Belt Press ISP 350

ISAR ISP 350

Condition: new, capacity: up to 7 000 kg/h Dledpfedix N Hsx Aduoa electric outlet: 3kW 400V 50Hz (3 phases) fuse: 16 A dimensions: length: 4 435 mm width: 2 250 mm height: 2 160 mm insertion resp. discharge height: 1 430 mm belt width: 1 100 mm spread width: 320 - 870 mm spread height (infinitely adjustable setting): 10 - 50 mm weight: 3 400 kg material: 1.4301 / AISI 304 juice yield : up to 80 % belt Speed: 1,2 – 4,5 m/min contact time: 1,5 - 6 min water consumption for cleaning: 20 l/min connections: sewage connection: Ø 75 mm juice discharge connection: DN 40 juice discharge height: 200 mm sewage discharge height: 100 mm pomace discharge height: 800 mm suitable for pomaceous and stone fruit scope of delivery: high-pressure cleaner, compressor

Year of construction: 2025, condition: new, Our belt presses are equipped with two large pressing rollers that extend the pressing process, ensuring particularly gentle juice extraction. The result is a clear, foam-free juice of high quality. The pneumatic belt tension and automatic belt control guarantee consistently high quality throughout the entire pressing process. The belt press features an automatic brush cleaning system, eliminating the need for a high-pressure cleaner. The belt is cleaned by six specially designed water nozzles. For cleaning, only a compressor with 8 bar pressure and a ½” water connection are required. Thanks to these special nozzles, water consumption is reduced, leading to lower operating costs. The open design allows for quick and uncomplicated cleaning, which can be completed in just a few minutes. Technical Information: • Nominal capacity: 950 kg/h • Power requirement: 1 kW, 400 V, 16 A • Material: WNr. 1.4301, AISI 304 stainless steel • Compressed air requirement: 50 l/h at 6 bar • IP65 electronic control cabinet • Juice yield: Up to 75% • Fully automatic and stepless control of belt speed • User-friendly • Easy to clean • Rollable machine feet Dimensions: Length: 2230 mm Width: 1450 mm Height: 1250 mm Loading height: 1240 mm Pomace discharge height: 500 mm Juice outlet height: 370 mm Dlodpfx Asv Sq S Neduoa Weight: 540 kg Optional: Juice collection tray ISW 100 Automatic juice discharge

Year of construction: 2024, condition: new, MSP 1100 belt press The complete system can be dismantled down to the base frame in just a few minutes! Fully automatic fruit and vegetable press with closed working chamber to minimize oxidation. Two high-pressure nozzles are fitted under the machine, which rotate constantly to ensure optimum performance. Due to the small distance between the pressing rollers and the juice collection tray, foaming is no longer a problem. Most parts of the machine can be dismantled without tools and are therefore easy to clean. With heavy-duty vibration-damping machine feet. Requires minimal maintenance. Dedporz I Hqsfx Aduela Technical data: - Nominal output: 1100 kg/h - Power requirement: 1.5 kW, 400 V, 6 A, three-phase - Material: Wnr. 1.4301, AISI 304 stainless steel - Dimensions: 2200 x 1330 x 1200 mm - Filling height: 1250 mm - Dry material discharge height: 470/770 mm - Weight: 950 kg - With integrated juice pump, collection container and fill level switch. - Touchscreen control - Electronics to IP65 - Extra high juice yield: 75% (depending on freshness and quality of the fruit) - Air requirement: 50 l/hour at 6 bar - High-pressure water requirement: 360 l/h - Frequency inverter: speed control for even more professional processing - High-strength, food-safe polyester press belt, fiber thickness: 2 mm, fabric density 6×16 fibers/cm^2, ½-fold weave (suitable for juicing without large fibers) - Easy to clean - Requires minimal maintenance - Adjustable, with vibration-damping machine feet - Brush roller for cleaning the belt High-pressure cleaner and air compressor are required for operation.

Condition: good (used), Drum speed: 5500 rpm Dljdpfx Adsu Rr Iyeusa

Condition: good (used), Peter Cox all s/s destoner spiral elevator, with tank. Approx. 1.2 x 1.4 m x 5 m high Dlodpfx Ast Sxxmsduja

