Filling line for glass bottles

Krones

Condition: used, Year of construction: 2016, Inspection machine for checking empty glass bottles prior to filling. The base, sides and neck of the bottle are inspected. Bottles containing residual detergent from the cleaning process are also detected. An additional inspection unit is positioned upstream of the main inspector, which screens out foreign and defective bottles in advance. The inspection criteria are recorded using cameras as well as RF and IR technology. Additional title: Empty bottle control Capacity filline line: 12000 bo/h Current: 6 A Voltage: 400 / 230 V Frequency: 50 Hz Running direction: left -> right Operation / Control: Simatic S7 Position: in a footed housing Base construction: straight-running Features: Control and display panel, housing with safety doors, bottle discharge Dkodpfx Afsy Nnbbofsl

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, For sale: (For more extensive technical data, see PDF) Dkodewqz Nnopfx Affsl Technical details of the machine: - Long-tube filling system with 40 filling valves and 8 KK plungers. - Pre-evacuation system to reduce oxygen intake. - Hygienic bottle table and stainless steel components for durability. - Mechanical adjustment range: 3,000 to 15,000 bottles/hour. - Performance range: 0.33l LN 3,000–13,500 bottles/hour, 0.5l NRW 3,000–12,000 bottles/hour. - Minimal oxygen intake: maximum 0.02 mg O2/l. - Conversion parts available for different bottle types (0.33l longneck, 0.33l Steini, 0.5l NRW). Advantages of the machine: The machine offers numerous advantages that enhance the quality of the filling process. - Gentle, product-friendly filling under CO2 atmosphere. - 50–60% less CO2 consumption compared to short tube filling systems. - High longevity thanks to reinforced drive components. - Hygienic design for easy cleaning. - Short changeover times. - Convertible to cans according to manufacturer specifications (conversion kit not included). Low operating hours: 3 days per week, 7 hours each; rarely operated for 4 days per week. Annual maintenance by the manufacturer. The machine is immediately available; it was only removed from production about 5 months ago. Original purchase price was approx. €330,000.

Condition: used, Year of construction: 2005, 6-head packer for 0.5 litre and 0.33 litre glass bottles: Krones Linapac II E35 LT1G Bottle holder: 6 x 20 or 6 x 24 bottles Additional title: Packing machine for bottle crates Performance: 50000 bottles/h Air consumption: 0,0002 m³ / bottle Power: 24,5 kW Voltage: 230/400 V Frequency: 50 Hz Length: 6160 mm Width: 4120 mm Height: 5033 mm Formats: 0.5 l glass bottle (D = 68.5 mm, H = 270 mm; Ale / Longneck), 0.33 l glass bottle (D = 61 mm, H = 238 mm; Ale / Longneck) Dksdpfxsxbqldo Affjl Running direction: right -> left Operation / Control: PLC, control cabinet with touch panel Position: free standing Base construction: Square tube frame on dome feet Features: 1 basic machine (lifting mechanism, horizontal linear unit, gripper head carrier, movement axes), 2 gripper head sets (frame with 6 ring gripper heads, 20 (24) ring grippers each, pulling device, manual changing device, insertion frame, vibrator set, folding unit for completeness control, terminal strips for guide plate adjustment), shelf magazine (magazine locations with drive for automatic storage), container transport, container transport, safety device, electrical and pneumatic equipment Periphery: Buffer tables for empty and full boxes Layer patterns: 6 x 20 across, 6 x 24 across, 20 plastic crate (400 x 300 x 300 mm), 24 plastic boxes (400 x 300 x 270 mm),

Condition: used, Year of construction: 2000, Conveyor belts for glass bottles, with 2 unpressurised converging conveyors Transport with 1, 3 or 4 conveyor belts Capacity: 30,000 bottles/h Manufacturer: Krones Year of construction: 2000 Additional title: free container conveyors Dsdpfx Asw Ta Hceffekl Capacity approx.: 33000 Bottles/h Free bottle transport approx.: 115 m 90° Bottle transport curves: 10 pc. Conveyor belt widths: 4 conveyor belts Formats: 0,33 l Vichy, 0,33 l Euro, 0,35 l Lemonade, and 0,5 l NRW Operation / Control: Simatic S7-400 / S7-300 Material: Mainly stainless steel Position: free standing Features: Conveyor frames, deflection stations, drives, frequency controls, electrical switching devices, 2 pressureless bottle mergers (17/9/7/5/3/1 and 12/7/3/1 conveyor belts), automatic belt lubrication

