Condition: defective spare-parts repository (used), Year of construction: 1994, operating hours: 13,067 h, functionality: not functional, Equipment: documentation/manual, Control system issues (under Programs) Electrical fault (control boards) Suitable for spare parts Laodjznvm Hopfx Ak Aod Tool changer – chain conveyor included Without tools Already disassembled and stored separately!

Condition: used, Year of construction: 2011, operating hours: 48,000 h, machine/vehicle number: IntNr231180, DMG Gildemeister CNC Multi-Slide Automatic Turning Machine MSL 60/7 Year of manufacture: 2011 Machine on-time: 56,000 hours Automatic cycle hours: 48,000 hours CNC control: FANUC 31i – Model A, 7 axes Technical specifications - Number of axes: 7 - Number of spindles: 2 MAIN SPINDLE - Max. bar diameter: 60 mm - Spindle speed: 5,000 rpm - Spindle drive power: 7.5 kW COUNTER SPINDLE (on turret) - Max. bar diameter: 42 / (60) mm - Spindle speed: 5,000 rpm - Spindle drive power: 3.7 kW Driven tools (turret): - Tool drive power: 3.7 kW - Max. speed: 6,000 rpm Back-side machining: - 4 fixed tool stations - Capacity for up to 14 tools possible Bar feeder: FMB Turbo 5-55 / 3200 / A Year of manufacture: 2008 Bar diameter: 5 – 55 mm Bar length: 3,200 mm Chip conveyor included Laedpfxoznulbe Ak Ajd Machine can be inspected under power by appointment. Technical data, details, and prior sale subject to change and error.

Condition: ready for operation (used), Year of construction: 2022, travel distance X-axis: 240 mm, travel distance Z-axis: 430 mm, overall weight: 4,500 kg, controller manufacturer: SIEMENS, controller model: Sinumerik, number of axes: 2, This complete automated production cell includes two Hyundai HIT-200C CNC lathes and a FANUC M-20iA industrial robot with a ROBOTOWER automatic loading and unloading system. Each lathe offers a maximum turning diameter of 340 mm and a maximum turning length of 420 mm. The complete cell is designed for automated serial production, especially for larger production batches. Contact us for further details regarding this production cell. Laodpfjznm H Rjx Ak Aed • 2 x Hyundai HIT-200C CNC Lathes • Year of manufacture: 2003 • CNC control: Siemens Sinumerik • Maximum turning diameter: 340 mm • Maximum turning length: 420 mm • X-axis travel: 240 mm • Z-axis travel: 430 mm • Spindle nose: A2-8 • Spindle bore: 80 mm • Hydraulic chuck: 10" • Machine weight: approx. 4,500 kg each • Rigid and dimensionally stable construction • Capable of maintaining IT6 tolerance class Additional Equipment / Automation • FANUC M-20iA industrial robot, year 2014 • ROBOTOWER automatic loading and finished-part unloading station • Automatic handling of raw and finished parts • Set of robot grippers • Operating manuals • CE documentation • Complete production cell suitable for serial production, especially for batches of 500 parts or more • Robot and loading/unloading system in very good condition • LOSMA air filtration units (oil mist collectors) visible in the photos is not included in the offer Technical Specification Counter Spindle No Driven Tools No

Condition: used, Year of construction: 1992, Emco Turn 342 CNC Lathe with Fanuc OT Control, 2 Axis, 125mm Collet Chuck, 8 Tool Turret. S/No. RSG E2ES 002 S, Run Time 3241 Hours, Sameca Bar Feed Type SAM65. S/No. M062103 (1992) includes Autoblok Chuck, Selection of Tooling & Collets. Country of Origin: Austria Ljdeznkpcepfx Ak Asad Location: This lot is located in Birmingham, UK. A charge of £200 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser.

Condition: used, Year of construction: 2008, turning diameter 100 mm turning length 280 mm control Index C200-4D bar passage 60 mm spindle tunring speed 6.000 U/min auto power on hours ca. 76.525 In our assessment, the machine is in good used condition and can be inspected under power by appointment. The machine comes from its original owner, operates in an oil environment, and has undergone annual maintenance. Only brass was processed on the machine. Ljdpfezndtujx Ak Asad No tool holders are included in the scope of delivery! Accessories: - Short bar loader - Chip conveyor - Parts removal device Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change and errors in technical data and specifications; subject to prior sale!

