Used Haulotte Optimum 6 for sale (107)

Condition: new, Year of construction: 2024, Functionality: fully functional, OPTIturn TH 3309D Lead and Feed Screw Lathe Manufacturer: Optimum Model: OPTIturn TH 3309D Year of Manufacture: 2024 Condition: New machine Delivery Time: Available immediately (subject to prior sale) Bob Eovu Aryspzufswl Dimensions and Weight Length: approx. 1685 mm Width/Depth: approx. 745 mm Height: approx. 1590 mm Net Weight: 512 kg Working Areas Center Height: 165 mm Distance Between Centers: 830 mm Swing Over Bed: 330 mm Swing Over Cross Slide: 208 mm Turning Length in Bed Bridge: 430 mm Speed Range Number of Speed Ranges: 16 Speed Range: 70 – 2000 min⁻¹ Electrical Specifications Motor Power: 1.5 kW Connection Voltage: 400 V Frequency: 50 Hz Spindle Spindle Mount: Camlock DIN ISO 702-2 No. 4 Spindle Bore/Rod Passage Diameter: 38 mm Max. Tool Holder Height: 16 mm Spindle Taper: MT 5 Tailstock Tailstock Taper: MT 3 Tailstock Quill Travel: 110 mm Tailstock Quill Diameter: 32 mm Thread Cutting Metric Thread Pitch Range: 0.4 – 7 mm/rev (26 pitches) Imperial Thread Pitch Range: 56 – 4 TPI (34 pitches) Travel Top Slide Travel: 98 mm Cross Slide Travel: 164 mm Carriage Travel: 695 mm Feed Rates Longitudinal Feed Rate: 0.052 – 1.392 mm/rev (32 feed rates) Cross Feed Rate: 0.014 – 0.38 mm/rev (32 feed rates) Included Accessories Steady Rest (Ø 6 - Ø 50 mm) Follow Rest (Ø 8 - Ø 30 mm) LED Machine Light Reducing Sleeve MT 5 / MT 3 Two Fixed Center Points MT 3 Four-Position Tool Holder (16 mm) Change Gear Set Machine Base Initial Filling with High-Quality Oil Operating Tools Additional Accessories Further accessories available on request. Price and additional technical data available upon request.

Year of construction: 2015, Condition: used, Empty weight: 1.400 kg Dimensions (LxBxH): 140 x 138 x 200 cm - Year: 2015 Bwjbsv Stkuj Epzufjl - Documentation available: Yes - CE mark available: Yes - Control: CNC - Motor power: 1.5kW - Transport dimensions: 1400mm x 1380mm x 2000mm (l x w x h) - Transport weight [kg]: 1400kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: new, Year of construction: 2025, turning diameter over cross slide: 270 mm, spindle bore: 58 mm, turning diameter: 460 mm, center height: 230 mm, center width: 1,060 mm, quill stroke: 130 mm, quill diameter: 60 mm, total length: 2,280 mm, total width: 1,150 mm, total height: 1,650 mm, Turning diameter in gap: 690 mm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 25 rpm, overall weight: 1,910 kg, quill mount: MK 4, metric thread pitch (max.): 14 mm, tailstock quill diameter: 60 mm, Optimum TH 4610D center lathe with DPA 31 Plus digital position indicator and quick-change tool post Hardened and ground Z-axis guideway Guaranteed spindle nose concentricity ≤ 0.015 mm Shafts, gears, and main spindle run in an oil bath Lead screw cover Precisely machined slide All guideways adjustable via V-ledges Mechanical longitudinal feed shutoff of the bed slide with four adjustable eccentrics Right/left rotation on the bed slide can be switched via a switch spindle Central lubrication in the bed slide Top slide adjustment range ± 90° Smooth-running, hardened, and ground gears mounted on two adjustable precision tapered roller bearings Switch with life cycle calculation, tested according to EN ISO 13849 Large chip guard with integrated LED Machine lamp Handwheels with adjustable fine scales of 0.04 / 0.02 mm Safety handwheels with disengagement function according to EN23125 on the X and Z axes Quick-action feed gears in a closed design, gears and shafts hardened and ground, running in an oil bath on precision bearings Adjustable thread dial scale Tailstock for taper turning adjustable ± 10 mm Tailstock sleeve and handwheel with adjustable fine scale of 0.025 mm Quick, easy, and tool-free adjustment of the tailstock using a clamping lever Cable routing via energy chain Bwob Epswaaf Hjzufjl Heavily ribbed prismatic bed, induction-hardened and precision-ground from gray cast iron Coolant system with separate coolant tank with level indicator and oil separator; Easy and complete emptying and cleaning according to DIN standards Emergency stop device with foot operation Scope of delivery: Fixed steady rest, opening Ø 25 - Ø 178 mm Revolving steady rest, opening Ø 19 - Ø 114 mm LED machine light Adapter MK6-MK4 Non-revolving center MK4 Non-revolving, but temperature-resistant center MK4 Quick-change tool holder SWH 5-B Tool holder 25 x 120 Type D for 20 mm square chisel Thread gauge Set of interchangeable gears Gears for thread gauge (metric) Initial machine filling with high-quality oil Operating tools Options available upon request; we will be happy to advise you: - Three-jaw chuck / four-jaw chuck - Steel reamer / turning tool - Mounting elements - Commissioning Do you need a different machine? Please contact us!

