Condition: excellent (used), Year of construction: 2000, Model ... Vipros 20-50-50 Frame Construction ... Bridge Type Press Capacity ... 20 Tonnes (196kN) Press Type ... Servo Controlled Hydraulic Ram Axis Traverse Distance ... 1270 mm x 1270 mm Workable Max. Sheet Size . 1270 mm x 2540 mm (with auto repositioning) Maximum Material Thickness ... 6.35 mm Mild Steel Max. Material Weight ... 105 Kg Max. Material Weight (Max Speed) ... 62 Kg Max. Hole Dia. ... 88.9 mm Number Of Stations ... 31 Stations: 19 x 12.7 mm 6 x 31.7 mm 1 x 50.8 mm 2 x 88.9 mm Auto Index 2 x 31.7 mm 1 x 50.8 mm Axis Speed ... 82 m/min Fjdpfx Aoxtu Nwoc Hjgi Hits Per Minute (2mm Pitch) ... 1000 H.P.M./2.5mm Stroke (25.4mm Pitch) ... 340 H.P.M./8mm Stroke Turret Speed Bi-Directional ... 35 R.P.M. Punching Accuracy ... ± 0.07 mm Punching Accuracy (High Accuracy Mode) ... ± 0.05 mm Repeatability ... ± 0.015 mm Ram Stroke Length (Maximum) ... 40 mm Axis Drive ... AC Servo Motor Turret Drive ... AC Servo Motor Electric Power Required ... 22 kVA 400V +/- 10% 50 Hz Air Pressure Required ... 5.0 kgf/cm² Air Flow ... 250 1/min Machine Length ... 5030 mm Machine Width ... 2630 mm Machine Height ... 2160 mm Machine Weight ... 9200 kg NC SPECIFICATION Model of NC ... FANUC 18-P Axis ... 3 Axis Simultaneous + PHNC Tape Code ... EIA or ISO (Automatic Recognition) Programming Mode ... Absolute/incremental Min. Input ... 0.01 mm (0.01°) Max. Input ... 99999.99 mm Preparatory Function ... G - 2 Digit T Function ... T - 3 Digit M Function ... M - 3 Digit Single Block ... Yes Block Delete ... Yes Optional Stop ... Yes Editing ... Yes Manual Data Input ... Yes Memory Capacity ... 64 Kb No. Of Programs ... 200 Machine Operation ... Memory Interface ... RS 232 C

Condition: ready for operation (used), Year of construction: 2004, operating hours: 48,177 h, General Data Measurements width 6650 mm Measurements depth 2700 mm Measurements height 2980 mm Machine weight 15000 kg Control Unit Brand FAGOR Model 8070 Main Drive Punching force 300 kN Number of axis 4 Movement X-Axis Movement 1600 mm Y-Axis Movement 1250 mm Turret Number of tool slots 4 Tools Number of station 27 Max Material Thickness Steel 0.5–5 mm Media Main electronic connection 400 V / 50 Hz Fgjdpfjxqta Aex Ac Hji Power consumption 25 kVA This 4-axis DANOBAT P1317 turret punch press was manufactured in 2004. It features a punching force of 300 kN, a maximum sheet thickness of 5 mm, and can perform up to 750 strokes per minute. The machine includes a Fagor 8070 CNC control, 27 turret stations, and 4 auto-index stations. Dimensions are 2,700 × 6,650 × 2,980 mm, and it weighs approximately 15,000 kg. Consider the opportunity to buy this DANOBAT P1317 turret punch press. Contact us for more information. Application Types Punching

Condition: good (used), Year of construction: 1998, Neat used punching machine from Euromac Type CX 1000 30 Fodpexld R Ijfx Ac Hegi Capacity 30 ton Unloading 1000mm Overwrap up to 10000mm Including drawer cabinet with lots of tooling and multitool

