Condition: good (used), Tos W100A Table 1250 x 1250 mm X-1600, Y-1120, Z-1250, W-900 Fodexvrdkepfx Ac Hjgi ISO 50 3-axis digital readout (DRO) Motor 11 W 17500 kg

Condition: good (used), Year of construction: 1987, functionality: fully functional, The machine is in good technical condition; inspection and demonstration under power are possible by appointment. X = 1150 mm, Y = 1000 mm, Z = 600 mm Fgodpfxoxt Hw To Ac Hsi

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, Spindle 105mm, ISO 50, Table 1,500 x 1,250mm. X 2,999 Y 1,625 Z 1,500mm, W 700mm. Angel plates, tooling. Fgedsxrkzmepfx Ac Hoi

Condition: used, machine/vehicle number: 74144236, with NCT screen control, separate control cabinet, spindle diameter: 100 mm, table size: 1200x1000 mm, tool holders: SK50 Fjdpexpy E Nsfx Ac Hegi

Condition: used, Year of construction: 1984, functionality: fully functional, travel distance X-axis: 1,800 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 2,000 mm, table load: 5,000 kg, spindle diameter: 110 mm, total height: 3,800 mm, total length: 5,000 mm, total width: 3,000 mm, table length: 1,520 mm, table width: 1,225 mm, feed length X-axis: 1,800 mm, feed length Y-axis: 1,500 mm, feed length Z-axis: 2,000 mm, Tool holder SK50, Heidenhain control, machine is ready for collection and immediately operational. Fsdpjxga Tnjfx Ac Hsgi

Condition: new, travel distance X-axis: 2,000 mm, travel distance Y-axis: 2,050 mm, travel distance Z-axis: 1,500 mm, table load: 8,000 kg, spindle diameter: 110 mm, spindle speed (max.): 3,000 rpm, table length: 1,600 mm, table width: 1,440 mm, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 12,000 m/min, feed rate Z-axis: 12,000 m/min, travel distance W-axis: 500 mm, workpiece weight (max.): 8,000 kg, quill travel distance: 500 mm, quill diameter: 110 mm, overall weight: 25,000 kg, Equipment: rotational speed infinitely variable, BRAND NEW BORING MILL (T-STRUCTURE) Fgedpfoxc Hphox Ac Hsi Control and Motors: HEIDENHAIN TNC 640 digital contouring control HEIDENHAIN package (motors, measurement systems, and handwheel) IKZ: Internal coolant supply, 20 bar Additional equipment: Tool changer with double gripper, 60 positions Double hinged belt chip conveyor (longitudinal), one at the front and one at the rear Perimetric enclosure Spindle support bearing 250mm Hinged belt chip conveyor RENISHAW RMP 60 measuring probe Only inquiries from Germany will be answered // Only inquiries from Germany will be processed

Condition: used, total height: 2,550 mm, total length: 4,800 mm, total width: 2,740 mm, Empty weight: 7.000 kg Price: On request - Documentation available: No - Spindle speed max.: 1000rpm - Model: terbank - Digital readout: Yes - Table width: 970mm - Table length: 1140mm - Drilling capacity: 1mm - Travel X: 1500mm - Travel Y: 1500mm - Spindle diameter: 80mm - Travel Z: 1100mm - Type digital: Heidenhein - Number of axes: 3 - Spindle speed min.: 12rpm - Transport dimensions: 4800mm x 2740mm x 2550mm (l x w x h) - Transport weight [kg]: 7000kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Fedpfjxazypex Ac Hegi Lukas van Rossum

