Used Mounting technology for sale (145)

Condition: excellent (used), For sale: Lot of several: 1 unit: SAMSUNG VT200E inspection conveyor, 0.8 m 3 units: ASYS TM6V conveyor, 1 m Iislhcjwld S Uscqmeb 2 units: SAMSUNG WT200E conveyors for spare parts 1 unit: ROBOLAN conveyor, 0.5 m 1 unit: SAMSUNG VT200E inspection conveyor 1 unit: ASYS TM6V conveyor, 1.90 m

Condition: used, Year of construction: 2014, Machine in opertional condition. Working times 2014-2018 only 1 shift, 2018-2022 stored, 2022-2023 in 3 shifts, 2023- stored. Ijlhccqewlfaysmeib Ask for additional information!

Year of construction: 2009, operating hours: 500 h, Condition: like new (used), Functionality: fully functional, This 2009 machine has worked around 500 hrs. It looks and smells like almost new. Belt conveyor. Ideal for portotyping and/or glue curing Iielhccqswiwz Domjb

Year of construction: 2020, Condition: new, Transport systems Depending on the customer's requirements, transport systems can move on the floor or be suspended on poles. - For comfortable solutions for manual installations, we recommend suspended cross traverses (cross transport). - For automated systems, chain conveyors are most often used that do not stop and are a great solution for companies that focus on quality and repeatability of the process. - For companies that make different items at once and have e.g. several cabins with different colors, flexible solutions with the use of the power-and-free conveyor are used. This is the most expensive solution. All installations are made to measure, depending on the customer's requirements. Continuous suspended chain transport systems are designed and manufactured to individual customer orders. In this system, it is also possible to make bottom conveyor systems on which details are placed, e.g. flower pots, rims (photo). ROMER also manufactures suspended transport systems. Crossbeams (cross transports) are designed and made for the needs of specific installations The use of one photocell The use of one photocell in the space of the detail allows you to measure its length and, consequently, gives the option of switching on the guns when the detail appears in their range, and switching off the guns immediately after painting the detail. The photocell is standard equipment. Identification of details by means of special markers. Iijljfz Nb Tshccqmjb Above the sling there are plates with identification holes. Based on them, the PLC controller in conjunction with the photocell recognizes the painted detail, turns the guns on and off in good time - thus saving energy and powder paint. Vertical shape detection. The use of light gates with horizontal detectors allows the PLC controller to analyze the shape of a detail vertically. The PLC controller counts the time in which the detail should appear in the gun space - thanks to this it is possible to selectively turn the guns on or off. Using light gates with multiple sensors horizontally and vertically. This solution allows precise measurement of workpiece dimensions, thanks to which it is also possible to control manipulators.

Year of construction: 2010, operating hours: 4,786 h, Condition: excellent (used), Our X-ray inspection system from Dage is for sale. The system is in excellent condition. The system was serviced twice a year by the manufacturer. (Documents available) Type: Dage XD 7600 NT 100 HP including aluminum sample tray. X-ray on hours: 4786.4 hours The system has an XPlane function, with which it is possible to create a partial CT. The µCT tray is not required for this partial CT. We used the system for the following applications: • Analysis of electronic components (bonding wires, chip size, lead frame) • Void measurements • Solder penetration measurements • Analysis of circuit boards and assemblies (vias, conductor tracks, hidden solder joints such as QFNs, BGAs, solder joints, press-fit connections, crimp connections, rigid-flex circuit boards, etc.) • Analysis of components and solder joints under potting compound and/or paint • Analysis of aluminum die-cast parts for air inclusions and cracks • CT analysis of components • Analysis of plastic parts for cracks The system is expected to be available from the beginning of May and can be demonstrated until then. Please see the technical data below (documents). Ieljv Hc Ryjhccqmoib

Condition: good (used), Year of construction: 2011, Functionality: fully functional, The BF-Comet is equipped with Saki's unique line-scan camera image acquisition concept and vector analysis and can be used for all inspections (SMD, THT), both before and after soldering. Due to the very short cycle times, the operator practically never has to wait. This makes Saki technology ideal for benchtop use. The high-precision line-scan camera forms the central unit of the Saki image acquisition concept. During image acquisition, the circuit board is moved in one axis under the stationary optical system. The line-scan camera records line by line, with each line being recorded four times, alternating with the different light sources. After a few seconds, the image of the entire circuit board is available for inspection and programming. Variable and constant illumination methods are essential for reliable image analysis. Iijlhccqowbgwrjmsb The Saki system includes three central, variable units: coaxial (top), offset (side), and low (low) light sources. Thanks to the line scan concept, every component, regardless of its location on the circuit board, is always at the same distance and angle to the respective illumination. This results in evenly illuminated images for evaluation. The so-called top light unit is a 100% coaxial light source, which is introduced into the vertical camera view by a half-mirror. This creates a shadow-free image for 2D viewing. This is especially important for reliable solder joint inspection and inspections between tall components. The MLT illumination provides a clear, color-coded display between tinned/soldered and non-tinned surfaces. Surfaces without tin or with poor wetting are displayed in red tones and can thus be reliably detected using color recognition algorithms. Foreign objects such as "lost" components, solder balls, scratches, damage, etc. can be detected with Saki's ECD function with a little additional programming effort. Since the image of the entire circuit board is already available, this function only requires a few seconds of additional inspection time (computing time). Foreign Body Inspection - Automatic Library Creation. Saki's KPK function automatically creates a library for unrecognized/new components with a presence inspection tailored to the assembled components. - Automatic X/Y coordinate generation for THT solder joints. If the layout data (CAD) for the THT solder joints is missing, this function can be used to automatically generate a library using an unsoldered and a soldered circuit board. - Programming Wizard The software offers a wizard to guide the programmer through the entire programming process, from importing the CAD data, aligning the data, and assigning libraries.

