DIVERSE ROBOTER DREHTISCH EXPERT

EXPERT

Year of construction: 2024, condition: ready for operation (used), This EXPERT cut Expert ecocam 2 was manufactured in 2024. It features a high positioning speed of 90 m/min and can handle cutting heights up to 100 mm. The machine operates on a PC-based NC software and supports various tool options including electric oscillating knives and driven circular knives. Ideal for cutting leather, textiles, and foams. For more information about this machine, please reach out to us. Machine Benefits Technical Machine Benefits • Positioning speed: 90 m/min / cutting height: standard: up to 50 mm / special version: up to 100 mm / repeat accuracy: ±0. 25 mm / precision: 0. 1 mm • Material layers: single layers or low layers • Electrical requirements: operating voltage: 400 vac, 50/60 hz / current: 63-125 a / control: pc-based nc software / compressed air: standard: 6. 0 bar / 200 l/min / for pneumatic knives: 8. 5 bar / 600 l/min • Working area (standard sizes): maximum size: 7500 x 3200 mm / further options: 3500 x 2100 mm, 5500 x 3200 mm, etc. / customization: customer-specific sizes possible Bledpfx Ajx D Nnpjc Noc • Tool options: fot: electric oscillating knife (up to 15000 oscillations/min) / prt: driven circular knife (up to 11000 rpm) / kct: kiss-cut tool (gentle on the surface) uct: universal cutter (tangentially controlled) / v-cut: angle-cut knife / milling head: with suction device • Nest expert: optimum material utilization / pattern expert: cad template management / order expert: erp connection (e. G. , sap) / pick-up expert: visual sorting aid • Areas of application: cutting of leather, technical textiles, foams, plastics, rubber, composite materials, prepregs, sealing materials, foils, cardboard

Condition: new, Year of construction: 2021, Expert EL390/1301 linear positioner - 8 pcs. Travel distance 8000 mm. Bsdpfx Acetuv Ike Nslc Length 9000 mm. never used

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 45 h, machine/vehicle number: 202023-078, Multifunctional CAM cutting system in pure waterjet technology - without abrasives (waterjet cutting system / water cutting system) 2 cutting bridge with 2 cutting heads including Z-axis 1 head 2D cut 1 head 2D cut For cutting foam, plastic, technical textiles and other flat, flexible, non-metallic materials Maximum feed-through height: 140 mm Cutting area in X and Y: 28500 mm * 2750 mm Protection class: IP54 incl. high-pressure pump BFT Ecotron 40.22 Bedpfx Acswrn Iye Nslc (Product photo as an example) The machine is CE-certified.

Condition: used, Year of construction: 1990, Expert Eda450 Size of table plate 450 mm Bledpfx Acjf Nlrqo Njc weight of the machine ca. 380 kg +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: used, Year of construction: 2025, operating hours: 15 h, functionality: fully functional, machine/vehicle number: 204065, Used machine CNC cutter/plotter Cutting area in X and Y: 3,500 x 2,100 mm. Multifunctional CAM cutting system in CNC knife technology for 2D cutting of leather, fabric, technical textiles, foam and other flat, semi-flexible or rigid, non-metallic materials Equipment of the used machine • 1 cutting bridge and 1 multifunctional tool head The machine is sold with one driven circular knife, electric oscillating knife and one Milling Head + exhaust • Multifunctional tool head to hold max. 2 interchangeable tools • powerful vacuum blower for fixing the material • Standard equipped with gray conveyor table (Conveyor). Green-blue exchange conveyor possible (offers high contrast for dark materials) Can be extended with other tools (on request): • EOT electric oscillating blade • POT pneumatic oscillating knife • PRT rotating blade • UCT universal blade • KCT Kiss-Cut tool • CTT creasing tool • V-Cut angle-cut cutting blade • Punching tool for pinches or holes • Printer mark detection • Camera registration Easy-to-use function • Easy interchangeable cutting tools, "PLUG & CUT • Intuitive user interface • Easy blade change • Vacuum zones can be activated with a click Fast amortization • Low cost with high added value • Best material utilization through nest expert software modules (not included in equipment) • High velocity • Constant precision Data: • Short cutting times due to high positioning speed up to 90 m/min. • Repeatabiliy +/- 0.25 mm • Cuts single or multiple layers • Suitable for both single ply and multi ply or sheet goods and roll goods (can be extended with suitable unwinder) Bodpfxoif Ek Ro Ac Njlc (Product photo as example) The machine is CE certified.

