Used Mazak Multiplex 6300 Cnc for sale (352)

Condition: used, Year of construction: 2011, travel distance Z-axis: 2,150 mm, MAZAK QT NEXUS 450IIM year of production 2011 control MATRIX NEXUS C axis driven tools travel: Z axis 2150mm X axis 310mm Ppjdpfx Afjvt A Raj Tep Maximum turning diameter 580 mm Hydraulic chuck Kitagawa BB218 Spindle passage 165mm Maximum spindle speed 2000rpm -Tailstock -Probe -Chip conveyor with tub and pump -Holders -Documentation

Condition: used, Year of construction: 2003, Mazak Integrex E-410H Multi-Tasking Lathe with Mazatrol 640M Pro Control, Serial No. 164385 (2003). Country of Origin: Japan Please note: Toolholders/Tooling photographed in the toolchanger will not be supplied with this machine. Any available tooling will be a specifically described. Ppsdpfx Ajx T Df Def Tjp Please Note: This lot is located in Birmingham, UK. A charge of £4,500 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: good (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 265864, turning diameter: 350 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 195 mm, travel distance Z-axis: 560 mm, spindle motor power: 15 W, feed rate X-axis: 30 m/min, feed rate Z-axis: 33 m/min, torque: 233 Nm, distance table center to spindle nose: 687 mm, Equipment: documentation/manual, Mazatrol Smart Control. Spindle speed 5000 rpm. X/Z travel 195mm/560mm. Fitted with 215mm diameter. 3 jaw-powered chuck 12-station turret. Tailstock. Tool setter. Psdpfx Afsvfm H Ao Tjpp Part catcher.

Condition: like new (used), Year of construction: 2006, machine/vehicle number: 184620, Control: Mazatrol 640 Nexus X-way: 560 mm Ppodpfx Afjkn Dxqj Top Y-way: 410 mm Cdnxm9qiuu Z-way: 510 mm Table size: 900x410 mm Spindle cone: Sk40 Tool changer: 30 pl. Spindle speed: 12000 1/min IKZ: 15 bar Chip conveyour Machine weight: 5010 kg

Condition: ready for operation (used), Year of construction: 2018, spindle speed (max.): 5,000 rpm, travel distance X-axis: 225 mm, travel distance Z-axis: 605 mm, overall weight: 4,950 kg, controller manufacturer: MAZATROL, controller model: Smooth C, number of axes: 2, Horizontal turning machine manufactured in 2018. This Mazak QUICK TURN 200MA L features a maximum workpiece diameter of Ø 360 mm and a maximum workpiece length of 535 mm. It is equipped with a spindle speed of 5,000 rpm and a turret with 12 VDI positions. If you are looking to get high-quality turning capabilities, consider the Mazak QUICK TURN 200MA L machine we have for sale. Contact us for further details. • Max Workpiece Diameter: Ø 360 mm • Max Workpiece Length: 535 mm • Max Bar Capacity: Ø 65 mm • Spindle Nose: A2-6 • Spindle Bore: Ø 76 mm • Turret Tool Station: 12 VDI positions Additional equipment • Chip extractor Ppjdpfx Afeyuyh Ae Tep Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, turning length / mm control / centre height / mm Make / Model: MAZAK QUICK TURN 8NSP Technical Specifications: Maximum turning diameter: 160 mm Maximum swing over bed: 300 mm Spindle speed: up to 4,500 rpm Weight: 2700kg Equipment: Various accessories Psdoyukikspfx Af Tspp

Condition: used, Year of construction: 2015, x-travel 560 mm y-travel 430 mm z-travel 510 mm control Mazatrol Smart table surface area 900 x 430 mm max. table load 500 kg number of spindle speeds 40-12000 U/min rapid speed 42000 mm/min tool magazine with 30 Plätzen max. tool diameter 125 mm weight of the machine ca. 4800 kg Just 4,362 hours of pure machining! Capacity: External dimensions of the machine table: 900 x 430 mm Travel range X/Y/Z axis: 560/430/510 mm Distance from spindle head to table surface: Min: 150 mm Max. 660 mm Spindle: Spindle speed: 40-12000 (two electrical stages) Feed rate: Rapid traverse speed: 42000 mm/min Cutting feed rate: 1-8000 rpm ATC magazine: Tool magazine slots: 30 Tool shank type: MAS BT-40 Max. tool diameter: with adjacent tools: 80 mm without adjacent tools: 125 mm Max. total weight of tools in magazine: 120 kg Ppodpfx Aeyukgiof Tsp Equipment/accessories: Coolant system Vices (not shown in the photo) Tool holders Tools Documentation

