Condition: used, Year of construction: 2004, turning diameter max. 560 mm turning length 600 mm control 840D powerline Siemens greates pass round over bed 680 mm Swing dia. over traverse guideway 565 mm centre distance 620 mm turning speed range - main spindle 20 - 5.000 min/-1 power capacity - main spindel 25 / 37 kW max. Torque 390 Nm spindle nose 170H5 spindle bearing diameter 120 mm usable bar diameter 65 mm max. chucking diameter 250 mm C-Axis 0,025° / 360 ° Spindle speed range subspindle 20 - 7.000 min/-1 power capacity - Sub spindle 25 / 33 kW max. Torque 213 Nm spindle bearing diameter 90 mm spindle bore 57 mm spindle nose 140H5 C-Axis 0,025° / 360 ° number of toolpositions 12 pos. Number of driven toolspositions 12 pos. Spindle speed - driven tools max. 4.500 min -1 power capacity - driven tools 12,2 kW tool taper VDI 40 DIN 69880 Tool dimensions with square shank 40 mm Hnodpfxjwmf Tpo Ah Uew x-axis 185 mm y-axis 80 mm z-axis 620 mm rapid traverse X: 60 m/min rapid traverse Y: 15 m/min rapid traverse Z: 45 m/min total power requirement 50 kVA weight of the machine ca. 7 t dimensions of the machine ca. 6,0 x 3,0 x 2,5 m CNC Turning- and MillingCenter GILDEMEISTER - CTX 420 linear V6 - Main and sub spindle - Tool drive - C axis / Y axis - Partial hollow clamping device - ShopTurn - Surface - Package bar processing consisting of: - Hollow clamping device 66mm - Workpiece picking device - Incl. 2x driven tools - Incl. 4x double tool holders - Incl. 4x tool holders - Incl. 83x tools

Condition: excellent (used), Year of construction: 2010, operating hours: 15,600 h, functionality: fully functional, Spindle speed: 50-6000rpm Movement XA-XB: 205mm ZA-ZB: 700mm W: 730mm YA-YB: 95mm Turrets: 2x 16pos Multitasking V16 Spindlespeed live tools: 45-6000rpm Motors live tools: 5.5/3.7kW Spindle motors: 22/15kW Manufacturing year: 2010.12 Length: 3300mm Hsdpfxewfr R Eo Ah Uonw Width: 2500mm Height: 2500mm Weight: 9000kg Robot interface

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 32 [mm] - Max. machining length : 320 [mm] - Spindle speeds : 8.000 [rpm] - Spindle power : 3.7 / 5.5 [kW] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Max. bar diameter : 32 [mm] - Spindle speeds : 8.000 [rpm] Hsdpfx Ahjwdalne Uonw - Spindle power : 2.2 / 3.7 [kW] - C axis indexing precision : 0,001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 9 - Number of motorized positions : 4 - Live tools speed : 6.000 (T01-T02-T03) / 4000 (T04) [rpm] - Live tools power : 1 [kW] - X/Y stroke : 142 / 348 [mm] GUIDE BUSH HOLDER 2 - Number of positions : 3 GUIDE BUSH HOLDER WITH AXIS B - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 5.000 [rpm] - Live tools power : 1 [kW] - Stroke axis B : 0 - 135 [°] SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6.000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 2 - Number of motorized positions : 2 - Live tools speed : 8000 [rpm] - Live tools power : 1 [kW] POWER SUPPLY - Total installed power : 21 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.150 x 1.280 [mm] - Machine height : 2.010 [mm] - Machine weight : 3.600 [kg] MACHINE HOURS - Number of hours under power : 37855 [h] - Number of working hours : 9578 [h] EQUIPMENT - CNC : Fanuc 31i-B5 - Interface : RS232 / PCMCIA / RJ45 / USB - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : MULLER COMBILOOP CL2 * with high-pressure pump : 100 [bars] - Bar loader : IEMCA BOSS 338 HD / 32 LL - Electric transformer

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, turning length: 810 mm, turning diameter over cross slide: 800 mm, turning diameter: 320 mm, spindle motor power: 25,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 810 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 50 m/min, rotational speed (max.): 6,000 rpm, CNC FANUC MSX-701 / MAPPS IV CAPACITY Swing diameter over bed: mm 800 Swing diameter over cross slide: mm 800 Maximum turning diameter: mm 320 Standard turning diameter: mm 200 Maximum distance between the center: mm 1.130 Maximum turning length: mm 810 Maximum workpiece size: mm 300 TRAVELS X axis turret 1 and 2: mm 210 Y axis turret 1 and 2: mm +65 / -45 Z axis turret 1 and 2: mm 810 B axis headstock 2: mm 920 MAIN SPINDLE Maximum speed: rpm 5.000 Drive power (30 min / continuous operation): kW 25/22 Maximum bar diameter: mm 65 Spindle bore: mm 73 Spindle diameter in front bearing: mm 120 Spindle mount: JIS A2-6 C-axis resolution: degrees 0,001 SUB SPINDLE Maximum speed: rpm 5.000 Drive power (30 min / continuous operation): kW 25/22 Maximum bar diameter: mm 65 Spindle bore: mm 73 Spindle diameter in front bearing: mm 120 Spindle mount: JIS A2-6 C-axis resolution: degrees 0,001 FEED DRIVES Hjdpfxswlvlge Ah Uonw Rapid traverse turret 1 X/Y/Z: m/min 30/20/50 Rapid traverse turret 2 X/Y/Z: m/min 30/20/50 TOOL TURRET Number of turrets: 2 Number of tool stations per turret: 16 Shaft cross – section for turning tools: mm 20 x 20 Maximum shaft diameter for boring bars: mm 32 Turret switching time (1 station): s 0,18 Maximum speed of the driven tools: rpm 6.000 Drive power for driven tools (5 min/continuous operation): kW 7,5/5,5 DIMENSIONS Installation area with chip conveyor: mm 5.120 x 2.720 Net weight: kg 8.300 Macchina equipped with: • High pressure cooling system • Bar loader interface • Gantry-type piece unloading arm • Cutting effort management system and load monitor • No. 1 double radial motorized tool holder • No. 3 axial motorized tool holders • No. 2 external tool holders • No. 2 double boring bar holders • No. 2 single radial motorized tool holders • No. 2 internal boring bar holders • No. 2 Kitagawa BD 208 self-centering chucks diam. Mm 210 • No. 1 set of jaws for each self-centering chuck • Instruction manuals and CE declaration Year of manufacturing: 2010

