Used Oerlikon Pump for sale (75)

Condition: excellent (used), Leybold Oerlikon Dkjdpfxeytfzrs Affel Type: RUVAC WSU 501 Leybold Oerlikon RUVAC WSU 501 Roots Vacuum Pump Booster 505 m³/h 2.2kW DN100 For sale is a high-performance industrial roots vacuum pump manufactured by Oerlikon Leybold Vacuum. This roots pump serves as a booster pump to increase pumping speed in vacuum systems and is typically operated together with a backing pump. It is ideally suited for industrial applications such as coating systems, vacuum furnaces, laboratory equipment, or general vacuum technology. The pump impresses with its robust construction and high pumping capacity. Technical Data: Manufacturer: Oerlikon Leybold Vacuum Model: RUVAC WSU 501 Year of manufacture: 12/2010 Pumping speed: 505 m³/h (50 Hz) / 606 m³/h (60 Hz) Max. pressure difference: 80 mbar Motor power: 2.2 kW Rotational speed: 2,900 rpm Voltage: 230 / 400 V three-phase Current draw: approx. 9.0 / 5.2 A Duty type: S1 continuous operation Important Note: "The table shown in the photos is not included in the sale." Condition: used Scope of delivery: (see photos) (Specifications and data are subject to change and error!) If you have further questions, we would be happy to answer them by phone.

Condition: good (used), Year of construction: 2006, voltage 110 - 230 V frequency 50 - 60 Hz Power connection 0,5 kVA weight 150 kg dimensions of the machine ca. 1,0 x 0,8 x 1,75 m Stick blade profile control unit - Control via PC control with Windows XP operating system - Digital drive amplifiers, linear motors and measuring systems - Fully automatic position determination of the cutting edges and axis position of the stick blade - Measurement of almost all single-part and continuous processes required for Dodeymfz Sjpfx Affskl spiral bevel gears and hypoid gears - Machine concept designed for the shortest set-up and changeover lines and maximum measuring accuracy - Combination probe for measuring tip and surface measurement - Integrated drawer for accessories - Keyboard integrated in flat drawer - Operating elements and PC protected against unauthorized access with lockable cabinet element

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types Dkedpfjw N S E Aex Affol - Interface for neutral data

Condition: good (used), Oerlikon Type: Optitome² 2040 HPi / CPQ170628608 Dimensions: Length: approx. 5325 mm, Width: approx. 3050 mm, Height: approx. 2000 mm (machine body) Max. cutting area: 1000 × 2000 mm, 1500 × 3000 mm, 2000 × 4000 mm Max. material thickness: 50 mm Longitudinal drive X-axis: dual-sided brushless 300 W motors, maintenance-free precision gearboxes Transverse drive Y-axis: brushless 300 W motor, maintenance-free precision gearbox Mechanical guidance: linear guides on all axes Positioning speed: 15 m/min Cutting speed: 10 m/min Positioning accuracy: ±0.1 mm Cutting table: sections of 600 mm each, pneumatic extraction control, diffuse extraction Support grids: 100 – 150 mm Plasma unit: NERTAJET HPI 300 / 300A / NERTAJET 50 Oxy-fuel cutting: up to 50 mm cutting thickness Cutting current: 15 – 300 A Plasma power source output: 82 kVA Duty cycle: 100 % Plasma unit dimensions: approx. 820 × 710 × 930 mm Dkjdpfx Afjy Nay Aofol Plasma unit weight: approx. 350 kg Protection class: IP21 Chiller capacity: 2475 W Tank capacity: 30 l Power supply: 230 V Power input: 1.7 kW Chiller weight: 65 kg Dust extractor air flow: 5,000 – 8,000 m³/h Pressure: 3,100 – 2,400 Pa Filter class: H13 Separation efficiency: 99.9987% Total weight: approx. 3600 kg Condition: used (machine as shown in images) Scope of delivery: (See image) (Specifications and technical details subject to change and errors!) For any further questions, please feel free to contact us by phone.