Condition: used, Year of construction: 2012, x-travel 185 mm z-travel 385 mm control Mazatrol Matrix Nexus Maximum swing diameter 550 mm Maximum turning diameter 280 mm bar capacity 51 mm workpiece weight max. 200 kg main spindle speed 35-6000 U/min milling head speed 25-4500 U/min tool turret 12 Plätze rapid power traverse in X-and Z direction 30/33 m/min spindle bore 61 mm weight of the machine ca. 3800 kg Capacity: Chuck size: 6 inches Max. swing diameter: 550 mm Standard turning diameter: 221 mm Max. turning diameter: 280 mm Max. bar capacity: 51 mm Distance between spindle nose and turret edge: 84–469 mm Main spindle: Speed: 35–6000 rpm Spindle bore: 61 mm Spindle nose: A2-5 Ppjdpfx Afjyukgcs Top Tailstock: Tailstock body travel: 350 mm Max. thrust: 1962 N Turret: Number of tools: 12 pieces Tool size: External turning tool: 20 mm Internal turning tool: 32 mm Milling drill: 16 mm Milling tap: M16 x 2.0 mm End mills: 16 mm Milling spindle speed: 25–4500 rpm Equipment/Accessories: Tool holders Tools Powered tools Turning tool holders Coolant system Documentation

Condition: excellent (used), Year of construction: 2001, x-travel 185 mm z-travel 360 mm b-travel 460 mm control Mazatrol 640 T Maximum swing diameter 550 mm Maximum turning diameter 280 mm workpiece weight max. 200 kg bar capacity 51 mm main spindle speed 35-6000 U/min milling head speed 25-4500 U/min rapid power traverse in X-and Z direction 30/33 m/min Rapid traverse B axis 30 m/min tool turret 12 Plätze weight of the machine ca. 4100 kg Capacity: Chuck size: 6 inches Max. swing diameter: 550 mm Standard turning diameter: 221 mm Max. turning diameter: 280 mm Max. bar capacity: 51 mm Distance between spindle nose and turret edge: 80–535 mm Pedoyukf Sopfx Af Tjpp Main spindle: Speed: 35–6000 rpm Spindle bore: 61 mm Counter spindle: Speed: 35–6000 rpm Spindle bore: 52 mm Turret: Number of tools: 12 pieces Tool size: External turning tool: 20 mm Internal turning tool: 32 mm Milling drill: 16 mm Milling tap: M12 End mills: 16 mm Milling spindle speed: 25–4,500 rpm Equipment/Accessories: Tool holders Tools Powered tools Turning tool holders Coolant system Chip conveyor Documentation

Condition: excellent (used), Year of construction: 2019, 3-Axis CNC Machining Center MAZAK VCN-530C SmoothG Year of manufacture: 2019 Control: Mazatrol Smooth Travels: X-1050 mm Y-530 mm Z-510 mm Rapid traverse: 36 m/min Spindle max speed: 12,000 rpm Ppsdpsywv Dgjfx Af Tsp ATC tool magazine: 40 stations Spindle taper: SK40 Table: 1,300 x 550 mm Max. table load: 1,200 kg Through-spindle coolant (IKZ) High-pressure pump: 15 bar Mayfran chip conveyor (right side of machine) Renishaw workpiece probe Renishaw tool probe

Condition: good (used), Year of construction: 2008, Table size, pallet size: 500 x 500 mm Pallet quantity: 2 Maximum workpiece size: 730 x 500 mm Maximum table load: 500 kg Travel paths: X-axis: 630 mm Y-axis: 765 mm Z-axis: 510 mm C-axis: 360° (turntable) A-axis: +30°/-120° (swivel table) Speed range: 12 000 rpm Tool holder: SK 40 Tool positions: 80 Internal tool cooling: 20 bar Main drive power: 26 KW Machine weight: 17 000 kg Space requirement (LxWxH): 5 500 x 4 000 x 3 400 mm Control system: Mazatrol Matrix Ppedpfx Afor Drcme Top Accessories: Chip conveyor, complete documentation for the machine.

