Condition: used, Year of construction: 2014, workpiece weight (max.): 25,000 kg, total length: 10,000 mm, total height: 6,000 mm, total width: 10,000 mm, overall weight: 60,000 kg, DÖRRIES SCHARMANN VCE 3000 / 280 CNC Vertikaldrehmaschine Modernisierung: im Rahmen des Retrofits im Jahr 2014 auf Siemens SINUMERIK 840D SLArbeitsbereichTi schdurchmesser: 2.800 mm Max. Umlaufdurchmesser / Drehdurchmesser: 3.000 mm Ijdpfx Acszmkzpjhjid Max. Tischbelastung: 25.000 kg Max. Drehhöhe: ca. 2.100 mm Verfahrweg X-Achse: ±1.550 mm Verfahrweg Z-Achse / RAM-Hub: 1.500 mmHauptantrieb und SpindelnHauptantrieb: Siemens-Hauptmotor Antriebsleistung: 130 kW Max. Spindeldrehzahl: 4.500 min⁻¹ Betriebsart: S6, 40 %Ausstattung: 2 vertikale SpindelnWerkzeugwechsler und Peripherieo    2 automatische Werkzeugwechslero    Kühlschmierstoffanlageo    Späneförderero    Ölnebelabsaugungo    2 separate HydraulikaggregateBetriebsstunden: ca. 12.571 Stunden laut mechanischem Betriebsstundenzähler Table diameter: 2,800 mm Control: Siemens SINUMERIK 840D SL Component weight max.: 25,000 kg Swing: 3,000 mm Rotation height max.: 2,100 mm Weight approx.: 60,000 kg Dimensions (LxWxH) approx.: 10000 x 10000 x 6000 mm Year of construction: 2,014 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: No

Condition: used, Year of construction: 2012, swing diameter 210 mm x-travel 400 mm z-travel 200 mm control FANUC Series 32i Model A weight of the machine ca. ~ 5.500 kg Iedpfx Acszmiwveheid Vertical Turning Machine | EMAG - VL 3 + VL 3 The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL3 | VL-3

Condition: used, swing diameter 210 mm x-travel 400 mm z-travel 200 mm control FANUC Series 18i TB weight of the machine ca. ~ 5.500 kg Vertical Turning Machine | EMAG - VL 3 mLT with driven tools The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Isdpozmiwpsfx Achoid #Tags: VL3 | VL3mLT | VL-3

Condition: used, Year of construction: 2012, swing diameter 210 mm x-travel 400 mm z-travel 200 mm control SIEMENS SINUMERIK 840D sl weight of the machine ca. ~ 5.500 kg Vertical Turning Machine | EMAG - VL 3 + VL 3 Y The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Iedpjzmiwiofx Achoid #Tags: VL3 | VL-3

Condition: refurbished (used), Year of construction: 1992, functionality: fully functional, feed length X-axis: 2,500 mm, feed length Z-axis: 3,200 mm, workpiece weight (max.): 25,000 kg, travel distance X-axis: 2,500 mm, travel distance Z-axis: 1,500 mm, spindle motor power: 51,000 W, chuck outer diameter: 2,500 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 1,500 rpm, turning diameter: 3,000 mm, total height: 3,000 mm, type of input current: three-phase, turning height: 3,200 mm, rotational speed (min.): 5 rpm, rotational speed (max.): 150 rpm, torque: 452 Nm, overall weight: 40,000 kg, year of last overhaul: 2022, Machine was overhauled in 2022 with new spindle servo motor and control unit The machine is under power and can be checked in our workshop Details are as below. Fagor 8055i-TC-4 Cnc Kontrol Ünitesi ii) 512 Mb Harddisk iii) Look Ahead (200 Blok Önden Okuma) iv) USB ve RS232 Haberleşme Protokolleri v) Türkçe Kullanım Paneli, vi) Türkçe Alarm Listesi vii) Parametrik Programlama Özelliği viii) 12 Dil Kullanım Seçeneği ix) Manual yada Otomatik Takım Kalibrasyon x) Vidalı Mil Telafisi (Ballscrew Compensation ) xi) Kontrol Üzerinde Ballbar Testi ve Osilascop Özelliği xii) 4 Eksen Motor & Sürücü Kontrol Kabiliyeti xiii) Uzatmalı standart El çarkı (3 M) xiv) 3 Eksen Fagor Servo Motor & Sürücüleri Spindle Servomotor, Power (S1/S6) 51/71 kW, Nom. Torque (S1) = 325 Nm, Max Torque 1 FM7-A510-C3B1-E01 (S6) = 452 Nm, 1500 / 5000 rpm Integrated C AXIS Encoder, Foot Mounting,, Keyway, Protection Degree IP44, ") Iisdpfozl H Ipex Achsd

