WOOD MASTER
WOOD MASTER from Kaunas
JSC “WOOD MASTER” is one of the biggest suppliers of wood processing equipment in the Baltic States since 1995.
WOOD MASTER
K. Petrausko 26
44156 Kaunas
Lithuania
Current offers from similar dealers
Listing
Drachten
7,501 km
High speed fourside moulder 300 m/min
WeinigHydromat 4300
WeinigHydromat 4300
Call
Condition: like new (used), Year of construction: 2023, functionality: fully functional, Factory new – never installed!
Weinig Hydromat 4300, high speed planer and moulder
Feed speed 30-300 m/min
Spindle 1 (Bottom)
– Radial CNC-controlled adjustment
– Hydro bearing with automatic locking
– Straight jointer, fully automatic
Spindle 2 (Top):
– Radial and axial CNC-controlled adjustment
– Hydro bearing with automatic locking
– Straight jointer, fully automatic
Spindle 3 (Right):
– Radial and axial CNC-controlled adjustment
– Straight jointer, fully automatic
Spindle 4 (Left):
– Radial and axial CNC-controlled adjustment
– Straight jointer, fully automatic
Spindle 5 (Top):
– Radial and axial CNC-controlled adjustment
– Hydro bearing with automatic locking
– Straight jointer + profile jointer fully automatic
Spindle 6 (Bottom):
– Table tops with wood inserts, maximum cutting height of 65 mm with a flange of 100 mm
– Rotaplan pressure plate above the bottom shaft
– Radial and axial CNC-controlled adjustment
– Straight jointer, fully automatic
Iedpfjzu Awrsx Ah Esba
– Hydro bearing with automatic locking
General:
– Horizontal CNC-controlled pressure rollers
– CNC-controlled positioning input
– Marathon Powercoating Plus
– Automatic waxilit pump
– Weinig WMC with touchscreen
– Kickback protection for sawing operations
– Machine with spindle and feed brakes
– Safety and sound insulation housing
Listing
Germany
7,743 km
Planing and profiling machine HOMAG OPTIMAT LPP 306 (2019)
HOMAGOPTIMAT LPP 306
HOMAGOPTIMAT LPP 306
Call
Condition: used, Year of construction: 2019, - 6 working spindles
- max. working width 250 mm
- feed rate 6 - 24 m/min
used planing and profiling machine
Manufacturer: HOMAG
Type: Optimat LPP306
Ibodpfx Ahezuzf Ue Eoa
Year of construction: 2019
OPTIMAT LPP306
Planing and profiling machine with 6 working spindles.
Workpiece width after processing:
- min. 10 mm
- max. 250 mm
Workpiece height after processing:
- min. 10 mm
- max. 160 mm
Control system:
- PowerControl with powerTouch LPP300
Infeed table 2,500 mm
Feed rate min. 6 m/min
max. 24 m/min
FIRST LOWER SPINDLE:
- Spindle motor power 7.5 kW
- Siemens IE3 energy-saving motor
Power speed range:
- 7.5 kW
- 6,000 rpm
Spindle diameter 40 mm
Spindle length 281 mm
FIRST RIGHT SPINDLE:
Spindle motor power 7.5 kW, adjustable
- Siemens IE3 energy-saving motor
- Spindle speed continuously adjustable
Power speed range:
- 7.5 kW
- 4,000 rpm
- up to 8,000 rpm
Spindle diameter 40 mm
Spindle length 176 mm
FIRST LEFT SPINDLE:
Spindle motor power 7.5 kW, adjustable
- Siemens IE3 energy-saving motor
- Spindle speed continuously adjustable
Power speed range:
- 7.5 kW
- 4,000 rpm
- up to 8,000 rpm
Spindle diameter 40 mm
Spindle length: 176 mm
Total length: 176 mm
FIRST UPPER SPINDLE:
- Spindle motor power 7.5 kW, adjustable
- Siemens IE3 energy-saving motor
- Spindle speed continuously adjustable
Power speed range:
- 7.5 kW
- 4,000 rpm
- up to 8,000 rpm
Spindle diameter 40 mm
Spindle length 266 mm
SECOND UPPER SPINDLE:
Spindle motor power 7.5 kW, adjustable
- Siemens IE3 energy-saving motor
- Spindle speed continuously adjustable
Power speed range:
- 7.5 kW
- 4,000 rpm
- up to 8,000 rpm
SECOND LOWER SPINDLE:
Spindle motor power 7.5 kW, adjustable
- Siemens IE3 energy-saving motor
- Spindle speed continuously adjustable
Power speed range:
- 7.5 kW
- 4,000 rpm
- up to 8,000 rpm
Spindle diameter 40 mm
Spindle length 266 mm
Note:
The technical data and descriptions are a transcript of the original order confirmation. Data is for informational purposes only and is not binding.