Condition: reconditioned (used), Year of construction: 2007, MAZAK QUICK TURN NEXUS 200-II MSY Max. turning diameter: 380 mm Max. machining length: 511 mm Max. milling speed: 4,500 rpm Max. spindle speed: 5,000 rpm Max. bar diameter: 65 mm Ppedpfx Afsyhwy Io Tsp Machine is equipped with: - CNC control Mazatrol Matrix - KITAGAWA three-jaw chuck for main spindle, diameter 210 mm - KITAGAWA three-jaw chuck for secondary spindle, diameter 169 mm - Tool Eye - C-axis - C-axis on sub-spindle - Y-axis - Interface for bar loader magazine - Automatic parts catcher - Reinforced coolant pump - Chip conveyor - 8 stationary tool holders - 2 driven tool holders

Condition: used, Year of construction: 2013, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 740 mm, controller manufacturer: Mazatrol, controller model: Matrix Nexus, workpiece weight (max.): 700 kg, total height: 2,814 mm, total length: 4,690 mm, total width: 2,330 mm, table width: 500 mm, table length: 500 mm, overall weight: 11,000 kg, spindle speed (max.): 18,000 rpm, Equipment: documentation/manual, CNC Horizontal Machining Centre CNC Control Mazatrol Matrix Nexus Pallet table size 500 x 500 mm Number of pallets 2 Table load 700 kg Pedpeytc Nmofx Af Tspp Movement X-Y-Z-axis 730x730x740 mm Table indexing 0,001 ° Spindle taper CAT 40 Spindle speed 18.000 1/Min Spindle motor 30/22 kW Magazin capacity 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: used, Year of construction: 2008, x-travel 410 mm y-travel 570 mm z-travel 140 mm control Mazatrol Matrix Maximum working diameter 545 mm Maximum working length 519 mm main spindle speed 35 - 6000 U/min tool taper Capto C6 rapid traverse y/x/z axis 30/26/33 m/min Performance/capacity: Max. swivel range: 545 mm Max. machining diameter: 545 mm Max. outside diameter for bar work: 51 mm Max. machining length: 519 mm Max. workpiece weight: -Chuck work: 150 kg -Bar work: 200 kg Main spindle: Spindle speed: 35-6000 rpm Spindle bore diameter: 61 mm Max. torque: 161 Nm Tailstock: Rapid traverse: 8 m/min Travel range (advance/return): 434/281 mm Milling head: Milling head type: Single spindle with ATC Tool shank type: Capto C6 Tool size: External turning tool: 20 mm Internal turning tool: 32 mm Milling tool: Max. 90 ? x 200 long mm Milling spindle speed: 15-12000 rpm Equipment/accessories: Psdpfxoyt R Ido Af Tspp -Chip conveyor -Mist extraction -Tools -Documentation

