Used Loedige Mixer for sale (22)

Condition: excellent (used), Year of construction: 2004, Type Loedige TSHK-160/KGU-400 Iiodsvzzw Uopfx Ad Nsh Serial no. 3901 Year of manufacturing 2004 Hot mixer 210 liters Cooling mixer 391 liters

Condition: used, Used Morton model FKM1200-D stainless steel ploughshare mixer/dryer. Has approximate total capacity of 1,200 litre with a working capacity (product dependent) of 480 to 840 litre. Unit has serrated ploughshare blades driven by Brook Crompton electric motor through a SEW Eurodrive gearbox. Unit includes external stainless steel jacket rated 5.5 bar design pressure at 163 deg. C. Unit has provision for 4 choppers but only 1 chopper currently fitted. Unit has stainless steel Morecroft Engineers stainless steel top-mounted feed hopper and Mitchell Dryers stainless steel jacketed dust filter. Includes centre bottom entry discharge port with flap valve. All mounted on stainless steel frame. Specifications: Bowl Volume: 1,200 L Material Of Construction: Stainless Steel Choppers (Y/N): Y Number Of Choppers (1-10): 1 Vacuum Internal (Y/N): N Jacket (Y/N): Y Jacket Pressure: 5.5 Bar Ijdpsz R R A Rsfx Ad Nsih Jacket Temperature: 163 deg.c.

Condition: good (used), Year of construction: 1978, LÖDIGE FM 50 1MZ plowshare mixer with knife head This mixer with a maximum useful volume of 35 liters operates using the throwing and vortex method. The machine can process powdery, granular, and short-fiber dry materials. The scope of supply includes a multi-stage knife head with a separate 2.2 kW drive. All parts that come into contact with the product are made of stainless steel 1.4571. Product inlet opening: Ø 200 mm Discharge: manual - flap 110 x 90 mm Underframe height: approx. 600 mm Iisdpfxjzu Rblj Ad Noh Manufacturer: Lödige Year of manufacture: 1978 Space requirement: 140 x 105 x 140 cm

Condition: not inspected (used), Year of construction: 1971, functionality: unexamined, space requirement length: 6,500 mm, space requirement width: 1,800 mm, overall weight: 6,580 kg, usable tank capacity: 4,200 l, Equipment: type plate available, Make Lodige Model: FKM 4200D Iisdot H Dy Eepfx Ad Noh Year of manufacturing: 1971 Serial nr: 5648 Capacity (Kw) 37 Dimensions LxWxH (mm) 6500 x 1800 x 2500 Weight (Kg) ca 6580 Total quantity in stock 1 Capacity (m3) 4200 ltrs Country of origin Germany Comments As / is condition, steel construction ploughshare mixer

Condition: used, Year of construction: 1972, Manufacturer : Lodige Iedpox R Dyiefx Ad Njih Model : M20 GRE Year : 1972 Type: ploughshare mixer for powders Total volume : 20 Litres Motor : 1,1 KW Video available in operation Static counter blade Transmission and sealing: reconditioned Mixing chamber rotation Bin: filling / emptying

Condition: good (used), Year of construction: 1974, This mixer was designed for intensive mixing and wet granulation of materials such as powder / granulate. Iiodowa Tcfspfx Ad Njh Working volume: 63 - 200 liters Total volume: 250 liters Cutter head: 4.9 / 6 kW, speed 1,500 / 3,000 min¹ Mixing tool: 18,5 kW, speed 2 speeds Manufacturer: Lödige Year of construction: 1974 Floor Space: 200 x 110 x 145 cm

Condition: used, Used Lödige model FKM 1600D stainless steel ploughshare mixer. Unit has an approxmately 1600 litre total capacity and 550-1100 litre working capacity. Ploughshare mixing blades direct driven by 21-35 kW 400 volt 3/50 740-1479 rpm motor through Flender type 185 102 025-2-1 gearbox rated 31kW with 1500rpm input and 115rpm output. Unit has (2) MK 30/55 choppers with air purged seals driven by 5.5kw motors. Has (2) side inspection doors and pneumatically operated drop door discharge. Iedpfx Adjzn Nmyo Nsih

Condition: used, Year of construction: 2002, Manufacturer : Lodige Iijdpfozv Uzfex Ad Njh Model : ECO 600 Year : 2002 Type: Ploughshare mixer Type of mixing tool: plain blade Volume : 600 litres Material: stainless steel Number of ploughshares: 6 Power main motor : 18,5 kW Side knives: 1 chopper, 5.5 kW Technical documentation available Dimension : 270 x 135 x 109 cm A machine similar to the FKM model.