Condition: used, total length: 1,900 mm, total width: 950 mm, total height: 1,800 mm, Empty weight: 2.150 kg Price: On request - Maximum capacity (⌀ x thickness): 28 mm x 20 mm - Strokes per minute (at 20 mm stroke): 38 - Working height: 890 mm - Largest hole (optional): 38 mm - Max. bar bending: 250 x 12 mm - Max. sheet bending: 500 x 3 mm - Max. angle cutting (90°): 130 x 13 mm - Max. angle cutting (45°): 70 x 10 mm - Notching (material thickness): 10 mm - Documentation available: No - CE marking present: Yes - Motor power: 7.5kW - Table width: 350mm - Throat depth: 355mm - Table length: 600mm - Ram length: 40mm - Model: Hydraulic - Max. stroke: 55mm - Power: 80.0ton - Transport dimensions: 1900mm x 950mm x 1800mm (l x w x h) - Transport weight [kg]: 2150kg - Transport packages [pcs.]: 1 Fodpfexhcfpsx Ac Hogi Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Punching Machine MUHR & BENDER - MUBEA Model KL 350 / 203 Machine No. KL3509864 Year of manufacture: 1998 Punching force: 35 tons Throat depth: 200 mm Ram stroke: 22 mm Capacity: Ø 28 mm in 10 mm sheet (at 450 N/mm²) Ø 23 mm in 12 mm sheet (at 450 N/mm²) Ram plate: 265 x 70 mm Ram plate thickness: 25 mm outside / 50 mm in the center Table plate: 285 x 250 mm, thickness 40 mm Table cutout: 115 x 85 mm Drop-through opening in table cutout: 115 x 25 mm Installation height: 125 mm (with table and ram plate) Number of strokes: single stroke via foot switch Motor power: 1.5 kW Power supply: 400 Volt, 50 Hz - Electric foot switch for stroke activation - Manual lever search device for punch movement - Special tool as punching tool Space required (L x W x H): 800 x 800 x 400 mm Weight without tool: 340 kg Weight with tool: 370 kg Good condition Fodpfoxf Utasx Ac Hsgi

Condition: used, TÜNKERS Pneumatic Punching Unit Pneumatic punching yoke, punching press, punching unit Year of manufacture: 2019 Model No.: 141-1040F Yoke No.: B-13-26/100 Pressing force: 4 tons (40 kN at 8 bar) Air connection: max. 8 bar Fsdpfx Acexf Uqxo Hjgi Throat depth: 100 mm Yoke width: 60 mm Hole diameter: Ø 2-13 mm Hole diameter (installed punch): Ø 4 mm Die diameter (outer): Ø 22 mm - Stripper via Vulkollan polyurethane elastomer Dimensions (L x W x H): 280 x 110 x 480 mm Weight: 36 kg Very good condition

Condition: good (used), functionality: fully functional, Year of construction: 2013, operating hours: 1,000 h, machine/vehicle number: GRM80E, control type: CNC control, degree of automation: automatic, actuation type: mechanical, controller manufacturer: Otto Bihler, controller model: Otto Bihler, punching force: 30 t, stroke rate (min.): 99 1/min, stroke rate (max.): 120 1/min, sheet thickness (max.): 5 mm, sheet thickness steel (max.): 5 mm, sheet thickness stainless steel (max.): 5 mm, sheet thickness aluminum (max.): 5 mm, sheet thickness brass (max.): 5 mm, sheet thickness copper (max.): 5 mm, overall weight: 1,500 kg, Equipment: centralized greasing system, emergency stop, We Sanjit Moulds Private Limited have a Bihler Machine GRM80E. Its a wonderful machine with Multiple Slides. We have maintained the machine properly. The price mentioned is CIF Hamburg. This machine is located in India in Nashik which is very 180 Kms from Mumbai. Fgodoxc Txcjpfx Ac Hji

Condition: used, Punching force: 300 kN For example, punch a 20 mm hole in 12 mm steel Stroke triggering via foot switch Fgjdpexcndyjfx Ac Hoi Assortment of tools is included in the price

Condition: used, Punching force: 350 kN For example, punch a 23 mm hole in 12 mm steel Stroke triggering via foot switch Support table with folding cams Assortment of tools is included in the price Fedpfxexcncce Ac Hogi

Condition: used, Punching Bracket, Punching Unit SUPRA-CLAP Type C12.300 Throat Depth: 300 mm Punching Capacity: 0.3 to 2 mm material thickness, depending on cutting clearance Hole Diameter: Ø 2 to Ø 12 mm Distance between lower die and punch holder: 8.5 mm Distance between upper and lower bracket: 13 mm Punch Shank Diameter: Ø 12 mm Cutting Plate Outer Diameter: Ø 30 mm Cutting Plate Thickness: 12 mm Drop-through Opening in Punching Bracket: 14.5 mm Installation Height: approx. 145 mm - Standard punch length 70 mm with 60° head (Punch per DIN 9861 Form C) - Punch holder with spring stripper and return spring Fgodpfx Aexbh Rdec Hoi - Mounting slot 50 x 13.5 mm and 8 mm locating pin Punching Bracket Dimensions (L x W x H): 390 x 36 x 145 mm Weight: 4 kg Good condition 9 units available, price per unit 3 units with tool inserts (punch + die) 6 units without tool inserts (without punch + without die)