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 9022, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,450 mm, travel distance Z-axis: 930 mm, spindle diameter: 100 mm, spindle speed (max.): 1,600 rpm, travel distance W-axis: 506 mm, swivel angle B-axis (max.): 360 °, TECHNICAL DETAILS x-axis travel: 1,500 mm y-axis travel: 1,450 mm z-axis: 930 mm w-axis: 506 mm B-axis (table): 360° Table size: 1,100 x 1,400 mm Table rotary: 360° Tool holder: SK 50 Spindle diameter: 100 mm Spindle speed: 5 - 1,600 rpm / stepless Feed rates (X/Y/W/Z-axis): 2 - 2,000 mm/min Rapid traverse X-axis (X/Y/W/Z-axis): 5,000 mm/min Fgedpfx Acow T Sqtj Hsi MACHINE DETAILS Table load capacity: 4.0 t Total power requirement: 40 kW Control cabinet dimensions: 2,000 x 600 x 2,000 mm Machine dimensions (LxWxH): 4.9 x 3.7 x 3.8 m Machine weight approx.: 14 t EQUIPMENT - Measuring probe - Electronic handwheel - Hydraulic weight compensation Y-axis - Universal milling head - CNC drilling and milling machine with hydraulic unit

Condition: refurbished (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 193 34-41, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,600 mm, table load: 2,500 kg, spindle diameter: 102 mm, spindle speed (min.): 4 rpm, spindle speed (max.): 1,600 rpm, total height: 3,500 mm, total length: 6,500 mm, total width: 4,700 mm, table length: 1,400 mm, table width: 1,250 mm, year of last overhaul: 2025, Equipment: rotational speed infinitely variable, The machine was overhauled and modernized in 2025 and is immediately ready for operation! Travel paths: - Table cross travel (X-axis): 1600 mm - Spindle head vertical travel (Y-axis): 1250 mm - Table longitudinal travel (Z-axis): 1475 mm (restriction due to large table) - Quill travel (W-axis): 710 mm - Table rotation (B-axis): 360 degrees Clamping table: - Clamping surface: 1250 x 1400 mm - Table load capacity: 2.5 t Fedpsw Rn R Rofx Ac Hsgi Spindle: - Diameter: 102 mm - Tool holder: DIN2080, SK 50 - Infinitely variable speed: 4 – 1600 rpm - Drive power: 13 kW Feed: - X, Y, Z axes, stepless: 1 – 4000 mm/min Rapid traverse: - X, Y, Z axes: 4 m/min Power consumption: 42 kW Weight: 10 t Space requirements (L x W x H): 6.5 x 4.7 x 3.5 m Equipment: - Heidenhain TNC 320 - Coolant device

Condition: excellent (used), Year of construction: 2014, Year: 2014 Fodpfx Ajwtm Axec Hegi - technically efficient, ready to work – after full service - pneumatically rotating table -90°/ 0°/ +90° - vertical and horizontal pneumatic profile clamping - cooling and lubrication system - copying template

Condition: used, total height: 2,450 mm, total length: 4,000 mm, total width: 2,000 mm, Empty weight: 6.300 kg Price: On request - Documentation available: No - Motor power: 7.0kW - Drilling depth: 600mm - Spindle speed max.: 1000rpm - Model: terbank - Digital readout: Yes - Tool holder: ISO 40 - Table width: 800mm - Table length: 1000mm - Travel X: 800mm - Travel Y: 800mm - Spindle diameter: 75mm - Travel Z: 100mm - Type digital: Sony - Number of axes: 3 - Spindle speed min.: 13rpm - Transport dimensions: 4000mm x 2000mm x 2450mm (l x w x h) - Transport weight [kg]: 6300kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum Fgodpfxswr Drhs Ac Hji

Condition: good (used), Year of construction: 1988, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, table load: 3,000 kg, 4 Axis HeidenHain digital readout Ballscrews in all axis Face plate 460 mm stroke 180 mm Coolant system Fgodpswq Rcwsfx Ac Hsi Verplaatsing X - as: 1600mm Verplaatsing Y - as:1000mm Verplaatsing Z - as:1000mm Verplaatsing W - as:710mm Tafellengte: 1400mm Tafelbreedte: 1250mm Tafelbelasting: 3000 Toeren - Range: 1600Rpm Vermogen kW: 11kW Spindelopname: 50ISO/Bt/Mk Voeding X-as: 5000mm/min. Voeding Y-as: 5000mm/min. Voeding Z-as: 5000mm/min. Voeding W-as: 2000mm/min. Lengte: 3400mm Breedte: 3400mm Hoogte: 3500mm Gewicht: 9800kg

