Condition: excellent (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 915 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 20 m/min, controller manufacturer: Heidenhain, controller model: iTNC530, workpiece width (max.): 900 mm, workpiece height (max.): 500 mm, workpiece diameter (max.): 500 mm, workpiece weight (max.): 700 kg, total height: 2,519 mm, total length: 3,404 mm, total width: 2,450 mm, table width: 900 mm, table length: 500 mm, table load: 700 kg, overall weight: 7,300 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 8,265 h, spindle nose: SK40, number of slots in tool magazine: 16, Equipment: rotational speed infinitely variable, Additional options & accessories: - Heidenhain electronic handwheel. - Heidenhain TS460 3D probe. - Approximately 30 tool holders. - Original HEMRLE & Heidenhain documentation. - Swivel lever for swiveling the milling head. - No chip conveyor present! Iodpfx Aszdr R Hjdrjau

Condition: used, Year of construction: 2024, operating hours: 60 h, functionality: fully functional, machine/vehicle number: 6LUE00127, travel distance X-axis: 800 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 620 mm, rapid traverse X-axis: 48 m/min, rapid traverse Y-axis: 48 m/min, rapid traverse Z-axis: 48 m/min, torque: 180 Nm, controller manufacturer: Heidenhain, controller model: TNC 640, workpiece weight (max.): 1,000 kg, total height: 3,600 mm, total length: 3,780 mm, total width: 2,420 mm, table load: 1,000 kg, rotary table diameter: 800 mm, overall weight: 21,000 kg, spindle speed (min.): 5 rpm, spindle speed (max.): 15,000 rpm, operating hours of spindle: 30 h, coolant supply: 42 bar, distance table center to spindle nose: 100 mm, spindle motor power: 3,400 W, number of spindles: 1, number of slots in tool magazine: 64, tool length: 300 mm, tool diameter: 127 mm, tool weight: 7,000 g, coolant supply through spindle: 42 bar, swivel angle A-axis (min.): -120 °, swivel angle A-axis (max.): 120 °, swivel angle C-axis (max.): 360 °, number of axes: 5, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Maximum stability with 21,000 kg mass Isdpozddzlofx Adreau High speed thanks to torque drives in the A/C axes 5-axis simultaneous machining Demonstration machine at used machine price Equipment: - Heidenhain TNC 640 - Heidenhain glass scales on all 5 axes - Kinematic Optimizer - 15,000 rpm direct drive spindle with 34 kW and max. 180 Nm (25% duty cycle) - Production package I with 42 bar CTS (coolant through spindle) - Air through spindle - Automatic workpiece measurement Renishaw OMP 40 - Laser tool breakage control Blum - Paper band filter system - Spindle ring flushing system - 64 tool magazine slots - SK40 - Scraper belt chip conveyor with pre-filtration - Chip flushing - Extraction system

Condition: used, Year of construction: 2010, x-travel 800 mm y-travel 1.050 mm z-travel 800 mm control 840D solutionline Siemens Speed Mainspindle max. 10.000 min/-1 power capacity - main spindel 44 kW max. Torque 288 Nm tool taper HSK-A 100 DIN 69893 Swivel range -10° / +180 ° table surface area dia. 900 x 700 mm max. table load 1.500 kg distance spindlenose - table horizontal 50 - 850 mm distance spindlenose - table vertical 150 - 950 mm table speed 35 min/-1 rotatable C: 360 ° number of toolpositions 120 pos. tool taper HSK-A 100 max. tool diameter 110 mm max. tool-dia with free toolbox 230 mm max. tool length 550 mm max. tool weight 30 kg tool changing time 5,4 sec rapid traverse ( X / Y / Z ) 60 m/min Rapid B-Axis 23 min/-1 Accelaration 7 / 6,5 / 6,5 m/s² Feed force ( X / Y / Z ) 13 / 13 / 9 kN Iodpozc Rqwofx Adrjau weight of the machine ca. 13,0 t dimensions of the machine ca. 6,0 x 5,5 x 3,7 m total power requirement 80 kVA 5 Axis Machining Center - Universal DMG DECKEL MAHO - DMU 80 P duoBLOCK - controled Swivel-Milling-Head / Gear-Spindle (B-Axis) - NC-Rotary Table (C-Axis) - Tool identification - 3D machining, 3D tool compensation - TRANSMIT cylindrical surface transformation (milling of cylindrical paths) - CompCad compressor function for high-speed machining - WITHOUT tools

