Condition: excellent (used), Numerical Control Type NC 400 Through-feed motorized conveyoring belts (No.) 2 Horizontal units/supports (No.) 2 Drilling heads for each horizontal unit (No.) 2 Splindles for each horizontal drilling head (No.) 10 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) Bottom vertical units/supports (No.) 4 Drilling heads/blocks for each bottom vertical unit (No.) 2 Vertical top pressure clamps (No.) 2 Digital quota (axes) display Total installed power (Kw) 23.7 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops Gusdezk Eulspfx Achod

Condition: good (used), Year of construction: 2011, functionality: fully functional, feed length X-axis: 2,500 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 60 mm, Technical description of the machine The machine is designed for the precise machining of furniture and carpentry components using multi-spindle drilling technology. Thanks to its large working area and CNC control, it provides high productivity, repeatability, and accuracy in production. Operating parameters Maximum width of the workpiece: 2,500 mm Maximum working depth: 1,000 mm Maximum height of the workpiece: 60 mm Drilling grid: 32 mm Infinitely adjustable feed rate, allowing for optimal parameter adjustment to the type of material. Drilling system The machine is equipped with: 7 vertical drilling heads 7 bottom-mounted drilling heads 2 horizontal drilling heads 2 drilling blocks per head, enabling the simultaneous execution of multiple operations. Gsdpfx Acezi E Ebjhsud The positioning of the blocks and drilling heads is manual, while the drill feed is pneumatic, ensuring a fast and repeatable work cycle. Clamping system 7 clamping bridges guaranteeing stable clamping of the workpieces during the entire machining process. Control The machine operates under the control of: HOMAG POWER CONTROL HOMAG WOODWOP software, which enables intuitive programming of operations and integration with the production process. Electrical data Total connected power: 49 kW Additional information CE marking for conformity. The machine’s design ensures high drilling accuracy and reliability in the serial production of furniture components, fronts, bodies, and other wood and wood-based components. Thanks to its large working area and extensive drilling system, the machine is ideally suited for both single-item and large-scale production.

Condition: excellent (used), Catalogue number 7689 Gusdpfszfppiox Ached TECHNICAL SPECIFICATIONS - Tool diameter: 16mm - Maximum drilling depth: 160mm - Maximum milling length: 160mm - Adjustment of drilling unit: forward/backward, up/down and sideways - Working table dimensions: 600x320mm - Material clamping system - Motor power: 2.2kW - Dimensions (L/W/H): 950x740x1330mm - Weight: 283kg ADVANTAGES – Made in Poland – Very good condition – Used drilling machine Net price: 6300 PLN Net price: 1500 EUR (depending on the exchange rate of 4.2 EUR) (Prices may change with significant exchange rate fluctuations)

Condition: excellent (used), Year of construction: 2021, Used HOMAG Drillteq V-200 - Year of manufacture: 2021 - Immediately available - Excellent condition - Tools can be included for an additional charge. Godpfozdvuvjx Achjud Please feel free to contact us if you have any questions.

Condition: excellent (used), Year of construction: 2022, Specification: Vertical Drill Block with 13 Spindles Horizontal drill block with 4 spindles in the X Horizontal drill block with 2 spindles in the Y Grooving Saw D=100mm Godozdki Uepfx Achoud Plausibility check 10kw tool change spindle 4 position tool changer Workpiece length max 200-3050mm Workpiece width 70-850mm Workpiece thickness 8-56mm Powertouch screen Woodwop for machine Energy Saving Mode

Condition: good (used), Year of construction: 1998, functionality: fully functional, Weeke through-feed drilling machine BST 500, with drilling heads on the right and left sides, 5 units underneath, none above. Gjdezb El Hjpfx Acheud 5 drilling machines in stock, sold individually.

Condition: good (used), Year of construction: 2001, functionality: fully functional, Equipment: CE marking, Through-feed drilling machine, CNC controlled, with drilling heads on the right, left, 4 above, and 7 below. Gusdpfx Acey U H R Eohjd

Condition: new, Year of construction: 2018, I sell the throughfeed CNC drilling machine MAGGI Boring Evolution 1000 Router, Year 2018. New machine from showroom ! Configuration: Milling head motor 3,3kW / 24.000 rpm 11 + 4 + 2 pcs. drilling units Grooving saw 1 pc. Backfeeding system to return the elements to the operator or move forwards as a throughfeed machine. Gjdpey U Er Uefx Achsud Max. Working width 1200mm Max. Element thickness 40mm Total area covered: 2200 x 1400mm / Only 3m2 Total weight: 1350 kg. With full documentation and CE. Tools included and programmed. Very good condition. Available immediately.