Condition: good (used), Year of construction: 2007, - Speed range: [rpm]: 6,000 - Torque: [Nm]: 480 - Max. turning diameter over bed: 290 mm - Chuck diameter: 200 mm - Turret: 12-position, VDI 40, Sauter - Driven tools: 7.8 kW - Travel: - X-axis: 550 mm - Z-axis: 200 mm - Rapid traverse (X/Z) [m/min]: 30 / 20 - Feed (X/Z): [m/min.] 11 kN - Features: - Left-hand chip conveyor; 300 mm wide; ejection height 800 mm - Probe; direct linear measuring system; glass scales on all axes - Heidenhain circulating pickup tape - Machine with feed belt for part loading - Specification: - Overhauled in 2007 for approx. €50,000, complete headstock replaced. Iijdpszlyq Djfx Achod - Feed unit exchanged.

Condition: excellent (used), Year of construction: 2017, 2 x YOU JI TY 400 H Maximum turning diameter: 400 ∅ mm Maximum turning diameter: 250 ∅ mm Maximum turning height: 350 mm Maximum workpiece weight: 300 Kg Spindle speed: 4,000 rpm Tool turret (ATC): 8 Iedezlcvvepfx Achjid Chip conveyor Coolant tank Weight: 5,500 Kg

Condition: good (used), Year of construction: 2008, Ref. -No.: 10657 Manufacturer: EMAG Type: EMAG VTC 250 Year of construction: 2008 Type of control: CNC Control: Siemens Sinumerik 840D Storage location: Hakberstadt Country of origin: Germany Turning Length: 630 mm Tool Taper: VDI 40 Turret places: 1 Pcs Number of tool stations: 12 pc Turning Speeds: 5000 RPM Chuck diameter: 250 mm Further information: - The machine features an overhead drive spindle with a tailstock at the bottom. - Coolant tank, approx. 1,000 L, including - a paper filter roll. - Clamping devices: Hainbuch clamping top, including various centering tips - Gripping devices on the turrets for feeding and removing raw and finished parts during magazine operation. - Magazine loading Iedpfszkthgex Achjid - Vertical pick-up lathe, which can generally be easily upgraded for automatic loading and unloading. The machine can be viewed while powered on by prior arrangement.

Condition: good (used), Year of construction: 2005, functionality: fully functional, Equipment: documentation/manual, BOEHRINGER NV 250 CNC vertical turning lathe For sale is a BOEHRINGER NV 250 CNC vertical turning lathe, manufactured in 2005. The machine is ideally suited for automated series production of turned parts. The pick-up spindle and the existing workpiece feeder enable automatic loading and unloading. Technical data: Manufacturer: BOEHRINGER Type: NV 250 Year of manufacture: 2005 Spindle head: A6 Max. chuck diameter: 250 / 315 mm Spindle bore: 65 mm X-axis: 760 mm Z-axis: 260 mm Y-axis optional: ±50 mm Max. spindle speed: 5,000 rpm Spindle power: 31 kW Iijdpfx Acozkk Udshsd Max. torque: 350 Nm C-axis: available 12-position tool turret Tool holder: VDI 40 / DIN 69880 Rapid traverse X/Z: 120 / 40 m/min Machine weight: approx. 8,500 kg Connection: 400 V / 50 Hz / 3 AC Equipment: Pick-up spindle Automatic workpiece feeder C-axis 12-position turret VDI 40 tool holder Chip conveyor Coolant system UNIFIL extraction system / filter system Documentation available Condition: Used Machine complete Inspection under power possible by arrangement

