operations that value clean cutting quality, minimal reworking, and high flexibility in terms of materials. Projects with complex shapes, bevel cuts, or 3D processing – especially with the optional 3D cutting head.

Condition: good (used), Year of construction: 2019, functionality: fully functional, We are selling our used THIBAUT 815 V4, a proven multifunction machine for the professional processing of natural and engineered stone. Bjdpfowu Rg Dsx Abweda The machine is in good, fully functional condition and ready for immediate use. Ideal for stonemasonry businesses, workshops, or restorers looking for a robust and versatile solution for cutting, milling, drilling, and polishing tasks.