Condition: used, Year of construction: 2020, turning diameter 380 mm turning length 511 mm control Mazatrol SmoothG turning diameter over slide 276 mm max. swing diameter over bed 675 mm Standard machining diameter 276 mm bar material dia. 65 mm x-axis 234 mm rapid traverse X-axis 30 m/min z-axis 625 mm rapid traverse Z-axis 33 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 spindle bore 76 mm Motor output (40%ED) 26 KW 22 KW Max. Torque 465 Nm turning speeds 6000 U/min Main drive power 11 KW Max. Torque 90 Nm Milling spindle speeds ( driven tools) 35-6000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20x2,5 Switching time one turret station ca. 0,20 sec coolant tank 180 l connected load 46,2 kW weight of the machine ca. 5,9 t Ppsdjtugggepfx Af Top dimensions of the machine ca. 2,7 x 1,9 x 1,9 m incl. the following accessories: - Signal light (3-colour LED), rectangular - High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min, pressure (at pump) 5 bar. - Additional coolant nozzle main spindle - Preparation for oil mist extraction electrical/mechanical flange 98mm - Preparation for bar feed - Robot interface (Advance/Profibus) - Chip conveyor with low ejection height - Overload monitoring system - Drilling cycle with torque-dependent chip breaking - Preliminary use of a hollow clamping cylinder on counter spindle - Hollow clamping device incl. draw tube + cylinder - Clamping chuck Hainbuch Spanntop Nova Axfix mini size 52 - Chuck Hainbuch Spanntop Nova Axfix special mini size 52 - 2 x collets - Changing device for collet chuck STANDARD ACCESSORIES Automatic on/off and warm-up function Air blowing device on the chuck on the counter spindle Use of linear systems with guide carriage USB connection (1 connection) Set of manuals in electronic form on CD C-axis main spindle Input accuracy 0.0001° Spindle positioning counter spindle without C-axis Input accuracy 0.001° Tool turret with 12 stations VDI, Operator door with locking switch Double foot switch for both main and counter spindle Hydraulic pressure interlock Fully enclosed work area Work area lighting Safety precautions in accordance with global standards High-performance coolant system (520W) Flow rate max. 11.5 l/min. Complete coolant system Automatic opening/closing of the chuck jaws Automatic tool eye Absolute positioning system Preparation for chip conveyor (lateral) Synchronisation of main and counter spindle Synchronised tapping with milling spindle Relocation Detector Mazatrol SmoothG control 19" LCD colour screen (touch screen) User macro (600 variables) EIA/ISO input function Optional stop (optional stop) Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN SD memory card I/F - Second-hand machine without warranty - All dimensions, weights and performance specifications are non-binding

Condition: used, turning diameter max. 360 mm turning length 505 mm control Mazatrol SmoothC max. swing diameter over bed 660 mm swing diameter over slide guides max 255 mm bar material dia. max. 80 mm turning speed range - spindle 35 - 4000 U/min max. torque on the spindle 358 Nm x-axis 225 mm rapid traverse X-axis 30 m/min z-axis 605 mm rapid traverse Z-axis 33 m/min spindle nose A2-8'' spindle bore 91 mm spindle hollow 80 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40%ED) kW tailstock quill taper MT 5 Travel- tailstock 565 mm Axial pressure max 5000 Nm Tool turret 1 Numbers of tools 12 (angetrieben) turning tool - shaft cross cut 25 x 25 mm tool taper BMT Required air-pressure 5 / 160 bar / l/min voltage 400 V coolant tank 180 l engine output 18,5 (30min Betrieb) kW Rated power (100% continuous operation) 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 3,6 x 2 x 1,8 m Machine incl. the following special accessories: Chip conveyor on the right side Productivity package C - special according to storage machine This package includes: High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min Preparation for chip conveyor (lateral) Psdpev Dxw Rjfx Af Tepp Automatic tool eye STANDARD ACCESSORIES Transformer for the European market Use of linear systems with guide carriage SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB memory interface (1 slot) Spindle bore 91 mm Set of manuals in electronic form on CD Mazak standard colour CE marking, metric, 50 Hz C-axis input accuracy 0.0001° NC controlled tailstock Tailstock pressure adjustment Tailstock with fixed quill MK5 SAFETY DEVICES Operator door with interlock switch Double foot switch Hydraulic pressure lock Fully enclosed work area Work area lighting Safety precautions according to global standard COOLANT SUPPLY Grundfos coolant pump type MTA (0.25kW / 7.6L/min) Complete coolant system Automatic switch-off via circuit breaker triggering MESSSYSTEM Absolute positioning system NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothC 10.4’ colour screen User macro (600 variables) EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN Various tool holders - All dimensions, weights and performance data are non-binding - Used machine without warranty -