Condition: used, Table Size 72” Machine swing 84” Table speed Range 3.8 to 83 rpm. Feed range .005” to 0.250” per rev. Iijdpfx Acjzkkcushed Max Height under cross slide 48” Max Height under turret 48” Ram Travel 38” 4 Std jaws Main motor 40hp Newall 2 Axis Digital Read Out

Condition: used, Year of construction: 2016, operating hours: 18,071 h, functionality: fully functional, machine/vehicle number: 06960000941, spindle motor power: 25,000 W, spindle speed (max.): 5,000 rpm, rapid traverse Y-axis: 30 m/min, torque: 280 Nm, input voltage: 400 V, overall weight: 6,000 kg, power: 25 kW (33.99 HP), input frequency: 50 Hz, controller manufacturer: Siemens, controller model: Sinumerik 849D sl, input current: 63 A, tool type: VDI 40, number of axes: 3, DMG MORI CTV 250, 2nd Generation – Vertical Turning Center (Pick-up), Year of Manufacture 2016 For sale is a well-maintained DMG MORI (Gildemeister) CTV 250, 2nd Generation, manufactured in 2016, with only 18,071 spindle hours. The machine is fully equipped for automated series production of chucked parts and is currently still powered on – inspection and demonstration possible by arrangement. Control System & Drive Siemens Sinumerik 840D sl (Slimline) including ShopTurn option AC main drive 25 / 32 kW, torque 280 / 360 Nm Spindle speed up to 5,000 rpm, duty cycle 100 % / 40 % Iijdpfx Acezi R R Nshed Hollow cylinder, programmable clamping pressure via NC program Axes & Tools 12-station turret (disc diameter 340 mm), all stations powered (UDI 40) C-axis with powered tool system Y-axis +90 / -65 mm Linear guides, ball screws, glass scales, AC servomotors with absolute encoder Rapid traverse 30 m/min Automation & Metrology Workpiece transport system SRA 160 (drag chain, NC-controlled) including drag chain set Storage capacity: 30 parts (Ø 30–70 mm, max. 7 kg) or 18 parts (Ø 30–100 mm, max. 15 kg), max. total weight 320 kg including pallets Workpiece diameter 30–160 mm, workpiece height max. 160 mm Robot interface Profinet (electrical interface for 6-axis robot) Workpiece probe Renishaw LP2DD at the loading/unloading station, measuring accuracy 10 µm, with air blow cleaning Coolant & Peripherals Coolant system 8 / 20 bar, tank 600 l, high-pressure pump 20 bar / 40 l/min Coolant supply via turret disc to all stations Band filter system 40 µm with forced indexing, coolant level monitoring Hinged belt chip conveyor with extended discharge chute (+300 mm), enlarged chip container, modified sludge pump Aluminum machining package Integrated work area extraction max. 400 m³/h, work area flushing with 3 flushing nozzles Cabinet cooling up to 40 °C, hydraulic oil cooler Air blower via main spindle, 4-color signal light Remote diagnostics via the internet Connection values: 400 V / 50 Hz, 40 kVA, 63 A · Weight: approx. 6,000 kg Sale from current location, dismantling/loading/transport by arrangement or by the buyer. Sale is subject to the exclusion of all warranties (commercial sale of used machines, sold as seen). Please contact us if you have any questions or would like to arrange a viewing.

Condition: good (used), Year of construction: 2008, Vertical CNC-Lathe Machine type: Gildemeister CTV 400 V3 Control: Sinumerik 840D powerline (XP) Year: 2008 SPECIFICATIONS X-Axis: 700 mm Z-Axis: 340 mm C-Axis Max. revolution: 3.500 rpm Spindle power: 47 kW Torque: 1.100 Nm Direktantrieb Amount of turrets: 1 Tool capacity: 12 Driven Tools: 12 Tool: VDI 50 Iijdpfx Acjzing Ushjd Amount of paletts: 15 Accessories

Condition: good (used), Year of construction: 2007, Parts shown by hand not come. Ijdpfozibgzex Acheid Technical details are shown on picture.