Condition: used, Year of construction: 2020, Monoblock for rinsing, filling and capping glass bottles. 1. Rinser: Rinsing tower with 6 grippers for single-stage rinsing of empty bottles. 2. Filler: Filling tower with 6 electro-pneumatic backpressure valves. 3. Capping machine: Stainless steel cap container with cap conveyor and capping head 4. Bottle exterior washer Additional title: Counterpressure filler with 6 filling valves, sealer with one sealing head Capacity: 1100 bo/h referring to 0,33 l bottles Filling temperature: 2 °C Length: 2,20 m Dodpfjw Tbgdjx Affjkl Width: 1,90 m Height: 2,10 m Formats: Euro 0.5 l and 0.33 l; 26 mm crown caps Running direction: clockwise Operation / Control: Schneider Electric Base construction: Monobloc; Stainless steel housing on feet with plexiglass doors Features: Rinser with 6 grippers, filler with 6 filling valves, capper with one capping head, bottle exterior washer, beer pump, free bottle transport

Condition: used, Year of construction: 1991, Additional title: cold glue labeling Nominal capacity of filler: 50000 b/h Formats: Neck-/ breast-/ body-/ back-labels Running direction: left -> right Operation / Control: Siemens S5 Dodpjvcqwtefx Affjkl Features: 2 cold glue stations

Condition: used, Glass bottle filling line for beer and non-alcoholic beverages for filling 9000 bph. Includes: - Empty bottle inspector: Inex type Optiscan 4s - Bottle filler and capper: Krones type 28/7, built in 1975, with 28 filling valves and 7 capping stations - Capper: Adelski, with 4 capping stations - Labeling machine: Pirzer, built in 1979, for belly and neck labels, with 8 labeling stations - bottle transport Additional title: years of manufacture: 1975 - 1979 Dkodpfx Ajw Tmt Aeffol Capacity: 9000 bo/h Formats: 0,5 l Euro bottle; crown cap; screw cap; 20x0,5 l beverage crate Features: empty bottle inspector; bottle filler and capper (28 filling valves and 7 capping heads); screw-capper; labelling machine; bottle transport

Condition: reconditioned (used), Year of construction: 2018, STORK VS 24/8 Monobloc Bottling Line, fully refurbished by the professional company Z.M. ROBAK. The machine is virtually unused, with the protective film still on the housing. Currently, it is set up for filling glass containers – it has been test run for bottling alcohol. Filling valves: 24 pcs (with light vacuum for still beverages) Capping heads: 8 pcs (configured for aluminum screw caps) Output: approx. 7,000 bph (700 ml) Dsdpfx Afou Nhiqjfekl Capable of operating with bottles of the following dimensions (after format adjustment): - Diameter: 45 mm to 110 mm - Height: 105 mm to 400 mm - Standard neck diameter: 28 mm - Optional neck diameter (after format change): 18 mm to 43 mm Machine dimensions: - Width: 2,900 mm - Height: 2,200 mm - Depth: 2,200 mm Weight: 3,200 kg Installed power: 5.5 kW Required air pressure: 0.6 MPa Year of manufacture/modernization: 2018 – has not been used in production since refurbishment Condition: The machine is practically as new, with negligible signs of use. The machine comes with original electrical documentation.

Condition: used, Year of construction: 2000, Empty bottle inspector Manufacturer: Krones Model: Linatronic 712-M1; Year of manufacture: 2000 Additional title: Empty bottle inspection machine Capacity: 32000 Bottles/h Length: 4200 mm Width: 1100 mm Height: 2900 mm Formats: 0,5L NRW, 0,33L Vichy, 0,33L Euro, 0,35L Lemonade Dksdsw Taypspfx Affol Running direction: right -> left Operation / Control: Simatic S7-300 Position: free standing Base construction: Square tube frame on dome feet Features: Basic machine, detection and inspection systems, rejection systems, supply/machine protection, drives, conveyor belt