Condition: used, turning diameter 340 mm turning length 575 mm control Mazatrol SmoothEZ max. swing diameter over bed 695 mm Standard machining diameter 235 mm bar material dia. max. 65 mm x-axis 215 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 10 m/min z-axis 605 mm rapid traverse Z-axis 30 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 spindle bore 76 mm Motor output (40%ED) 15 KW 11 KW Max. Torque 167 Nm turning speeds 35 - 6000 U/min spindle nose A2-5 Motor output (40%ED) ca. 7,5 KW Power (continuous operation) 5,5 KW Max. Torque 53 Nm Milling spindle speeds ( driven tools) 20 - 4500 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20 coolant tank 225 l Chuck diameter main spindle 8 '' Chuck diameter counter spindle 6 '' w-axis 585 mm rapid travel W 30 m/min c-axis 555 weight of the machine ca. 4,9 t dimensions of the machine ca. 2,8 x 2 x 1,8 m Special accessories: - Chip conveyor, hinged belt, side ejector - Production package, this package includes Preparation for bar feed Automatic parts catcher (Ø:80mm x L:120mm x 2.5 kg) 15 bar high-pressure coolant system Preparation for chip conveyor (lateral) Signal light (3-colour LED), rectangular C-axis counter spindle 0.0001° Automatic tool eye 8" power chuck Kitag. BR08 & Cyl. SR1566C (HD1) GENERAL MACHINE OPTIONS Air blowing device on the chuck (counter spindle) Transformer for the European market Linear roller guides SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB - Memory Interface (1 slot) CE marking CE marking, metric, 50 Hz Counter spindle positioning 0.0001 degrees without C-axis Tool turret with 12 stations Y-axis control ADDITIONAL PROCESS SOFTWARE Smooth restart function / restart mode Set of manuals in electronic form on CD Main spindle motor AC 15 kW (20 hp) 2nd spindle motor AC 7.5kW (20 hp) Main spindle motor AC 7.5kW MAIN SPINDLE C-axis main spindle Input accuracy (contour/index) 0.0001° Mazak standard colour (F white(fine)/S black) Automatic switch-off via circuit breaker trip Double foot switch Hydraulic pressure interlock RFID door interlock Safety foot switch with locking mechanism Safety measures according to worldwide standard Work area lighting Complete coolant system Automatic opening/closing of chuck jaws (main and counter spindle) Feedback of the chuck status (main and counter spindle) Feedback of the chuck status via sensors. 8" power chuck 6" power chuck (counter spindle) Absolute positioning system Synchronous tapping with milling spindle Relocation Detector NC control Mazatrol SmoothEz 15" colour Lcd (touch screen) User macro (common variables: 600 pairs) EIA/ISO package EIA/ISO - input function EIA/ISO - additional functions Bolt line interpolation 3D tool compensation Workpiece coordinate rotation Geometric function Scaling External data input/output Pjdpfxewngklj Af Tspp Tapping function (G33) Reverse feed rate G93 G37 Tool length measurement Polar coordinate input (EIA) Optional stop Additional workpiece coordinate systems 300 pieces User macro (600 variables) Mazak tapping/drilling cycle EIA/ISO - input function Scaling External data input/output Thr...

Condition: used, Year of construction: 2019, x-travel 2.000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 22 kW distance spindle centre table top edge 140 - 860 mm table load 1700 Kg rapid travel x/y/z 50 m/min table width 820 mm table length 2500 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz Pjdpotuggcsfx Af Tepp coolant tank 450 l high-performance coolant system 25 bar total power requirement 46,7 kW weight of the machine ca. 14,8 t dimensions of the machine ca. 4,3 x 3,6 x 3,1 m STANDARD ACCESSORIES Transformer for the European market USB port (1 port) Mazak standard colour Spindle speed 12,000 min-1 (steep taper 40) Work area lighting SAFETY DEVICES Operator door with locking switch Work area panelling The splash guard encloses the working area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply through spindle (pressure at the pump = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of quality components. FACTORY AUTOMATION Automatic switch on/off and warm-up function Automatic switch-on of a warm-up cycle via digital timer MEASUREMENT SYSTEM Tool length measurement and tool breakage detection CHIP DISPOSAL Factory preparation for chip conveyor (left) NUMERICAL CONTROL Fixed control/operating unit Relocation Detector Mazatrol SmoothG control unit 19" LCD colour screen (touch screen) Mazak tapping/drilling cycle Tornado (Mazatrol) By drilling and tapping in helical machining mode, a wide range of diameters a wide range of diameters can be machined at high speed with a wide range of diameters can be machined at high speed with just one tool. This function minimises programming and machining times. EIA/ISO input function Tool path check in the background The tool path of a programme can be checked even if another programme number is programme number is called up and processed in automatic mode. 3D coordinate conversion Shape compensation for rotating axes Mazacc 2D software (contour correction) Accuracy is maintained at high feed rates. Mazacc-3D software package for high-speed machining High-speed and high-accuracy machining for contours defined in the finest programme contours defined in the finest programme increments. MAZACC-3D high-speed software package (NO456) is additionally required. Control with high smoothing Interface for LAN SD Memory Card I/F Smooth standard software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes - NO497 D) High accuracy control for finishing operations - Seamless corner point control - Variable acceleration control - Ultra high speed machining mode - NO498 Rapid traverse paths Rounding function Absolute positioning system Machine incl. the f...

