Creep speed Unit FG20 13/3P4

Demag

Condition: good (used), Year of construction: 1970, Column jib crane, overhead crane, workstation crane -Manufacturer: Demag, wall-mounted jib crane, lifting capacity 1000 kg -Projection: 5070 mm -Swivel range: 270° -Chain hoist: DEMAG type PK5NF -Main stroke: 5.0 m/min -Fine stroke: 1.25 m/min -Hook travel: 4300 mm -Transport dimensions: 5300/1310/H400 mm Lhedpfx As Adzazodcen -Weight: 316 kg

Year of construction: 1992, condition: used, Technical details: lifting capacity: 12,5 t span width: 9000 mm stroke speed: 5 / 0,8 m/min rope diameter: 14 mm lifting height max. hook position: 10.000 m total power requirement: 13,6 kW weight of the machine ca.: 5,2 t dimensions L x W x H: Brücke: ca. 10,3 x 2,2 x 2,3 (3,15to) m dimensions L x W x H: Laufträger Nr.1: ca. 4,38 x 0,8 x 0,7 (1,01to) m dimensions L x W x H: Laufträger Nr.2: ca. 4,38 x 0,8 x 0,7 (0,99to) m dimensions L x W x H: Pal. Zubehör ca. 4,2 x 0,8 x 0,4 (0,16to) m Crane classification according to DIN 15018H2B3 Crane trolley: DEMAG type RF 400; type KBF 100 A8/2, travelling speed 12.5 / 50 m/min., size of travel wheels Ø 200mm (16 pcs.) Main hoist trolley EKDH 532 H20 KV3-4/1 F6; type KBF 90 A8/2, travelling speed 5 / 20 m/min., size of travel wheels Ø 160mm (4 pieces) DEMAG DH5 32 hoist; lifting height 10,000 mm; braked with sliding carriage; main lifting speed 5 / 0.8 m/min. Single hook size 5 with rope safety device Lhedpfsvbh Rhex Adcjn Rope Ø 14mm; rope length 46 metres; drive unit group 1Bm Bridge Hoisting gear Trolley/crab Wireless remote control and conventional control *

Condition: used, Pillar Jib Crane DEMAG Type KBK 2 Year of manufacture: 1979 Load capacity: 500 kg Ljdpfjxtq Amex Adcohn Slewing range: 270° Outreach: 3200 mm Overall height: 3250 mm Jib length: 3100 mm Height to underside of jib: 2730 mm - Jib profile DEMAG C-section rail KBK 2 - Trolley for DEMAG C-section rail KBK 2 - Base plate of crane pillar is no longer original L x W x H = 450 x 450 x 25 mm with cut-out (4 holes Ø approx. 28 mm) Dead weight: 270 kg Good condition

Condition: used, total height: 1,000 mm, total length: 16,400 mm, total width: 3,000 mm, Year of manufacture: 1990 Colour: Yellow Empty weight: 3.500 kg Lhodpjzwxd Hefx Adcsn - Year: 1990 - Lifting capacity [kg]: 6000 - Span [mm]: 16000 - Girder: Single - Crane control: Radio-controlled - Dismantled: Yes - Transport dimensions: 16400mm x 3000mm x 1000mm (l x w x h) - Transport weight [kg]: 3500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, total height: 1,000 mm, total length: 11,500 mm, total width: 2,450 mm, - Documentation available: No - CE certificate present: No - Lifting capacity [kg]: 5000 - Lifting height [mm]: 5500 - Span [mm]: 11300 - Girder: Single - Crane control: Fixed cable - Dismantled: Yes - Transport dimensions: 11500mm x 2450mm x 1000mm (l x w x h) - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lodpfxozmd T Eo Adcjhn Lukas van Rossum

Condition: used, Year of construction: 2000, screw diameter: 95 mm, clearance between the columns: 1,000,900 mm, injection pressure: 1,832 bar, injection weight: 2,550 g, mold height (min.): 450 mm, ejector force: 138,000 N, ejector stroke: 300 mm, plate length: 1,450 mm, plate width: 1,350 mm, total length: 10,100 mm, total width: 2,500 mm, total height: 2,600 mm, overall weight: 33,200 kg, Demag Ergotech 650/1000-5200 system Year of manufacture: 2000 Control system: NC4 Injection unit 5200 - Screw diameter: 95 mm - Specific injection pressure: 1832 bar - Injection volume: 2835 ccm - Injection shot weight: 2550 g - Pump motor power: 74 kW - Cylinder heater power: 43 kW - Screw L/D ratio: 20 Mold closing unit 6500 - Clamping force: 650 t - Mold plate dimensions: 1450 x 1350 mm - Distance between tie bars: 1000 x 900 mm - Ejector force: 138 kN - Mold height: 450 mm - Opening stroke: 930 mm - Maximum mold plate distance: 1880 mm - Ejector stroke: 300 mm Electrical connection (fuse): 1300 A Weight: 33200 kg Dimensions (m) length x width x height: 10.1 x 2.5 x 2.6 m Equipment: - NC4 control system with color screen - Screw Ø 95 mm, L/D 20 - Injection, holding, and packing pressure adjustable by servo valve - Core pull system with 4 circuits on proportional valves on the moving platen - Hot runner control with 8 zones - Hydraulic control for hot runner nozzles (1 valve) - 10-circuit water distribution manifold with temperature indication - Pneumatic ejector - Additional fine oil filter in the bypass Lhodpj Adp Elefx Adcon - Interface for a host computer