Condition: good (used), Year of construction: 2011, Min. PCB width 60mm Max. PCB width 520mm Min. PCB length 100mm Center support SMEMA interface Ijlowh R Hkshccqmeib Temperature calibration Aerosol filter

Year of construction: 2011, operating hours: 4,752 h, Condition: ready for operation (used), Machine in great working condition!  Total assembly time 4752 hours. Comes with 2 x Transport conveyor (4 segment) 200cm (MY12) and 2 x Transport conveyor (2 segment)150cm (MY100). Possible to buy additionally following items: Magazines LM8 8x Ijlhccqewi Snlomjib LM1216 7x LMFLEX 2x ASM 1x Feeders White 8mm 121x Yellow 8mm 99x Red 8mm 38x Green 8mm 3x Black 8mm 4x Yellow 8.5mm (12mm) 16x Yellow 12.5mm (16mm) 4x Black 7.5-9.5mm (12mm) 24x Black 11-13mm (16mm) 10x LMFLEX 8mm 5x LMFLEX 12mm 1x LMFLEX 16mm 1x LMFLEX 24mm 10x LMFLEX 32mm 3x LMFLEX 44mm 2x Plus additional accessories KIT (ask for details).

Year of construction: 2010, Condition: excellent (used), Tex Tray Exchanger T5 Conveyor Auto width in-line option BHS Position: Middle / Mitte Component Height Range: 22mm / Bauteilhöhe: 22mm TPSys 4.2 Without AGILIS magazines and Feeders. Ielhsib Dr Isccqmeib

Year of construction: 2008, Condition: ready for operation (used), Two inspection machines for the semiconductor industry, specifically for PCB production, are available. 1) 3D solder paste inspection system Saki SPI-Spider, year of manufacture: 2007, inspection type: tomography, 2) automatic optical inspection system Saki AOI System BF-Frontier II, year of manufacture: 2008, resolution: 18µm, min. board dimensions X/Y: 60mm/50mm, max. board dimensions X/Y: 500mm/460mm, board warp: +/- 50mm. PCB dimensions X/Y: 500mm/460mm, PCB warp: +/-2mm, component clearance top/bottom: 40mm/40mm, rotation: 359°, transport height: 900mm, transport height adjustment: +/-20mm, machine dimensions X/Y/Z: approx. 850mm/1350mm/1250mm, weight: approx. 450kg. Documentation available. On-site inspection is possible. Iijlhswhfnvsccqmob

Condition: like new (used), Year of construction: 2022, Functionality: fully functional, NC joining module from Kistler NCFH 30 400 300 B H C G 30 kN Brake 18 Nm Year of manufacture according to seller: 2022 Comes from a test setup for pressing battery cells. This means it has only been used a short time. Includes control cabinet, joining module (including sensor as shown), and monitor. Islswhvrrehccqmoib Please note: The parts should be complete, but some of the cables have been cut off. Unfortunately, a circuit diagram is not available.

Condition: good (used), Year of construction: 2013, Functionality: fully functional, machine/vehicle number: S013A-12F0008, total length: 8,000 mm, Description: Ersa Versaflow 3 Selective Soldering Machine, Sequence: 3 preheating zones, 1 flux head on flux unit; 2 soldering units; 1 manual insertion conveyor; 2 Harpotec return lifts; Additional retrofit on the machine performed in 2022: • Pressure tank 2 l. V4A 1.4404 NR • Maintenance and improvement of the soldering machine done. Line is still in use. Can be used for any product (see product cluster). ----- Iiolowi Uz Iohccqmob Please send us your offer. Sale only within the European Union (EU), including Switzerland, Turkey, and Great Britain. Please send us your offer. Sale only within the European Union (EU), including Switzerland, Turkey, and the United Kingdom. ----- For technical data, see handout. Without packaging; any warranty is excluded. If you wish to disassemble the system yourself, please provide appropriate information in your bid. We assume no liability for the accuracy of the technical specifications, the completeness of accessories and tools, or compliance with all safety and environmental protection requirements specified in accident prevention regulations.