Condition: ready for operation (used), Year of construction: 2016, spindle speed (max.): 3,500 rpm, travel distance X-axis: 255 mm, travel distance Z-axis: 790 mm, spindle motor power: 15,000 W, number of axes: 3, This 3-axis DOOSAN LYNX 300M was manufactured in 2016. It features a maximum turning diameter of 370 mm and a maximum turning length of 712 mm. The machine is equipped with a FANUC 0i-TF CNC control, a 12-station turret, and driven tooling capabilities. If you are looking to get high-quality turning capabilities, consider the DOOSAN LYNX 300M horizontal turning machine we have for sale. Contact us for further details. • CNC control: FANUC 0i-TF with 10.4-inch LCD and Manual Guide • Driven tools: power 5.5 kW, up to 5,000 rpm • Tailstock: Yes • Manual positioning along bed • Quill operated by foot pedal or via CNC program • Capacities: • Maximum turning diameter: 370 mm • Maximum turning length: 712 mm • Maximum swing over bed: 651 mm Lsdpfx Akjznb Shj Aoad • Bar capacity: 76 mm • Rapid traverse: X 24 m/min, Z 30 m/min • Workholding: 255 mm 3-jaw hydraulic chuck • Turret: 12 stations; indexing time 0.15 s • Tooling: • Tool shank size: 25 × 25 mm • Boring bar diameter: Ø40 mm • 4 axial driven tool holders • 3 radial driven tool holders • Basic tool holder package • Other: CE certification, transformer • Control options: Fast Ethernet connection, 2 GB CNC control memory Additional equipment • Chip conveyor • Bar feeder interface and preparation • Box-type parts catcher • Automatic tool setter • High-pressure coolant system (7 bar) • Oil skimmer • Three-colour machine status light • Tool load monitoring system Technical Specification Counter Spindle No Driven Tools Yes

Condition: used, turning length: 210 mm, turning diameter: 190 mm, travel distance X-axis: 125 mm, travel distance Z-axis: 195 mm, rotational speed (min.): 6,000 rpm, Turning diameter: 190 mm Turning length: 210 - 230 mm Lsdezm Uquepfx Ak Ajad X-axis: 125 mm Z-axis: 195 mm Spindle speed range: 6,000 rpm Swing diameter over bed: 190 - 200 mm Spindle bore: 43 mm Machine weight (approx.): 2,500 kg Accessories/Equipment: - Chip conveyor

Condition: ready for operation (used), Year of construction: 2003, travel distance X-axis: 240 mm, travel distance Z-axis: 430 mm, overall weight: 4,500 kg, controller manufacturer: SIEMENS, controller model: Sinumerik, number of axes: 2, Horizontal turning machine manufactured in 2003. This Hyundai HIT-200C features a maximum turning diameter of 340 mm and a turning length of 420 mm. It is equipped with a Siemens Sinumerik CNC control and has an X-axis travel of 240 mm and Z-axis travel of 430 mm. If you are looking to get high-quality turning capabilities, consider the Hyundai HIT-200C machine we have for sale. Contact us for further details. • Maximum turning diameter: 340 mm • Maximum turning length: 420 mm • Spindle nose: A2-8 Ledpfezmxt Tex Ak Asad • Spindle bore: 80 mm • Hydraulic chuck: 10" • Machine condition/accuracy: very rigid and dimensionally stable construction; capable of maintaining IT6 tolerance class Additional equipment • Optional automation package: • FANUC industrial robot • ROBOTOWER loading and finished-part unloading station • Set of grippers • Operating manuals • CE documentation • Note: Feeder/robot reported in very good condition; complete production cell suitable for serial production (e.g., batches of 500 parts or more) Technical Specification Counter Spindle No Driven Tools No

Condition: used, Year of construction: 1987, functionality: fully functional, Mazak QTN 8 CNC lathe Manufacturer: Mazak Lajdpfozmpxtex Ak Aod Type: QTN 8 Year of manufacture: 1987 Condition: used Scope of delivery: - Machine feet - Chip tray - Documentation - Tool holder