Listing
Germany
7,743 km
Four-side planer Weinig P 23 E (1998)
WeinigP 23 E
WeinigP 23 E
Call
Condition: used, Year of construction: 1998, Four-sided planing machine
Manufacturer: Weinig
Type: P 23 E
Year of manufacture: 1998
Ibodpezuzfujfx Ah Eja
Technical data
- Working width: 230 mm
- Working height: 8-120 mm
- Number of spindles: 5 (top, right, left, bottom, top)
- Spindle speed: 6000 rpm
- Feed rate: 5-24 m/min
- Total connected power: approx. 25 kW
- Infeed table: approx. 2000 mm
- Weight: approx. 2500 kg
Note:
The technical data and descriptions are copies of the original order confirmation. The information provided is for informational purposes only and is not binding.
Listing
Germany
7,743 km
Profile milling machine SCM Superset NTE (2008)
SCMSuperset NTE
SCMSuperset NTE
Call
Condition: used, Year of construction: 2008, Profiling machine
Manufacturer: SCM
Type: Superset NTE
Year of construction: 2008
Technical data
- Touchscreen control for the machine with 6 spindles + UNIWAVE
- Spindle speed 8,300 rpm
- Working width 240 mm, working height 125 mm, electronic
- Touchscreen control MOBILE 10
- HSK 85S
- SPINDLE QUICK-CHANGE SYSTEM T-SET
- QUICK-CLAMPING DEVICE for tools
- 7 shafts as a UNIWAVE, suitable for separating
- 2 feed units after the upper spindles to reduce the center distance from 620 to 450 mm
- Motor-driven feed roller in the working table, basic equipment for forced lubrication, electronic horizontal positioning, electronic adjustment of the tool diameter (setup)
- Manual pump for lubricating the working table
- WITH machining tool
- Min. working width (finished size) mm 15
Ibodezuzfhspfx Ah Eja
- Max. working width (finished size) mm 240
- Min. length of the individual workpiece mm 450
- Feed speed controlled via inverter 6 - 36 m/min, feed motor power kW 4
- Motor power surfacing spindle kW 7.5, quick-clamping device
- Motor power vertical spindle right kW 7.5, Powerlock HSK 85
- Motor power vertical spindle left kW 7.5, Powerlock HSK 85
- Motor power upper horizontal spindle kW 7.5, quick-clamping device
- Motor power 2nd upper horizontal spindle kW 7.5, Powerlock HSK 85
- Motor power lower horizontal spindle kW 7.5, Powerlock HSK 85
- Motor power universal spindle kW 7.5, quick-clamping device
- Spindle speed rpm 6000/8300
- Spindle diameter mm 40
- Spindle receiving length vertical mm 220
- Spindle receiving length horizontal mm 250
- Axial adjustment range of the vertical spindles standard mm 75
- Axial adjustment range of the horizontal spindles standard mm 45 min. max.
- Sweeping circle diameter of the surfacing cutter mm 120/140 mm min. max.
- Sweeping circle diameter of the profiling spindles mm 100/200
- Profiling depth of the 2nd lower shaft with a tool diameter of mm 200 mm 15
- Diameter of the spindle cylinders mm 120
- Diameter of the feed rollers mm 140
- Infeed table length mm 2500
- Adjustment range of the infeed table and infeed fence 10 mm
- Motor-driven feed roller in the outfeed table
- Manual central lubrication
- On/off switch for the feed unit before the surfacing cutter
- Horizontal pressure pads before the surfacing cutter with on/off switch
- Pressure shoes at the front on the protective cover of the horizontal spindle(s), hardened insert in the working table in front of the surfacing cutter
- Pneumatic pressure shoes in front of the upper horizontal spindles
- Horizontal pressure device in front of the surfacing cutter, can be switched on from the control panel
- 2 feed rollers 140 x 25 per feed shaft
- Lighting inside the protective cover
- Extraction capacity min. 10,443 m3/h
- Including extraction hood!
- Including Powerlock mounting bracket
- All 240 mm heads, horizontally arranged, and fixed tools on HSK spindles are included.
- Spare parts catalog: Complete, 8 PDF catalogs available
Note: Not all tools shown are part of this offer.
Note:
The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.
Listing
Germany
7,743 km
4-side planer WEINIG Unimat 23 E (1999)
WEINIGUnimat 23 E
WEINIGUnimat 23 E
Call
Condition: used, Year of construction: 1999, Used 4-sided planing machine
Manufacturer: WEINIG
Type: Unimat 23 E
Ibedpfezuzdqox Ah Eja
Year of manufacture: 1999
with infeed unit EM11
Year of manufacture: 1999
Technical data:
5 spindles (bottom, right, left, top, bottom)
Total connected load min. / max. 42 kW - 126 kW
Air flow rate 30 - 32 m³ / MIN
Air flow rate per spindle 28 - 32 m³ / MIN
Total air flow rate 8400 - 9600 m³ / H
Nominal pressure 8 bar
Operating pressure 6 bar
Connection diameter DN 8
Machine weight approx. 3200 kg
Static load (with support plates 80 x 100 mm) max. 120 N / CM²
Note:
The technical data and descriptions are transcriptions from the original order confirmation. The data is for informational purposes only and is not binding.