Year of construction: 2000, condition: used, Bottle washing machine (with chemical dosing) Manufacturer: Krones Model: Lavatec Kes Year of manufacture: 2000 Performance: 39,000 bottles/h Additional title: Bottle washing machine Capacity: 39000 Bottles/h Length: 12700 mm Width: 4700 mm Height: 3500 mm Formats: 0,33 l Vichy, 0,33 l Euro, 0,35 l Lemonade, and 0,5 l NRW Operation / Control: Simatic S7-300 Position: free standing Base construction: Single-end machine, self-supporting housing on dome feet Features: H2 extraction, label press, bottle tables, ladders, walk-on platforms, various spare parts, another 400 baskets of 22 bottles each Concentrate dosing station Layer patterns: 22 bottles per basket row Dedpfjw Taxfox Affekl

Condition: used, Year of construction: 2000, machine/vehicle number: LC574, Technical Specifications & Performance Data This used bottling line is a complete isobaric PET solution engineered for high-volume beverage production of still water, sparkling water, and carbonated soft drinks. Built around robust Krones and Simonazzi process equipment with a Sidel SBO14 S2 blow molder, it offers dependable industrial packaging performance with consistent product quality. Line type: Used isobaric PET complete bottling line (second hand) Nominal speed: up to 18,000 bottles/hour (configured for 2.0 L PET; format-dependent) Bottle formats: 0.10 L and 2.0 L; additional formats possible with change parts Container type: PET (air-conveyed handling) Product range: Water (still and sparkling), CSD Core technology: Isobaric rinsing/filling/capping monoblock with downstream labeling and end-of-line packaging Line composition: Approx. 14 integrated machines including blow molder, air conveyors, rinser, isobaric filler, capper, labeler, packer/shrink wrapper, palletizer, stretch wrapper, inspection and coding modules Main manufacturers: Krones, Simonazzi; blow molder: Sidel SBO14 S2 Years: Main line 2000; blow molder 1999 Condition: Ready for operation; safety features included Advanced Automation & Control Systems Centralized PLC/HMI control coordinates blow molding, rinsing, isobaric filling, capping, labeling, and end-of-line functions. Recipe management supports format and product changeovers, with synchronized conveyors and VFD-driven motors to maintain constant flow at high speed. Line accumulation and defective-bottle rejection are integrated to minimize downtime and scrap. Automation level: Fully integrated, recipe-based operation Operator interface: Intuitive HMI with alarm diagnostics and production reporting Electrical: Industrial 3-phase supply (typical 400–460 V, 50/60 Hz; to be confirmed on inspection) Safety: Interlocked guards, emergency stop network, and category-rated safety circuits Production Line Integration Capabilities Designed for seamless integration across the packaging hall, the line interfaces upstream with preform handling and syrup room/premix systems and downstream with packers, palletizers, and warehouse logistics. Fast format change procedures and clearly defined change parts enable efficient switching between bottle sizes and product SKUs. Dsdpfow D E Ubox Affjkl Compatible with standard beverage production utilities (CIP, CO₂, chilled water) Interfaces available for inspection systems, laser/inkjet coding, and vision verification Modular conveyors allow adaptation to plant layouts and future upgrades Machine Condition & Maintenance History This second hand complete bottling line is in ready-for-operation condition with safety protections installed. The equipment has been maintained in a production environment and inspected for functional performance. Maintenance records, documentation, and layout drawings can be made available for review during a technical visit. Operational Performance & Versatil...

Condition: used, Year of construction: 1994, Combined bottle filler with labeller ‘Krones Bloc’ Additional title: Monobloc arrangement Capacity: 7000 bo/h Power: 38,1 KVA Current: 55 A Voltage: 230/400 V Frequency: 50 Hz Formats: 0.5 litre NRW (belly/neck/back), 0.33 litre Steinie (belly/back), 0.33 litre Longneck (belly/neck/back) Dkjdpfx Afexb Ahwsfsl Running direction: left -> right Operation / Control: Siemens S 5 Position: free standing Features: Labeller Universella Periphery: miho inspection device