Condition: new, Year of construction: 2025, x-travel 580 mm y-travel 200 mm z-travel 340 mm Bweb Epjtv Riajzufsl speeds 115 - 1750 U/min table surface area 1000 x 240 mm tool taper ISO 40 total power requirement 4,5 kW weight of the machine ca. 820 kg dimensions of the machine ca. 1290 x 1090 x 2170 mm Universal precision drilling and milling machine for horizontal and vertical milling work with digital 3-axis position display DPA 31 Plus Description: - Heavy, solid design made of high-quality, vibration-absorbing gray cast iron - Oil bath gear with ground, hardened gear wheels - Coolant system - Halogen machine lamp with bundled beam - Solid and large cross table, precisely surface-machined with T-slots and adjustable wedge strips - Milling head can be tilted ± 45° - Right/left rotation - X-axis moves either with the handwheel or via the table feed device - Automatic limit switch on the X-axis - Height-adjustable protective screen with microswitch, against flying chips and parts, for the greatest possible protection of the user Scope of delivery: - Gear rim drill chuck 1 - 16 mm / B 18 - Arbor drill chuck ISO40 / B18 - Horizontal milling spindle with counter bearing, disc milling cutter holder Ø22 mm, Ø27 mm - Adapter ISO 40/MK3 - Adapter ISO 40/MK2 - Vertical and horizontal drawbar - T-slot nuts - Drifter - Operating tool

Condition: used, Technical details: cutting diameter: 260 mm Bwobev T Tcmj Epzufol saw band length: 4640 mm saw band width: 34 mm total power requirement: 1,5 kW machine weight approx.: 800 kg Bandsäge - Halbautomat schwere Industriebandsäge mit Rollenbahn Gehrungsschnitt möglich hydr. Werkstückklemmung i.D. *

Condition: used, Year of construction: 2006, x-travel 600 mm y-travel 270 mm z-travel 430 mm 630 mm table-size 1120 x 270 mm spindle turning speed range 45 - 1660 U/min spindle taper SK 40 control konventionell Bjb Epzuev Sdz Refswl spindle motor 2,2 kW total power requirement 2,4 KVA weight of the machine ca. 1,35 t dimensions 1,8 x 1,4 x 1,8 m Machine equipped with: - Digital display - Machine light - Coolant system - Machine feet