Condition: used, Price: On request Drilling machine, horizontal boring machine  Model: Conventional Manufacturer: WMW Union Type: BFT 90/3-2 Including rotating table Including digital readout Including multiple belongings X-Z travel: 1600x1000 Y-travel (up-down): 1050mm W-travel: 710mm Spindlemotor: 11kW Spindle diameter: 90mm Spindlespeed: 8-1600 rpm Fsdpjwnhi Ajfx Ac Hegi Table: 1000x1120mm Machine-weight: 9000kg - Documentation available: No - Serial number: 90/3-2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, table load: 6,000 kg, spindle diameter: 110 mm, spindle speed (min.): 5 rpm, spindle speed (max.): 1,120 rpm, total height: 4,300 mm, total length: 7,200 mm, total width: 4,600 mm, table length: 1,600 mm, table width: 1,400 mm, feed length W-axis: 800 mm, type of input current: AC, spindle stroke: 800 mm, overall weight: 26,000 kg, year of last overhaul: 2020, A Union Gera BFT 110/6 horizontal boring mill is for sale The machine was built around 1980 and was overhauled by us in 2009/2010 and has been in our care since then. The scope of the overhaul includes the following: - Electrical system almost completely renewed - New control cabinet incl. Siemens S7-200 PLC control system - New drive technology Siemens Simodrive 611, feed motors Siemens 1FK7 - Heidenhain TNC 124 line control + electronic handwheel - Heidenhain length measuring systems on X, Y and Z axes - Heidenhein angle measuring device in B-axis (rotary table) - Spindle drive three-phase asynchronous with DC brake electronics - Renewal / overhaul of all hydraulic components - New KGT in X and Y axes - Overhaul of the drive systems of all feed axes - All axles were rescraped - Lubrication systems of axes and headstock overhauled Fgsdpfxsu U Hvws Ac Hoi - New bearings and overhaul of the gear components of the headstock For further technical details see photos or on request. Equipment of the machine: - Heidenhain TNC 124 line control + electronic handwheel - Facing slide (U-axis) - Electric tool clamp SK 50 The sale is due to capacity reasons. The machine is fully functional and immediately available. It achieves production accuracies according to the manufacturer's protocol. Technical documentation is available. The machine is fully functional and, by prior arrangement, can be inspected under power. The offer is subject to our terms and conditions of business and delivery. Subject to errors and prior sale. As a warranty is excluded for the purchase of used machines, we recommend that our our customers to inspect the machine before making a purchase. As is customary with used machines, payment is made by bank transfer before delivery of the goods. bank transfer. Dismantling, relocation, installation, commissioning and geometric adjustment at the new location, can be carried out by us on request. We will be happy to submit a separate offer for this. Delivery of the machine to other EU countries is also possible on request.

Condition: used, Year of construction: 1987, Technical details: spindle diameter: 110 mm x-travel: 1985 mm y-travel: Spindelstock vert. 1270 mm z-travel: Tisch längs: 1260 m. Setzstock/1490 m. Setzstock mm table adjustment: nein ° B-axis (table): 360 W-axis (spindle longitudinal): axial: 710 mm U-axis: Planschieber radial: 250 mm control for program: Heidenhain 320 Fgsdpfx Acsu Utwbo Hsi tool taper: ISO 50 table-size: 1600 x 1400 mm table rotating: 360 ° table load: 6,3 t range drill spindle revolution per minute: 6,3 ... 1250 / 4 step U/min revolution per minute: Plansupport: 6,3 ... 315 / 2 step U/min feed steps: Tisch: 5...2500 und Spindelstock vert. 5...2500 mm/min total power requirement: ca. 90 kW weight of the machine ca.: 30 t Tailstock Facing slide 700 Electronic handwheel max. turning Ø for drilling: 630mm max. turning Ø for facing: 1250mm At the moment the Horizontal Boring and Milling Machine has an electrical fault in the control (unknown). Our offer/sale is as described and as is! *