Condition: used, Year of construction: 2000, Bottle filler Manufacturer: Krones Short tube filler with double pre-evacuation Model: Mecafill VKVP 084-094 Year of manufacture: 2000 The capper runs with twist-off and standard crown corks Additional title: Filling and Capping machine Capacity: 30000 Bottles/h Length: 7000 mm Width: 4500 mm Height: 3800 mm Formats: 0.5L NRW, 0.33L Vichy, 0.33L Euro, 0.35L Lemonade Machine partitioning: 84 filling valves, 12 cappers Dsdpew Tay Asfx Affskl Running direction: right -> left Operation / Control: Simatic Material: mostly stainless steel Position: free standing Base construction: Square frame construction on domes Features: 1 capper for standard and twist off crown caps, 84 filling valves, 12 cappers, protective housing with glass doors, vacuum pump Periphery: Crown cap feed, fill level control,

Condition: used, Year of construction: 2018, Used Filling Monoblock for beer 800 bph Monoblock Structure The Used Filling Monoblock for beer 800 bph consists of three separate units: an automatic rinser, an isobaric filler with a double vacuum system, and a crown capper. This configuration optimizes the management of rinsing, filling, and sealing phases. As a result, the system ensures suitability for processing beer in 0.5-liter glass bottles. Moreover, this modular layout facilitates maintenance and replacement, therefore increasing operational reliability. Rotary Rinser ZPC-12 The rinser in the Used Filling Monoblock for beer 800 bph operates with a continuous rotation system and uses 12 gripping clamps. First, the operating cycle handles bottle entry. Then, it performs internal rinsing with treated water, followed by dripping and final exit. The machine handles glass bottles with a height between 150 and 330 mm and a diameter between 50 and 90 mm. It processes 600 to 800 bottles per hour. The installed motor delivers 1.5 kW of power. Additionally, the design allows rapid changeovers between bottle formats, which enhances production flexibility. Isobaric Filling with Double Vacuum The BFP-12 filling unit, at the heart of the Used Filling Monoblock for beer 800 bph, includes 12 filling valves and applies an isobaric process with double vacuum. Specifically, the system performs two evacuation cycles and CO₂ reinjections before the filling stage. Consequently, it significantly reduces residual oxygen and preserves beer quality. It supports bottle volumes from 250 to 1000 ml. Furthermore, the unit integrates key components such as a Southern Pump, a Mitsubishi PLC, a THINEDA touchscreen, Korean-made sensors, and AUTONICS pneumatic systems. This machine also operates with a 1.5 kW motor. In terms of control, the electrical interface provides real-time adjustments, thus improving accuracy during production. Dksdpfx Asw Tlz Esffjl Crown Capping Machine ZDS-3 The crown capper of the Used Filling Monoblock for beer 800 bph applies metal crown caps to glass beer bottles. The machine includes 3 capping heads and operates with a continuous rotary motion. It handles bottles up to 330 mm in height and caps with diameters from 20 to 30 mm (cP size), compatible with the normal European neck type. Notably, the capper reaches up to 1500 bottles per hour, thereby providing an operational buffer that prevents bottlenecks downstream of the filler. In comparison to standard cappers, this model delivers greater precision and cap stability. In addition, its robust frame reduces vibration during high-speed operation. Electrical Characteristics and Compatibility The machines in the Used Filling Monoblock for beer 800 bph use reliable and industry-standard electrical components. The full line features an estimated total power consumption of approximately 4.5 kW. From an integration standpoint, this makes the system suitable for facilities with medium energy capacity. The system exclusively handles 0.5-liter glass beer bottles. During operation, it performs filling under controlled pressure to preserve CO₂ levels and ensure the product’s final stability. Overall, the system delivers consistent performance, reduced oxygen pickup, and excellent packaging quality. Lastly, the compact footprint simplifies installation even in limited space environments.

Condition: used, Year of construction: 1995, Capacity: 20000 l/h Dedpfx Afevcqwgefjkl CO2 connection pressure: 10 bar Current: 69 A Voltage: 230/400 V Frequency: 50 Hz Heating / Cooling: Connection pressure steam: min. 0.5, max. 1 bar Water: Connection pressure: min. 4, max. 5 bar Compressed air: min. 7, max. 10 bar Length: 2 m Width: 2,4 m Height: 2,5 m Weight: 4000 kg Operation / Control: Siemens Simatic S5 Features: Saturation Tank (d = 750 mm) with fill level detectors as a carbonisation tank, measuring writer (ABB), circulating pump (Hilge), various ventils