Condition: as good as new (ex-display), Year of construction: 2025, operating hours: 35 h, functionality: fully functional, machine/vehicle number: 2002-045, Used machine CNC cutter/plotter Cutting area in X and Y: 3,500 x 2,100 mm. Multifunctional CAM cutting system in CNC knife technology for 2D cutting of leather, fabric, technical textiles, foam and other flat, semi-flexible or rigid, non-metallic materials. Equipment of the used machine. • 1 cutting bridge and 1 Multifunctional tool head The machine is sold with one driven circular knife and one punching tool. • Multifunctional tool head to hold 2 interchangeable tools • powerful vacuum blower for fixing the material • Standard equipped with gray conveyor table (Conveyor). Green-blue exchange conveyor possible (offers high contrast for dark materials) Can be extended with other tools (on request): • EOT electric oscillating blade • POT pneumatic oscillating knife • PRT rotating blade • UCT universal blade • KCT Kiss-Cut tool • CTT creasing tool • V-Cut angle-cut cutting blade • Punching tool for pinches or holes • Printer mark detection • Camera registration • Milling Head + exhaust Easy-to-use function • Easy interchangeable cutting tools, "PLUG & CUT • Intuitive user interface • Easy blade change Bledpfx Acsfnlkws Nsc • Vacuum zones can be activated with a click Fast amortization • Low cost with high added value • Best material utilization through nest expert software modules (not included in equipment) • High velocity • Constant precision Data: • Short cutting times due to high positioning speed up to 90 m/min. • Repeatabiliy +/- 0.25 mm • Cuts single or multiple layers • Suitable for both single ply and multi ply or sheet goods and roll goods (can be extended with suitable unwinder) (Product photo as example) The machine is CE certified.

Condition: used, Year of construction: 2023, operating hours: 45 h, machine/vehicle number: 202023-078, Multifunctional CAM cutting system in pure waterjet technology - without abrasives (waterjet cutting system / water cutting system) 2 cutting bridge with 2 cutting heads including Z-axis 1 head with angle cutting function 1 head 2D cut For cutting foam, plastic, technical textiles and other flat, flexible, non-metallic materials Blsdpsfhgvwefx Ac Njc Maximum feed-through height: 140 mm Cutting area in X and Y: 28500 mm * 2750 mm Protection class: IP54 incl. high-pressure pump BFT Ecotron 40.22 (Product photo as an example) The machine is CE-certified.

Condition: used, Year of construction: 2025, operating hours: 10 h, functionality: fully functional, machine/vehicle number: 2025-078, working width: 1,600 mm, working height: 100 mm, cutting width (max.): 1,600 mm, number of slots in tool magazine: 2, Used machine CNC cutter/plotter Cutting area in X and Y: 1,500 x 1,600 mm. Multifunctional CAM cutting system in CNC knife technology for 2D cutting of leather, fabric, technical textiles, foam and other flat, semi-flexible or rigid, non-metallic materials. Equipment of the used machine. • 1 cutting bridge and 1 Multifunctional tool head • max. material height 100 mm • Multifunctional tool head to hold 2 interchangeable tools • powerful vacuum blower for fixing the material • Standard equipped with gray conveyor table (Conveyor). Can be extended with other tools (on request): • EOT electric oscillating blade Bljdpfxowgc I Rj Ac Noc • POT pneumatic oscillating knife • PRT rotating blade • UCT universal blade • KCT Kiss-Cut tool • CTT creasing tool • V-Cut angle-cut cutting blade • Punching tool for pinches or holes • Printer mark detection • Camera registration • Milling Head + exhaust Easy-to-use function • Easy interchangeable cutting tools, "PLUG & CUT • Intuitive user interface • Easy blade change • Vacuum zones can be activated with a click Fast amortization • Low cost with high added value • Best material utilization through nest expert software modules (not included in equipment) • High velocity • Constant precision Data: • Short cutting times due to high positioning speed up to 90 m/min. • Repeatabiliy +/- 0.25 mm • Cuts single or multiple layers • Suitable for both single ply and multi ply or sheet goods and roll goods (can be extended with suitable unwinder) (Product photo as example) The machine is CE certified.

Condition: good (used), functionality: fully functional, Technical details: SEW motor Type: DV132H8/4BH/HF/TH rpm: 700/1450 IP:54 Bsdpfx Aswu Dbbjc Nelc Hz: 50 400V AC Brake: 400V kg: 83.94 The SEW motor with rotary table is a powerful and versatile drive solution, ideally suited for precise positioning and automation tasks. The motor stands out due to its robust construction and reliable operation, ensuring stable and efficient performance. The integrated rotary table allows flexible and accurate control of movement sequences, making it particularly suitable for use in manufacturing and assembly applications.

Condition: used, functionality: fully functional, machine/vehicle number: I-109052, overall weight: 1,360 kg, The Expert Tünkers rotary table ET920/00067/flex is a versatile and powerful solution for precise positioning and automation in industrial manufacturing processes. Its flexible design enables efficient rotation and alignment of workpieces, optimizing production flows and increasing accuracy. The rotary table is characterized by its robust construction and reliable functionality, ensuring a long service life even under demanding conditions. Blodpswrpt Rofx Ac Njc