Condition: new, Year of construction: 2024, Functionality: fully functional, Metal Band Saw OPTIsaw S 275NV Description: Quiet operation Sturdy cast construction High cutting accuracy due to vibration-free operation Adjustable lowering of the saw bow via hydraulic cylinder with throttle valve Microswitch for automatic shut-off at the end of the cut Coolant system included Equipped with a high-quality bi-metal saw blade as standard Adjustable material stop for series work Robust machine base Ball-bearing saw blade guide Quick-action vise adjustable via handwheel Clamping of the workpiece with a convenient quick-action lever Easy-to-read scale for angle adjustment Overload protection S 275NV Features: Infinitely adjustable saw blade speed: 20 - 90 m/min Speed adjustment possible during operation Pressure gauge for easy and correct saw blade tension adjustment Technical Data: Dimensions and Weights: Length (product): approx. 1400 mm Width/Depth (product): approx. 685 mm Weight (net): approx. 185 kg Max. Width/Depth (product): approx. 985 mm Max. Height (product): approx. 1700 mm Electrical Data: Drive motor power: 1.5 kW Connection voltage: 230 V Frequency: 50 Hz Coolant pump motor power: 90 W Machine Data: Saw blade speed: 20 – 90 m/min Saw blade length: 2480 mm Saw blade width: 27 mm Saw blade thickness: 0.9 mm Cutting angle: 0 – 60° Feed: Infinitely adjustable Raising of the saw bow: Manual Cutting Ranges: Cutting range at 0° round (solid material): 225 mm Cutting range at 0° square (solid material): 190 mm Cutting range at 0° rectangle lying (solid material): 150 x 245 mm Cutting range at +45° round (solid material): 145 mm Cutting range at +45° square (solid material): 150 mm Bweb Epovkcztjzufol Cutting range at +45° rectangle lying (solid material): 190 x 150 mm Cutting range at +60° round (solid material): 90 mm Cutting range at +60° square (solid material): 90 mm Cutting range at +60° rectangle lying (solid material): 120 x 90 mm Note on cutting range: The cutting range is determined based on the weight of the saw bow with aluminum. It may vary with different materials and could be smaller (not cutting capacity). Accessories: Material stop Bi-metal saw blade Machine base Coolant pump Price: Available on request

Condition: reconditioned (used), Year of construction: 2018, Functionality: fully functional, turning diameter over cross slide: 146 mm, turning length: 600 mm, turning diameter: 350 mm, spindle speed (max.): 3,500 rpm, spindle speed (min.): 30 rpm, travel distance X-axis: 185 mm, travel distance Z-axis: 540 mm, feed rate X-axis: 600 m/min, feed rate Z-axis: 800 m/min, center height: 165 mm, Equipment: rotational speed infinitely variable, CNC-controlled lathe with linear guide Built in 2018, with few operating hours !!! including current maintenance and test report !!! - Precise workmanship - Spindle and feed motors from Siemens - Braced machine bed made of gray cast iron - Maintenance-friendly protective housing - Ground ball screw spindles - Elaborate spindle bearings - Linear guide in both axes - Central lubrication - Rear access flap for maintenance - Turning turret is located behind the turning center (left turning tool) SINUMERIK 808 ADVANCED Bwobevmgnie Epzufjl Thanks to a panel-based CNC design with few interfaces and an operator panel with protection class IP65, the SINUMERIK 808D ADVANCED is perfectly prepared for use in harsh environments. 8.4” LCD color display with 800 x 600 resolution Technical data Weight (net) approx. 1200 kg Working areas Lathe chuck diameter 160 mm Center height 165 mm Center distance 600 mm Swing diameter over machine bed 350 mm Swing diameter over cross slide 146 mm Bed width 208 mm Speed range 30 – 3500 min¯¹ Drive motor power 3.7 kW Repeatability ± 0.01 mm Positioning accuracy ± 0.01 mm Spindle mount ISO 702-1 No. 4 - Form A2 Spindle bore/bar passage diameter 46 mm Tailstock mount MK 3 Tailstock Quill stroke 120 mm Quill diameter 45 mm Travel path Travel path X-axis 185 mm travel path Z-axis 540mm Feed rate X-axis 6000mm/min Feed rate Z-axis 8000mm/min Tool changer type electric Tool changer positions 6pcs. Holding height, width square max. 16 x 16mm Boring bar max. 16mm Connection value 6.5kVA The CNC lathe comes from a training center and has not been used much there. It has been serviced by the manufacturer. The current maintenance and inspection report is enclosed. The machine is in our demonstration center in Chemnitz and can be viewed at any time. We are happy to help with transport, assembly and instruction.