Condition: used, Punching bracket, punching unit SUPRA-CLAP / CEWE Type PAE 50 - 400 3GN 3P1 Throat depth: 400 mm Punching capacity: max. 10 mm material thickness Hole diameter: max. Ø 50 mm Distance between upper and lower bracket: 19 mm Punch holder: Ø 78 mm Cutting plate outer diameter: Ø 78 mm Cutting plate thickness: 20 mm Drop-out opening in punching bracket: 52 mm Fgjdpfx Acexbh N Ts Hoi Installation height: approx. 220 mm - Punch holder as a punch unit with punch mount and material stripper with disc springs - Punch holder rotation-proof guided and spring-loaded - Punch length 97 mm, shank Ø 35 / 50 mm - Round hole tool: punch Ø 41 mm and die Ø 41.5 mm - Long fixing hole: 270 x 13.5 mm Dimensions of punching bracket (L x W x H): 550 x 95 x 220 mm Weight: 27.5 kg Good condition 4 units available, price per unit 3 units with Ø 41 mm punch tool 1 unit with Ø 43 mm punch tool

Condition: used, Punching bracket, punching unit SUPRA-CLAP type C7 300 Throat depth: 300 mm Punching capacity: max. 2 mm material thickness Hole diameter: Ø 2 to Ø 7 mm Distance between lower die and punch holder: 7 mm Fgedpfx Acjxbh N Ho Hsi Distance between upper and lower bracket: 12 mm Punch shank: Ø 7 mm Die outer diameter: Ø 20 mm Die thickness: 12 mm Pass-through opening in punching bracket: 11 mm Installation height: 142 mm - Standard punch length 70 mm with 60° head - Equipped with a round hole punch approx. Ø3 to 4 mm - Punch holder with stripping spring and return spring - Mounting slot 50 x 14 mm and 8 mm locating pin Dimensions punching bracket L x W x H: 390 x 26 x 145 mm Weight: 3.7 kg Good condition 13 pieces available, price per piece

Condition: used, pressure 30.0 t punching cross-cut in cmm 30.0 in 9.0 mm stroke ca. 35 Hub/min throat 610 mm stroke - stepless adjustable 0 - 28.0 mm oil volume 35.0 l work height max. 1010 mm Fedpfxsxaaipj Ac Hegi total power requirement 4.0 kW weight of the machine ca. 1200 kg. range L-W-H 1400 x 700 x 1600 mm good condition (!!) with a lot of application tools (stamps/dies) Furnishing: - electro-hydraulic hole punch, with large throat - Material/sheet metal scrapers including scraper plates - Large material support table, with adjustable depth stops - continuous stroke adjustment - freely movable foot switch including protective cover - Forklift pockets for easy transport - side storage area - lots of accessories + tools - including tool cabinet - Matrix base (for special size matrices) - Stamp holders (for special size stamps) - original user manuel

Condition: new, punching pressure 28.0 t punching cross-cut in cmm 31 in 7.0 mm ST throat 250 mm dayligth 223 mm no. of strokes 10 - 30 Hub/min oil volume 32.0 ltr. work height max. 1033 mm total power requirement 3.0 kW weight of the machine ca. 553 kg dimensions of the machine ca. 730 x 540 x 1530 m Furnishing: - Punch quick-change device up to Ø 31 mm - green series - Fgsdpfjw U U S Nex Ac Hsi installed: round punch no. 5 Ø 25.0 mm and round die no. 3 Ø 25.7 mm - Free: LED lighting in the punching area - Swiveling scraper (plates exchangeable) - Various material support tables are available separately - Brace - 2-step foot switch, with double press for grain search function - electrical controls - Stroke length and stroke position continuously adjustable - integrated hydraulic unit with oil filling - Performance specifications apply to a material strength of 450 N/mm² - Main connection cable and plug for 16 amps are not included in the scope of delivery

Condition: used, Year of construction: 2000, pressure 16 t throat 350 mm stroke 25 mm no. of strokes 200 - 1000 /min distance table/ram, max. stroke up, adjustment up 230 mm table surface area 480 x 280 mm Table height above floor 1050 mm ram surface 200 x 110 mm ram adjustment 25 mm diameter of blanks - 1800 mm no. of flutes 16 - 460 material thickness 2,0 mm distance between mid parts spindle and mid ram 160 - 680 mm power requirement 6,0 kW Weight 5,60 t dimensions of the machine (WxDxH) 1,4 x 2,9 x 2,4 m year of manufacture 1971 - new control 2000 with infinitely variable AC-drive, pneumatic clutch (Ortlinghaus), manual ram adjustment, electro-pneumatic blank clamping, automatic stripping device, intermittent control (ram lifting for idle stroke), fully automated centralized oil lubrication, two-hand operation, electrical control Siemens S 7 (yom 2000) Fgodpfx Acjw U Ekve Hji various change wheels

Condition: good (used), We are offering several dies, punches, reducing sleeves, and a quick-release clamping set for Peddinghaus here. Fjdpfx Acjw Trkgj Hogi Exact details can be found in the PDF.