Condition: excellent (used), Year of construction: 2018, I sell the throughfeed CNC drilling machine HIRZT Imaco MAGGI Unica F12, Year 2018. New machine from showroom ! Configuration: Milling head motor 2,2kW / 18.000 rpm 14 + 6 + 2 pcs. drilling units Grooving saw 1 pc. Backfeeding system to return the elements to the operator or move forwards as a throughfeed machine. Max. Working width 1200mm Max. Element thickness 40mm Total area covered: 2600 x 1300mm Total weight: 1650 kg. Gujdpfey U Elusx Ached With full documentation and CE. Tools included and programmed. Very good condition. Available immediately.

Condition: good (used), Year of construction: 2002, Station 1: Cutting components to length Station 2: Drilling in the end face at pitch dimensions of 27, 32 or 60 mm, to a depth of 95 mm Station 3: Additional drilling in the end face or blowing out the drill holes from Station 1 Station 4: Deflection testing Processing of strips: possible with lengths between approx. 400/450 mm up to approx. 2500 mm Gusdpfx Acoy Hv Uqshsd

Condition: used, Year of construction: 2021, input frequency: 50 Hz, input current: 21 A, We are offering this used HOMAG DRILLTEQ V-200 through-feed drilling machine, manufactured in 2021. The machine has been regularly serviced by HOMAG. The package includes a KOGI dust extraction unit (2.2 kW / 1,650 Pa), two collection bags, and various tools. Specifications Vertical drilling block with 13 spindles Horizontal drilling block with 4 spindles on the X-axis Horizontal drilling block with 2 spindles on the Y-axis Grooving saw, Ø100 mm Correctness control system 10 kW tool-changing spindle Maximum workpiece length: 200–3,050 mm Workpiece width: 70–850 mm Workpiece thickness: 8–56 mm Guedpfx Acjy Extmohod PowerTouch display WoodWOP software included Machine Data Type: DRILLTEQ V-200 OPTIMAT BHX050 Serial number: 0-250-73-6562 Year of manufacture: 2021 Power supply: 400Y/230 V Number of phases: 3 Frequency: 50 Hz Rated current at full load: 21 A Fuse rating: 25 A Control voltage: 24 V The package also includes a KOGI dust extraction unit with a 2.2 kW motor and 1,650 Pa suction pressure, equipped with two collection bags, as well as various tooling. Should you have any questions or require additional information, please do not hesitate to contact us by email or telephone.

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, feed rate X-axis: 95 m/min, plate height: 60 mm, plate length: 900 mm, plate width: 3,000 mm, production capacity: 1,500 unit/h, TECHNICAL DETAILS Minimum panel width: 250 mm Maximum panel width: 3,000 mm Minimum panel length: 100 mm Maximum panel length: 900 mm Minimum panel thickness: 12 mm Maximum panel thickness: 60 mm Maximum panel weight: 50 kg Working height: 1,060 mm Panel conveyor speed with inverter: 20 - 95 m/min Speed for panels over 50 kg: 50 m/min MACHINE DETAILS Control model: TPA - Albatros - CNC 2000 Gjdpeyzn Sdefx Achoud EQUIPMENT EASYTOOL software 5 split lower vertical drilling heads, automatically adjustable with NC control, each with 26 independent spindles 2 horizontal drilling heads with split heads, 28 + 28 spindles (per side), independently arranged on two levels External reference: MMA004.003

Condition: ready for operation (used), functionality: fully functional, workpiece weight (max.): 50 kg, feed rate X-axis: 95 m/min, plate height: 60 mm, plate length: 900 mm, plate width: 3,000 mm, TECHNICAL DETAILS Panel width min.: 250 mm Panel width max.: 3,000 mm Panel length min.: 100 mm Panel length max.: 900 mm Panel thickness min.: 12 mm Panel thickness max.: 60 mm Maximum panel weight: 50 kg Working height: 1,060 mm Panel conveyor speed with inverter: 20 - 95 m/min Speed for panels over 50 kg: 50 m/min MACHINE DETAILS Control model: TPA - Albatros - CNC 2000 EQUIPMENT EASYTOOL software 5 segmented lower vertical drilling heads, automatically adjustable via NC control, each with 26 independent spindles 3 segmented upper vertical drilling heads, automatically adjustable via NC control, each with 26 independent spindles 2 horizontal drilling heads with split heads, 28 + 28 spindles (each side), independently arranged on two levels Gujdpfx Aceyzn D Tohjd External reference: MMA004

