Screw making machine

SACMA SP260

Condition: good (used), grinding diameter: 1,600 mm, grinding length: 6,000 mm, Manufacturer: CINCINNATI Type: 60 x 216 Year of manufacture: 1970 Covex and Concave grinding 6 steady rest included 2 steady rest hydrostatic Coolant system with magnetic filter Measuring system with 5 arms caliber: Arm 1: Working area 1300 to 1600 mm Arm 2: Working area 1000 to 1300 mm Arm 3: Working area 700 to 1000 mm Arm 4: Working area 400 to 700 mm Specifications Metric US Standard Center height 787 mm Grinding diameter Ø 1574 mm Grinding length 5800 mm Grinding stone dimensions 914 x 101.6 x 304.50 mm Grinding stone speed 1800 rpm Rjdpjvvvw Eofx Adwsbt Dimensions (estimate) Length 15100 mm Width 5500 mm Height 3550 mm Weight 120000 kg Please note: The information on this page is correct to the best of our knowledge and belief and, where possible, has been obtained from the manufacturer. The information is given in good faith but accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you check all important details.

Condition: used, Year of construction: 1952, Technical details: turning diameter over bed: 1000 mm turning diameter over support: 520 mm turning length: 2500 mm support travel z-axis: plan: ca. 500 mm support travel z-axis: Obersupport: ca. 300 mm centre height: 300 mm spindle passage: 90 mm range of revolution per miute: 3,2 - 382 / 22 step U/min range of feed in x - axis: längs: 0,213 - 2,67 / 36 step m/min range of feed in y - axis: quer: 0,070 - 1,11 / 36 step m/min tailstock quill taper MT: 6 total power requirement: 22 weight of the machine ca.: 8,2 t dimension machine xH: 5,3 x 1.,6 x 1,6 m transport measurements machine: ca. 5,5 x 1,7 x 1,6 m Equipment: Faceplate Ø 1000mm 4-fold turning tool holder Lynette Ø 250 closed Accesorios Rbodpeu Tq U Iofx Adwet four-jaw chuck Ø 630 i.D. *

Condition: good (used), Universal milling head, milling adapter, milling extension, angle milling head -Manufacturer: Waldrich -Spare part: comes from a milling machine -Milling head: swiveling Rjdpfxofxlf Ae Adwjbt -quill stroke: 150 mm -Spindle mount: SK50 -Motor: 11 kW 1470 rpm -Spindle speed: 25 - 560 rpm -Transport dimensions: 1550/600/H460 mm -Weight: 636 kg

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, Vertical Turret Lathe - Double Column / Brand: SCHIESS BRIGHTON Type: Vertimaster / Year of construction: 2009 Rsdpfx Ajxgv Egodwobt The machine can be inspected by appointment. Condition: Fully functional / operational. TECHNICAL DATA: Working area and traverse: - Max. Machining- / Swing diameter: 9.000 mm - Processing height max.: 6.000 mm - Faceplate diameter: 6.000 mm - Passage width between racks/pillars: 8.300 mm Power and torque: - Main drive: 240 KW - Max. Torque on the face plate: 250 kN m - Max. Workpiece weight: 150 tons Boring and milling device: - Power max.: 63 kW - Speed max.: 2.500 rpm - Torque max.: 2.200 Nm Support: - Cross section: 520 x 420 mm - Injection diameter min.: 750 mm - Cutting power at 6 m Diameter max.: 75 kN EQUIPMENT: - CNC-Control: SIEMENS Sinumerik 840D - Tool holder: SK 50 - Operating platform - Chip conveyor - Documentation - Additional excellent accessories ... There is no guarantee for correctness and completeness of the technical details and accessoires. - Subject to prior sale. Detailed technical data sheet and information on equipment available on request.

Condition: excellent (used), functionality: fully functional, Swing over bed: 1290mm Swing over cross slide: 910mm Swing in gap (l:500mm): 1580mm Center distance: 6000mm Spindlebore: 155mm Spindle speed: 6-800rpm Spindle nose: ASA A2 11" Workpiece between centers: 20 tons Taper in tailstock: Mk6 Longd.feed: 0.045-5mm/r Crossfeed: 0.0220-1.5mm/r Rodpfx Aowc Nzpodwjbt Thread metric: 0.5-56 Thread's modulus: 0.25-28 Threads whitworth: 1/2-84/ " Spindle motor: 30 hp Manufacturing year: 1971 Length: 9500mm Width: 2000mm Height: 1600mm Weight: 13400kg Sony DRO cross slide 3 pcs. Steady rests Face plate 4-jaw chuck Hardened guideways Power on topslide

Condition: good (used), functionality: fully functional, Paper production line consisting of stock preparation, paper machine, inline coaters, offline coater, calander, reeler, offline calanders and slitter winders. Various updates including headbox, top former, press section, offline coater, Voith speedsizer, Voith jet coaters and steambox & ceramic rolls. Characteristics: Capacity: max ~ 240000 T/pa Width: 4800 mm Grammage: 40 – 170 gr/m2 Speed: max 1165 m/min Rodpfxevptqis Adwobt

Condition: good (used), functionality: fully functional, Year of construction: 1989, number of rollers: 3, Over roll 280mm, 12mm Prebending, capacity 18mm 3x top roll diam. Weight 7,100kg Rbodowtp Haopfx Adwot

Condition: excellent (used), functionality: fully functional, turning diameter: 1,000 mm, turning length: 8,000 mm, total length: 10,500 mm, A used lathe from the Italian manufacturer Leopolod Pontiggia, model NH 500, is for sale. Technical specifications: Turning diameter over bed: 1,000 mm Turning length: 8,000 mm Extensive equipment as in the photos: Rbedpfx Adjv Epigewjt 1 x 3-jaw chuck 1 x 4-jaw chuck 1 x steady rest + various adapters

Condition: used, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 4,500 rpm, Equipment: rotational speed infinitely variable, X-AXIS STROKE 6000 MM Y-AXIS STROKE 1800 MM AXIS STROKE 1000 MM 7300 X 1090 X H 900 MM BENCH ISO 50 SPINDLE NOSE CONNECTION SPINDLE SPEED 0 - 4500 RPM 2.5 ° X 2.5 ° AUTOMATIC INDEX HEAD CNC SELCA 3045 PD EXTERNAL AND INTERNAL HIGH PRESSURE COOLING TOOL CHANGE 60 PLACES NR 01 CNC-MANAGED DIVIDING DEVICE Rjdpev H D Exjfx Adwebt

Condition: good (used), Year of construction: 1970, Brand HILGELAND Type CH 5 ALL Year of build 1970 Serial number 5282 Electric connection 380V Dimension l 5500mm Dimension w 2200mm Dimension h 1900mm (screw and rivet), capacity : M6 - M14, cutting length max. 200mm, variable speed: ... up to pieces 90 p/min, diameter 16mm Rsdpju Szucefx Adwebt