Condition: used, Year of construction: 1987, greates pass round over bed 560 mm swing diameter over face slide 365 mm turning speed range - main spindle 11,2 - 2.240 min/-1 drive capacity - main spindle 15 kW spindle head No. 8 spindle diameter in front bearing 100 mm spindle bore 62 mm machine weight ab. 2,5 t dimensions of the machine ca. L 3,5 x B 2,0 x H 2,2 m In our assessment, the machine is in good used condition and can be inspected under power by appointment. Djdpfx Aoy Nfbljffokl The machine has undergone a geometric overhaul. Technical features & accessories: - 3-axis digital readout, Fagor - Rapid traverse Accessories, tools, and clamping devices shown are only included if specifically stated in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 1982, Center height: 220 mm Center width: 1250/1300 mm Swing diameter: over bed 440 mm Dksdpfovzn Itsx Affsl Spindle bore: Spindle mount: Tailstock taper: 5 MK Spindle speeds: 11.2 - 2240 rpm Feeds: longitudinal/transverse 0.1-2.8/0.05-1.4 mm/rev Thread pitches: Electrical connection: 380 V, 11 kW Space required: 3400 x 1400 x 1300/1700 mm Weight: approx. 2700 kg

Condition: used, Year of construction: 2000, Oerlikon L50 Lapping Machine Condition: Used Year of manufacture: 2000 Technical Data Max. workpiece diameter: 500 mm Y-axis distance: 150 - 350 mm Z-axis distance: 120 - 340 mm Dedoy N Aqdjpfx Affskl Hypoid adjustment X-axis: ± 70 mm Axis angle: 90° Control: Fanuc Dimensions (L x W x H) approx. 2350 mm x 2240 mm x 2100 mm

Condition: used, Year of construction: 2001, Oerlikon L50 Lapping Machine Condition: Used Dkodjy N Ai Tspfx Affsl Year of manufacture: 2001 Technical data Max. workpiece diameter: 500 mm Axis distance Y-axis: 150 - 350 mm Axis distance Z-axis: 120 - 340 mm Hypoid adjustment X-axis: ± 70 mm Axis angle: 90° Control: Fanuc Dimensions (L x W x H) approx.: 2350 mm x 2240 mm x 2100 mm

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 275 mm gear width: 55 mm max. module: 6,5 min. module: 1,5 Face Hobbing-Continious Process Continuous process: The workpiece and tool (usually Spiron) rotate at the same time, and all teeth are created in one operation at the same time. Knife head has several knife groups (not arranged in a circle) Parallel tooth Conical tooth tip surface Dedpjv N Hilofx Affokl Single Item procedure: The workpiece is stationary and the tool (usually Arcon) rotates and cuts a tooth by immersing the tool. Once a tooth is cut, the tool moves out of the tooth again, the workpiece divides by one tooth width and the next tooth is cut until all teeth are finished. Knife head has arranged all knives in a circular path. Conical tooth height Parallel tooth head surface C28 can do both, wheel + pinion. However, a C28 must be “prepared” for the individual part procedure. I.e. direct measuring system + part gear brake, workpiece axis + license file for the production of individual parts. *

Condition: used, Year of construction: 2007, max. wheel diameter 400 mm workpiece dia. 36-300/400 mm axis distance 135-290 mm spindle turning speed - stepless 3000 1/min dist. between centers 100-550 mm Control Siemens 840D weight of the machine ca. 4000 kg dimensions of the machine ca. 2000x3055x2788 mm Test method: - Single flank rolling test - Double flank rolling test - Structure-borne noise test - Heli testing in two-flank contact. Features: - Use of up to 6 test slides Dsdpfoy D T Suex Affekl - Highest testing accuracy and repeatability - Machine table with workpiece drive - Swiveling pneumatic unit - Spray oil lubrication (type: Vogel) - Oil mist extraction (type: Elbaron)