Condition: used, Year of construction: 2002, feed length Y-axis: 1,200 mm, feed length Z-axis: 900 mm, Make: Daewoo-Doosan Iisdpfxsziavno Achod Model: PUMA V-1200M Category: Vertical CNC Turning Center Year of manufacture: 2002 CNC Control: FANUC Series 18-T Machine weight: 23,000 kg Machine dimensions Length: 8,500 mm Width: 4,900 mm Height: 5,650 mm Capacities Maximum turning diameter: Ø 1,600 mm Maximum machining diameter: Ø 1,600 mm Maximum machining height: 1,200 mm Maximum load on spindle: 6,000 kg Main spindle Chuck diameter: Ø 1,200 mm Spindle speed: 2 ÷ 320 rpm Number of ranges: 2 Motor power: 37/45 kW (continuous / 30 min) Powered spindle (RAM) Tool holder: ISO-50 Speed: 15 ÷ 1,500 rpm RAM section: 240 × 240 mm Travels X-axis: 1,200 mm Z-axis: 900 mm C-axis: 360° (minimum resolution 0.001°) Feed rates Rapid traverse X/Z axes: 10,000 mm/min Working feed rate X/Z: 3,000 mm/min Turret Number of stations: 16 Tool holders: BT-50 Drawbar type: 403 P50T-I Maximum tool diameter: Ø 400 mm Maximum tool length: 450 mm Maximum tool weight: 50 kg Maximum tool weight in the magazine: 600 kg Accessories Chip conveyor Coolant tank with washing pumps Spindle line cooler Powered and fixed tool holders Manuals, electrical diagrams, and CE Declaration.

Condition: excellent (used), Webster Bennett 48" Elevating Rail Vertical Turning Lathe With Copying attachment 48" diameter table Can be shown demonstrating at our premises if you wish to view. Iodpfxozh Ndrj Acheid

Condition: excellent (used), Webster & Bennett 72" Elevating Rail Vertical Turning Lathe with copying attachment 72" diameter table Isdpfxszh Ndfs Achsid Can be shown demonstrating at our premises if required.

Condition: good (used), Year of construction: 2013, functionality: fully functional, CNC vertical lathe / twin-spindle vertical turning machine Year of commissioning: 2013 Manufacturer: FAMAR S.r.l., Italy Voltage: 400 V / 50 Hz / 3P + N + PE Power supply: 90 kW / 160 A max. Auxiliary circuits: 230 V AC PLC and general devices: 24 V DC CE marked: Yes Chip conveyor: Yes Iijdpszh H Rpefx Achsd Workpiece conveyor system: Yes Concept: tandem machine with two independent machining stations Condition: used, regularly serviced, currently connected

Condition: used, Make: Doosan Model: Puma V-550M CNC Vertical Lathe Year: 2012 Max. cutting diameter: 800 mm Max. cutting height: 750 mm 2,000 rpm 22/30 kW motor 12-position turret 380 mm 4-jaw manual chuck Iedpfx Acezh D Tujheid 1 angular milling holder Chip conveyor Fanuc 32iA control