Year of construction: 2025, Condition: new, Motor power: 1,1kW / 400V Cutting area: 100mm x 145mm Coolant device: Yes Feed: stepless Saw band speed: 45 /90 m/min Saw band dimension: 2480 x 27 x 0.9 mm Cutting angle: 0° to 60 Dimension: 1400mm x 685mm x 1235mm Weight: 185kg Bob Epzuoha Nz Uefjwl

Year of construction: 2015, Condition: ready for operation (used), Center height: 230mm, center width: 1060mm, orbital diameter over bed/plane slide/bed bridge: 460mm/270mm/690mm, turning length in the bed bridge: 240mm, bed width: 300mm. Spindle bore: 58mm, spindle taper: MK6, speed: 2000rpm, travel X/Z: 125mm/285mm, tailstock mount: MK4, quill diameter: 60mm, quill stroke: 130mm. Machine dimensions X/Y/Z: approx. 2250mm/1100mm/1550mm, weight: approx. 1700kg. Documentation available. On-site inspection is possible. Beb Eov Rp R Iopzufowl

Year of construction: 2010, Condition: excellent (used), Coolant pump Make Optimum Canister : 370 x 250 x H.170 mm Type 3352001 Bwsbjfdzzuo Epzufol Motor 32 W/400 V -50 Hz min.2800 Amp.0,08 Series BJ 201006

Condition: used, Technical details: x-travel: 200 mm y-travel: 450 mm z-travel: 460 mm control: Siemens 802S base line spindle taper ISO: ER 32 spindle head swivable left - right: nein ° turning speed range: 150 - 8600 U/min feed:: X/Y/Z: 2000 - stufenlos mm/min table surface area: 750 x 210 mm interface: 232 total power requirement: 3 kVA weight approx.: 760 kg dimension machine xH: 1,9 x 1,2 x 2,1 m Table movement: X-axis: 200mm and Y-axis: 450mm spindle vertical Z-axis: 460mm max. tool holder milling cutter: Ø 20mm drilling capacity ST: Ø 13mm max. distance spindle-table: 470mm Equipment: Manual control unit cooling system central lubrication Bsb Epzju Ndcaoufjwl machine interior lighting Machine feet *

Condition: new, Year of construction: 2025, New machine. Please ask for current price and delivery time. Dimensions and weights: Length (product): approx.1750mm Width/depth (product): approx.1075mm Height (product): approx.1420mm Weight (net): approx.550kg Width/depth max. (product): approx.1415mm Max. height (product): approx.2000mm Electrical data: Power drive motor: 2.2kW Supply voltage: 400V Mains frequency: 50Hz Motor power coolant pump: 0.05kW Machine data: Saw blade speed(s): 36 / 72m/min Saw blade length: 2925mm Saw blade width: 27mm Saw blade thickness: 0.9mm Cutting angle: -45 - +60° Feed: infinitely adjustable Lifting of the saw bow: manual Cutting ranges: Cutting range 0° round (solid material): 270mm Cutting range 0° square (solid material): 230mm Cutting range 0° rectangular horizontal (solid material): 230 x 350mm Cutting range -45° round (solid material): 230mm Cutting range -45° square (solid material): 170mm Cutting range -45° rectangular horizontal (solid material): 140 x 200mm Cutting range +45° round (solid material): 230mm Cutting range +45° square (solid material): 200mm Cutting range +45° rectangular horizontal (solid material): 210 x 220mm Cutting range +60° round (solid material): 140mm Bjb Esrah R Tepzufowl Cutting range +60° square (solid material):140mm Cutting range +60° rectangular horizontal (solid material): 140 x 220mm

Condition: ready for operation (used), Optimum milling machine Bwob Eov H Nnxepzufol

Year of construction: 2017, Condition: ready for operation (used), A conventional double-spindle universal milling machine Optimum is available. Drilling capacity in steel (S235JR): 30mm, continuous drilling capacity in steel (S235JR): 28mm, max. cutter head diameter: 100mm, max. end mill diameter: 20mm. Vertical spindle mount: ISO50, speed: 1750 rpm, spindle table distance: 140mm-540mm, swivel range X-Y/Z-X: 360°/90°. Horizontal spindle holder: ISO50, speed: 1800 rpm, spindle-table distance: 0mm-400mm. Table dimensions X/Y: 1600mm/360mm, max. table load: 450kg, travel X/Y/Z: 1290mm/280mm/400mm, feed X/Y/Z: 420mm/min/393mm/min/168mm/min, rapid traverse X/Y/Z: 1290mm/min/1205mm/min/513mm/min. Machine dimensions X/Y/Z: approx. 3350mm/2200mm/1950mm, weight: approx. 2300kg. Documentation available. On-site inspection is possible. Beb Epzsv Rp Rusufewl

