Barth GmbH

Year of construction: 2002, condition: ready for operation (used), total width: 2,500 mm, total height: 8,400 mm, product length (max.): 2,250 mm, Dust extraction system manufactured in 2002. This LBH Suction system features a robust radial fan with a motor power of 22 kW and an impressive air flow rate of 13,750 m³/h. The filter area is 155 m², ensuring efficient dust removal with a residual dust content of less than 0.2 mg/m³. If you are looking to get high-quality dust extraction capabilities, consider the LBH Suction system we have for sale. Contact us for further details. • Return air/exhaust air (technical data): • Duct cross-section: 700 x 700 mm • Return air velocity: 7.5 m/s • Exhaust air velocity in workshop: <0.5 m/s • Sound pressure at 3 m from exhaust outlet (summer operation): 55 dB(A) • Extraction fan: • Design: Belt-driven radial fan (impeller statically/dynamically balanced) • Type: VSR-080-0450-K • Motor power: 22 kW • Airflow: 13,750 m³/h • Total pressure: 3000 Pa • Main pipe diameter (fan side): 450 mm • Extraction speed: 24 m/s • Sound pressure at 3 m: 78 dB(A) • Intermediate filter system: • Filter media: Polyester needle-felt hoses • Cleaning: 2 vibrating motors, each 180 W / 3,000 min⁻1 • Filter area: 155 m² • Filter area load: 88 m³/h per m² • Residual dust in clean air: <0.2 mg/m³ • Application categories: U, S, G • Installation: Outdoors with galvanized weather protection cladding • Drives: Gear motor for screw conveyor 0.55 kW; gear motor for sluice (rotary valve) 0.55 kW • Pipe system (technical data): • Main chip extraction pipe: Ø459 mm • Air velocity at extraction points: 22–26 m/s Additional equipment • Ducting and safety: • Galvanized return/exhaust air ducting • Tested K90 fire damper at wall penetration • Controls/automation: • Frequency converter (VFD) in switch/control cabinet for variable air volume • Vibration/noise isolation: • Fan mounted on vibration dampers • Suction- and pressure-side compensators Blsdpoyn Nn Eofx Afyed • Filter discharge and handling: • Screw conveyor (discharge screw) with worm gear drive • Rotary valve (sluice) with rubber sealing elements; sprocket/chain drive • Chip collection container (under filter discharge) • Protection and safety systems: • Extinguishing line with blast nozzles, routed outside and downwards, terminating with C-coupling • Bursting devices (explosion relief) per VDI 3673 • Piping and connection hardware: • Galvanized piping network with pipes, elbows, branches, clamps • Transitions/sleeves to machines • Flexible extraction hoses with hose clamps • Galvanized shut-off valves for unused extraction points

Condition: used, machine/vehicle number: 008411, Max. panel width: 1200 mm Max. panel length: 2700 mm Blodpfxjyngy Es Afyed Rotation system: double cone Rotation direction: from long to transverse

Year of construction: 2023, condition: used, Tree diameter 50mm Digitized guide Trainer ascent descent and depth digitized Bi-directional for rotation Machine like new Blsdpfx Aeynf Hksfysd +- 100h of work counter

Year of construction: 2007, condition: ready for operation (used), Other machine manufactured in 2007. This Barberan PUR-33-L is a continuous wrapping line designed for applying PVC foil, CPL, paper, and veneer on various materials using hot-melt technology. It features a robust one-piece electro-welded steel frame, motorized rubber-coated feed wheels, and a slot die extrusion system for precise glue application. If you are looking to get high-quality wrapping capabilities, consider the Barberan PUR-33-L machine we have for sale. Contact us for further details. Blodpsym U Diofx Afyjd • Base Frame: One-piece electro-welded steel frame with high structural rigidity. It is designed to absorb vibrations and maintain pressure roller alignment. • Transport System: Motorized rubber-coated feed wheels with speed controlled via inverter, ensuring precise synchronization between glue application and profile feed. • Pressing / Calendering Zone: Universal supports and multiple pressure rollers with various shapes and hardness levels, suitable for complex profile geometries. • System Type: Slot die extrusion system with adjustable lips. • Working Width: 330 mm. • Glue Application Accuracy: Constant gram-per-square-meter distribution, independent from line speed. Closed system reduces oxidation, prevents premature PUR crosslinking, and minimizes material waste. • Adjustment: Micrometric lip adjustment for precise control of glue film thickness. • Type: 20 kg PUR drum melter with heated platen, where only the top layer is melted to preserve the chemical integrity of the remaining adhesive. • Sealing System: Airtight design with dedicated seals to prevent air/moisture ingress. • Pump: Integrated gear pump providing constant, pulsation-free adhesive flow to application head. • Function: Maintains adhesive working temperature between approximately 120–150 °C during transfer from melter to slot die head. • Length: 4.5 meters. • Technical Features: Internal core made of PTFE (Teflon), high pressure, and PUR-resistant. It includes a uniform electric heating element to prevent cold spots, high-efficiency thermal insulation, an integrated thermocouple, and temperature control via machine PLC.