Condition: ready for operation (used), Year of construction: 1981, functionality: fully functional, machine/vehicle number: 8109/30, Drilling and Dowel Inserting Machine with PLC + Part Return | 8 heads For sale: a professional through-feed drilling and dowel inserting machine for the production of furniture components, particularly drawer sides. The machine is equipped with PLC control, automatic part return, and an expanded head arrangement (including rear heads), enabling the complete operation to be performed in a single pass—without re-feeding the workpiece. Technical Specifications: - Number of heads/motors: 8 - Head configuration: front/side/rear (double-sided machining in a single cycle) - Control: PLC - Part return: yes (closed production loop) - Maximum working width: 2000 mm - Power supply: 400 V - Pneumatics: yes - Year of manufacture: 1981 - Manufacturer: Gerhard Koch (Germany) - Condition: operational, in ongoing serial production Performance: Approx. 6,000 drawer sides per 8-hour shift Gjdpfx Acjyzg Udoheud Thanks to the rear heads, components that typically require two passes are processed in one, significantly reducing cycle times and increasing productivity. Applications: - Drawer sides - Cabinet components - Batch and repeat production - Automated production lines Key advantages: - Single pass processing instead of two - High repeatability - Stable, heavy-duty construction - Perfect for mass production - Proven German technology Location: Elbląg Please contact me for further information.

Condition: excellent (used), ELECTRONIC (CNC control) machine, Numerical Control Type NC 500 - Software Tooling System N. 2 Through-feed motorized conveyoring belts - Feeding speed (m/min) 35 - 75 ca. Max. working width (mm) 3200. Min. working width (mm) 215 N. 2 Horizontal units/supports N° 2 Drilling heads for each horizontal unit (11 Spindles for each horizontal drilling head) N. 5 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 x HP 1,8 N. 2 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 x HP 1,8 N. 4 Vertical top pressure clamps - N. 2 Motorized endless screws to evacuate wastes/chips Godsyyw S Rspfx Achoud Quota (axes) digital display. Total installed power (Kw) 62,7 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the vertical movement (Hv) of the 2 horizontal units The CNC controls the movement (X axe) of all the vertical units The CNC controls the movement (Y1 and Y2 axes) of the boring heads The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the pressure clamps The CNC controls the movement (X axe) of the conveyor belts The CNC controls programming of the working cycles

Condition: excellent (used), Numerical Control Type NC 400 Deluxe Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 1 Splindles for each horizontal drilling head (N°) 20 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) No. 5 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 2 Top vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 Vertical top pressure clamps (N°) 4 Gujdeyyw Sdopfx Achod Transport belts to evacute chips (wastes) (N°) 2 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts Total installed power (Kw)

Condition: excellent (used), 6 drilling units with two heads two side heads spindles span 32mm max material length 2250mm magazine feeding Guedeyxcwvepfx Achod manual regulation of units span rotated heads pneumatic top pressure drilling depth regulation

Condition: excellent (used), bottom heads 2x 22 spindles side head 21 spindles spindles span 32mm 3 pneumatic clamps pneumatic setting of heads Godeyxcwcspfx Achjud working dimensions 2400x1200mm

Condition: excellent (used), two bottom heads one side - right head heads with 21 spindles spindles span 32mm motors 3x1,1kW 2 pneumatic pressure Guodpfxoyxcv Se Achjd regulation of span between heads right/left spindles

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, input frequency: 50 Hz, working width: 1,200 mm, For sale: Throughfeed drilling and dowel inserting machine LAZZONI Group – model Next 2+3K, designed for efficient series production of furniture components. The machine is equipped with automatic infeed and outfeed of workpieces, allowing for single-operator use and significantly reducing production costs. Key Information: Manufacturer: Lazzoni Group Model: Next 2+3K Year of manufacture: 2018 Control: PLC + operator panel (HMI) Functions: Drilling + automatic dowel insertion Working width: 230–1200 mm Working height: 10–22 mm Working depth: 40–260 mm Power supply: 400 V / 50 Hz Installed power: 9.1 kW Machine weight: approx. 2900 kg CE certificate Working Configuration: - Number of heads: 5 - 2 side heads Gjdpfx Acoywxy Rjheud - 3 top heads - Total number of spindles: 35 (7 spindles per head) - Spindle pitch: 32 mm - Throughfeed operation – ideal for repeatable parts Automation and Ergonomics: - Infeed magazine - Outfeed magazine (no need for a second operator) - Automatic dowel insertion - Fast retooling/changeover - Stable and repeatable operation for large production runs Applications: - Drawer side production - Furniture carcass components - Fronts, sides, rails - Ideal for both large factories and smaller businesses focusing on automation The machine is in good working condition, has been used in serial production, and is available for inspection onsite. Loading assistance available. Location: Elbląg Net price: 25,000 PLN