Condition: used, Used syrup room with pasteurizer Alfa Laval This second hand Syrup Room is a complete processing section designed for the preparation of concentrated base syrups and finished syrups for beverage production. Engineered for integration upstream of a premix and an isobaric filler, it supports efficient industrial packaging workflows in a used bottling line. Manufactured and supplied by BBM Service with components from recognized European brands, it is ideal for beverage production environments that require reliable sugar dissolving, thermal treatment, and hygienic storage prior to mixing, carbonation, and filling. The system covers the full syrup preparation sequence: simple syrup creation from treated water and sugar, finished syrup blending with concentrates, acids, colors, and flavors, and hygienic storage in stainless steel tanks. A dedicated pasteurizer helps ensure product stability, while mixers and pumps support consistent, repeatable processing. This Syrup Room is well suited for soft drink formulations such as cola, tonic, and other flavored carbonated beverages, and it integrates seamlessly with premix units that add CO2 just before the filling machine. The plant layout and component selection make it a practical solution for upgrading or expanding a used bottling line in the beverage production sector. Technical Specifications & Performance Data Sugar dissolver: AICMA Pasteurizer: Alfa Laval Storage tanks (finished/simple syrup): 4 x 4,000 L Cavalzani Storage tanks (finished/simple syrup): 3 x 2,000 L Bertuzzi Mixers and pumps: Included for circulation, transfer, and blending Process materials: Treated water, sugar/sweeteners, fruit concentrates, flavors, additives Construction: Stainless steel AISI 304/316 process equipment Cleaning: CIP-ready design for sanitary cleaning in place Djdpfexywg Ssx Aduela Advanced Automation & Control Systems The Syrup Room features a centralized control panel with analog/digital selectors for process management, enabling operators to supervise dissolving, thermal treatment, storage, and transfer operations. Dosing can be achieved using precision pumping and flow control to maintain recipe accuracy. Hygienic design, sanitary valves, and instrument connections support repeatability and quality. The configuration is suitable for integration with plant-level automation and recipe control, with clear operator interfaces that simplify changeovers and routine adjustments while supporting safe and reliable operation. Production Line Integration Capabilities This processing plant is designed to feed finished syrup to a premix unit, where it is blended with treated water and CO2 immediately before the isobaric filler. It can be integrated inline with existing beverage production and industrial packaging equipment and is compatible with used bottling line layouts handling both PET and glass bottling downstream.

Year of construction: 2025, condition: new, SPECIAL OFFER! Washing system with granulator + destoning system IWR2000 Washing system with granulator for fruit and vegetables. The system is made entirely of stainless steel and features a sorting grate, a washing tank, and a conveyor belt. The fruit falls into the water and, after pre-washing, is transported along the conveyor belt, where it is thoroughly cleaned with fresh water. The cleaned fruit is then transferred to the mill, where it can pass through the desired sieve to reach the desired mashing unit. • Easy to clean • Minimal maintenance • The belt speed is continuously adjustable in both directions • With 2 steerable rollers • With 2 fixed rollers Technical information Rated capacity: 2000 kg/h Power requirement: 3 kW, 400 V, 10 A Mash discharge height: 1400 mm Wash tank connection: G 6/4" Cleaning connection: G ½" Material: Wnr. 1.4301, AISI 304 stainless steel Water consumption: approx. 12 L/min. Dimensions: Length: 2700 mm Width: 840 mm Height: 2270 mm Weight: 150 kg IPE4MAX The destoning and straining system is suitable for processing fruit and vegetables. It is equipped with interchangeable sieves and an adjustable rotating rotor for straining or pitting stone fruit, pome fruit, and various types of fruit and berries. The pulp and seeds are ejected separately. The sieves can be replaced quickly and easily. The system is supplied with one sieve; additional sieves can be ordered separately. • Food-safe rubber scraper Dlodpfx Adjwcl Ulsusa • Adjustable distance between sieve and scraper • Rolling machine feet/swivel casters with brakes Technical information • Rated capacity: up to 4000 kg per hour • Power requirement: 4 kW, 400 V, 16 A • Material: Wnr. 1.4301, AISI 304 stainless steel Sieve sizes: • 0.8 mm: Berries, puree • 1.5 mm: Berries, puree • 3 mm: Apple, pear puree • 5 mm: Cherry • 8 mm: Plum, apricot • 10 mm: Peach, mango Dimensions: Length: 1130 mm Width: 574 mm Height: 1138 mm Weight: 125 kg

Year of construction: 2025, condition: new, The press is suitable for high juice yields of various fruits such as apples, pears, blackberries, strawberries, blueberries, currants, carrots, herbs, quinces, onions, etc. The types of fruit listed above have been tested by our customers with our packing presses. The system is equipped with an automatic pressing programme so that the system switches off the pressing pressure itself at the end of the pressing process. You can order the machines with one or two turning juice basins. Dledpfx Aotz Sp Doduea Accessories: • 18 pieces of press cloths • 20 pieces of press grate Technical Information • Output: 600 kg/h • Pressing force: 18 T • Power consumption: 2.2 kW, 230 V, 10 A • Material: Wnr. 1.4301, AISI 304 stainless steel Dimensions: • 1,250×1,370×1,520 mm • Weight: 450 kg • IP65 electronic switch boxes • High yield up to 60–80%

Year of construction: 2008, condition: not inspected (used), functionality: unexamined, machine/vehicle number: 1723085102, This gas pasteurizer comes from a business closure. Precise temperature control. High-quality components are installed: Viessmann boiler, Schmitt-Bretten plate heat exchanger, premium impeller juice pump. Suitable for operation with natural gas or propane/butane. Includes a new impeller for the juice pump. Dedjwrb Exjpfx Aduela

Condition: used, Electric motor, three-phase motor Dlodpfogfrb Rsx Aduja -Manufacturer: VEM, electric motor type KRA 132 3/4 -Power: 7.5 kW -Speed: 1450 rpm -Shaft: Ø 32 x 80 mm -Construction: B3 -Protection class: IP44 -Dimensions: 525/340/H265 mm -Weight: 80 kg