Condition: good (used), We are offering several dies, punches, reducing sleeves, and a quick-release clamping set for Peddinghaus here. Exact details can be found in the PDF. Fodpfow Tri Nex Ac Hsgi

Condition: used, total length: 1,800 mm, total width: 1,000 mm, total height: 2,000 mm, Empty weight: 2.000 kg Price: On request Thickness 45 mm Maximum pressure 70 tons Punch cutting machine Model: Hydraulic Manufacturer: GEKA Fedpfx Acow Ryxmj Hogi Type: Hydracrop 70S Power: 70 tons Cutting round: 45mm Cutting beam: 45mm Cutting plate: 450x15mm Cutting corners: 250x6mm Incl. multiple punches Machine-afmetingen: 1800x1000x2000mm Machine weight: 2000kg - Documentation available: No - Power: 70.0ton - Transport dimensions: 1800mm x 1000mm x 2000mm (l x w x h) - Transport weight [kg]: 2000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: new, functionality: unexamined, Year of construction: 2024, machine/vehicle number: 16.41-PS0382, control type: CNC control, degree of automation: automatic, actuation type: electric, sheet thickness (max.): 8 mm, input voltage: 400 V, input current: 20 A, type of input current: three-phase, 2024 Pima Power PS 1225 Brand new Complete machine. Machine was tipped on its side during transit and was damaged. Fedpfx Acow Nbh Ho Hegi Machine is stored in Our warehouse in California USA. Contact to set up in person inspection.

Condition: used, Year of construction: 2001, Combined punching machine with shear and automatic loading/unloading system – FINN-POWER SG + TRS6FB _____ Brand: FINN-POWER Model: SG + TRS6FB Year of manufacture: 2001 Machine weight: 22,000 kg Punching force: 300 kN Shearing force: 250 kN Fodpow Iflmofx Ac Hsgi Max. working pressure: 300 bar Description: CNC combination punching machine + corner shear, complete with: • automatic loading system with sheet metal storage • CNC rotary turret • integrated corner shear • conveyor belts for unloading • soundproof cabin and safety guards • dedicated Finn-Power CNC The machine is currently installed and can be inspected by appointment. Condition: • Immediately available 📍 Location: Italy _____

Condition: not inspected (used), functionality: unexamined, machine/vehicle number: 4203773681008, table length: 1,400 mm, table width: 600 mm, No reserve price – guaranteed sale to the highest bidder! Placing a bid obligates the buyer to collect the machine within the specified period from 28/07/2025 to 31/07/2025. TECHNICAL DETAILS Table dimensions: 1,400 x 600 mm Motor: 11.4 kW MACHINE SPECIFICATIONS Overall width: 2,500 mm Overall length: 2,200 mm Overall height: 2,000 mm Total weight: 1,500 kg Operating voltage: 380 V Frequency: 50 Hz Rated current: 25 A Control voltage: 220 V with transformer Auxiliary voltage: 24 V Breaker rated short-circuit current: 0.165 kA Fedpfewvi N Tox Ac Hjgi Documents and Numbers Control number: 42037.301.01.00 Wiring diagram: 42037.301.01.01 Serial number: 42037.736.81.008

Condition: used, Year of construction: 2017, total length: 1,500 mm, total width: 900 mm, total height: 1,700 mm, Empty weight: 1.400 kg Price: On request Steel round: 40mm Steel flat: 200x20mm / 300x15mm Notching + Punching + cutting - Year: 2017 - Documentation available: Yes - CE marking present: Yes - Serial number: 155976 Fgjdpfxjwraazj Ac Hsi - Motor power: 4.0kW - Model: Hydraulic - Power: 60.0ton - Transport dimensions: 1500mm x 900mm x 1700mm (l x w x h) - Transport weight [kg]: 1400kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 1995, Specification: Fgjdpewql S Hofx Ac Hji Model: Indumasch Year of manufacture: 1995 For metal up to: 6 mm Other: foot pedal, interchangeable dies If you have any further questions, we will be happy to answer them.

Condition: used, Year of construction: 2011, Equipment: type plate available, CNC turret punching machine Amada type AE2510NT, Year of manufacture 2011, Control panel, Fedpfowpgvwsx Ac Hjgi Metal cabinet 200 cm, 2-door, red/black, Contents: machine accessories, Metal cabinet 120 cm, 2-door, red/black, Contents: small tools, Punching capacity 200 KN, Turret with 51 stations, Max. material size 1270x5000 mm, X-axis travel 2500 mm, Y-axis travel 1270 mm,

Condition: good (used), NOVOPRESS - Punching Machine -incl. 3 punching tools -Separate hydraulics with foot switch including trolley -Length measuring system -Protection grid Dimensions: Fgodpfxown Tgms Ac Hei LxWxH 1.7x1.2x1.7 meters / Weight 700kg Errors and input mistakes excepted.
