Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, cutting range round steel at 90°: 400 mm, cutting length (max.): 760 mm, working height: 720 mm, saw band length: 5,920 mm, TECHNICAL DETAILS Saw band dimensions: 5,920 x 41 x 1.3 mm Cutting speed: steplessly adjustable (1:7) Working range (round): max. 400 mm Working range (square): 400 x 370 mm Kedpfxoyzn Hbo Ad Esdk Cutting length (single stroke): 10 - 760 mm Cutting length (multiple strokes): max. 9,999.9 mm Working height: 720 mm Clamping force: 3,600 N Minimum finished part length: 10 mm (35 mm vertical) Note: Dismantling and loading can be offered by the seller at an additional cost. Roller conveyor is not included.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2006, operating hours: 24,314 h, machine/vehicle number: A0230A1231, laser power: 6,000 W, sheet thickness (max.): 25 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 100 mm, No reserve price – guaranteed sale to the highest bidder! Bidding obligates the buyer to collect the machine by 30.04.2026! Due to increased selling pressure, the auction period has been shortened and the reserve price reduced! TECHNICAL DETAILS Travel range X-axis: 3,000 mm Travel range Y-axis: 1,500 mm Travel range Z-axis: 100 mm Laser power: 6,000 W Laser unit: CO2 laser TLF 5000, high-frequency excited Max. workpiece weight: 900 kg Positioning speed (X/Y): 200 m/min Positioning speed simultaneous (X+Y): 300 m/min Max. sheet thickness steel: 25 mm Max. sheet thickness stainless steel: 25 mm Sheet thickness aluminum: 15 mm MACHINE DETAILS Power-on hours: 55,176 h Cutting hours: 24,314 h Control model: Siemens Sinumerik 840D Control features: - Open PC-based control system - Online support - Diagnostic functions - Maintenance logbook - Technology data - Remote maintenance Safety equipment: - Multi-beam light barriers and guard enclosure - Fully enclosed beam path with nitrogen ventilation - Monitoring system - Multi-chamber extraction and compact dust collector Paint finish: white RAL 9002 / gentian blue RAL 5010 Drives: Gantry drive combined with linear direct drives ADDITIONAL EQUIPMENT - Cooling unit - Logbook function - Automatic pallet changer - Laser power control - HI-LAS high-pressure cutting - PMS plasma sensing - Programmable power cycles - Programmable cutting gas pressure regulation - Laser cutting head with 5" lens and 7.5" lens - Quick-change system for cutting heads - Automatic sheet edge detection Kjdpfeyynu Nex Ad Ejdk - APC capacitive height control and process monitoring - PCS (Process Control System) - Laser diode positioning - Automatic focus adjustment (AutoLas Plus) - Spraying device for safe thick sheet processing - Automatic shutdown - Work area lighting - Fully enclosed machine frame with integrated laser unit

Year of construction: 2003, operating hours: 10,600 h, condition: repair required (used), functionality: limited functionality, machine/vehicle number: 6094, Equipment: centralized greasing system, Spare parts donor! Kjdpoyzznlefx Ad Ejdk TECHNICAL DETAILS Coarse screen deck: 120/150 Fine screen deck: 10/25 MACHINE DETAILS Generator voltage: 400 V / 50 Hz Weight: 20,000 kg Engine operating hours: approx. 10,600 h EQUIPMENT Trailer Hopper Magnetic drum for mid-size fraction conveyor Magnetic drum for oversize fraction conveyor Clip-on chute Hydraulic rear support Direct connection Central lubrication system Generator 50 mm drawbar eye Note: The engine starts but shuts off again after a while. Presumably there is a fuel issue. The generator produces power. The machine is currently not roadworthy as it has been stationary for a long time. Road registration is currently not possible.