Condition: excellent (used), Year of construction: 2015, Functionality: fully functional, Kirsten Modula Wave Gen2 Wave Soldering System Inlet Fluxer Ijlhovvk Tnoccqmoib 2 Preheaters Soldering Module (Nitrogen) Outlet and additional roller conveyor for solder frames 6 solder frames Refurbished crucible filled with solder Various spare parts

Condition: ready for operation (used), Machine is in good operational condition! Further pictures and videos are available! Iielhccjwh Numoqmjb

Condition: used, Year of construction: 2007, Functionality: fully functional, Description: Inline convection reflow soldering system Other: 5 zones (3 preheating zones, Quattro Peak with underside heating) Peak zone (top / bottom): 4 heating modules Condensate trap in the cooling zone Cooled process chamber seal Process chamber length: 3,926 mm Heated process length, total: 2,798 mm Active convection section: 2,370 mm Iieljvq Nbyehccqmob Cooling zone length: 1,393 mm Free inlet / outlet length: 265 mm Process temperature (preheating zone / peak zone): max. 300 °C / 350 °C (peak) External exhaust air control Temperature monitoring Inlet height: 930 mm +/- 20 mm Chain transport, cam length 3 mm Transport width: 60 - 460 mm Fixed stop: front Passage height (top / bottom): 30 / 30 mm Automatic drip oiler with level reduction PCB support ABS self-cleaning system Interface: SMEMA

Year of construction: 2006, Condition: ready for operation (used), A DEK inline stencil printer is available for SMT production. Print accuracy at 1.33 Cpk: +/-25µm, max. PCB dimensions X/Y: 508mm/508mm, print speed: 150mm/s, print force: 20kg, print gap: 0mm-6mm, stencil separation: 0mm-3mm, PCB thickness range: 0.2mm-6mm, max. PCB weight: 1kg, max. warpage including PCB thickness: 8mm, component ground clearance: 3mm-42mm, transfer height range: 840mm-980mm, stencil loading height range: 925mm-1065mm, machine dimensions X/Y/Z: approx. 2100mm/1500mm/1600mm, weight: approx. 800kg. Documentation available. On-site inspection is possible. Expected to be available from August 2025. Ielhcjwhfn Ascqmsib

Year of construction: 2003, Condition: excellent (used), Functionality: fully functional, The Teradyne Spectrum 8851 test system is a versatile PC-based tester for testing a range of printed circuit boards. It offers high speed and accurate tests for a wide variety of applications and includes both hardware and software components. The Spectrum 8851 includes a Windows PC (W7), an LCD monitor, a mouse, a keyboard, and signal processing equipment. The device also features a PCIe expansion slot for connecting external peripherals such as data acquisition devices. The TERADYNE Spectrum 8851 also offers software support, including an easy-to-use Windows-based interface. Users can select from a variety of test sequences and customize the tests to their specific requirements. Centralizing test parameters allows users to easily switch between different tests, making it simple to develop a sequence tailored to their board. A powerful scripting language enables the fast and efficient development of complex test sequences. The machine includes powerful error analysis and reporting features that provide detailed analysis of all errors detected during testing. With a test library of up to 65,000 tests, the Spectrum 8851 can be tailored to the needs of a wide variety of applications. With its combination of hardware and software solutions, the Spectrum 8851 can provide users with reliable and accurate testing at a reasonable price. Ijlhccowhiq Isqmoib The test system is currently still in production and can be demonstrated upon request. If interested, we would be happy to send you a video of the system in operation.

Year of construction: 2008, Condition: excellent (used), Functionality: fully functional, For sale is a 6-axis placement robot from Erowa, this was used to load 2 die-sinking EDM machines from Ingersoll, both with tools and workpieces. The Ingersoll machines are also for sale and can be offered as a package Technical data: X-axis: 1200 mm Z-axis: 1050 mm C-axis: 350 ° A-axis: +/-180 ° B-axis: +/- 90 ° Y-axis: 1.1-18.74 m Disassembly, loading and shipping can be organized throughout Europe for an additional charge. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? Iielhcetdrkqocqmob For further information or contact options, please visit our website