Listing
Belgium
7,824 km
LEADERMAC Compact LMC-530C
LEADERMACCompact LMC-530C
LEADERMACCompact LMC-530C
Call
Condition: ready for operation (used), Year of construction: 2022, This 5s LEADERMAC Compact LMC-530C was manufactured in 2022. It features a working width of 15 – 300 mm and a working thickness of 10 – 150 mm, making it suitable for various woodworking applications. With multiple spindles and a Schneider 5.7” EASYSET touchscreen control, this machine offers advanced capabilities. Consider the opportunity to buy this LEADERMAC Compact LMC-530C wood planer. Contact us for further details.
• Ref.: e/haaaa/dc
Iedpfxezuhfhe Ah Ejba
• Working width: 15–300 mm
• Working thickness: 10–150 mm
• Minimum workpiece length: 800 mm
• Minimum consecutive length: 300 mm
• Infeed table: 2500 mm
• Pneumatic left side pressure roller
• Two-piece pressure shoe
• Schneider 5.7" EASYSET touchscreen control
• NC control axis 3 (left radial)
• NC control axis 4 (top radial)
• NC control for pressure beam height adjustment
• Feed motor: 7.5 HP, feed speed 6–24 m/min
• 1st spindle: 15 HP, Ø50 mm, 6,000 rpm
• 2nd spindle: 10 HP, Ø50 mm, 6,000 rpm
• 3rd spindle: 10 HP, Ø50 mm, 6,000 rpm
• 4th spindle: 20 HP, Ø50 mm, 6,000 rpm
• 5th spindle: 20 HP, Ø50 mm, 6,000 rpm
Additional equipment
• Additional table for multi-rip saw
• Anti-kickback device for multi-rip saw
Listing
Slovenia
7,824 km
REIGNMAC 520 MOULDING MASTER
REIGNMAC520 MOULDING MASTER
REIGNMAC520 MOULDING MASTER
Call
Condition: ready for operation (used), Year of construction: 2016, working width: 200 mm, total width: 1,635 mm, total height: 1,730 mm, overall weight: 3,750 kg, spindle speed (max.): 6,000 rpm, controller manufacturer: SIEMENS, controller model: Smart Line, spindle motor power: 5,500 W, product length (max.): 3,850 mm, This 6-axis REIGNMAC 520 Moulding Master was manufactured in 2016. It features a working width of 20–200 mm and a working thickness of 8–120 mm, with a feed speed of 6–24 m/min. The machine is equipped with six spindles, with a spindle speed of 6000 rpm and a maximum tool diameter of Ø145 mm. If you are looking to get high-quality woodworking capabilities, consider the REIGNMAC 520 Moulding Master machine we have for sale. Contact us for further details.
• Working width: 20–200 mm
• Working thickness: 8–120 mm
• Feed speed: 6–24 m/min
Ibsdpfx Aozuhbpeh Eea
• Working table length: 1700 mm
• Pressure beam vertical adjustment: 10 mm
• Infeed table adjustment: 10 mm
• Spindle configuration:
• Number of spindles: 6
• Spindle diameter: 40 mm
• Maximum tool diameter:
• First bottom spindle: 108–145 mm
• Right/left spindles: 108 mm
• Top spindle: 140 mm
• Bottom finishing spindle: 96 mm
• Motor power:
• Feed motor: 5.5 kW (7.5 HP)
• Right spindle motor: 5.5 kW (7.5 HP)
• Left spindle motor: 5.5 kW (7.5 HP)
• Top spindle motor: 7.5 kW (10 HP)
• Bottom spindle motor: 5.5 kW (7.5 HP)
• Feed beam lifting motor: 1.1 kW
• Total installed power: 28.6 kW
Additional equipment
• Safety cabin included
Listing
Germany
7,824 km
SCM Fs 7
SCMFs 7
SCMFs 7
Call
Condition: ready for operation (used), Year of construction: 2020, working width: 520 mm, spindle speed (max.): 5,000 rpm, spindle motor power: 9,000 W, working length: 2,310 mm, This SCM Abricht/ Dickenhobelmaschine was manufactured in 2020. It features a working width of 520 mm and an adjustable thicknessing height from 3 mm to 250 mm. The machine includes a "TERSA" cutter block system with 4 disposable knives and offers four feed speeds. Consider the opportunity to buy this SCM Abricht/ Dickenhobelmaschine wood planer. Contact us for further details.
• Working width: 520 mm
• Thicknessing height: 3–250 mm (adjustable)
Ibsdpjzug Axefx Ah Eoa
• Surface table length: 2,310 mm
• Feed speeds: 5 / 8 / 12 / 18 m/min
• Cutter block: TERSA system, 4 disposable knives, 120 mm diameter
• Control unit: READY electronic control
• Programmability: up to 99 programs
• Axis control: motorized vertical adjustment of thicknessing table with digital position display
• Power-assisted changeover: pneumatic/hydraulic automatic lifting of surfacing tables
• Supply voltage: 400 V, 3-phase, 50 Hz
• Main motor: 9 kW (12 HP) with automatic star-delta start
• Braking: automatic electronic motor brake
• Suction: 120 mm extraction outlets for surfacing and thicknessing
Listing
Germany
7,870 km
Four-side moulder
WEINIGPowermat 500 mit Nutentisch
WEINIGPowermat 500 mit Nutentisch
Call
Condition: excellent (used), Number of spindles 5 St.