Condition: used, Year of construction: 2014, Manufacturer Citizen Machinery Miyano Co., Ltd., Japan Model BNA 42DHY2 Year of Manufacture November 2014 Serial Number DK4Y1085 Control Fanuc Series 0i TD CNC Machine Type CNC Twin Spindle Turning Center with Y Axis Country of Manufacture Philippines Capacity Maximum Bar Capacity: 42 mm Maximum Turning Diameter: Approx. 42 mm Maximum Turning Length: Approx. 100 mm, depending on workholding Main Spindle: Built in spindle Sub Spindle: Yes Y Axis: Yes C Axis: Main and Sub Spindle Turret: 12 station live tooling turret Live Tooling: Yes Travels X Axis: Approx. 135 mm Z Axis: Approx. 320 mm Y Axis: Approx. ±40 mm Spindle Main Spindle Speed: Up to approximately 6,000 rpm Sub Spindle Speed: Up to approximately 6,000 rpm Spindle Nose: 42 mm bar capacity Rapid Traverse X Axis: Approx. 24 m/min Z Axis: Approx. 30 m/min Y Axis: Approx. 12 m/min Electrical Power Supply: AC 200 V Phase: 3 Phase Frequency: 50 / 60 Hz Rated Power: 30 kVA Full Load Current: 87 A Lsdozmh R Uopfx Ak Aead Short Circuit Interrupt Rating: 2.5 kA Machine Weight Weight: 3,100 kg Equipment Visible on This Machine Fanuc Series 0i TD CNC Control Twin Spindle Y Axis C Axis Live Tooling Hydraulic Chuck Coolant System Fully Enclosed Splash Guard Emergency Stop Electronic Handwheel

Condition: ready for operation (used), Year of construction: 2011, spindle speed (max.): 4,000 rpm, travel distance X-axis: 70 mm, travel distance Z-axis: 115 mm, overall weight: 4,000 kg, number of axes: 12, This 12-axis LICO LNT 65 S CNC Multi-Slide Screw Machine was manufactured in 2011. It features a maximum spindle speed of 4000 rpm and comes with a tooling package and IEMCA Master 80 HF bar loader. If you are looking to get high-quality turning capabilities, consider the LICO LNT 65 S machine we have for sale. Contact us for further details. - Machine Type: CNC Multi-Slide Screw Machine / Automatic Lathe- Number of Axes: 12-Axis configuration- Voltage: 400 V- Phase: 3- Frequency: 50 Hz- Total Connected Load: 25 KVA- Total Current: 38 AMP- Optional available Equipment: Tooling package, IEMCA Master 80 HF bar loader Technical Specification Counter Spindle No Lajdpfx Akszmhvds Ajd Driven Tools Yes

Condition: used, Year of construction: 1990, functionality: fully functional, turning length: 250 mm, turning diameter: 160 mm, travel distance X-axis: 100 mm, travel distance Z-axis: 290 mm, Mazatrol T 32-2 CNC control main spindle: collet chuck device sub spindle: collet chuck device Ljdpfx Akszmfdxj Aead 8-fold revolver bar loading device Technische Daten / technical details: max. Drehdurchmesser / max. turning diameter 160 mm max. Schwingdurchmesser / max. rotary diameter 300 mm Drehlänge / turning length 250 mm X-Weg / X-travel 100 mm Z-Weg / Z-travel 290 mm Durchlass / spindle hole 40 mm Drehzahl / spindle speed 45-4500 UpM /rpm Gewicht der Maschine / weight 3500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: not inspected (used), Year of construction: 2013, functionality: unexamined, spindle speed (max.): 5,000 rpm, travel distance X-axis: 600 mm, travel distance Z-axis: 212 mm, This SPINNER CNC turning center, type TC 600 65 MC, built in 2013, will be auctioned online on our RESTLOS auction platform as part of our industrial auction "Insolvency Auction for Metalworking." You can find this and many other machines from the metalworking sector in this auction and in regularly scheduled future auctions. Additional data for the machine: Spinner CNC turning center Type: TC 600 65 MC Year: 2013 Operating hours: unknown 16-station turret, VDI 30 mounting Control: Fanuc 31i Serial number: AT0640 Without workbench Machine has already been disconnected. We explicitly recommend a personal inspection. As shown in the pictures. Items with pallets, pallet attachments, and boxes include these as part of the respective item. Any other items or positions shown in the pictures are not included in the offer. Laodpfx Ajzmdp Tsk Aed Content, condition, and completeness are not checked. The function has not been tested.