Condition: used, Used Morton-Lodige stainless steel ploughshare mixer. Unit believed to be FKM1200D, approximately 1200 litres capacity. Unit measures approximately 1750mm long x 1000mm diameter. Unit has stainless steel ploughshare blades and (2) stainless steel half ploughshare blades driven by motor/gearbox. Unit has a pneumatically operated bottom entry discharge valve. Has provision for (2) choppers but none currently fitted. Unit is mounted on a mild steel frame. Iiedpfx Adjy Inr De Noh Specifications: Bowl Volume: 1,200 L Material Of Construction: Stainless Steel Choppers (Y/N): N Vacuum Internal (Y/N): N Jacket (Y/N): N

Year of construction: 1987, condition: used, Lodige ploughshare mixer type FKM600D with 2x lump breakers. Material: steel. Motor power 11kW. Gross capacity 600 liters. Year of manufacture: 1987. Machine is mounted on a mobile frame. Discharge pneumatically operated. See our other advertisements. VMA Wekerom. Iisdpfoxc Exnsx Ad Nsh

Condition: used, Year of construction: 1967, Manufacturer : Lodige Model : M50G Iiedex R Dycspfx Ad Noh Year : 1967 Type: ploughshare mixer for powders Total volume: 50 Litres AEG 1.5 KW motor Video available in operation Transmission and sealing: reconditioned Mixing chamber rotation Bin: filling / emptying

Year of construction: 2005, condition: excellent (used), The designation TSHK160 refers to a rapid-heating mixer with a gross volume of 160 liters, while KGU400 describes a large-volume, universal cooling mixer with a gross volume of 400 liters. Both units are optimally matched to each other and enable a continuous, reproducible production process. - In ATEX design / explosion-proof - Bevel helical gear motor: 11 kW, n1 = 1300 rpm n2 = 104 rpm Motor IM V1 - Frequency controlled: 45kW 300/1500 rpm Ijdpfx Asiup H Tsd Noih - Product-contacting parts: stainless steel 1.4541 - Hopper diameter: 300/200 x 350 Cooling mixer KGU400: - Capacity of the vessel KGU400: 391 liters - Capacity of the jacket KGU400: 45 liters - Min./Max. temperature TS. vessel and jacket KGU400: 5/95 °C - Min./Max. pressure PS. jacket KGU400: 0 / 0.5 bar - Test pressure PT jacket KGU400: 0.72 bar - Motor power: 11 kW High-speed heating mixer TSHK160: - Capacity of the vessel TSHK160: 210 liters - Capacity of the jacket TSHK160: 30 liters - Min./Max. temperature TS. vessel and jacket TSHK160: 0/158 °C - Min./Max. pressure PS. jacket TSHK160: 0/6 bar - Test pressure PT jacket TSHK160: 9.3 bar - Motor power: 45 kW - Working volume: 168 liters Accessories: 1. Platform with stairs MSH 80 2.Temperature control unit 30 kW 3. Hopper 4. Control panel 5. Control cabinet 6. Dust filter DN 200/ 100 7.Dust filter DN 150/ 100 8.Technical doc. Message: It was used in a technical plant for wood chip and melamine resin additives.

Condition: ready for operation (used), A compact steam boiler system Gebrüder Lödige is available. Boiler content: 610l, jacket content: 45l, max. boiler operating pressure: 1bar, max. jacket operating pressure: 1.5bar, max. operating temperature: 110°C. Including control box. An on-site inspection is possible. Expected to be available June 2026. Iisdpfx Ajyypmtod Neh

Condition: used, Year of construction: 2017, Old Lodige KM 1200 D continuous mixer with ploughshares (year 1977) transformed into a mixer-dryer (year 2017) by the previous user. Modification made : New enclosure / mixing chamber in stainless steel 316. Change of motor transmission: belt -> geared motor Main material: 316 stainless steel Year: 2017 Type of drying: hot air blowing Without electrical cabinet With piping 1 – Ploughshare mixer 1200 L Motor manufacturer: SEW Power : 18,5 KW Material: 316 stainless steel + 2 manual butterfly valves + 2 manual Orbinox knife gate valves Porthole interior view Safety box suppression (brand : Vigilex) No manufacturer’s plate 2 – Fan n°1 Manufacturer: Kiekens Model : 8 KTEN 355 Year: 2017 Volume: 1204 m3 / H Power : 15 KW Temperature : 80°C Atex : yes Ex II 3D/G td nA 3 - Fan n°2 Manufacturer: Kiekens Model : 8 KTEN 280 Year: 2017 Volume: 1204 m3 / H Power : 4 KW Temperature : 80°C Atex : yes Ex II 3D/G td nA 4 – Heat exchanger Manufacturer : Bronswerk heat transfer B.V Year: 1996 Exchange surface: 67 m2 x 2 Max pressure : 20 bar Iodpfjx R An Eex Ad Nsih Max. temperature: 215°C Fluid : water or steam Volume : 17 L x 2 Temperature sensor connection 5 – Dust collection cyclone Year: 2017 With DMN Westinghouse rotary valve (type : butterfly) On frame 6 – Platform with stairs and mixer support Manufacturer: IJSSEL technology

Condition: excellent (used), Year of construction: 1988, manufacturer: LÖDIGE year of construction: 1988 type: FKM 4200 D e-engine: 75 kW Siemens Isdpfjrywvdex Ad Nsih

Year of construction: 2000, condition: used, Drais Mannheim / Lödige CoriMix® CM Continuous Ringlayer Mixer Type: K-TT 700 Iiodpfx Aoh H S Hded Neh Motor: 55 kW 1500rpm Fully Stainless execution