Year of construction: 2002, condition: used, z-travel 200 mm Clamping diameter of the cutter heads max. 550 mm Max. permissible cutter head weight 150 kg Mounting plate diameter for cutter heads 360 mm Mounting cone for cutter heads Nominal diameter 500 mm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m Cutter Head Set-Up- and -Measuring Machine In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in dry milling, high gear cutting quality and a long service life can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with Djdpfx Afey A S U Sjfskl tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2006, voltage 110 - 230 V frequency range 50 - 60 Hz Power connection 0,5 kVA Dimensions (HxWxD) 1000 x 800 x 1750 mm weight 150 kg Measuring machine for bar knives. Equipment/accessories: -Measuring tools -Clamping devices Dkjdpfx Aeyhq T Ajffol -Computer -Monitor -Printer -Cabin -Technical documentation

Condition: used, Year of construction: 2007, max. wheel diameter 500 mm Hypoid adjustment ±70 mm axial cross angle 90 ° Distance Y- 150 - 350 mm Distance Z-axis 120 - 340 mm turning speed range - stepless 0 - 5000 U/min max. torque on the spindle 57 Nm Cone 99,2 mm Pull-in force Tool clamping 23000 N Braking torque max. 93 Nm total connected load 20 kVA total power requirement 15 kW weight of the machine ca. 6 t Dkodpfx Afoukitxefsl dimensions of the machine ca. 2,35 x 2,24 x 2,5 m

Condition: good (used), Year of construction: 1973, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 860 mm, Oerlikon milling machine, lightly used, only employed for punch tool repairs. Guide columns are like new, showing no signs of wear! Highly precise, equipped with FAGOR CNC control. Suitable for workpiece weights up to 3000 kg. Djdey I S Rwopfx Affokl

Condition: used, functionality: fully functional, load capacity: 2,000 kg, Equipment: foot remote control, 3-axis welding positioner, 2-ton load capacity, in good condition Incl. hand remote control (foot control available on request) Dkjdpfxsyupgzj Affjl Inclination and rotation speed continuously adjustable 0.05 - 1.0 rpm Clamping plate diameter: 1.0 meter Height tilted to center min. approx. 0.7 m, horizontal 0.9 m Height tilted to center max. 1.6 m, horizontal 1.8 m Length 2.2 m, width 1.35 m

Condition: used, turning diameter over bed 1000 mm turning diameter over slide rest 640 mm turning length 6300 mm turning dia. in gap 1250 mm spindle diameter 50 mm Dksdpeyqva Tofx Affol speed 6-925 U/min Coolant 3-jaw chuck Ø 500 mm 4-jaw chuck Ø 900 mm Steady rest Ø 300 mm Steady rest Ø 560 mm Power compound Multi Fix Toolholder The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: new, Year of construction: 2011, overall weight: 1,250 kg, volume flow: 630 m³/h, power: 15 kW (20.39 HP), type of cooling: water, rotational speed (max.): 2,930 rpm, protection type (IP code): IP5K5, For sale is a new vacuum pump in original packaging: OERLIKON LEYBOLD VACUUM Technical data: Forevacuum pump station with dry-compressing forepump EXTRUVAC III SP630F NOS – New old stock Electric motor, water-cooled With VEGA VEGABAR 52 pressure transmitter With spring-closing valve from AMG-Pesch Manual in German and English Further technical details: see images Dedpfxjy D Rbme Affekl

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, wheel diameter: 400 mm, overall weight: 4,000 kg, distance between centers: 550 mm, spindle speed (max.): 3,000 rpm, controller model: Siemens 840 D, TECHNICAL DETAILS Max. wheel diameter: 400 mm Workpiece diameter: 36–400 mm Centre distance: 135–290 mm Max. spindle speeds (infinitely variable): 3,000 rpm Centre width: 100–550 mm MACHINE DETAILS Control: CNC Siemens 840 D Dedpfx Afsywg Hxsfjkl Dimensions & Weight Space requirement: approx. 2,000 x 3,055 x 2,788 mm Machine weight: approx. 4,000 kg EQUIPMENT Single-flank rolling test Double-flank rolling test Structure-borne noise testing Helical contact testing (double-flank contact) Use of up to 6 test carriages Highest test accuracy and repeatability Machine table with workpiece drive Swivelling pneumatic unit Spray lubrication (Type: Vogel) Oil mist extraction (Type: Elbaron)