Condition: good (used), Year of construction: 2002, Swing diameter over bed: 350 mm Swing diameter over carriage: 180 mm X-axis travel: 155 mm Z-axis travel: 800 mm Lajdpfjzl Tkkox Ak Asd

Condition: ready for operation (used), Year of construction: 2002, operating hours: 147,007 h, spindle speed (max.): 6,300 rpm, travel distance X-axis: 370 mm, travel distance Z-axis: 250 mm, spindle motor power: 10,700 W, bar diameter (max.): 36 mm, controller manufacturer: TRAUB, controller model: TX8i (64-bit), workpiece diameter (max.): 32 mm, number of slots in tool magazine: 22, number of axes: 10, This 10-axis TRAUB TNK 36 horizontal turning machine was manufactured in 2002. It features a main spindle speed of 6,300 rpm and a counter spindle speed of 6,300 rpm. The machine includes a maximum workpiece diameter of 32 mm and a coolant tank capacity of approximately 360 liters. If you are looking to get high-quality turning capabilities, consider the TRAUB TNK 36 machine we have for sale. Contact us for further details. Laodpfx Akezl S Ems Aod • 14" flat screen • Additional V24 RS232 interface in the electrical cabinet • MDE interface in the electrical cabinet (machine status and parts counter) • Rigid tapping without compensation chuck • Polyform function for C-axis • Tool monitoring • Main spindle bore: 36 mm • Main spindle drive power: AC 6.7 / 10.7 kW • Main spindle C-axis • Motorized counter spindle • Counter spindle bore: 32 mm • Counter spindle speed: 6,300 rpm • Counter spindle Z-axis travel: 250 mm • Counter spindle Z-axis rapid traverse: 30 m/min • Counter spindle C-axis • Counter clamping pressure device • Workpiece ejector • Increased feed force • Hainbuch Axfix chuck • X2 travel: 50 mm • Y2 travel: ±20 mm • Z2 travel: 100 mm • X2 rapid traverse: 15 m/min • Y2 rapid traverse: 15 m/min • Z2 rapid traverse: 15 m/min • 12 driven tools (via central drive) • Driven tool speed: 6,000 rpm • Electronic gearbox • X3 travel: 370 mm • Z3 travel: 250 mm • X3 rapid traverse: 30–60 m/min • Z3 rapid traverse: 30 m/min • 5 driven tools • Tool holder diameter: 40 mm • Driven tool speed: 6,000 rpm • Increased feed force • X4 travel: 73 mm • Y4 travel: ±50 mm • X4 rapid traverse: 15 m/min • Y4 rapid traverse: 15 m/min • 5 driven tools • Tool holder diameter: 40 mm • Driven tool speed: 6,000 rpm • Left-hand workpiece conveyor • Pneumatic workpiece gripper • Gripper jaws: Ø5–8 mm / Ø8–20 mm / Ø20–36 mm • Maximum workpiece length: 200 mm • Maximum workpiece diameter: 32 mm • RESY compact belt filter • Cooling unit • Coolant tank capacity: approx. 360 l • Coolant pressure: 7 bar • Coolant flow rate: 50 l/min • Through-tool coolant: 30 bar • Coolant gun • Connected load: 22 kW Optional equipment, not included: • KNOLL 240S-1/100 hinged belt chip conveyor (discharge height: 950 mm) • Bar feeder preparation (guide tubes Ø25 / Ø36) • Rotating workpiece stop (16 × 16 mm shank) • Brankamp CMS 100 collision monitoring (main and counter spindle) • FMB Turbo 5-42 XT / 3200 "C" bar feeder • Basic set of static and driven tool holders included Technical Specification Through-spindle Coolant Yes Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 2018, Lathes Travel distance X: 135 mm Travel distance Y :40 mm Travel distance Z: 200 mm turning length: 330 mm max. turning diameter: 32 mm max. circulation diameter: 32 mm spindle boring: 32 mm input Power: 5,5 kW max. turning moment: 18 NM Ledpfxjzl Suhj Ak Aead range of revolution from: 200 rpm range of revolutions till: 8000 rpm Control: Fanuc 32i-B powered tools control Fanuc Scrapper chip conveyor Main and Sub Spindle Y-Axis C-Axes on Main and Sub Spindle Live Tooling Complete Tool Package Top Infinity Automatic Bar Feeder Kraft & Bauer Automatic Fire Suppression System Chip Conveyor High-Pressure Coolant System