Working width 230 mm
Working height 120 mm
Length of the planing table 2500 mm
Feed motor 4 kW
Feed speed 5-30 m/min.
control Memory-Funktion
Weinig Powermat 500 with grooved table
-----
The machine arrives at the warehouse and is cleaned and fully inspected.
Brief Summary:
-----
- 5 Spindles
- 8,000 rpm
- Grooved table for short or difficult-to-guide workpieces, coated
with Marathon PowerCoating
- One driven roller in the outfeed table, hardened: 210 mm wide
- Left and top spindles controlled for width and height
- Quick-release spindle nut
Detailed Description:
-----
Technical Data:
Working width: 20-230 mm
Working height: 8-120 mm
Number of spindles: 5
1st Spindle - bottom
-----
Motor with brake: 7.5 kW
Spindle diameter: 40 mm
Speed: 8,000 rpm
Tool circle: 125-180 mm
Tool circle for rebate cutter: 130-160 mm
Travel Axial: 17 mm
Folding attachment
MarathonCoatin for table insert in front of 1st lower tool holder
Iedozughzepfx Ah Ejba
2nd Spindle - right
-----
Motor with brake: 5.5 kW
Spindle diameter: 40 mm
Speed: 8,000 rpm
Tool swing diameter: 93 - 200 mm
Max. groove depth: 35 mm
Axially travel: 80 mm
Radial travel:
Min. tool diameter at stop level: 93 mm
Max. tool diameter behind stop level: 200 mm
3rd Spindle - left
-----
Motor with brake: 7.5 kW
Spindle diameter: 40 mm
Speed: 8,000 rpm
Tool swing diameter: 93 - 200 mm
Tool swing diameter for straight cutter heads: max. 163 mm
Max. Groove depth: 35 mm
Axially travel: 55 mm
Pressure shoe in front of left spindle, including 2 lateral
pressure rollers, spring-loaded
Spindle radially CNC-controlled
4th Spindle - top
-----
Motor with brake: 11.0 kW
Spindle diameter: 40 mm
Speed: 8,000 rpm
Tool swing diameter: 93 - 200 mm
Maximum tool swing diameter for straight cutter heads: 180 mm
Maximum groove depth: 35 mm
Axially travel: 40 mm
Spindle radially CNC-controlled
Split pressure shoe in front of upper tool holder, adjustable to the
tool swing diameter and pivoting away from the tool, spring-loaded.
5. Spindle - Lower
-----
Motor with brake: 5.5 kW
Spindle diameter: 40 mm
Speed: 8,000 rpm
Tool swing diameter: 93 - 225 mm
Max. throat depth: 15 mm
Axially travel: 35 mm
Radial travel:
Min. tool diameter to table level: 93 mm
Max. tool diameter 6 mm below table level: 225 mm
Feed system
-----
Frequency-controlled feed, infinitely variable with brake: 4 kW, 5 - 30 m/min
Infeed roller in front of the first lower tool, pneumatically controlled up/down.
Durofer pointed tooth rollers with depth limiter and self-cleaning.
Feed roller adjustment travel relative to the left tool holder, axial 35 mm
Reduced roller spacing relative to the right tool
Machine electrical system
-----
Operating voltage 400 V (voltage range 380 - 420 V), 50 Hz.
Machine stand, tables, and stops
-----
Infeed table: 2500 mm long (including jointing guide)
Slotted guide for short or difficult-to-guide workpieces, coated...
Listing
Denmark
7,529 km
Moulder
WeinigU23 E
WeinigU23 E
Call
Condition: used, Year of construction: 2000, Used Weinig U23E with 6 spindles:
Ijdpfx Aszuartoh Eoba
1. Lower spindle, 5.5 kW motor
2. Right spindle, 11.0 kW motor
3. Left spindle
4. Upper spindle, 7.5 kW motor
5. Upper spindle, 7.5 kW motor
6. Lower spindle, 7.5 kW motor
Feed speed 5-24 m/min, motor 2.2 kW.