Condition: used, Year of construction: 1980, spindle diameter 105 mm cross travel of table 1600 mm vertical adjustment of drilling slide 1600 mm longitudinal movement of column 1000 mm spindle stroke - max. 600 mm spindle taper ISO SK 50 Fodsu Rt Inepfx Ac Hegi spindle turning speed range 6,3- 1600 U/min table surface area 1120 x 1120 mm spindle motor 45 kW voltage 400 V feeds x/y/z -stepless 0 - 5000 mm/min rapid travel x/y/z 10 m/min table load 6 t table rotation 360 ° total power requirement 82 kW weight of the machine ca. 18 t dimensions of the machine ca. 4,8 x 4,9 x 4,2 m Machine was complete reconditioned and retrofitted with Siemens 840 D control in 2008 for a price of 400.000,- Euro ! Machine has a 40 position ATC, 5 CNC axes with ball screw drives (X,Y,Z,W,B), housing around machine with safety doors, cooling arrangement built in 2020 and new spindle drive Siemens built in 2008.

Condition: used, Year of construction: 1992, Technical details: spindle diameter: 100 mm x-travel: 1500 mm y-travel: 1450 mm z-axis: 930 mm w-axis: 506 mm B-axis (table): 360 ° control for program: HdH TNC 407 tool taper: SK50 number of spindle speeds: 5 - 1.600 / stufenlos table load: 4,0 t table-size: 1100 x 1400 mm table rotating: 360 ° feed steps: X/Y/W/Z-Achse: 2 - 2000 mm/min Rapid feed X axis: X/Y/W/Z-Achse 5000 mm/min. total power requirement: 40 kW dimensions electric cabinet: 2000 x 600 x 2000 mm machine dimensions LxWxH: 4,9 x 3,7 x 3,8 m weight of the machine ca.: 14 t CNC drilling-milling machine with hydraulic power unit. Working paths from the table: X-axis table transverse 1500mm W-axis table longitudinal 1000mm 9x T-slots according to DIN 650 Equipment: measuring probe electronic handwheel hydr. weight compensation Y-axis Fodpfx Aeu Idqbec Hogi universal milling head And some accessories, ask for them! i.D. *

Condition: used, Technical details: spindle diameter: 110 mm x-travel: 2000 mm y-travel: 1600 mm Fgedpju Idp Dsfx Ac Hsi z-travel: 2000 mm control for program: TNC Heidenhain 320 B-axis (table): ja W-axis (spindle longitudinal): Planschieber mm tool taper: ISO 50 table-size: 1400 x 1250 mm machine dimensions LxWxH: 8,0 x 6,0 x 4,5 m weight of the machine ca.: 28 t with face slide 700mm , electronic hand control *

Condition: used, Year of construction: 1978, spindle diameter 105 mm x-travel 1250 mm y-travel 1000 mm z-travel 600 mm table length 1100 mm table width 900 mm tool adaptor 50 ISO / MK Fodet Hwtxopfx Ac Hogi total power requirement kW weight of the machine ca. t CNC Table Borer, Reconditioned 2002, BOSCH CC 300

Condition: used, Year of construction: 1974, spindle diameter 90 mm x-travel 1000 mm y-travel 1200 mm z-travel 1200 mm feed movement 710 mm spindle taper ISO 40 turning speed range 8 - 1600 U/min table-size 1120 x 1000 mm table rotating 360 ° table load 2,5 t total power requirement 11 kW Fgjdpfx Aotv Ibdjc Hji weight of the machine ca. 10 t dimensions of the machine ca. 4,5 x 3,3 x 3 m separate switchboard, rapid traverse some tool holders, without facing plate, without steady rest,