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, turning diameter: 145 mm, CNC turning machine Gildemeister Twin 42 RG2 Year of manufacture: 2004 Control system: Siemens 840D Powerline Turning diameter: 145 mm Max. bar diameter: 45 mm Spindle head: Flat flange 120 h5 Chuck: 130 / 140 mm Main spindle speed: 20–7,000 min⁻¹ Main spindle power: 28 / 22 kW (40/100 % ED) Main spindle torque: 180 / 140 Nm Tailstock: Yes, same power X-axis: 220 mm Z-axis: 320 mm Y-axis: ±30 mm Rapid traverse X/Y/Z: 30 / 15 / 30 m/min Turret: 2 × 12 stations Tool holder: VDI 25 Machine weight: approx. 5,300 kg Connection power: approx. 40 kVA Design: 60° inclined bed, linear guides Chip conveyor Bürener type SPE 63/30-250 Z60 Tool monitoring system from Artis, type CTM Tailstock mounted on the counter-spindle slide, tailstock stroke = 230 mm Tailstock force = 300 daN Center: MK3 Overload coupling for the X and Z axes of slides 1 and 2 Laedozl Dvkepfx Ak Asd Package for bar machining consisting of: Workpiece removal device Workpieces can be automatically unloaded from both the main and counter-spindle Workpiece dimensions: Ø6 – Ø65 mm, length approx. 300 mm, max. weight 3.5 kg Collet chuck for quick-change tool holders, size 42 Hainbuch Spanntop Connection for bar feed Bar loader magazine from IRCO, type SiMag 42

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning diameter: 145 mm, Feature | Gildemeister Twin 42 RG2 Control system | Siemens 840D Powerline Turning diameter | 145 mm Max. bar diameter | 45 mm Spindle head | Flat flange 120 h5 Chuck | 130 / 140 mm Main spindle speed | 20–7,000 min⁻¹ Main spindle power | 28 / 22 kW (40/100 % ED) Main spindle torque | 180 / 140 Nm Counter spindle | Yes, same power X-axis | 220 mm Z-axis | 320 mm Y-axis | ±30 mm Rapid traverse X/Y/Z | 30 / 15 / 30 m/min Turret | 2 × 12 stations Tool holder | VDI 25 Machine weight | approx. 5,300 kg Connected load | approx. 40 kVA Design | 60° inclined bed, linear guides Chip conveyor Bürener Type SPE 63/30-250 Z60 Tool monitoring system by Artis, Type CTM Tailstock mounted on the counter spindle slide, tailstock stroke = 230 mm Tailstock force = 300 daN Ljdpfezl Drxsx Ak Ajad Center bore MK3 Overload clutch for the X and Z axes of slides 1 and 2 Bar machining package consisting of: Part removal device Workpieces can be automatically unloaded from both the main and counter spindle Workpiece dimensions: Ø6 – Ø65 mm, length approx. 300 mm, max. weight 3.5 kg Collet chuck for quick-change toolholders, size 42, Hainbuch Spanntop Connection for bar feed Bar loader magazine by IRCO, Type SiMag 42

Condition: ready for operation (used), Year of construction: 2013, operating hours: 30,959 h, spindle speed (max.): 1,750 rpm, travel distance X-axis: 200 mm, travel distance Z-axis: 600 mm, total height: 1,945 mm, total width: 1,565 mm, overall weight: 4,500 kg, controller manufacturer: FANUC, controller model: Series Oi-TD, product length (max.): 2,800 mm, number of axes: 2, Horizontal turning machine manufactured in 2013. This Leadwell T-7 features a maximum turning diameter of 350 mm and a maximum turning length of 540 mm. It includes a 12-station hydraulic turret and a spindle speed of 1,750 rpm. If you are looking to get high-quality turning capabilities, consider the Leadwell T-7 machine we have for sale. Contact us for further details. • Maximum turning diameter: 350 mm • Maximum swing over bed: 520 mm • Maximum turning length: 540 mm • Spindle nose: A2-6 Lsdpfxszl Awge Ak Asad • Spindle bore: 62 mm • Maximum bar capacity: 65 mm • Chuck size: 8" hydraulic chuck • Turret: 12-station hydraulic turret • Rapid traverse (X/Z): 20–30 / 24–30 m/min • Tailstock: Hydraulic Additional equipment • Chip conveyor: Standard or optional Technical Specification Counter Spindle No Driven Tools No