Condition: used, Year of construction: 2012, turning diameter 203 mm turning length 300 mm control Mazatrol Smart Distance spindle end - turret 99-434 mm max. turning diameter 280 mm bar material dia. 51 mm travel -x axis 200 mm travel -z axis 340 mm spindle turning speed range 35 - 6000 U/min rapid traverse X-axis 33 m/min rapid traverse Z-axis 36 m/min spindle bore 61 mm Tool turret 12 -fach turning tool - shaft cross cut 20 Boring bar- Ø 32 mm workpiece weight 150 kg spindle nose A2-5 taper in tailstock-quill MK4 Travel- tailstock 350 mm total power requirement 16,3 kW weight of the machine ca. 3,5 t dimensions of the machine ca. 1,9 x 1,6 x 1,8 m Special accessories: Autom Tool Eye Spindle orientation Signal light Additional coolant nozzles above the chuck Automatic switch-off Interface for bar feed Automatic parts catcher Ø 51 x L:100 x 2.5 kg Workpiece conveyor for automatic parts catcher with workpiece tray Ppedpsynbd Eefx Af Top Chip conveyor, side ejection Includes: Automatic short bar loading magazine LNS QUICK LOAD SERVO 80_S2 Diameter range: 6 - 80 mm round and hexagonal material Bar lengths: 350 - 1600 mm, however max. headstock length /UVV Weight max. 67 kg / bar Burr-free bars or bar sections Depth 600 mm for holding bars Input voltages from 200 – 460 volts / operating voltage 24 V DC, LNS control programmed on SIEMENS STEP 7 PLC, flexible control panel with large screen, user guidance via symbols for easy operation and adjustment. Device cover with 2 viewing windows made of Plexiglas.

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, CNC Turning- and Milling Center (Multi-functional-Machine) | Brand: MAZAK Type: INTEGREX e-650H II | Year of construction: 07/2009, Commissioning: November 2009 The machine can be inspected under power by appointment. Condition: Fully functional / operational. Operating hours (as at 10 March 2026): - Total: 91.430 h - Automatic operation: 52.054 hours - Automatic machining: 38.974 hours - Pure machining: 31.316 hours TECHNICAL SPECIFICATIONS: Ppedpfx Afoyuq Dzj Tep Workspace: - Max. Swing diameter: 920 mm - Max. Swing diameter over tool slide: 920 mm - Max. Turning diameter: 1.100 mm Main spindle: - Max. speed: 1.600 rpm - Min. speed: 35 rpm - Spindle bore: 260 mm (1.000 rpm) - Spindle nose: A2-11" - Spindle bearing inner diameter: 220 mm - Rated power (30 min. operation / 100% continuous operation): 45.0 / 37.0 kW - Max. torque: 4.500 Nm Tailstock (programmable): - Chuck: MK 6 Milling spindle: - Turret type: Single-spindle with ATC - Tool shank: Steep cone 50 - Max. tool diameter: 260 mm - Max. tool length: 500 mm - B-axis indexing increments: 0,0001° - B-axis positioning for turning - Min./max. milling spindle speed: 35 - 10.000 rpm - Milling spindle motor, AC: 37 kW Travel ranges: - X-axis: 1.025 mm - Y-axis: 650 mm - Z-axis: 6.423 mm - B-axis swivel range: 240° Dimensions: - Spindle centre height: 1.350 mm - Length: 13.267 mm - Width: 3.938 mm - Height: 3.920 mm - Weight: 41 tons Additional information: - Rated power (100% continuous operation): 99,5 kVA Automatic tool changer: - Number of tools: 120-position, SK50 DIN 69871 SPECIFICATIONS / SPECIAL ACCESSORIES: - Numerical control: MAZATROL MATRIX - Documentation - CE marking - Further excellent optional extras ... Without guarantee of completeness and correctness of the technical information and the equipment. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: used, turning length / mm control / centre height / mm MAZAK SUPER QUICK TURN 15M-Y MARKII CNC lathe Travel distances X-axis: 180 mm Y-axis: 100 mm (± 50 mm) Z-axis: 620 mm Spindle Speed range: 35 – 5,000 rpm Ppjdeyukidjpfx Af Tsp Power Motor power: 15 kW (approx. 20 hp) Equipment/accessories Extensive accessory package (see images) Various tools and holders Additional accessories included in delivery as shown in the image