Condition: used, machine/vehicle number: 008431, X axis working area: 6360 mm Y axis working area: 1905 mm Working Table: Pod and Rail Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 60 Bljdpfxsym Rphj Afyed

Year of construction: 2014, condition: ready for operation (used), Quality scanner manufactured in 2014. This MICROTEC GOLDENEYE GLD 600 DSC is designed for the inspection of large boards and panels up to 1.8 meters in width. It integrates geometric, visual, and X-ray multi-sensor cameras to assess both external and internal properties of lumber, providing a comprehensive evaluation of material quality. If you are looking to get high-quality inspection capabilities, consider the MICROTEC GOLDENEYE GLD 600 DSC machine we have for sale. Contact us for further details. • Max board/panel width: up to 1.8 m • Inspection capabilities: geometric, visual, and X-ray sensors to assess external and internal material properties for comprehensive quality evaluation Bledpfx Afeymthgoysd • Application: Inspection of large wood boards and panels • Units available: 2

Year of construction: 2023, condition: like new (used), Double sided with 6000mm capacity on either side Total of 12000mm total working/ storage capacity for elements 3m height capacity Complete with 2 special fixing arms for one element 4 off additional supports Bodpfx Aoymnh Ujfyjld Year - 2023 CE Condition - Never been installed. Condition almost as new

Year of construction: 2020, condition: used, Fully Automatic Wrapping Machine. Year 2020. Suitable for shrink-wrapping doors, frames, architrave etc Bledpfxoymnclo Afyjd Ring Diameter 1100mm Conveyor height 870 - 900mm Conveyor width 750mm Infeed conveyor length 1300mm Intermediate conveyor length 1800mm Outfeed conveyor 1300mm Conveyor load capacity 120 kg / m Max Crown rotation velocity 80 Total Weight 710kg Installed Power 3.00kw Power Supply 400v, 50 hz 3 Phase and Neutral Working Pressure 5 - 7 Bar

Condition: used, LIMAB length scanner Bljdpfx Asymlfwjfyjd

Condition: used, TECHNICAL SPECIFICATIONS: – Length of feed rollers: 7800 mm – Roller width: 1430 mm – Roller diameter: 110 mm – Destacking system – Stacker width: 1540 mm – Package depth: 1430 mm Bledpfx Afjymd I Dsyjd – Package height: 1830 mm – Element collection with chains: 1600 mm x 1600 mm – Return of crossbars via belt conveyor: 3000 mm – Crossbar stacking up to 1370 mm at lifting height 1700 mm – Total length: 12 m

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, Brusa di Garboli TV 65 dowel milling machine Year of manufacture: 1998 Max. milling diameter: 65 mm Min. milling diameter: 15 mm Number of cutter heads: 1 Min. workpiece length: 350 mm Main motor power: 5.5 kW Max. feed rate: 18.5 m/min CE marking present Blsdpfxoyl Uqme Afyed

Condition: used, Year of construction: 2005, machine/vehicle number: ae-0274847, functionality: fully functional, input frequency: 50 Hz, type of input current: three-phase, total width: 1,100 mm, overall weight: 1,740 kg, Wide belt sander SCM - SANDAYA 7S, year 2005 Bledpsyl Sl Usfx Afysd

Condition: used, machine/vehicle number: 008346, Max width workable: 1300 mm Max length workable: 1250 mm Max height workable: 650 mm Bledpfoyl Ihrsx Afyed

Condition: used, functionality: unexamined, Ferwood Code: RU0010420 - Manufacturer Code: BK1120 - Condition: Used - Functionality: Not tested - Compatible Machine: - If interested, we offer a reconditioning service; please contact us. 0.5KG 20X20X20cm Bljdpfxsyk Ekbe Afysd

Condition: used, functionality: unexamined, Ferwood Code: RU0000311 - Manufacturer Code: KL9010 - Condition: Used - Functionality: Not tested - Compatible Machine: - If interested, we offer refurbishment service; please contact us. 0.5KG - 20X20X20 Bsdpfx Afoyk Ed Ijyjld

Condition: used, machine/vehicle number: 008403, Max. machinable height: 160 mm Bljdpfx Ajykivhefyjd Maximum machinable width: 250 mm Max. forward feed speed: 24 m/min Operator shafts number: 5