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 3,000 rpm, travel distance X-axis: 450 mm, travel distance Z-axis: 520 mm, spindle motor power: 15,000 W, controller manufacturer: OKUMA, controller model: OSP U10L, number of axes: 2, Horizontal turning machine manufactured in 2008. This Okuma ES-L10II features a maximum turning diameter of 390 mm and a maximum turning length of 500 mm. It is equipped with a 10" chuck and a robust Okuma MQ Turret with 12 stations. If you are looking to get high-quality turning capabilities, consider the Okuma ES-L10II machine we have for sale. Contact us for further details regarding this machine. • Working capacity: • Max swing over bed: 520 mm • Max swing over cross slide: 450 mm • Max turning diameter: 390 mm • Max turning length: 500 mm • Rapid traverse: X 20 m/min, Z 25 m/min • Main spindle: • Spindle bore: 80 mm • Speed range: 50–3,000 rpm • Gear ranges: 2 automatic • Max spindle torque: 416.9 Nm • Spindle motor power: 20 kW (continuous), max power at 251 rpm • Chuck: 254 mm (10"), through‑hole Ø70 mm • Spindle nose: JIS A2-8 • Turret: • Type: Okuma MQ turret • Stations: 12 • Tool shank size: 25 × 25 mm • Boring bar capacity: Ø40 mm • Indexing time: 0.1 s per station • Clamping force: 4,000 kg • CNC control: Ljdszl Auxjpfx Ak Asad • Okuma OSP-U10L • 10.4" TFT colour display • NC Operating Monitor • Cycle Time Reduction Function • Three-colour machine status indicator • Option included in quotation: • 15 kW high-torque spindle, 25–3,000 rpm, max torque 570.7 Nm Additional equipment • Chip conveyor • Automatic coolant system (0.25 kW) • Tool kit • Instruction and spare parts manual • Dutch operating manual Technical Specification Driven Tools No Counter Spindle Yes

Condition: used, Year of construction: 2002, MIYANO BND51S2, manufactured in 2002 equipped with: Lsdozlx Rvopfx Ak Aead MULTIFEED bar feeder Chip conveyor

Condition: ready for operation (used), Year of construction: 2009, operating hours: 28,580 h, spindle speed (max.): 3,250 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,050 mm, controller manufacturer: SIEMENS, controller model: ShopTurn, number of slots in tool magazine: 12, number of axes: 3, Horizontal turning machine manufactured in 2009. This DMG CTX510 ecoline features a maximum turning diameter of 465 mm and a swing diameter over the bed of 680 mm. It includes a 12-position tool turret and a spindle speed of up to 3,250 rpm. If you are looking to get high-quality turning capabilities, consider the DMG CTX510 ecoline machine we have for sale. Contact us for further details. • Maximum Turning Diameter: 465 mm • Swing Diameter over Bed: 680 mm • Bar Capacity: 76 mm • Spindle Speed: up to 3,250 rpm • Tool Turret: 12 Positions • Driven Tools • Kitagawa Chuck Ø 380 mm • Hydraulic Clamping System Optional, not Included: • Tailstock • Chip Conveyor • SMW Autoblok Chuck Ø 250 mm • Various Tool Holders Ledpfx Aszlt Amek Asad • Boring Bars • Turning Post • Additional Tools and Accessories Technical Specification Counter Spindle No Driven Tools Yes

Condition: good (used), Year of construction: 1992, FOR SALE JOHNFORD TC-20 CNC Lathe – FANUC 0-T Description: Selling a JOHNFORD TC-20 CNC lathe, manufactured in August 1992 (Serial No.: C9208035). This is a robust machine (cast iron frame), ideal for general mechanical work and precision machining. Lajdozltg Sspfx Ak Asd Main capabilities (estimated for this model): Maximum machining diameter: ~ 300 mm Maximum machining length: ~ 400 - 500 mm Bar capacity through the spindle: ~ 50 mm CNC control: FANUC Series 0-T (full panel + remote handwheel)

