Used Scm Class S 630 for sale (3)

Condition: new, The SCM S630 CLASS thickness planer is a practical heavy duty thicknesser with robust industrial design. All controls and indicators are at the front control panel The machine can plan parts up to a massive 300 mm thickness and 630 mm width. The SCM feed system uses up to three driven upper feed rollers. They have a large diameter and are power driven Gtedpfxjdccuko Afasu The first roller is sectional The two outfeed rollers are rubber coated. Max working width 630 mm Main motor power 7 kW 9.5hp Worktable dimensions 640 x 1000 mm Working height (min / max) 3.5 / 300 mm Maximum stock removal 8 mm Minimum working length 260 mm Minimum working width 10 mm Cutterblock speed 4500 rpm Cutterblock diameter 120 mm No of knives 4 Dimensions of standard knives 630 x 35 x 3 mm Variable Feed speeds 4 - 20 m/min Dust exhaust diameter 150 mm

Condition: used, Year of construction: 2017, Max. working width: 630 mm Number of knives: 4 pcs Cutterblock: Tersa cutterblock Motor brake: Yes Max. thicknessing height: 300 mm Min. thicknessing height: 3.5 mm Max. chip removal: 8 mm Thickness display: digital display Infinitely variable feed speed: 4-20 m/min Gtodpfx Afoyfwg Reaeu Thicknessing table guidance: 2-point Thicknessing table spindles: 4 pcs Infeed rollers: steel, serrated Outfeed rollers: rubber, 2 pcs. Noise reduction: Yes Weight approx.: 925 kg Motor power: 7.5 kW Extraction diameter: 150 mm Stock location:

Condition: used, Technical data: Max planing width: 630 mm Max planing height: 300 mm Cutterhead diameter: 120 mm Number of knives: 4 Number of feed rollers in the table: Feed speed: 5/8/12/18 m/min Gedoxz Dlkjpfx Afaetu Electric height adjustment Extraction port: 150 mm Power supply: 400 V Motor power: 7 kW Overall dimensions: Length: 1280 mm Width: 630 mm Height: 1200 mm
