Used Haas St-20Y for sale (6)

Condition: good (used), Year of construction: 2016, Swing 806mm, Swing over cross slide 527mm, maximum cutting diameter 305mm, 593mm maximum cutting length, 50mm Bar capacity, Dsdpfx Aex Dk Ahedujwf 8” chuck, 20Hp Spindle Motor, C axis 0.01 degrees, Y axis +/- 51mm, 4000rpm spindle, 12 Station turret, swarf conveyor, tailstock, tool setter, coolant,

Year of construction: 2014, operating hours: 5,316 h, condition: ready for operation (used), Main Drive Spindle speed range 4000 Spindle bore 52 mm Number of axis 3 Movement X-Axis Movement 213 mm Y-Axis Movement ±51 mm Z-Axis Movement 572 mm Turret Tool taper VDI/BOT Tools Number of station 12 Dedpfx Aex D Nzpedujwf This 3-axis HAAS ST-20Y was manufactured in 2014. It features a CNC lathe with C and Y-axis capabilities, a spindle speed of 4000 rpm, and a chuck size of 8 inches. Additional features include a 12-station turret, chip conveyor, and a programmable hydraulic tailstock. Ideal for precision turning operations. If you are looking to get high-quality turning capabilities consider the HAAS ST-20Y machine we have for sale. Contact us for more information about this machine. Application Types Turning

Condition: like new (used), Year of construction: 2023, operating hours: 800 h, functionality: fully functional, machine/vehicle number: SN3128158, turning diameter over cross slide: 533 mm, turning length: 572 mm, spindle bore: 63 mm, spindle speed (max.): 4,000 rpm, New condition + tooling + bar fender Dedpfxovwz T Us Aduewf

Year of construction: 2022, operating hours: 119 h, condition: ready for operation (used), Control Unit Brand HAAS Model NGC Main Drive Number of axis 3 Spindle Speed 4000 RPM Spindle motor power 14.9 kW Movement X-Axis Movement 213 mm Z-Axis Movement 571 mm Dsdpfx Adjx D Ik Neuswf Y-Axis Movement 50 mm Technical Specification Driven Tools yes This 3-axis HAAS ST-20Y was manufactured in 2022, featuring X-axis travel of 213 mm, Y-axis travel of ±50 mm, and Z-axis travel of 571 mm. It includes a spindle bore of 64 mm and a three-jaw chuck diameter of 210 mm. The machine offers a maximum spindle speed of 4000 rpm and comes equipped with a chip conveyor, tool measuring probe, and a hydraulic tailstock. Consider the opportunity to buy this HAAS ST-20Y horizontal turning machine. Contact us for more information. Application Types Turning

Year of construction: 2019, operating hours: 3,728 h, condition: ready for operation (used), Control Unit Brand HAAS Model NGC Main Drive Spindle Speed 4000 RPM Spindle bore 88.9 mm Number of axis 4 Spindle motor power 149 kW Movement C-Axis Movement 360 º X-Axis Movement 213 mm Z-Axis Movement 572 mm Y-Axis Movement 51 mm Tools Slots in storage 12 Dwjdpjx D Hn Tsfx Adusf Technical Specification Max. Bar Diameter 64 mm Driven Tools yes This HAAS ST-20Y lathe, manufactured in 2019, features a Y-axis, tailstock, automatic tool probe, and chip conveyor. With a spindle speed of up to 4000 rpm and driven tools supported by a C-axis, it offers strong capabilities for complex machining. If you are looking for a high-quality turning solution, consider the HAAS ST-20Y we have for sale. Contact us for more information. Application Types Turning

Year of construction: 2019, operating hours: 3,934 h, condition: ready for operation (used), Control Unit Brand HAAS Model NGC Main Drive Spindle speed range 4000 Spindle motor power 14.9 kW14.9 kW Movement X-Axis Movement 213 mm Y-Axis Movement ±51 mm Z-Axis Movement 572 mm Media Chip conveyor Yes Djdsx D Nxhopfx Aduswf Additional Equipment ATP – Automatic tool probe Install Kit – Bar feeder installation kit with adapters for bar diameters 9–44 mm / Programmable, pneumatically operated finished part catcher (max. part dimensions: 108 mm x 54 mm, max. weight: 2.27 kg) CONVEYOR – Chip conveyor (belt type) LINER ADAPTER 2.00 – Haas liner adapter for spindle with bar diameter 2" (51 mm) HAAS Bar Feeder – Compatible with HAAS lathes (ST-10 to ST-35), for automatic bar feeding LT-6K-UP – Option to increase the speed of driven tools up to 6000 rpm PCAT – Pneumatic part catcher, programmable, for parts up to 96 mm x 152 mm PTS – Hydraulic tailstock This 3-axis HAAS ST-20Y was manufactured in 2019. A robust horizontal turning machine, it offers reliable performance for precision machining. Consider the opportunity to buy this HAAS ST-20Y horizontal turning machine. Contact us for more information. Application Types Turning