Condition: used, Year of construction: 2003, screw diameter: 80 mm, clearance between the columns: 800,710 mm, injection pressure: 1,855 bar, injection weight: 1,600 g, mold height (min.): 380 mm, ejector force: 90,000 N, ejector stroke: 230 mm, plate length: 1,200 mm, plate width: 1,100 mm, total length: 8,400 mm, total width: 2,200 mm, total height: 2,500 mm, overall weight: 21,000 kg, Demag Ergotech 420/800-3300 system Year of manufacture: 2003 Control system: NC4 Injection unit 3300 - Screw diameter: 80 mm - Specific injection pressure: 1855 bar - Injection volume: 1779 cc - Injection shot weight: 1600 g - Cylinder heating band power: 31 kW - Screw L/D ratio: 20 Tool clamping unit 4200 - Clamping force: 420 t - Tool plate dimensions: 1200 x 1100 mm - Daylight between columns: 800 x 710 mm - Ejector force: 90 kN - Tool height: 380 mm Lhodpfx Ads Adpt Ajcsn - Opening stroke: 710 mm - Maximum distance between platens: 1530 mm - Ejector stroke: 230 mm Electrical connection (fuse rating): 760 A Weight: 21000 kg Dimensions (m) length x width x height: 8.4 x 2.2 x 2.5 m

Condition: excellent (used), The item for sale is a used Mannesmann Demag geared motor, consisting of a three-phase electric motor and an angular gearbox. Gearbox data: Manufacturer: Mannesmann Demag Type: S050 H-53-3 Number: 21300262 Gear ratio: i = 20.0 Oil capacity: 0.200 l Lubrication: oil Made in Germany Motor data: Manufacturer: Mannesmann Demag Motor number: 394356 Power: 0.37 kW Voltage: 220/380 V Current: 1.91/1.1 A Motor speed: 1370 rpm Frequency: 50 Hz Power factor: cos φ 0.78 Ledpfx Asz Spbtodcohn Protection class: IP54 Insulation class: B Three-phase power supply With a gear ratio of i = 20, the approximate output speed of the gearbox is about 68.5 rpm.

Condition: excellent (used), For sale: Mannesmann Demag AF06-L-M-0-145-1 geared motor with a three-phase Demag ZBA90 A4 B020 motor. The unit is fully functional, tested, and ready for operation. The visual condition is good, with normal signs of use. Notes: * One mounting lug has been cut – this does not affect the operation or correct mounting of the geared motor. * There is a small crack on the plastic motor cover, which does not affect the operation of the unit. Technical data: Manufacturer: Mannesmann Demag AG Gearbox model: AF06-L-M-0-145-1 Motor model: Demag ZBA90 A4 B020 Power: 1.1 kW Supply: 3×400 V AC, 50 Hz Brake voltage: 180 V DC Rated current: 2.80 A Lhedpoz Snpzofx Adcen Motor speed: 1400 rpm Output speed: approx. 23 rpm Gear ratio: i = 60.1 Brake torque: 20 Nm Cos φ: 0.75 Ingress protection: IP54 Insulation class: F Weight: 21.2 kg

Condition: excellent (used), For sale: a Mannesmann Demag geared motor with an angular gearbox, fully functional and ready for operation. The unit has been inspected and is in good technical condition. Normal signs of wear and tear resulting from use are visible. Technical data: Manufacturer: Mannesmann Demag Motor type: UMF71BX-6-7 Gearbox type: S040-B5-21-3 Motor power: 0.25 kW Power supply: 3×220/380 V Frequency: 50 Hz Motor speed: 890 rpm Lhsdpfx Adsz Snn Socen Output speed: 64 rpm Gear ratio: i = 14:1 Protection rating: IP54 Insulation class: B