Condition: ready for operation (used), Year of construction: 2009, travel distance X-axis: 530 mm, travel distance Z-axis: 750 mm, spindle motor power: 38,000 W, spindle speed (max.): 5,000 rpm, number of slots in tool magazine: 22, number of axes: 4, This 4-axis EMAG VTC 250 vertical turning machine was manufactured in 2009. It features a maximum workpiece diameter of 140 mm and a workpiece length of 630 mm. The machine is equipped with a chuck diameter of 250 mm and a maximum spindle speed of 5,000 rpm. If you are looking to get high-quality turning capabilities, consider the EMAG VTC 250 machine we have for sale. Contact us for further details. - Workpiece Diameter Max: 140 mm- Workpiece Length Max: 630 mm- Chuck Diameter: 250 mm- Main Spindle Speed Max: 5,000 rpm- Main Spindle Power (40% ED): 38 kW- Main Spindle Torque (40% ED): 450 Nm- Rapid Traverse Rate X / Z: 30 / 40 m/min- Tool Taper: VDI 40- Number of Turrets: 2- Total Tool Stations: 2 x 11 (22 stations total, all live capable)- Integrated Automation: Self-loading pick-up spindle design with workpiece storage tracks- the technical specifications may vary slightly Technical Specification Iedpfx Ajzhblujchjid Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 332 mm, travel distance Z-axis: 625 mm, number of axes: 4, This 4-axis EMAG VTC 100 vertical turning machine was manufactured in 2014. It features dual-turret machining with 2 tool stations, live tooling, and an enclosed working area. The machine is designed for high-volume production and is suitable for shaft machining. If you are looking to get high-quality turning capabilities, consider the EMAG VTC 100 machine we have for sale. Contact us for further details. • 4x units • CNC Control: Siemens SINUMERIK • Turrets: 2 • Live Tooling: Yes • Enclosed Working Area • Hydraulic Chuck • Automatic Workpiece Handling • Dual-Turret Machining • Suitable for Shaft Machining Isdpjzhbiaofx Achsid • Suitable for High-Volume ProductionThe technical specifications may vary slightly as these are custom made machines Technical Specification Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2011, operating hours: 38,546 h, travel distance X-axis: 745 mm, travel distance Z-axis: 300 mm, spindle motor power: 18,000 W, spindle speed (max.): 4,500 rpm, total height: 3,200 mm, total width: 1,500 mm, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840Dsl with integrated PLC S7-300, positioning accuracy: 0.001 mm, product length (max.): 3,900 mm, number of slots in tool magazine: 12, number of axes: 2, This EMAG VSC 250 vertical turning machine was manufactured in 2011. It features a Siemens SINUMERIK 840Dsl control system, a robust hydraulic 6-jaw chuck, and a flange turret with 12 tool positions. With a spindle speed up to 4500 rpm and a main spindle drive power of 18kW, it's ideal for precise, efficient operations. For more information about this vertical turning machine, please reach out to us. Additional equipment, optional • Hydraulic 6-jaw special chuck from EMAG with face clamping device and central lubrication • 15-inch TFT monitor • V24 interface Machine Benefits Qualitative Machine Benefits • Machine from single-shift operation • Maximum room temperature: up to 30°c • Maximum humidity: 50% • Sound pressure level: 78 db(a) • 2nd unit with yom 2014 available Technical Machine Benefits • Spindle torque: 300 nm • Vdi shaft diameter: 40 mm • Maximum speed of driven tools: 6000 rpm • Maximum torque of driven tools: 40 nm / 8. 5 kw • Coolant system standard delivery pressure: 7 bar maximum delivery pressure: 7 bar internal coolant supply pressure range: 7 bar (non-adjustable) coolant tank capacity: 360 liters • Chuck model: 6agf 260 k6 k14 • Chuck diameter: 260 mm • Chuck weight: 57 kg • Maximum clamping force for internal clamping (50 bar): 12. 8 kn • Maximum clamping force for external clamping (50 bar): 4. 2 kn Extra Information Machine still under power Technical Specification Iiedpjzg I Dhsfx Achod Driven Tools Yes Dimensions Machine Depth 3900 mm

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 745 mm, travel distance Z-axis: 300 mm, spindle motor power: 18,000 W, spindle speed (max.): 4,500 rpm, total height: 3,200 mm, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840Dsl, number of axes: 2, This EMAG VSC 250 vertical turning machine was manufactured in 2014. It features a powerful main spindle drive with 18kW and a speed range of 0-4500 rpm. Equipped with a Siemens SINUMERIK 840Dsl control system and a robust 12-position EMAG flange turret, it ensures precise and efficient operations. Ideal for handling workpieces up to 6kg with its specialized hydraulic chuck. For more information about this vertical turning machine, please reach out to us. Additional equipment, not included • Coolant tank capacity: 360 liters Machine Benefits Technical Machine Benefits • High working accuracy, rapid traverse speeds, high maximum speed of driven tools • Machine from single shift operation • Maximum room temperature: up to 30°c • Maximum humidity: 50% • Sound pressure level: 78db(a) Extra Information Machine still under power Technical Specification Through-spindle Coolant Yes Dimensions Iijdpfxozg H Dys Ached Machine Depth 3900 mm