Condition: used, Used Morton-Lödige FKM1200D ploughshare mixer approximately 1200 litres capacity. Unit measures approximately 1750mm long x 1000mm diameter. Unit has (6) stainless steel ploughshare blades and (2) stainless steel half ploughshare blades driven by an 18.5kW , 1450rpm geared motor through a Renold Ltd gearbox with 49/4 : 1 ratio giving approximately 118rpm output on the shaft. Unit has a pneumatically operated bottom entry discharge valve. Unit is mounted on a mild steel frame. Specifications: Bowl Volume: 1,200 L Motor Power: 18.5 kW Iodpoyw S R Nefx Ad Noih Material Of Construction: Stainless Steel Choppers (Y/N): N Revolutions Per Minute: 118 Jacket (Y/N): N Dimensions: 1750mm x 1000mm

Condition: used, Year of construction: 2001, machine/vehicle number: 14873, LODIGE Coating and Enrobing Turbine Type LHC170 Year 2001 Partially perforated drum volume: 550 litres Drum material: AISI 316, K240 polished finish CIP system Batch size: 165–550 kg Sold complete with: - Turbine - Air treatment unit including: - 2-stage filtration (F8 + H13) - 1 preheating coil (steam) - 1 dehumidification coil (chilled water) - 1 main heating coil (steam) - 1 supply fan - Trolley with Watson Marlow spray pump (5 heads) - Dedusting unit - Air outlet filter - Exhaust fan - Sound attenuator - Electropneumatic cabinets - Siemens S7-300 PLC - Operator panel - PC with Lödige WinCC supervision software - Operator panel language: German and French - CIP skid with Prominent dosing pump - All necessary peripherals for operation: - Loading chute - Discharge chute - Sight glass cap - 5 spray nozzles - Flexible connection pipes for the CIP skid Dimensions: L3000 x W2300 x H2700 mm Iodpfx Aswpwt Hsd Nsih Weight of turbine assembly: 3 tonnes Complete documentation (in French) included: - P&ID - Drawings - Operator manual - Data sheets - Material certificates - Etc. Full program backup performed prior to machine shutdown.

Condition: used, Comprehensively tested and refurbished, used Morton-Lödige model FKM600 stainless steel jacketed ploughshare type mixer. Manufacturer: Morton Material: Stainless steel Iedpfsykn Sbjx Ad Neih External Jacket: Stainless steel rated 5.5 Bar design pressure at 162 deg.c. Capacity: Approximately 150-450 litre working capacity, 600 litre total capacity (product dependent) Discharge Type: Bottom bomb door style with pneumatically operated door. Type Of Blades: Stainless steel shaft with Becker-shovel type blades Motor: 22kW motor with gearbox Also includes: Provision for (2) side entry choppers. (Not fitted).

Condition: used, Used Morton-Lödige model FKM600D 321 stainless steel contact parts ploughshare mixer. Material: 321 Stainless steel Capacity: 600 litre total capacity. 200-420 litre working capacity (Product Dependent) Container Dimensions: 790mm diameter x 1240mm long Discharge Type: 300mm x 240mm centre bottom outlet with pneumatically operated valve. Type Of Blades: 321 stainless steel ploughshare blades Motor: 37kw, 1500rpm, 3/50 motor with Flender gearbox giving reduction ratio of 14:1. Unit includes: provision for 2 choppers. - x2 400mm x 450mm side access doors. - Mounted on a mild steel frame A video of this mixer is available below. Iedpfx Adeykn T Ej Neih Specifications: Bowl Volume: 158.5 gal Motor Power: 37 hp Material Of Construction: 321 Stainless Steel Choppers (Y/N): Yes Number Of Choppers (1-10): 2 Revolutions Per Minute: 1500 Dimensions: 790mm diameter x 1240mm long

Condition: used, Comprehensively tested and refurbished used Morton-Lödige model FKM800 304 stainless steel ploughshare mixer. Manufacturer: Morton Material: Stainless steel (304) Capacity: 240-560 litre working capacity. 800 litre total capacity (product dependent) Mixing Chamber: 1,800mm straight side x 760mm diameter Discharge Type: Pneumatically Operated Bomb Door Style Discharge Valve Type Of Blades: Stainless Steel Shaft with Ploughshare Blades Motor: 15kW Motor with Gearbox Also Includes: 2 Stainless Steel Side Entry Choppers Direct Driven by 4kW Motors. Ijdpfxeykn Sue Ad Njih Click on the link below to see a video of the machine running. Dimensions: 1,800mm straight side x 760mm diameter

Year of construction: 1962, condition: ready for operation (used), A horizontal ploughshare mixer Gebrüder Lödige is available. Total volume: 300l, usable volume: 225l, mixing chamber diameter: 640mm, mixing chamber length: 1000mm, inlet opening diameter: 250mm, ground clearance: 800mm, machine dimensions X/Y/Z: approx. 2500mm/1500mm/2200mm, weight: approx. 500kg. An on-site inspection is possible. Expected to be available June 2026. Iedpfx Adoyxramo Nsih