Condition: ready for operation (used), Year of construction: 1987, functionality: fully functional, machine/vehicle number: 08500, turning diameter over cross slide: 225 mm, turning length: 1,000 mm, turning diameter: 400 mm, spindle speed (max.): 4,000 rpm, controller model: EPL 2, TECHNICAL DETAILS Maximum turning diameter: 400 mm Turning length: 1,000 mm Swing diameter over bed: 400 mm Swing diameter over cross slide: 225 mm X-axis travel: 260 mm Z-axis travel: 1,040 mm Kdedoyxm Tnepfx Ad Eok Main spindle Speed range: 20 - 4,000 rpm Drive power: 11 kW Maximum torque: 75 Nm Spindle bore: 72 mm Chuck diameter: 185 mm Spindle nose: 140H5 Spindle diameter at front bearing: 100 mm Tool turret Number of tool stations: 12 positions Tailstock Quill diameter: 80 mm Quill stroke: 100 mm Tailstock taper: MT 4 Maximum quill pressure: 8,000 N Feeds Rapid traverse (X/Z axis): 10 m/min Feed speed (X/Z axis): 5 m/min Feed force (X axis): 5,000 N Feed force (Z axis): 8,000 N MACHINE DETAILS Control model: EPL 2 Operating voltage: 380 V Frequency: 50 Hz Operating current: 76 A Total power requirement: 29 kW Dimensions & Weight Space requirement approx.: 4.6 x 2.1 x 2.0 m Machine weight approx.: 4.0 t EQUIPMENT Chip conveyor Three-jaw chuck Documentation

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, spindle speed (max.): 7,000 rpm, spindle bore: 42 mm, controller model: Siemens 840 D - SL, counter spindle speed (max.): 7,000 rpm, Equipment: chip conveyor, TECHNICAL DETAILS Bar diameter: 42 mm Travel X-axis 1/2/3: 180 mm Travel Y-axis 1/3: ±45 mm Travel Z-axis 1/2/3: 704 / 620 / 704 mm Main spindle Speed: 7,000 rpm Drive power: 22 kW / 16.5 kW Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Counter spindle Speed: 7,000 rpm Drive power: 19 kW / 16.5 kW Kedjyxmnxopfx Ad Ejdk Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Tool turret Number of turrets: 2 + 1 pos Number of tool stations: 3 x 12 pos Number of live tool stations: 3 x 12 pos Rotational speed of driven tools: 8,000 rpm Power: 11.4 kW / 2.3 kW Torque: 26 Nm / 14 Nm Tool holder: VDI 25 Rapid traverse (X / Y / Z): 30 m/min Acceleration: 0.5 g MACHINE DETAILS Control: Siemens 840 D - SL Total power requirement: 60 kW Dimensions & Weight Space requirement: approx. 8.2 x 3.3 x 2.5 m Machine weight: approx. 7.5 t EQUIPMENT Documentation Knoll chip conveyor High-pressure coolant (14 bar) Parts catcher Counter spindle Interface for bar feeder Spinner Barload BL 0146 bar loading magazine C-axis: 2x 0.001° Hydraulic unit Hainbuch collet chuck Y-axis: 2x ±45 mm Various tool holders Various collets Tool measuring arm

Condition: ready for operation (used), Year of construction: 2013, operating hours: 7,546 h, functionality: fully functional, turning length: 284 mm, turning diameter: 300 mm, spindle bore: 62 mm, spindle speed (max.): 4,500 rpm, controller model: Fanuc Oi-TD, TECHNICAL DETAILS Max. turning diameter: 300 mm Max. turning length: 284 mm Swing diameter over bed: 550 mm Chuck diameter: 210 mm Bar capacity: 51 mm Spindle nose: A2-6 Main spindle max. speed: 4,500 rpm Spindle bore: 62 mm Spindle bearing diameter: 100 mm Main spindle drive power: 11 / 7.5 kW Travel - X axis: 170 mm Travel - Z axis: 335 mm Ksdpfx Adjyxmmue Eodk Number of tool stations: 12 positions Tool size: Ø25 x Ø40 mm Rapid traverse (X / Z): 36 / 36 m/min Quill diameter: 60 mm Quill stroke: 80 mm Tailstock taper: MT 4 MACHINE DETAILS Control: Fanuc Oi-TD Total power requirement: 25 kVA Dimensions & weight Installation space approx.: 8.5 x 2.5 x 2.0 m Machine weight approx.: 3.2 t Operating hours Control on-time: approx. 26,932 h Cutting hours: approx. 7,546 h EQUIPMENT Documentation Chip conveyor Coolant unit Tailstock Parts catcher Signal lamp Hydraulic unit Three-jaw chuck SEOAM CAH-08 Collet chuck HAINBUCH nova size 65 Tool setting device Interface for bar feeder Bar loading magazine Breuning SIMAG 70.1-3000 Various tool holders

