8
Steam pressure: 42bar, steam temperature: 400°C, rotational speed: 1500/min, output: 2.8-4.8t/h, with Generator DKB 80/500-4TS.
B2crtyunu
6
10330 kVA EXC 62 V ONLY UVW 1500 REV /MİN 50 Hz Cos:0,9 660 A EC 34 AMB TEMP 43 C STEAM TURBINE WITH WORKING CONDITIONS
Bzqhobwbro
13
COMPLETE ELECTRIC POWER STEAM TURBINE SIEMENS SST-300
YOM 2019
Bsq82bir
INCLUDES:
1.TURBINE MODEL SST- 300. CEE2L/V50.A_DB. MAX. POWER OUTPUT 14,2MWT with two controlled extraction, V50.A condensing blades,
Inlet steam parameters 37bar, 445°C, 60t/h (required boiler parameters).
2. PROTECTIVE AND SECURITY EQUIPMENT.
3. ELECTRONIC CONTROL SYSTEM.
4. LUBRICATING OIL SYSTEM.
5. STACKING AND WATER STATION UNIT.
6. SPECIAL TOOLING OF THE TURBO UNIT.
7. GENERATOR OF EL. POWER.
8. ELECTRICAL DEVICES....
6
Serial: T-5630
1 UNIT USED RD8MO STEAM TURBINE:
Hours: 10.000
5238kw
Gear: Single reduction double helical; 4750 RPM to 1500 RPM
1 UNIT USED INDAR BZK-710-L/A-4
ALTERNATOR
Serial: 4633
Build: 2003
6550 Kva 1500 RPM 6.300V – 50Hz
CONTROL PANEL INCLUDED
Control , protection and synchronization panel and auxiliary drives switchboard for one steam turbine Tuthill 5.2MW.
CONDENSER INCLUDED
Btfc27bvjf
Surface Condenser 42’2” x 72” x 113”
Inlet Steam Plenum 120” x 56”
Twin Element 2 Stage Condens...
9
Nominal output: 22 KW to 50 KW
Speed: 2980 rpm
Live steam pressure: 12.3 bar to 30 bar
Live steam temperature: 300 ° C to 300 ° C
Evaporation pressure: 2.6 bar to 2.6 bar
spec. Steam consumption: 43.7 kg / KWh to 33.7 kg / KWh
Live steam quantity 0.96 t / h max - 0.41 t / h max
Blade length 24mm
Duese Form: D - Form A
E83szwv
Implementation 7 to 10
Valve 4 (6.3 cm³) to 2 (2.5 cm³)
Turbine unit Nadrowski, 294 kW, 170°C, 1.35 bar
9tunozc
6
System includes (1) Steam Turbine KK&K CFR 3, fresh/ outlet steam pressure: 18-28/ 9-12bar, fresh/ outlet steam temperature: 250-310/ 278°C, max. power: 200kW, output: 3.3-9.5t/h (2) Steam Turbine KK&K CF 8, fresh steam pressure: 8-11.6bar, fresh/ outlet steam temperature: 200-240/ 74°C, max. power: 714kW, output: 1.08-4.16t/h (3) Generator with two shaft ends (4) Water Condensor, with condensate pumps (5) Switchgears and additional elements.
Jxzmp3
N.2 STEAM TURBINES "KALUGA" - 2004 - 3.6MW
Serial numbers: 13201 and 13202
Still installed and completed with all their components
English technical documentation available.
Bwztn0dcue
We are available to negotiate one turbine or both.
10
Back pressure steam turbine
Manufacturer: Blohm + Voss Industrietechnik GmbH
Live steam pressure: 26 bar(a)
He3dduc9
Live steam temperature: 470 °C
Nominal mass flow: 31 t/h
Exhaust pressure: 1.2 bar(a)
Nominal terminal power: 5375 kW
Nominal apparent power: 6720 kVA
Nominal speed: 10043 rpm
Gear: planetary gear (type: RTP 45II, manufacturer: BHS-Cincinnati Getriebetechnik GmbH)
Generator: three-phase synchronous generator (type: S5E710M52-4SE+WK, manufacturer: LDW Lloyd Dynamowerke GmbH, brushl...
3
USED SHIN NIPPON MACHINERY STEAM TURBINE GENSET
2000KW 60HZ 3300V 4P 1800RPM
Hjrxer9
STEAM INLET PRESSURE 2.73Mpa
STEAM OUTLET PRESSURE 1.45Mpa
15
VerdiCorp ORC System, High Quality.
Brand new, never used.
Output Power 200Kwe.
Bsndc22xy7
70% discount form buyng price.
Transport, installation and service excluded
Turbine unit Turbine factory Nadrowski, 330 kW, 170°C, 1.35 bar
Bm8wz3tgmt
2
Rated power: 37kW, rated current: 73.35A, max. rotational speed: 990/min, weight: 520kg, documentation available, machine is as good as new.
Cxvy7vbw
11
Back pressure steam turbine:
Manufacturer: Blohm + Voss Industrietechnik GmbH
Type description: MARC 2 - B00
Construction year: 2004
Live steam pressure: 26 bar(a)
Live steam temperature: 480 °C
Nominal mass flow: 26 t/h (different load cases see attached data sheets)
Exhaust pressure: 1.2 bar(a)
Nominal terminal power: 4435 kW
Nominal apparent power: 5544 kVA
Nominal speed: 11217 rpm
Gear: planetary gear (type: RTP 45E2, manufacturer: BHS Getriebe GmbH)
Generator: three-phase synchronous genera...
7
USED SHIN NIPPON MACHINERY STEAM TURBINE 5000KW/6250KVA 1997YOM
INLET :1.5Mpa
B7rmrzlrv3
OUTLET: 0.03Mpa
4
There are two induction motors available, 1x 2AD180D, 1x 2AD160B, weight: 205kg, condition: 1x new, 1x used.
Bfpj2hzl8w
1
Power: 30kW, was overhauled two years ago.
B0cir8uyb8
1
Power: 37kW, rotational speed: 1187/min, max. current: 74.3A, weight: 363kg.
Brgcf8pmkj
4
Max. steam temperature: 400°C, working pressure: 4-31bar, max. power: 632kW, with Synchronous Generator AVK DKBN 100K/ 800-4, power: 813kVA, current: 1173A.
Btlpzpq0