Condition: like new (used), Year of construction: 2017, operating hours: 784 h, functionality: fully functional, Controller Fanuc 31i Model B Spindel diameter 110 mm Table size 1250 x 1500 mm T slots in the table 22 mm / H8 x 150 mm x 7 Max. table load 5000 kgs Fgsdpfx Aottgzcjc Hei Distance between the spindle nase and table surface 0 - 1600 mm (universal head) Distance between the spindle center and table surface 105 - 2250 mm (universal head) X travel 2200 mm Y travel 1600 mm Z travel 1600 mm W travel 550 mm (spindle feedrate) B axis 0,001 degree (stepless adjustable) Spindle speed 35 - 3000 rpm Tool holder type ISO50 . ATC magazin 60-fold Rapid speed on X / Y / Z / W axes 12 / 12 / 12 / 6 m/min. Feedrate on X / Y / Z / W Achsen 10 / 10 / 10 / 6 m/min. Spindle power 18,5/15 kW Torque 863 / 740 Nm Power required 400V, 50 Hz, 50 kVA Weight 21500 kgs Dimensions L x W x H = 7750 x 4715 x 3700 mm Accessories, features - Coolant unit - ATC magazin - Coolant through spindle 20 bar - Chip conveyor - RENISHAW OMP60 Infra zero point presetter - Universal milling head - Clamping angles 2 pcs - Separated electrical cabinet - Manuals The machine can be found in almost new condition. It was barely used. Ready to buy immediately. Still under power in Hungary. The dismantling and loading are the buyer's cost.but we can help to customers in this job by ourself.

Condition: good (used), Maximum turning diameter with top carriage 1350 mm Maximum turning diameter with side carriage 1100 mm Maximum turning height 1000 to 1250 mm Table diameter 1100 mm Fgjdpfxstn S D Aj Ac Hoi Maximum table load 4000 kg Power of main motor 30 kW Table speeds 6.3 - 200 rpm Number of table speeds 16 Distance between floor and table surface 955 mm TOP CART: Vertical travel of the ram with tool holder (Z axis) 600 mm Longitudinal travel of the slide (X axis) 700 mm Number of tool holes in the tool holder 5 Diameter of tool hole 60 mm Working feeds 12; 0,21 - 10 mm/min Fast feed rate 1880 mm/min SIDE CARRIER: Vertical slide travel (R axis) 800 mm Slide travel (P axis) 630 mm CROSS BEAM: Vertical travel 1000 mm Feed rate 500 mm/min

Condition: refurbished (used), Year of construction: 2015, operating hours: 11,800 h, Retrofited WHQ 105 CNC year 2015 Travel distance X-axis: 1,800mm Travel distance Y axis: 1,600mm Travel distance Z-axis: 1,250mm Table load: 5,000kg Spindle diameter: 105mm Spindle speed (max.): 3,300 rpm Fsdpjr Hdqxofx Ac Hjgi Table length: 1,400mm Table width: 1,600mm Travel distance W-axis: 630mm Automatic Tool Changer.....40 pos Coolant through spindle.....20 bar Splash guard around rotary table Chip Conveyor Oil cooling unit (chiller)

Condition: new, BRAND NEW MACHINE HEIDENHAIN TNC 640 digital path control HEIDENHAIN package (motors, measuring systems, and handwheel) X-axis: 3,000 mm Y-axis: 1,300 mm Z-axis: 1,500 mm Rotary table: 1,600 x 1,200 mm Maximum workpiece weight: 6,000 kg Automatic universal diagonal swivel head 1° x 1° (optional with fixed ram Ø 210 mm) Spindle taper: SK-50 DIN 69871/A Max. spindle speed: 6,000 rpm (oil-cooled) Max. spindle motor power: 53 kW ICS – internal coolant supply – 36 bar Rapid traverse X,Y,Z: 30 m/min Positioning accuracy: 0.015 mm Repeatability: 0.010 mm Fodpfx Acoq I Ncqe Hjgi ATC – tool changer: 40 positions (vertical / horizontal change) 2 x longitudinal hinge-type chip conveyors Perimeter enclosure (open top) Only inquiries from Germany will be answered.

Year of construction: 1969, condition: refurbished (used), BORING TOS TYP: 100A YEAR 1969 Fjdpfohiarqjx Ac Hjgi