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning length: 380 mm, turning diameter: 450 mm, spindle bore: 59 mm, rotational speed (max.): 5,000 rpm, controller model: Seicos 40L Multi, TECHNICAL DETAILS Turning diameter: 450 mm Turning length: 380 mm Max. machining diameter: 340 mm Kedpsyxmkaefx Ad Ejdk Travel X-axis: 215 mm Travel Z-axis: 400 mm Bar capacity: 51 mm Speed range: 30 to 5,000 rpm Drive power - spindle motor: 11 / 7.5 kW Spindle nose: A2-6 Spindle bore: 59 mm Bearing diameter: 100 mm Turret: 16 stations Feed rate: 0.001 to 500 mm/min Rapid traverse X/Z: 30 m/min Shank diameter: 25 x 25 mm Drill shank diameter: 40 mm Tailstock taper: MT 5 Tailstock travel: 300 mm MACHINE DETAILS Control: Seicos 40L Multi Total power requirement: 23 kVA Dimensions & Weight Footprint: approx. 5.5 x 2.8 x 2.2 m Machine weight: approx. 4.6 t EQUIPMENT Documentation Chip conveyor Tailstock Signal lamp Parts discharge Tool setting arm Work area illumination Tool holder

Condition: ready for operation (used), Year of construction: 2006, operating hours: 12,500 h, functionality: fully functional, machine/vehicle number: FP3155-406/2006, working width: 1,500 mm, working height: 200 mm, sheet thickness aluminum (max.): 4 mm, working length: 2,850 mm, TECHNICAL DETAILS Maximum sheet length: 2,850 mm Minimum sheet length: 370 mm Maximum bending height: 200 mm Minimum sheet width: 180 mm Maximum sheet width: 1,500 mm Kdjdpfxoyx Tlde Ad Ejk Minimum material thickness: 0.5 mm Maximum material thickness (aluminium): 4 mm Maximum material thickness (steel): 3.2 mm Maximum material thickness (stainless steel): 2.2 mm Minimum distance between bends (length): 350 mm Minimum distance between bends (width): 160 mm Number of bends per side: 20 Maximum plate diagonal: 3,000 mm Angle tolerances: ± 40° C Bending angle: 0.2° C Bending tolerance: ± 0.2 mm Straightness and parallelism: 0.6 mm Minimum external bending radius: 1.5.../2 mm MACHINE DETAILS Compressed air: 6 bar Total connected load: 66 kW Main switch: 160 A Operating hours: approx. 12,500 h The seller can offer transport, on-site installation at the buyer’s location, and machine training for an additional fee.

Condition: ready for operation (used), Year of construction: 2007, operating hours: 19,357 h, functionality: fully functional, spindle speed (max.): 12,000 rpm, travel distance X-axis: 800 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 510 mm, controller model: Fanuc Series 31i-Model A5, TECHNICAL DETAILS X-axis travel: 800 mm Y-axis travel: 520 mm Z-axis travel: 510 mm Kdjdpfx Adoyw I Hts Esk Milling spindle: 12,000 rpm Tool holder: Capto C6 Rapid traverse: 60 m/min MACHINE DETAILS Control: Fanuc Series 31i-Model A5 Chain tool magazine: 48 positions Additional magazine: 90 positions Operating hours Total operating hours: approx. 48,974 h Machining time: 19,357 h EQUIPMENT Coolant system Chip conveyor Note: Clara extraction unit is not included in the scope of delivery.

Condition: not inspected (used), Year of construction: 2000, operating hours: 8,523 h, functionality: unexamined, travel distance X-axis: 1,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 10,000 rpm, number of slots in tool magazine: 22, No reserve price – guaranteed sale to the highest bidder! Bidding obligates the buyer to collect the machine on time, either between 11.05.2026 and 13.05.2026 or between 18.05.2026 and 21.05.2026! TECHNICAL DETAILS Travel distance X: 1,000 mm Travel distance Y: 500 mm Travel distance Z: 500 mm Table dimensions: 1,150 x 490 mm Number of tool positions in the magazine: 22 Spindle taper: SK 40 (DIN 69871-A40) Max. spindle speed: 10,000 rpm MACHINE DETAILS Control: HEIDENHAIN TNC 426 Dimensions & Weight Ksdpfxsyn Nwte Ad Ejdk Dimensions (L x W x H): 4,500 x 3,500 x 2,700 mm Weight: 4,200 kg Operating Hours Automatic operation: 8,523 h Control on-time: 71,860 h EQUIPMENT Technical documentation Spare parts (as shown in the pictures) Note: Only a 7.5t truck can turn around on the company premises. It is recommended to send a smaller truck for collection.