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 460 mm turning diameter over support: 388 mm turning length: 1016 mm centre distance: 1016 mm center height measured in bed: 230 mm turning dia. in gap: 640 mm spindle bore of work spindle: 52 mm range of revolution per miute: 30 - 2000 / 12 step U/min feeds:: längs: 0,032 - 0,898 mm/U feeds:: plan: 0,016 - 0,449 mm/U tailstock quill taper MT: 4 tailstock quill adjustment:: 120 mm total power requirement: 3,75 kW weight of the machine ca.: 1,6 t dimension machine xH: 2,1 x 1,1 x 1,5 m Switchable gearbox Quantum 3-way length measuring system Top slide adjustment +/-90° Multifix quick-change steel holder 3-jaw chuck Ø 200mm rotating center in tailstock Threads: Inch thread; Metric thread; Trapezoidal thread; Module thread Accessories: Change gears, machine feet, 1x fixed quill tip Bwob Epzueu Ixzbefol *

Condition: new, Year of construction: 2025, New machine. Please ask for current price and delivery time. Dimensions and weights: Length (product): approx.2129mm Width/depth (product): approx.1046mm Height (product): approx.1687mm Weight (net): approx.645kg Electrical data: Power drive motor: 3kW Supply voltage: 400V Mains frequency: 50Hz Hydraulic pump motor power: 1.4kW Motor power coolant pump: 100W Total connected load: 3.8kW Machine data: Saw blade speed(s): 20 - 80m/min Saw blade length: 3770mm Saw blade width: 34mm Saw blade thickness: 1.1mm Cutting angle: -45 - 60° Manual operation: hydraulic via push button Semi-automatic operation: automatic Bwob Epzujrah S Hofol Cutting ranges: Cutting range 0° round (solid material): 355mm Cutting range 0° square (solid material): 300mm Cutting range 0° rectangular upright (solid material): 300 x 490mm Cutting range -45° round (solid material): 290mm Cutting range -45° square (solid material): 250mm Cutting range -45° rectangular upright (solid material): 250 x 250mm Cutting range +45° round (solid material): 350mm Cutting range +45° square (solid material): 290mm Cutting range +45° rectangular upright (solid material): 290 x 340mm Cutting range +60° round (solid material): 230mm Cutting range +60° square (solid material): 180mm Cutting range +60° rectangular upright (solid material): 180 x 220mm

Year of construction: 2014, Condition: ready for operation (used), Travel X/Z: 185mm/540mm, feed X/Z: 6m/min/8m/min, repeat accuracy: +/-0.015mm, positioning accuracy: +/-0.03mm, tool positions: 8, spindle bore: 46mm, center distance: 800mm, center height: 170mm, orbital diameter over bed/face slide: 340mm/152mm, bed width: 208mm, speed: 4000rpm, lathe chuck diameter: 160mm. Machine dimensions X/Y/Z: approx. 2000mm/1500mm/2000mm, weight: approx. 1200kg, control: Siemens Sinumerik 808D. Documentation available. On-site inspection is possible. Bsb Epzuov Rfr Uefowl

Condition: new, Year of construction: 2025, New machine. Please ask for current price and delivery time. Dimensions and weights: Length (product): approx.1400mm Width/depth (product): approx.685mm Height (product): approx.1300mm Weight (net): approx.185kg Max. length (product): approx.1700mm Width/depth max. (product): approx.985mm Max. height (product): approx.1700mm Electrical data: Power drive motor: 1.5kW Supply voltage: 400V Mains frequency: 50Hz Motor power coolant pump: 100W Machine data: Saw blade speed(s): 15 - 100m/min Saw blade length: 2480mm Saw blade width: 27mm Saw blade thickness: 0.9mm Cutting angle: 0 - 60° Feed: infinitely adjustable Lifting of the saw bow: manual Standards and approvals: Bob Epjrah Hwezufowl EMC class: C2 Cutting ranges: Cutting range 0° round (solid material): 225mm Cutting range 0° square (solid material): 190mm Cutting range 0° rectangular upright (solid material): 150 x 245mm Cutting range +45° round (solid material): 145mm Cutting range +45° square (solid material): 150mm Cutting range +45° rectangular upright (solid material): 190 x 150mm Cutting range +60° round (solid material): 90mm Cutting range +60° square (solid material): 90mm Cutting range +60° upright rectangular (solid material): 120 x 90mm