Listing
Juszczyn
8,483 km
Shaping machine
WEINIGPowermat 1000
WEINIGPowermat 1000
Call
Condition: excellent (used), functionality: fully functional, Weinig Powermat 1000 four-sided planer
Working width: 230 mm
Working height: 160 mm
Number of spindles: 8
Spindle arrangement:
Bottom: 7.5 kW
Right: 5.5 kW (power lock)
Left: 5.5 kW
Right: 5.5 kW (power lock)
Top: 11 kW (power lock)
Bottom: 15 kW
Top: 7.5 kW (power lock)
Bottom: 7.5 kW
All spindles: 8000 rpm
Feed speed adjustable via frequency inverter up to 30 m/min
Electromotive positioning of working height and width
Weinig power com system
Pneumatic material clamping
Isdpfx Ahszt I Sfe Esba
2 smooth rollers in the working table
Working table length: 1970 mm
Drive on cardan shafts
Listing
Rattelsdorf
7,971 km
Moulder
WEINIGWeinig Unimat 23
WEINIGWeinig Unimat 23
Call
Condition: not inspected (used), functionality: unexamined, workpiece height (max.): 160 mm, workpiece width (max.): 230 mm, Working width: 20 – 230 mm
Working height: 8 – 160 mm
7-spindle configuration
Feed rate infinitely adjustable: 6 – 36 m/min
Spindle motors with 7.5 kW, 11 kW and 18.5 kW power
Mechanical brakes on the motors
Electrical adjustment options for spindles and feed rate
Hardened table insert in front of the first lower spindle
Pressure pads and guides for precise workpiece guidance
High-quality ball bearings and robust industrial design
Spindle arrangement:
Lower horizontal spindle 7.5 kW
Right vertical spindle 7.5 kW
Left vertical spindle 11 kW
Right vertical spindle 7.5 kW
Iedpjzt Hf Dofx Ah Eeba
Upper horizontal spindle 18.5 kW
Lower horizontal spindle 7.5 kW
Universal spindle 7.5 kW
Listing
Sierakowska Huta
8,052 km
Four Side Planer
LEADERMAC LMC 423C
LEADERMAC LMC 423C
Call
Condition: excellent (used), Catalog number 6765
TECHNICAL DATA
- max width of workpiece 230mm
- max height of workpiece 160mm
number of spindles 4:
1) horizontal lower 230mm, 5.5kW
2) vertical right 160mm, 5.5kW
3) vertical left 160mm – electrically adjustable left/right from the control panel, 5.5kW
4) horizontal upper 230mm – electrically adjustable up/down from the control panel, 7.5kW
- all spindles adjustable up/down, left/right
- spindle diameter 40mm
from above:
- infeed rollers, toothed, 6 pcs, including 2 double rollers
- outfeed rollers, rubber, 2 pcs
from below:
- infeed roller, toothed, metal, twisted in the lower bed +
- outfeed roller, metal, smooth
- rollers pneumatically adjustable
- length of infeed bed (with pneumatic feeder) 3390mm
- possibility of operation without engaging the pneumatic feeder, - bed adjustable up/down
- central lubrication
- electric adjustment of planing thickness
- smooth adjustment of feed speed
- feed on Cardan shafts
Ijdpfjztzmcsx Ah Ejba
- feed motor 4kW
- enclosed in a cabinet
- diameters of dust extraction nozzles 4x120mm
- dimensions L/W/H 7000x1950x1700mm, - weight approximately 3000kg
- for wet and dry wood
- pneumatic feeder on the infeed table, - planer used, very good condition
Net price: 65900 PLN
Net price: 15690 EUR
Net price calculated based on the exchange rate of 4.2 PLN/EUR
(price may change in case of larger exchange rate fluctuations)
Listing
Sierakowska Huta
8,052 km
Four-sided planer, also suitable for wet wood
MIDAP5E 510
MIDAP5E 510
Call
Condition: excellent (used), Catalog number 8033
Iodpfx Asztziwsh Ejba
TECHNICAL DATA
max. width of the workpiece – upper shaft 510mm
max. width of the workpiece – lower shaft 450mm
max. thickness of the workpiece, processed on both sides 200mm
– from above:
feed roller
ratchets
1 metal, toothed feed shaft
2 metal, sequential feed shafts
1 metal, toothed feed shaft
pressure roller
planing shaft 510mm, 4 knives, with the possibility of installing profile knives approx. 7.5kW
smooth, metal feed shaft
upper pressure roller at the outlet with 2 feed rollers
– from below:
adjustable infeed table with guide
planing shaft 300mm, 3 knives 3kW
slip feed shaft, metal
planing shaft 450mm, 4 knives 5.5kW
2 smooth, metal feed shafts
– from the back:
2 side spindles
1) vertical, right 150mm 4kW
2) vertical, left 150mm 4kW
spindle diameter 40mm
spindles adjustable up/down, right/left
spindles lockable
axes arranged alternately
electric height adjustment
2 types of feed speed + stepless 5-13, 13-36m/min
dust extraction nozzle diameter 2x120mm, 150mm
dimensions length/width/height 3200x1500x1600mm + control panel
weight 1980kg
– manufactured in Portugal
– electric table lifting
– ideal for processing wet and dry wood
– 3 planing shafts + 2 spindles
– very good condition
– used planer
Net price: 38900 PLN