Year of construction: 2021, Condition: new, Functionality: fully functional, Feeding and storage system for light articles in trays. Feeding of trays for magazine storage in automated production. Especially for surface or contour sensitive parts. Made in Germany • Designed for tray sizes up to 400 x 300 x max. 30mm. Ielhccqjt Dih Nemsib • Fast tray change time (4-8 seconds) • Tray weight incl. workpieces max. 5kg • Tray stacker weight max. 50kg • Positioning accuracy ± 1mm • PLC control with operating and monitoring display • ESD equipment • Safety package light curtain - Leuze for tray stacker • Preparation communication AGV - Siemens IWLAN client • RFID read-write head • Autonomy time increase 1 stack • Machine safety: active door interlock • Low space requirement, due to compact design • Flexible adaptation to different machines, due to different interfaces • Low investment costs • Complete equipment • Stable design • (solid steel construction, powder coated) • No machine adapters necessary • Supply voltage 400V / 50Hz / 3ph • Compressed air connection min. 6bar • Dimension: 1200 x 600 x 2300mm (LWH)

Year of construction: 2015, Condition: ready for operation (used), Functionality: fully functional, Model NPS510E Fully automatic in-line stencil printer with 2D paste inspection - Max. PCB size: 510x450mm - Max. stencil size: 736x736mm - Cycle time (without printing): 8 seconds Ijlhccjvuprmsqmeib - Alignment repeatability: 12.5µm at 3 Sigma - Squeegee pressure: 4-30kgf - User interface: Windows - Dimensions: WxDxH 1.20 x 1.40 x 1.50m; 900kg Included: - Stencil cleaning system, wet/dry/vacuum - CCD camera for 2D inspection of paste print and stencil - Automatic conveyor belt width adjustment - Support block - Support pins - 2 metal squeegees

Condition: good (used), Year of construction: 2020, Inline reflow soldering under vacuum System was in operation until dismantling Available now; commissioning can be carried out by the manufacturer after consultation. Serial number: R036A-20D0012 Year of manufacture: 2020 Dimensions: 8,063 x 2,205 x 1,969 mm (L x W x H) Weight: Approx. 5,000 kg Rated power: 138 kW Continuous power during operation: approx. 14 - 25 kW Extraction capacity: 2 nozzles, 400 m³/h each Transport system: Working width: 100 - 630 mm, center support PCB length: 120 - 400/600 mm Process zone: Iielhccqsv Inw Usmob Inlet 1,011 mm Heating zone with vacuum 4,600/4,750 mm Cooling zone 1,400 mm Outlet 730 mm Heating system: 4 cooling zones 11 heating zones, including: 9 convection heating modules Top/bottom preheating zone 2 convection heating modules top/bottom soldering zone Vacuum chamber: 400 mm Chamber volume: approx. 110 l / 150 l Pump power: up to 5.3 kW Ultimate pressure: up to 10 mbar

Year of construction: 2012, Condition: ready for operation (used), An i-Pulse SMD placement machine with IQ Vision, a subsidiary of Yamaha, is available. PCB thickness range: 0.4mm-4.8mm, min. PCB dimensions X/Y: 50mm/30mm, max. PCB dimensions X/Y: 1480mm/510mm, transport speed: 900mm/s, number of heads: 4, production output: 24000CPH. Placement accuracy CHIP: +/-0.04mm, placement accuracy IC: +/-0.025mm, placement angle: +/-180°, max. component size range: 0402-120mm/90mm, max. component height: 30mm. Machine dimensions X/Y/Z: approx. 1750mm/1750mm/1450mm, weight: approx. 1500kg. Including 3x feeder carriages and 2x tray feeders for installation in the machine. Documentation available. On-site inspection is possible. Ielhcowf Nywecqmeib

Condition: good (used), Year of construction: 2005, Functionality: fully functional, We are offering a SEHO wave soldering system, model MWS 2340. The wave soldering system was built in 2005 and is in good condition. The system is currently in operation and is expected to be available in weeks 28-30. It is welcome to view it during operation. The conveyor belt and fluxing station are also included in the offer. The wave soldering system was operated with a lead-free alloy (type: Sn3.5Ag0.7Cu). The system's operating system is Windows 7. The belt length is 15.5 meters. Including the lifting station and turning station, the total length is approximately 17.55 meters. The following system documents are available. ■ Operating instructions ■ Maintenance manual ■ Risk assessment Islhccsv Uhzyeqmsib ■ Operating instructions ■ CE conformity ■ Production approval ■ Analysis report for the tin (level of contamination), result: OK The stated price refers to the system without tin. However, it is possible to purchase the system with tin. For the tin (approx. 620 kg), we would charge a surcharge of €41,974. (Depending on the daily exchange rate)

Year of construction: 2000, Condition: good (used), ERSA ETS 250 wave soldering system Year 2000 10 soldering frames, 360 mm long Islewfd Hlehccqmeib 1 soldering frame, 420 mm long

Year of construction: 2008, Condition: used, machine/vehicle number: SN Nr. 803603, Our Ekra X 6 HSP screen printer is for sale. The system is already in our warehouse and has operated flawlessly until the end. Iielhccswgk Sqsqmsb Year of manufacture 2008 Immediately available. We are happy to answer any further questions you may have about the machine.