Year of construction: 2026, condition: new, DESCRIPTION Horizontal drum chipper, engineered and built for maximum performance and reliability. This heavy-duty, robust machine is suited for the most demanding conditions and is ideal for processing all types of waste wood materials. The Varli VDC-1600 drum chipper features a large infeed opening, making it highly capable of processing waste wood material, logs, and wood bundles (diameters over 700 mm can be easily accommodated). The VDC-1600 can achieve outputs of approximately 100,000 kg per hour of high-quality pulp mill chips or finer fractions suitable for biofuel production. The chipper can also deliver coarser fractions, producing chips up to 200 mm in length (depending on configuration). Built with a heavy-duty frame, the chipper features over-sized, self-aligning bearings housed in steel casings, firmly secured to the chipper’s side structure for long service life and reliable operation. Equipped with 14 feed rollers fitted with special, wear-resistant, surface-hardened teeth, the VDC-1600 provides secure feed and optimised material throughput. The chipper comes standard with drum-mounted cutting tools made from Hardox, along with replaceable wear plates. OPERATING PRINCIPLE The VDC-series is designed to produce wood chips from logs or bark bundles. Material is horizontally fed by vibrating chute into free-floating feed rollers, which automatically adjust to the material’s height. The feed rollers securely grip and transport the material into a high-speed rotating drum armed with solid knives, fixed with centrifugal wedges—fostering durability, preventing knife damage, and minimizing downtime during tool changes. The rotor knives are easily accessible and can be re-sharpened multiple times. Key features include an adjustable stator knife, hydraulic hood, and hydraulic device for stator knife exchange. BENEFITS - Extremely robust construction and heavy-duty design for stable operation - Centrifugal wedge knife mounting for reduced machine downtime - Adjustable stator knife to extend operating life - Hydraulic hood for swift and easy maintenance TECHNICAL DATA Model: VDC-1600 Infeed Width: 1250 mm Bljdpfx Afoyi H Ryoyed Rotor Diameter: 1600 mm Number of Infeed Rollers: 14 Number of Cutting Tools (Knives): 4 Drive Motor(s): 2 x 400 kW Electrical Supply: 400V, 3Phase, 50Hz Fraction Output: 60 mm (SPF), approx. 100,000 kg/h Total Weight: 96,000 kg

Condition: used, dimensions: 9.15 m x 2 m x 2.95 m Blodpfx Afoyi Hynjyed

Condition: good (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: VRBSI, Manual straightening and leveling center for straightening and tensioning of bandsaw blades. Manual roller device. Blsdpfoyizflox Afyod

Year of construction: 2016, condition: ready for operation (used), functionality: fully functional, Splitting machine for dividing round posts into various sections 1/2-1/4-1/5-1/6 using different knives in a rotary disc. Maximum post diameter approx. 8 cm. Posts up to 200 cm in length can be split. Feed rate is adjustable. This machine is used to produce laths for woven fences such as ganivelle (French fence), English sheep fence made from chestnut or hazel wood. High production speed. Bjdpfeyiut Aex Afyold

Condition: used, machine/vehicle number: 007815, Max. panel width: 2100 mm Bsdjyg Efwopfx Afyeld Max. panel length: 4250 mm Lifting capacity: 150 Kg Stock dimension length: 24000 mm Stock dimension width: 8000 mm

Condition: ready for operation (used), Width 70 cm Length 160 cm Height 220 cm Motor 2.2 kW Bjdpfx Asygxdgofysld

Condition: used, machine/vehicle number: 008395, X axis working area: 3050 mm Y axis working area: 1250 mm Main Electrospindle power: 10 KW Blodjygtcqjpfx Afyod Number of controlled axes: 3 axes Total number of drilling spindles: 27 Total number of tool changer positions: 8

Condition: used, machine/vehicle number: 008355, X axis working area: 3600 mm Y axis working area: 2120 mm Working Table: Flat table Bjdpjygr Urofx Afyeld Main Electrospindle power: 13 KW Number of controlled axes: 5 axes Total number of drilling spindles: 18 Total number of tool changer positions: 16

Year of construction: 2007, condition: used, functionality: fully functional, We offer this used Reich PB 520 3 pallet cap cutting machine, year of manufacture 2007. 3-blade model, high production capacity up to 8 pallets/min, currently in operation. Complete with cap positioner that rotates caps in all directions. Positioner for placing caps onto the nailing carriage of the original Omev machine. Similar to Corali, Omev, Storti, and CMS Scarpari models. Model: PB 520 3 Bljdpfx Ajygr Tbofyed Serial number: 020 Year of manufacture: 2007 Air pressure: 7 bar Power: 8.8 kW Voltage V-Hz: 380-50 V-Hz If you have questions or require further information, please do not hesitate to write us a message or call us.