Condition: new, Year of construction: 2025, For delivery times and current prices, please contact us directly. Drilling table work surface length: 387 mm Drilling table work surface width: 387 mm Drilling table type of T-slots: diagonal Drilling table T-slot size: 14 mm Drilling table T-slot number: 2 Max. distance spindle - drilling table: 775 mm Speed range: Speed range: 70 - 2800 min ̄1 Number of speed ranges: 9 steps Speed control: infinitely variable Electrical data: Drive motor power: 1.1 kW Supply voltage: 400 V Mains frequency: 50 Hz Machine base: Distance spindle - machine base max.: 1300 mm Bwjb Epzeq T Rx Esufsl Machine foot working surface length: 270 mm Machine foot working surface width: 327 mm Machine foot T-slot size: 16 mm Machine foot T-slots quantity: 2 Machine foot T-slot distance: 150 mm Spindle: Quill stroke: 125 mm Spindle holder: MK 4 Projection: 270 mm Drill head rotation: 360 ° Drill head inclination: 45 °

Condition: new, Year of construction: 2025, For delivery times and current prices, please contact us directly. Dimensions and weights: Column diameter: 150mm Length (product): approx.880mm Width/depth (product): approx.595mm Height (product): approx.2445mm Weight (net): approx.550kg Drilling capacity: Drilling capacity steel (S235JR): 40mm Bwjbjq T Ry Uo Epzufol Continuous drilling capacity steel (S235JR): 35mm Tapping steel (S235JR):M 30 Drilling table: Drilling table work surface length: 530mm Drilling table work surface width: 530mm Drilling table T-slot size:18mm Drilling table T-slot number: 3 Drilling table T-slot spacing: 125mm Drilling table rotation: 360 Drilling table inclination: ± 90 Load capacity drilling table: 250kg Distance spindle - drill table max.:740mm Distance spindle - drill table min: 130mm Speed range: Speed range: 30 - 2430min¯¹ Number of speed ranges: 4 steps Speed control: electronic Electrical data: Drive motor power: 2.2kW Supply voltage: 400V Mains frequency: 50Hz Machine base: Distance spindle - machine base max.: 1210mm Machine base working surface length: 435mm Machine foot working surface width: 445mm Machine foot T-slot size: 18mm Machine foot T-slots quantity: 2 Machine foot T-slot distance: 150mm Spindle: Quill stroke: 170mm Spindle holder: MK 4 throat: 350mm Quill feed: automatic Quill feed speed: 0.1 - 0.2mm/rev Speed levels quill feed: 3 levels Motor(s): Coolant pump Power drive motor: 100W

Condition: new, Year of construction: 2025, For delivery times and current prices, please contact us directly. Dimensions and weights: Length (product): approx.1760mm Width/depth (product): approx.745mm Height (product): approx.1320mm Weight (net): approx.469kg Max. height (product): approx.1590 (DPA)mm Working ranges: Center height: 165mm Center width: 1000mm Rotation diameter over machine bed: 330mm Swing diameter over cross slide: 216mm Bed width: 190mm Speed range: Number of speed ranges: 9 steps Speed range: 65 - 2000min¯¹ Electrical data: Drive motor power: 1.5kW Supply voltage: 400V Mains frequency: 50Hz Spindle: Spindle holder: Camlock DIN ISO 702-2 No. 4 Spindle bore/bar passage: Diameter 38mm Steel holder max. mounting height: 16mm Spindle cone: MK 5 Tailstock: Tailstock holder:MK 3 Tailstock quill stroke: 100mm Tailstock quill diameter: 38mm Pitch: Pitch metric: 0.4 - 10mm/rev Number of leads metric: 29 Pitch inch: 56 - 4Gg/1" Travel distance: Top slide travel: 90mm Travel of face slide: 168mm Bed slide travel: 850mm Bwob Epzueq T R Aajfjl Feed rate: Feed range longitudinal:0.02 - 0.4mm/rev Number of longitudinal feeds: 24 Feed range flat: 0.01 - 0.2mm/rev Number of feeds flat: 32