Condition: excellent (used), Numerical Control Type Power Control PC85T Software WoodWOP + TOPDRILL No. 2 Through-feed motorized conveyoring belts No. 2 Horizontal units/supports (with Digital quota/axes display) Guodpfoyv Ev Aox Achod No. 1 Drilling head for each horizontal unit (1 x Kw 1,5) No. 21 Splindles for each horizontal drilling head Max. working width (mm) 2500 Min. working width (mm) 250 No. 4 Bottom vertical units/supports (with Digital quota/axes display) No. 2 Drilling heads/blocks for each bottom vertical unit (2 x Kw 1,5) No. 4 Vertical top pressure clamps Motorized carpet to evacuate chips and wastes Total installed power (Kw) 35

Condition: excellent (used), Numerical Control Type NC 500 (Software Tooling System) Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) No. 8 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 4 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 5 Motorized endless screws to evacuate wastes/chips (N°) 2 Digital quota (axes) display Total installed power (Kw) 72,2 The CNC controls the movement (X axe) of the mobile horizontal unit Gsdpeyvrrqefx Achoud The CNC controls the movement (X axe) of the conveyor belts The CNC controls the movement (Y axe) of the stops The CNC controls the movement (Z axe) of all the vertical units

Condition: not inspected (used), Year of construction: 2009, functionality: unexamined, workpiece length (max.): 2,500 mm, workpiece width (max.): 700 mm, number of spindles: 40, TECHNICAL DETAILS Panel length min.: 170 mm Panel length max.: 2,500 mm Gujdpfxsyq Irho Achjd Panel width min.: 50 mm Panel width max.: 700 mm Number of injectors: 2 Number of support units: 2 Vertical spindles Speed: 2,800 rpm Number of spindles: 40 Horizontal spindles Speed: 2,780 rpm Number of spindles for horizontal drilling in Y-axis: 6 Number of spindles for horizontal drilling in X-axis: 8 (4 on each side) MACHINE DETAILS Control system: WINDOWS Motor power (vertical drilling): 3 kW Motor power (horizontal drilling): 2.2 kW Note: Tools not included The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photographic documentation and technical/commercial documents of descriptive character. The buyer has the right to inspect the goods prior to collection and is responsible for the installation, securing, and use of the machine at the destination. External reference: 6106

Condition: new, Year of construction: 2025, functionality: fully functional, feed length X-axis: 2,800 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 50 mm, feed rate X-axis: 140 m/min, feed rate Y-axis: 90 m/min, feed rate Z-axis: 50 m/min, workpiece length (max.): 2,800 mm, workpiece width (max.): 1,000 mm, control type: CNC control, High-performance CNC drilling center KDT KD-610NHZ for six-sided machining of workpieces. Immediately available from stock. Upper and lower drilling units. Precise machining and high speed. Ideal for carcass furniture production. The machine can be inspected by appointment. Guedpfx Aoymz Alsched

Condition: excellent (used), Year of construction: 2021, operating hours: 140 h, functionality: fully functional, feed length X-axis: 3,050 mm, feed length Y-axis: 1,250 mm, feed length Z-axis: 80 mm, input frequency: 50 Hz, input current: 29 A, working width: 3,050 mm, We offer this very good HOMAG DRILLTEQ V-500 throughfeed drilling machine, year of construction 2021. Working dimension X 3.050 mm Working dimension Y 1.250 mm Working dimension Z 80 mm Number of milling spindles 1 Main motor power 10 kW Rotation speed max 24.000 rpm Tool clamping system HSK-F63 Tool changer positions 4 Vertical drilling spindles 15 Horizontal drilling spindles in X 6 Horizontal drilling spindles in Y 4 Groove saw 90° turnable Vertical working surface Machine table Feed-through technology Special workpiece clamping system clamp gripper Barcode reader Safety device enclosed cabin Gjdpfx Asylp Slochsud Control Homag powerTouch, HOMAG POWER CONTROL Software HOMAG WOODWOP 7.2 Conformity marking CE mark Category: Machining centre Type designation: DRILLTEQ V-500 Subtype: OPTIMAT BHX200 Machine number: 0-250-73-7195 Wiring diagram: 0-250-73-7195 Supply voltage: 400Y/230 V Neutral conductor: yes Phases: 3 Frequency: 50 Hz Maximum operating full load current: 29 A Fuse rating: 35 A Control voltage: 24 V If you have any questions or need more information, feel free to send us a message or give us a call.