Condition: like new (used), Year of construction: 2011, functionality: fully functional, spindle motor power: 15,000 W, spindle speed (min.): 5,000 rpm, travel distance X-axis: 157 mm, travel distance Y-axis: 35 mm, travel distance Z-axis: 464 mm, rotational speed (max.): 6,000 rpm, total height: 1,885 mm, total length: 3,675 mm, total width: 2,258 mm, overall weight: 9,000 kg, CNC controller: Fanuc 18i-TB Capacity X-axis travel mm: 157,5 Y-axis travel mm: 35 Z-axis travel mm: 464,8 B-axis travel mm: 600 C-axis: 360º (0,001º) Hnedpfsxiwnnjx Ah Uow Turning length mm: 399 Max. turning diameter mm: ø: 190 Distance between spindle centers mm: 750 Bar work capacity mm: 52 Upper turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Number of upper turrets: 1 Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Milling function: Both Turrets Number of lower turrets: 1 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 15 / 11 Counter spindle Speed spindle rpm: 4.500 Drive power spindle kW: 11 / 7.5 Equipment Part catcher Workarea light Bar Loader ILS - RBK Machine running time: Nominal Kva: 67,2 Basic machine dimensions / weight Length mm: 3.675 Width mm: 2.258 Height mm: 1.885 Weight kg: 9.000

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, turning diameter over cross slide: 300 mm, turning length: 450 mm, turning diameter: 300 mm, spindle bore: 51 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 160 mm, travel distance Y-axis: 32 mm, travel distance Z-axis: 450 mm, spindle motor power: 20 W, rapid traverse X-axis: 60 m/min, rapid traverse Z-axis: 45 m/min, bar diameter (max.): 51 mm, CNC Fanuc 16i WORKING AREA: Max rotation diameter: mm 500 Rotation diameter above transverse guide: mm 300 Transverse travel (X): mm 160 Y-axis travel: mm +-32 Longitudinal travel (Z): mm 450 MAIN SPINDLE (integrated electrospindle): Spindle head (flat flange): 140 H5 Bar capacity: mm 51 Front bearing diameter: mm 100 Power (40/100% ED): kW 20/16 Torque (40/100% ED): Nm 200/155 Rotation speed: rpm 20-6,000 COUNTER SPINDLE (integrated electrospindle): Spindle head (flat flange): 140 H5 Spindle bore: mm 37 Front bearing diameter: mm 75 Power (40/100% ED): kW 9/7.5 Torque (40/100% ED): Nm 57/48 Rotation speed: rpm 20-6,000 FEEDS: Z-axis rapid: m/min 45 X-axis rapid: m/min 60 TOOL TURRET: Number of motorized tool stations: 12 Power (40/100% ED): kW 10 Torque (40/100% ED): Nm 20 Rotation speed: rpm 5.000 Machine complete with: • No. 03 radial motorized modules • No. 02 universal motorized modules • No. 3 fixed tool holders • Self-centering main spindle Autoblok diam. mm 210 • Self-centering counter-spindle Autoblok diam. mm 160 • Instruction manuals and CE declaration Year of construction: 2004 Hnsdpfx Ajwhkm Rsh Usw

Condition: used, Year of construction: 2007, functionality: fully functional, turning length: 510 mm, turning diameter: 330 mm, spindle speed (max.): 4,500 rpm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 24 m/min, rapid traverse Z-axis: 20 m/min, CNC Fanuc 18i - TB Max turning diameter x length: mm 330 x 510 Chuck size: mm 210 Hsdpfxjxqgl Ej Ah Usnw Spindle speed: rpm 4.500 Spindle motor power (Cont. / Short term): kW 11/15 Sub spindle motor power (Cont. / Short term): kW 5,5/7,5 Rapid traverse (X/Z/Y/B): m/min 20/24/7,5/20 Tool holder type: BMT 55P No. of tool stations: 12 Machine equipped with: • Nr. 2 self centering chucks • Nr. 1 radial live tool holder • Nr. 1 axial live tool holder • Nr. 2 external fixed tool holders • Nr. 2 boring tool holders • Dichiarazione di conformità CE

Condition: excellent (used), Year of construction: 2015, Data Fanuc 32i B Chuck: 250 mm / 170 mm Bar passage: 65 mm Y-axis: 120 mm Turret: 20 positions Tool measurement Hodpjxmid Nefx Ah Usnw Parts catcher Chip conveyor

Condition: good (used), Extraction, filter system, oil mist separator, oil mist separator, air filter, mist separator, oil and emulsion mist separator -Ventilation grille: louvered grille, Filter for oil mist separator -Material: aluminum -Total dimensions: 440/330/H345 mm -Weight: 13.8kg Hodpfxoi I Hc Hj Ah Uonw