Net price: 9260 EUR, depending on the exchange rate of 4.2 EUR
(Prices may vary due to significant exchange rate fluctuations)
Listing
Sierakowska Huta
8,052 km
Four-sided wet planer
SCMTOPSET XL na 6 głowic
SCMTOPSET XL na 6 głowic
Call
Condition: excellent (used), Catalog number: 7713
TECHNICAL DATA
- max width of workpiece: 240mm
- max height of workpiece: 130mm
- 6 spindles:
1) horizontal lower 240mm, 7.5kW
2) vertical right 130mm, 5.5kW
3) vertical left 130mm, 5.5kW
4) horizontal upper 240mm, 7.5kW
Ibedpfeztzhgex Ah Esa
5) horizontal upper 240mm, 5.5kW
Spindles 4 and 5 are adjustable up/down electrically
6) horizontal lower 240mm, 5.5kW
- all spindles are adjustable up/down, left/right
- spindle diameter 40mm
*from above:
- 8 feeding rollers, toothed metal rollers, including 3 double rollers
- 4 discharge rollers, smooth, rubber rollers, including 2 double rollers
*from below:
- 3 smooth feeding rollers
- 3 side pressure rollers
- stepless feed speed adjustment via a frequency inverter
- rollers are pneumatically pressed
- feed motor 7.5kW
- feed on Cardan shafts
- electric adjustment of cutting depth
- body lifting motor 0.75kW
- length of the infeed table: 2480mm
- pneumatic opening/closing of the cabinet
- pneumatic blowing of the table
- central lubrication of the table
- diameters of the dust extraction nozzle: 3x120mm, 3x150mm
- dimensions (L/W/H): 5300x1700x1800mm
- weight: 5000kg
ADVANTAGES
– Made in Italy
– With 6 heads
– For both wet and dry wood
– Pneumatic opening of the cabinet
– Pneumatic blowing of the table
– Spindles 4 and 5 are adjustable electrically
– Used planer, very good condition
Net price: 99900 PLN
Net price: 23785 EUR, depending on the exchange rate of 4.2 EUR
(Prices are subject to change due to higher fluctuations)
Listing
Sierakowska Huta
8,052 km
Four Side Planer
LEADERMACCompact LMC 723
LEADERMACCompact LMC 723
Call
Condition: excellent (used), Catalog number 6338
TECHNICAL DATA
- Max. width of workpiece: 230mm
- Max. height of workpiece: 160mm
Isdpoztzgpefx Ah Ejba
7 spindles:
1) Horizontal, lower: 230mm, 5.5kW
2) Vertical, right: 160mm, 5.5kW
3) Vertical, left: 160mm, 5.5kW
4) Horizontal, upper: 230mm, 7.5kW
5) Horizontal, upper: 230mm, 7.5kW
6) Horizontal, lower: 230mm, 7.5kW
7) Universal: 360°, 230mm, 7.5kW
- All spindles are adjustable up/down, left/right
- Spindle diameter: 40mm
- All spindles are equipped with a brake
- Spindle speed: 6000 rpm
Top:
- 6 toothed, metal feed rollers, including 2 double rollers
- 4 toothed, rubber feed rollers, including 1 double roller
- 3 pressure rollers at the outfeed
Bottom:
- Side pressure roller at the infeed
- Toothed, feed roller, swiveling, in the lower table
- 3 smooth, metal feed rollers
- Rollers are pneumatically adjustable
- Length of infeed table: 1190mm
- Central lubrication of the table
- Electric adjustment of planing thickness
- Body lifting motor: 0.56kW
- Smooth adjustment of feed speed on a frequency inverter: 6-24m/min
- Feed motor: 3.7kW
- Feed via Cardan shafts
- Enclosed in a cabinet
- Diameter of dust extraction nozzle: 7x125mm
- Dimensions (L/W/H): 5100x2070x1900mm
- Weight: approximately 5000kg
ADVANTAGES
– Equipped with 7 heads
– Universal spindle
– Ideal for both wet and dry wood
– Spindles equipped with brakes
- DTR documentation
– Used planer, very good condition
Net price: 115900 PLN
Net price: 27595 EUR, depending on the exchange rate of 4.2 EUR
(Prices may vary due to significant exchange rate fluctuations)
Listing
Sierakowska Huta
8,052 km
Four Side Planer
SCMSUPERSET Plus 7 głowic
SCMSUPERSET Plus 7 głowic
Call
Condition: excellent (used), Catalog number: 6368
TECHNICAL DATA
- max. width of the workpiece: 230mm
- max. height of the workpiece: 130mm
7 spindles:
1) horizontal, lower: 230mm, 5.5kW
2) vertical, right: 130mm, 5.5kW
3) vertical, left: 130mm, 5.5kW
Ibsdpeztzgiefx Ah Eea
4) horizontal, upper: 230mm, 7.5kW
5) horizontal, upper: 230mm, 11kW
6) horizontal, lower: 230mm, 18.5kW
7) universal: 230mm, adjustable at an angle of 360 degrees, 5.5kW
- all spindles adjustable up/down, left/right
- all spindles equipped with an electric brake
- spindle diameter: 40mm
- spindles 4 and 5 adjustable electrically up/down
- top: 8 feed rollers, metal, twisting, including 2 double rollers
- top: 4 feed rollers, rubber
- top: 2 pressure rollers
- bottom: pawls
- bottom, side: 3 pressure rollers
- bottom: 2 metal feed rollers, smooth
- bottom: 2 double feed rollers, rubber
- rollers are pneumatically pressed
- feed on Cardan shafts
- stepless feed speed adjustment: 5-36 m/min
- feed motor: 4kW
- electric adjustment of planing thickness: 0.75kW