Condition: new, Year of construction: 2025, For delivery times and current prices, please contact us directly. Condition: New machine Center height: 200 mm Center width: 1,000 mm Spindle speed: 70 - 2,000 rpm (8 steps) Equipped as standard with - 3-axis digital readout DPA 21 - Machine base - 200 mm three-jaw chuck - LED machine light - Reducing sleeve MK 4/MK 6 - Fixed center point MK 4 - Steady rest, fixed - Steady rest, moving - Quick-change steel holder Basic body E - Torsion steel holder ED - Chuck protection cover, electrically fused - Oil filling - Operating tool Beboq Ui Tde Epzufjwl - Operating instructions

Condition: new, Year of construction: 2025, For current prices and delivery times, please contact us. Dimensions and weights: Length (product): approx.3265mm Width/depth (product): approx.1065mm Height (product): approx.1550mm Weight (net): approx.1965kg Working ranges: Center height: 230mm Center width: 2060mm Circumferential diameter over machine bed: 460mm Circumferential diameter in the bed bridge: 690mm Swing diameter over cross slide: 270mm Turning length in the bed bridge: 240mm Bed width: 300mm Speed range: Number of speed ranges: 12 Speed range: 25 - 2000min¯¹ Electrical data: Power drive motor5.5kW Supply voltage400V Mains frequency50Hz Cooling lubricant system Cooling lubricant system Coolant pump output: 125W Spindle: Spindle holder: Camlock DIN ISO 702-2 No. 6 Spindle bore/bar passage diameter: 58mm Steel holder max. mounting height: 25mm Spindle cone: MK 6 Bob Epzusq Ukbpefewl Tailstock: Tailstock holder: MK 4 Tailstock quill stroke: 130mm Tailstock quill diameter: 60mm Pitch: Pitch metric:0.1 - 14mm/rev Number of leads metric: 41 Pitch inch: 112 - 2Gg/1" Number of pitches inch:41 Pitch Diametral Pitch: 4 - 112DPI Number of pitches Diametral Pitch: 50 Module thread pitch: 0.1 - 7mm/rev Number of module thread pitches:34 Travel distance: Top slide travel: 125mm Travel of face slide: 285mm Bed slide travel: 1805mm Feed rate: Feed range longitudinal: 0.031 - 1.7mm/rev Number of longitudinal feeds: 42 Feed range flat: 0.014 - 0.784mm/rev Number of feeds flat: 42 Electrical connection: Total connected load: 5.8kW

Condition: new, Year of construction: 2025, For current prices and delivery times, please contact us. Dimensions and weights: Length (product): approx.4450mm Width/depth (product): approx.1150mm Height (product): approx.1650mm Weight (net): approx.3000kg Working ranges: Center height: 280mm Center width: 2910mm Circumferential diameter over machine bed: 560mm Circumferential diameter in the bed bridge: 790mm Swing diameter over cross slide: 355mm Turning length in the bed bridge: 170mm Bwsb Epzsq Ukc Reufsl Bed width: 350mm Speed range: Number of speed ranges: 12 Speed range: 25 - 1600min¯¹ Electrical data: Drive motor power: 7.5kW Supply voltage: 400V Mains frequency: 50Hz Cooling lubricant system: Cooling lubricant system Coolant pump output: 125W Spindle: Spindle holder: Camlock DIN ISO 702-2 No. 8 Spindle bore/bar passage diameter: 80mm Steel holder mounting height: max.25mm Spindle cone: MK 7 Tailstock: Tailstock holder: MK 5 Tailstock quill stroke: 180mm Tailstock quill diameter: 75mm Pitch: Pitch metric: 0.2 - 14mm/rev Number of leads metric: 47 Pitch inch: 112 - 2Gg/1" Number of pitches inch: 60 Pitch Diametral Pitch: 4 - 112DPI Number of pitches Diametral Pitch: 50 Module thread pitch: 0.1 - 7mm/rev Number of module thread pitches: 34 Travel distance: Top slide travel: 130mm Travel of face slide: 316mm Bed slide travel: 2710mm Feed rate: Feed range longitudinal: 0.059 - 1.646mm/rev Number of longitudinal feeds: 35 Feed range flat: 0.020 - 0.573mm/rev Number of feeds flat: 35 Electrical connection: Total connected load: 8.5kW