Condition: used, Year of construction: 2019, operating hours: 17,324 h, functionality: fully functional, machine/vehicle number: 06990000471, spindle speed (max.): 5,000 rpm, type of input current: three-phase, rotational speed (max.): 5,000 rpm, input voltage: 400 V, overall weight: 6,500 kg, input frequency: 50 Hz, controller manufacturer: Siemens, controller model: 840d sl, For sale is a used DMG CTV 250 vertical turning center in good condition and ready for operation. The machine is equipped with driven tools, allowing for the economical complete machining of complex workpieces. Ijdezg Dy Ejpfx Achjid The scope of supply also includes a parts conveyor belt with 30 shuttles for automated workpiece transport and efficient series production. If you have any questions or require further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 2023, machine/vehicle number: 21760666, feed length X-axis: 420 mm, turning height: 780 mm, Machine Data • Year of manufacture: 2023 • Recorded operating hours: 2,730 • Machine control system: SIEMENS, Type SINUMERIK 840D SL Technical Data • Travel ranges o X-axis travel: 420 mm o Z1 / Z2-axis travel: 780 mm o Z3-axis travel (tailstock): 600 mm o Z4-axis travel (steady rest, optional): 550 mm o Y-axis travel (optional): +51 / -23 mm • Rapid traverse rates o Z1 / Z2-axis: 60 m/min o Z3-axis (tailstock): 30 m/min o Z4-axis (steady rest, optional): 30 m/min o X-axis: 30 m/min o Y-axis (optional): 15 m/min • Working area o Distance between centers (spindle nose - tailstock): 780 mm o Max. turning diameter: 300 mm o Max. turning length: 750 mm o Workpiece weight: approx. 300 kg • Performance data Iodszgfphspfx Achsid o Max. speed: approx. 6,000 rpm o Power: approx. 26 kW • Tool turret o Tool positions: 12 o Turret indexing time, one station with locking: 0.3 s o Turret indexing time, station to station with locking: 0.5 s o Tool holder (DIN 69880): VDI 40 • Weight o Total weight: approx. 13,000 kg Peripherals • Chip conveyor, BÄR & CO., Type GF25L42L-P63, year of manufacture 2017, serial no. 61170009 • Air filter unit, IFS, Type M 1600, year of manufacture 2015, serial no. 544070-1, self-weight approx. 85 kg, connection power 400 / 460 V, 50 / 60 Hz, 0.75 kW, 1.7 / 1.5 A • Coolant filter unit, BÄR & CO., Type SF 51, year of manufacture 2018, serial no. 61180006 • Cooling unit, RKV, Type 4.3 K, year of manufacture 2018, serial no. 3-36613, connection power 400 V / 50 Hz, permissible operating pressure approx. 28 bar, tank volume approx. 90 l

Condition: excellent (used), Year of construction: 2021, Maximum turning diameter 2800 mm Maximum swing diameter 3000 mm diameter of spindle flange 1100 mm control Siemens 840 D sl Table rpm 230 1/min Maximum speed of driven tools 6000 1/min x-travel 2700 mm z-travel 1000 mm Feed - X 24 m/min feed capacity - x 22 kN tool taper CAPTO C8 Isdpfjzf Np Nex Achsid total power requirement 200 kVA dimensions of the machine ca. 10,4 x 6.3 x 5,7 m weight of the machine ca. 120 t Equipment/Accessories: - 2 tool changers one with 25 positions and one with 41 positions - 2 x chip conveyors - Coolant system, 6 bar - High-pressure cooling, 70 bar - Knoll paper belt filter - 12-jaw balancing chuck, RÖHM - internal coolant supply - Hydraulic unit - Automatic door - Electric handwheel - Technical documentation