Condition: excellent (used), Year of construction: 2017, Mazak Optiplex Nexus 3015 Fiber 4KW Laser Cutting Machine Manufacturer: Yamazaki Mazak Corporation Type: Optiplex Nexus 3015 Fiber 4KW Year of manufacture: 12/2016 Condition: used, very good, under power Availability: from July 2023 Operating hours: Time CNC AN 16.276h Time Laser AN 15.653h Time automatic operation 11.096h Cutting time 10,964h Total cutting time 7,365h CNC control: MAZATROL PREVIEW 3 Weight: 12800 kg Power requirement: 57 kVA. Dimensions: 8,490mm x 3,485mm x 2,010mm Axis travel: 3,100mm x 1,580mm x 110mm GENERAL MACHINE OPTIONS 6981SD120 1 set of adjustment tools 6981TL307 Support grid (distance between bars 100mm) 6981AS670 Automatic calibration device 6981SD154 Non-contact height sensing with repeat function 6981AS684 Nozzle cleaning brush 6981AS678 Focus position adjustment 6981SD168 Manual workpiece clamping 6981SD130 Machine feet / leveling shoes 6981SD282 Machine status indicator light 6981SD216 NC monitoring for shielding gas pressure 6981SD189 Without resonator 6981NO513 Programming function on the control unit via fixed programs 6981CV222 Collecting container for material waste 6981NO612 Cutting table layer detection 6981EL110 Transformer for the European market 6981SD200 Additional selector switch for cutting gas CUTTING HEADS 6981LN705 Multi-Control cutting head 6981LN005 Lens for Multi-Control cutting head 6981LN610 Cassette for focus lens Multi-Contro cutting head 6981LN602 Protection window for Multi-Control cutting head 5 pieces NOZZLES 6981NZ068 Mazak Hi-Acc Pencil Nozzle(Sgl)1.0,3.0Mm 5 pieces each 6981SD317 Mazak Hi-Acc Pointed Nozzle (S)1.2,1.5,2mm each 5 pieces 6981SD303 Mazak precision nozzle adapter (8 pieces) AUXILIARY GAS LINES 6981TL321 3rd auxiliary gas line (30 bar) PAINTING 6981SD728 Mazak standard color PROTECTIVE HOUSING 6981CC096 Laser safety screen (5 pieces) SAFETY DEVICE 6981SD030 Work area lighting 6981SD748 Machine with CE mark 6981ES230 Preparation for dust separator Psdpfx Afeyuchxs Tjpp FACTORY AUTOMATION 6981AS050 Automatic switch-off via circuit breaker trigger The power supply is switched off at the end of a program. PALLET CHANGER 6981PC010 2-fold pallet changer. The next workpiece can be prepared during processing. NUMERICAL CONTROL 6981NC319 15″ Xga Color Tft monitor 6981NO869 LAN interface 6981NC083 Mazatrol Preview 3 control unit 6981FT575 NC repeat function 6981MZ200 Relocation Detector 6981NO870 USB interface for PC MACHINE MODEL 6981SD185 Preparation for 4kW resonator GENERAL MACHINE OPTIONS 6981AS662 Automatic nozzle change magazine with 8 slots 6981AS685 Nozzle cooling function 6981DEAA002 Fiber Laser Resonator 4kW incl. cable and cooling unit 6981SD118 Intelligent monitoring + focus point detection 6981RB165 Workpiece lifting table (CE) PERIPHERAL EQUIPMENT INCLUDED 6981DEES001 Extraction unit for Donaldson DFPRO4 laser cutting machine DOCUMENTATION 6981SD073 Set of manuals in electronic form on CD