- length of the infeed table: 1980mm
- enclosed in a cabinet
- central lubrication of the table
- dust extraction port diameters: 5x120mm, 2x150mm
- dimensions (L/W/H): 5500x1840x1900mm
- weight: approx. 5000kg
ADVANTAGES
- Made in Italy
- With 7 heads
- For wet and dry wood
- Last spindle is universal
- Unpainted
- Used planer, very good condition
Net price: 116,900 PLN
Net price: 27,830 EUR, depending on the exchange rate of 4.2 EUR
(Prices may vary depending on exchange rate fluctuations)
Listing
Sierakowska Huta
8,052 km
Four Side Planer
WEINIG UNIMAT 23Ena 7 głowic
WEINIG UNIMAT 23Ena 7 głowic
Call
Condition: excellent (used), CATALOG NUMBER: 6575
TECHNICAL DATA
- max. width of workpiece: 230mm
- max. height of workpiece: 170mm
- 7 spindles:
1) horizontal, lower, 230mm, 11kW
2) vertical, right, 170mm
3) vertical, left, 170mm (2 and 3 spindles), 11kW
4) horizontal, right, 170mm, 5.5kW
5) horizontal, upper, 230mm, 11kW
6) horizontal, lower, 230mm, 7.5kW
7) universal, 230mm, adjustable at 360°, 7.5kW
Ibsdpfx Ahjztzfls Eoa
- all spindles adjustable up/down, left/right
- spindles 3 and 5 are electrically adjustable
- ATS (Automatic Thickness Setting)
- spindle diameter: 40mm
- electric brakes
- 4 top infeed rollers, toothed, including 1 double roller
- top infeed roller, rubber, double
- top outfeed roller, rubber, double
- 2 bottom metal rollers, smooth
- bottom infeed roller, rubber, double
- feed on Cardan shafts
- rollers pneumatically pressed
- stepless feed speed adjustment: 6-24m/min
- feed motor: 5.5kW
- electric adjustment of cutting depth
- body lifting motor: 0.55kW
- central lubrication of the table
- diameter of dust extraction nozzles: 7x140mm
- dimensions (L/W/H): 5800x2050x1850mm
- weight approx. 4500kg
ADVANTAGES
– German production, WEINIG brand
– with 7 heads
– universal spindle
– with ATS
- for wet and dry wood
– used planer, very good condition
Net price: 126900 PLN
Net price: 30200 EUR
Net price calculated based on an exchange rate of 4.2 PLN/EUR
(price may change in case of larger exchange rate fluctuations)
Listing
Juszczyn
8,483 km
Shaping machine
WEINIGUNISTACK 811
WEINIGUNISTACK 811
Call
Condition: used, Weinig UNISTACK 811 stacking machine
Ibsdpfx Aoztzffeh Esa
Package length: 500 mm to 3100 mm
Package height: 1200 mm
Package width: 1200 mm
Listing
Sierakowska Huta
8,052 km
Four Side Planer
REIGNMAC RMM 723
REIGNMAC RMM 723
Call
Condition: excellent (used), CATALOG NUMBER 7220
TECHNICAL DATA
- Min – max working width: 20 – 230mm
Ibedpfsztzd Ujx Ah Eea
- Min – max working height: 8 – 160mm
7 spindles:
1) Lower horizontal 230mm 5.5kW
2) Right vertical 160mm 5.5kW
3) Left vertical 160mm 5.5kW
4) Right vertical 160mm 5.5kW
5) Left vertical 160mm 5.5kW
6) Upper horizontal 230mm 7.5kW
7) Lower horizontal 230mm 7.5kW
- All spindles adjustable up/down, left/right
- Spindle diameter: 40mm
- Spindle speed: 6000rpm
From above:
- 10 toothed steel infeed rollers, including 2 double rollers
- 3 lateral pressure units
From below:
- Lateral pressure unit at the infeed
- Toothed steel twisting feed roller in lower table
- 2 lateral pressure units
- Ribbed worktable
- Ribbed steel feed roller
- Smooth steel feed roller
- Pneumatically adjustable rollers
- Infeed table length: 2410mm
- Centralized table lubrication
- Electric thickness adjustment
- Body raising motor: 1.1kW
- Stepless feed speed adjustment via inverter: 6–30m/min
- Feed motor: 5.5kW
- Feed via Cardan shafts
- Enclosed in cabin
- Extraction port diameter: 7x160mm
- Dimensions (LxWxH): 5100x2190x1800mm
- Weight: 5400kg
ADVANTAGES
– Equipped with 7 heads
– Ideal for both wet and dry wood
– DTR technical documentation included
– Used planer, very good condition
Net price: 138,900 PLN
Net price: 33,070 EUR
Net price calculated at the rate of 4.2 PLN/EUR
(price may change significantly if the exchange rate fluctuates)
Listing
Strenči
8,163 km
REX HOMS-410K - 12-Spindle Moulder
REX HolzbearbeitungsmaschinenHOMS-410K
REX HolzbearbeitungsmaschinenHOMS-410K
Call
Condition: used, REX HOMS-410K — 12-Spindle Four-Side Moulder
Manufacturer: REX Holzbearbeitungsmaschinen (Georg Schwarzbeck GmbH & Co KG), Germany
Model: HOMS-410K
Machine No.: 22.303
Ijdpfxsztxyyj Ah Esba
Year of manufacture: 1998
Voltage: 400V / 50Hz
Number of spindles: 12
Feed mechanization: HIT
Operating hours: ~6,000 mth
Listing
Kehra
8,015 km
Moulder
WeinigPowermat 2400 (7 spindle 50mm)
WeinigPowermat 2400 (7 spindle 50mm)
Call
Condition: excellent (used), Year of construction: 2015, Weinig Powermat 2400 moulder with 7 Spindles. (Year 2015)
Working height: 10 - 160 mm .