Condition: excellent (used), Year of construction: 1982, Make: OERLIKON Type of machine: FM3 Year of manufacture: 1982 Control system: HEIDENHAIN x-travel: 1300 mm Dksdei If N Iepfx Affel Speed range: max. 1120 U/min Control: conventional Machine's weight: 6 t

Condition: ready for operation (used), welding circuit at 60% ED: 310 A welding circuit at 100% ED: 235 A Dksdpfxsd R S Dfs Affol electrical connection: 400 V space needed: 1000 x 750 x 630 mm

Condition: excellent (used), Year of construction: 2009, Brand: Oerlikon / SAF Model: LP100 Year 2009 Type: Self-aligning/Self-centering Capacity: 100T Diameter range: 2000 to 4500 mm. Turning speed: 100-1200mm/min. Wheel width: 235mm Wheel diameter: 450mm Distance between translation wheels: 1930mm between tabs Translation speed: 4m/min. It has a cable control with buttons for the direction of rotation, speed variator and translation of the turner. Dkjdelffdyjpfx Affjl Power: Three-phase 380V They have manual and Ce.

Condition: used, functionality: fully functional, For sale is an Oerlikon bevel/worm gear unit of the E 37 EX 2 series, serial number 828499L01.1. The unit comes from a fully functional installation and is suitable for test benches, special purpose machines, and industrial drive applications. Dkedpfxoypb Iye Affjl Technical specifications (general): Manufacturer: Oerlikon Type: E 37 EX 2 Design: Bevel/worm gear unit Application: Test bench technology, mechanical engineering, industrial drives Condition: used, functional

Condition: like new (used), Rotary vane bacuum pump in oil bath. Available in stock. Completely overhauled pump. With warranty. Dkedpfx Aoftzzgjffol Nominal flow: 300 m3 / h at 50Hz. Final vacuum: 0,1 mbar abs. Any clarification, do not hesitate to contact us.

Condition: used, Year of construction: 2001, max. wheel diameter 400/500 mm CNC-Control GE FANUC Series 160i-M pinion diameter - max. 400 mm crown gear diamter max. 500 mm x-axis +/- 70 mm y-axis 200 mm z-axis 200 mm axis angle 90 Grad speeds: R T min rated current 30 kVA weight of the machine ca. 6,2 t dimensions of the machine ca. 3,2 x 2,5 x 2,3 m The Oerlikon T50 is a 3-axis CNC testing machine for fully automatic hard and soft testing of spiral and hypoid bevel gears with an axle angle of 90° Bevel gear analysis ROTEC T50 GA2 Color unit company Binks Dkodsyv Iplepfx Affel

Condition: used, Year of construction: 2012, operating hours: 7,500 h, functionality: fully functional, type of input current: three-phase, sheet thickness (max.): 35 mm, sheet thickness steel (max.): 35 mm, sheet thickness aluminum (max.): 30 mm, overall weight: 1,500 kg, input voltage: 400 V, total width: 4,000 mm, total height: 2,000 mm, total length: 8,000 mm, cutting height (max.): 110 mm, track width: 2,950 mm, Equipment: documentation/manual, Selling an Oerlikon plasma cutting system, Plasmatome 20 HPC, Nertajet HP 300 plasma source with CPM 400/450 torch heads for aluminum, steel, and stainless steel. Cutting range 2 x 6 m, cutting current 30-260 A, power consumption 80 kVA. Material thickness of the sheets to be cut with piercing up to 35 mm, external thickness up to 50 mm. Dksdjv I U Hcopfx Affol Sold without cutting table.