Condition: ready for operation (used), Year of construction: 2020, spindle speed (max.): 4,000 rpm, travel distance X-axis: 200 mm, travel distance Y-axis: 102 mm, travel distance Z-axis: 406 mm, spindle motor power: 14,900 W, number of axes: 4, This 4-axis HAAS ST-15Y was manufactured in 2020. It features a maximum spindle speed of 4000 rpm and a spindle power of 14.9 kW. The machine has a workpiece diameter over the bed of 419 mm and a maximum cutting length of 406 mm. If you are looking to get high-quality turning capabilities, consider the HAAS ST-15Y horizontal turning machine we have for sale. Contact us for further details. • Capacities • Chuck size: 210 mm • Max part swing: 419 mm • Max cutting diameter (BOT or VDI turret): 305 mm • Max cutting length: 406 mm • Bar capacity: 64 mm • Feedrates (rapid) • X-axis: 12.0 m/min • Y-axis: 12.0 m/min • Z-axis: 30.5 m/min • Axis motors (max thrust) • X-axis: 10,676 N • Y-axis: 10,231 N • Z-axis: 16,458 N • Spindle • Spindle nose: A2-6 • Spindle bore: 88.9 mm • Max spindle torque: 203 Nm at 500 rpm Lajdpfx Akezlr I Is Asd • Main spindle C-axis • C-axis power: 3.7 kW • Max speed: 60 rpm • Positioning accuracy: ±0.02° • Brake clamp force: 4448 N • Brake diameter: 366 mm • Brake holding torque: 190 Nm • Control: Interpolated motion and positioning • Turret and tooling • Turret: 12-station hybrid (6 VDI / 6 BOT) • Tool taper: VDI40 • Live/rotating tools: Yes, max speed 4000 rpm • Boring bar rear clearance: 19.1 mm • Tool stations: 12 • Tailstock • Type: Hydraulic tailstock • Quill travel: 95 mm • Manual body positioning: 508 mm • Thrust range: 623–5027 N • Coolant and air • Coolant capacity: 114 L • Air required: 113 L/min at 6.9 bar • Electrical • Input AC voltage (3-phase high): 440 VAC • Full load amps (3-phase high): 20 A • Full load amps (3-phase low): 40 A • Configuration notes • C-axis: Yes • Y-axis: Yes • Driven tools: Yes • Counter spindle: No Technical Specification Counter Spindle No Driven Tools Yes

Condition: excellent (used), Year of construction: 2018, operating hours: 6,185 h, functionality: fully functional, Tsugami B0326E-II Long-Turn Lathe Manufacturer: Tsugami Model: B0326E-II Year of manufacture: 2018 Control: Fanuc 32i-B Technical data Max. bar diameter: 32 mm Max. machining length: 320 mm (with guide bush) Machining without guide bush: 70 mm Main spindle: 8,000 rpm Counter spindle: 8,000 rpm Tool spindles: 6,000 rpm Number of controlled axes: 6 Tool stations: 31 standard (optional up to over 40, depending on configuration) Driven tools Y-axis C-axis, main and counter spindle Lajdozlp Swjpfx Ak Ajd Rapid traverse up to 32 m/min Main spindle motor: 3.7 / 5.5 kW Counter spindle motor: 2.2 / 3.7 kW Connection power: 21.4 kVA Machine weight: approx. 3,500 kg Dimensions (L × W × H): 2,150 × 1,280 × 1,930 mm Equipment ✔ Fanuc 32i-B CNC control ✔ Counter spindle ✔ Y-axis ✔ C-axes ✔ Tool package ✔ Top Infinity bar feeder magazine ✔ Kraft & Bauer fire extinguishing system ✔ Coolant system ✔ Chip conveyor Very well-equipped Tsugami B0326E-II long-turn lathe from 2018 with Fanuc 32i-B control. The machine features a main and counter spindle, Y-axis, and driven tools, making it ideal for high-precision series production of complex turned parts up to Ø 32 mm. The scope of supply includes an extensive tool package, a chip conveyor, a Top Infinity bar feeder magazine, and a Kraft & Bauer fire extinguishing system. The machine is in good condition and is available for immediate delivery after consultation.