Working width: 20 - 230 mm.
Ibedpjztv I Ijfx Ah Eja
50mm spindles 6,000 RPM (Not Powerlock)
Bottom 15 kW + outboard bearing
Right 11 kW + Straight jointer
Left 11 kW + Straight jointer
Top 15 kW + Straight jointer + outboard bearing
Bottom 18.5 kW + Profile jointer
Top 18.5 kW + Straight + Profile jointer
Bottom 18.5 kW Straight jointer + outboard bearing
11kW feed motor, 60m/min.
Heavy duty feed works.
10x top feed rollers.
First top feed roller with clutch installed for use with mechanisation.
5x bottom feed rollers.
Automatic lubrication system.
Electric digital display memory system.
CNC POSITIONING ON SPINDLES 3, 5 & 8
Possible to supply with Weinig moulder infeed and outfeed
Listing
Kehra
8,015 km
Moulder
LEADERMACTHUNDERMAC 923T NOT WEINIG
LEADERMACTHUNDERMAC 923T NOT WEINIG
Call
Condition: reconditioned (used), LEADERMAC THUNDERMAC 923T
Ibsdpfx Asztv Hwoh Eja
SPINDLES: 9 X 50MM X 6000 RPM
BOTTOM (22 KW) -
RIGHT (15 KW) -
LEFT (15 KW) -
RIGHT (15 KW) -
LEFT (15 KW) -
TOP (22 KW) -
BOTTOM (22 KW),
TOP (22 KW) -
BOTTOM (22 KW).
WORKING WIDTH: 230 (245) MM, HEIGHT: 160 MM.
MAX FEED SPEED 80M/MIN (POSSIBLE TO INCREASE TO 150M/MIN)
STRAIGHT JOINTERS.
PROFILE JOINTERS.
CNC POSITIONING ON SPINDLES 3, 5, 6, 8
CONNECTION: 380 V / / 50 HZ 400 AMPS.
FULL DOCUMENTATION INCLUDED.
Listing
Kehra
8,015 km
Moulder
WEINIGHYDROMAT 2000
WEINIGHYDROMAT 2000
Call
Condition: excellent (used), Year of construction: 2008, WEINIG HYDROMAT 2000
FEED MOTOR 5.5 KW
FEEDRATE MAX 36 M/MIN
SPECIAL WIDE FEEDING SYSTEM WITH AIR BED
1ST SPINDLE BOTTOM 11 KW, COUNTER BEARING
2ND SPINDLE RIGHT 7.5 KW
3RD SPINDLE LEFT 7.5 KW
4TH SPINDLE BOTTOM 7.5 KW, COUNTER BEARING
5TH SPINDLE TOP 15 KW, COUNTER BEARING
WORKING WIDTH 250 MM
PLANING HEIGHT 160 MM
NUMBER OF SPINDLES 5
BOTTOM SPINDLES 2
RIGHT SPINDLES 1
SPINDLES LEFT 1
SPINDLES TOP 1
SPINDLE CONFIGURATION B-R-L-B-T
SPINDLE ROTATION SPEED MAX 1/MIN 7.200 RPM
SPINDLE DIAMETER 40 MM
CONTINUOUSLY VARIABLE INVERTER DRIVE FEED
FEED MOTOR
5,5 KW
MAIN MOTOR POWER 15 KW
SPINDLE(S) WITH COUNTERBEARING
SEPERATE MOTOR PER SPINDLE
MOTORIC ADJUSTMENT
PROGRAMMABLE CONTROLLER
INFEED TABLE LENGTH 700 MM
TABLE ROLLERS DRIVEN
LUBRICATION PUMP AUTOMATIC
SHORT PIECE PACKAGE
REDUCED ROLLER GAP
Ibsdpfeztvzzex Ah Eoa
PNEUMATIC TOP PRESSURE
FIRST INFEED ROLLER CONTROLLED
TYPE OF FEED ROLLER DRIVE CARDANIC
MANUAL CENTRAL LUBRICATION CONTROL
WEINIG POWERCOM PLUS
CONFORMITY MARKING
CE MARK
TOTAL CONNECTION
55 KW
Listing
Kehra
8,014 km
Moulder
WeinigPowermat 700
WeinigPowermat 700
Call
Condition: ready for operation (used), Year of construction: 2015, Weinig Powermat 700
6x 40mm Spindles.
CNC on spindles 3, 4 and 5.
Width 20-230mm
Height 10-160mm
Memory system
Ibsdpjztvhhsfx Ah Eja
Automatic lubrication system for bedplates.
No 1. 11kW - Bottom 7000rpm
No 2. 7.5kW - Right 7000rpm
No 3. 7.5kW - Left 7000rpm
No 4. 15kW - Top 7000rpm
No 5 . 11kW - Top 7000rpm
No 6 . 11kW - Bottom 7000rpm
Electronically variable feed. 40m/min
Short infeed table.
Marathon coating for machine bed plates.
Manuals & hand tools.