Condition: excellent (used), Year of construction: 2016, Mazak Optiplex 3015 Fiber 4KW Laser Cutting Machine Manufacturer: Yamazaki Mazak Corporation Type: Optiplex Nexus 3015 Fiber 4KW Year of manufacture: 05/2016 Condition: used, very good, under power Availability: from May 2023 Operating hours: Time CNC AN 29.999h Time laser AN 15.653h Time automatic operation 11.839h Cutting time 28,708h Total cutting time 6,665h CNC control: MAZATROL PREVIEW 3 Weight: 15000 kg Travel: 3,100mm x 1,580mm x 110mm Power requirement: 54 kVA. GENERAL MACHINE OPTIONS 1 set of adjustment tools Support grid (distance of the bars 100mm) Automatic calibration device Non-contact height sensing with repeat function Nozzle cleaning brush Focus position adjustment Manual workpiece clamping Machine feet / leveling shoes Machine status indicator light NC monitoring for shielding gas pressure without resonator Programming function on the control unit via fixed programs Collecting container for material waste 6981NO612 Cutting table layer detection Transformer for the European market Additional selector switch for cutting gas CUTTING HEADS Multi-Control cutting head Lens for Multi-Control cutting head Cassette for focus lens Multi-Contro cutting head Protection window for Multi-Control cutting head 5 pieces NOZZLES Mazak Hi-Acc Pencil Nozzle(Sgl)1.0,3.0Mm each 5 pieces Mazak Hi-Acc Pointed Nozzle (S)1.2,1.5,2mm each 5 pieces Mazak precision nozzle adapter (8 pieces) AUXILIARY GAS LINES 3rd auxiliary gas line (30 bar) PAINTING Mazak standard color PROTECTIVE HOUSING Laser safety screen (5 pieces) SAFETY EQUIPMENT Work area lighting Machine with CE mark Preparation for dust separator FACTORY AUTOMATION Automatic switch-off via circuit breaker triggering The power supply is switched off at the end of a program. PALLET CHANGER 2-fold pallet changer. The next workpiece can be prepared during processing. NUMERICAL CONTROL Psdpfxsyucguo Af Topp 15″ Xga Color Tft monitor LAN interface Mazatrol Preview 3 control NC repeat function Relocation Detector USB interface for PC MACHINE MODEL Preparation for 4kW resonator GENERAL MACHINE OPTIONS Automatic nozzle change magazine with 8 slots Nozzle cooling function Fiber Laser Resonator 4kW incl. cable and cooling unit Intelligent monitoring + focus point detection Workpiece lifting table (CE) PERIPHERAL EQUIPMENT INCLUDED Extraction unit for Donaldson DFPRO4 laser cutting machine DOCUMENTATION Set of manuals in electronic form on CD

Condition: used, Technical details: x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm turning speeds: 35-10.000 1/min spindle: 37 / 30 kW max. torque on the spindle: 525 / 206 Nm Tool bore: BT 50 Pedpfswix E Rox Af Tjpp rapid traverse: 60 m/min tool change unit: 160 Pos. size of pallet: 500 X 500 mm control: MAZATROL 640M Nexus c-axis: 0,001° x 360.000 workpiece weight: 1.000 kg workpiece height max.: 1.000 mm interference area: 900 mm 2 pcs. horizontal machining centers (HCN 6000 + HCN 6000-II, 2008), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, accessories for both machines: 18 pallets, approx. 300pcs. toolholders, miscellaneous devices for workpiece-clamping... *

Condition: used, Technical details: x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm turning speeds: 35-10.000 1/min Ppjdpfxowix Hhe Af Top spindle: 37 / 30 kW max. torque on the spindle: 525 / 206 Nm Tool bore: BT 50 rapid traverse: 60 m/min tool change unit: 160 Pos. size of pallet: 500 X 500 mm control: MAZATROL 640M Nexus c-axis: 0,001° x 360.000 workpiece weight: 1.000 kg workpiece height max.: 1.000 mm interference area: 900 mm 2 pcs. horizontal machining centers (HCN 6000-II + HCN 6000, 2005), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, *