Condition: good (used), Year of construction: 2000, Ref. -No.: 10468 Manufacturer: DECKEL MAHO Type: DMU 80 Year of construction: 2000 Control: Heidenhain Millplus Storage location: Halberstadt Country of origin: Japan Machine-No.: 111xxxxx Iaedezc Dziopfx Adrou X-Travel: 800 mm Y-Travel: 700 mm Z-Travel: 600 mm Number of T-slots: 9 / 14 Clamping Area: Ø 900 x 630 mm T - slot spacing: 63 mm Tool Taper: SK 40 Tool changer: 30 Spindle Speed: 12.000 RPM Max. Torque: 2659 Nm Operating hours: 67.452 H Center hole: Ø 50 mm Holding torque: 4500 Nm Max. rotation of the table top: 10,7 rpm Feed: 3600 °/min. Resolution of the measuring system: 0,001 ° NC rotary table: 800 kg NC swivel rotary table: 600 kg Further information: - Clamping table 900 x 630 mm - Chip conveyor, sheet metal technology - Belt filter system, manufacturer Interlit - Type SK 200-760 - Oil mist separator - Set of tool holders, - Workbenches - 2x 6 drawers - Vise - Jaw width 125 mm - Roller shutter cabinet with 1 door The machine can be viewed under power by arrangement.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Equipment: chip conveyor, For sale is a high-quality, CNC-controlled 5-axis vertical machining center, Hermle B 300 U, manufactured in 2008, with a Heidenhain iTNC 530 control system. The machine is equipped with an NC rotary table with a diameter of 280 mm and is ideally suited for precise 5-axis machining, toolmaking, mold making, single-part production, and complex CNC milling operations. Technical data: Manufacturer: Hermle Type: B 300 U Year of manufacture: 2008 Control system: Heidenhain iTNC 530 Travel distances X/Y/Z: 800 / 600 / 500 mm Spindle speed: 15,000 rpm Tool holder: SK40 Tool changer: 30 positions NC rotary table: Ø 280 mm Machine weight: approx. 8,500 kg Iasdpszcwncjfx Adrju Connection: 400 V / 50 Hz Total power: 41 kVA Equipment: 5-axis configuration NC rotary table Ø 280 mm Heidenhain measuring probe Electric handwheel Chip conveyor Coolant system Enclosed cabin Electric thermal compensation Chip flushing gun

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 850 mm, controller manufacturer: Heidenhain, controller model: TNC640, spindle speed (min.): 20 rpm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 26,500 h, coolant supply: 40 bar, spindle nose: SK40, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, The machine is in good condition and can be inspected while powered on. Ijdpfxozcuwnj Adreau

Condition: good (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 935 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 650 mm, controller manufacturer: Siemens, controller model: 840 D solutionline, spindle speed (max.): 14,000 rpm, coolant supply: 40 bar, Equipment: chip conveyor, rotational speed infinitely variable, Manufacturer: DMG MORI Pfronten Model: DMC 85 monoBLOCK RS3 Year of manufacture: 2014 Control system: Siemens 840D solutionline Shopmill Approx. 22,500 program hours Main spindle Interface: SK40 DIN 69871 Speed: 20-14,000 /min Spindle replaced by DMG MORI approximately one year ago Tool changer Type: Double gripper with three-phase motor Magazine: 60 positions X: 935 mm Y: 850 mm Z: 650 mm A: +/- 120° C: 360,000 * 0.001, continuous 5-axis simultaneous machining: YES Automation: DMG MORI RS3 Number of pallets in the system: 3 Additional pallets: 2 Iodpfx Adszamn Toreau Equipment 3D measuring probe Operating mode 4 Extraction system IKZ 40 bar with belt filter system Chip conveyor Coolant gun Hydraulic clamping system Media feedthrough through the pallet WITHOUT the clamping devices and tool holders shown in the images!

Condition: good (used), Year of construction: 2007, travel distance X-axis: 980 mm, CNC Universal Milling & Drilling Machine DECKEL MAHO DMU 80 monoBlock Equipped with Heidenhain iTNC 530 path control Year of manufacture: 2005 Travel distances: X 980 Y 630 Z 630 Spindle speed range: 0 – 18,000 rpm, continuously variable (HSK 63) With the following accessories: Rigid angle table, 1250 mm x 700 mm clamping surface + rotary table 700 mm 3D measuring probe Heidenhain Tool measurement in the working area via BLUM Laser Vertical tool changer with 32 magazine slots (HSK 63) Full protection enclosure with sliding doors and internal lighting Iasdpfx Aey Udydodrju Electronic handwheel Operating modes 3 + 4 Chip conveyor Coolant system 3 height-adjustable machine supports Spindle oil cooler Control cabinet cooling unit (Rittal) Operating manuals

Condition: used, Year of construction: 2000, x-travel 800 mm y-travel 600 mm Isdpoy T Sckefx Adroau z-travel 500 mm Control Heidenhain spindle tunring speed 15.000 U/min tool taper SK 40 table surface area ø630 mm In our estimation, the machine is in good used condition and can be inspected under power by appointment. Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, torque: 46 Nm, controller manufacturer: HEIDENHAIN, controller model: 530, spindle nose: HSK A 63, number of slots in tool magazine: 170, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, CNC Heidenhain iTNC 530 WORKING AREA Longitudinal travel X: 800 mm Transversal travel Y: 600 mm Vertical travel Z: 500 mm B axis: +30° / -100° C axis: n x 360° WORK TABLE Table dimensions: 320 x 320 mm Maximum workpiece weight: 120 kg SPINDLE Spindle taper: HSK A63 Maximum spindle speed: 24.000 rpm Motor power 40% ED: 22 kW Maximum torque 40% ED: 46 Nm AUTOMATION Tool magazine capacity: 170 tools Erowa pallet changer: 7 positions MACHINE EQUIPPED WITH • High-pressure coolant through spindle Iaedpfx Adsy Tam Roreu • Probe • Laser tool presetting • Chip conveyor • Oil mist cooling system • Rotoclear • ITC Intelligent Thermal Control • ITC-5X 5 Axis Intelligent Thermal Control • APS Advanced Process System • Remote electronic handwheel • Instruction manuals and CE declaration

Condition: used, DMG DMC 75 V linear is a 5-axis machining center engineered for precision, high accuracy and reliable operation. Working capacities: travels X 885 mm, Y 600 mm, Z 600 mm; table load max 600 kg; B axis +10/-110°; C axis 360°; table speed 100 t/min; tool magazine 60 places, tool Ø max 40 mm, length 300 mm; spindle interface HSK-A63. Key specs: spindle 0–28,000 rpm (stepless), spindle power 55/43.5 kW; rapid traverse 90 m/min; air 6 bar; power 3x400 V 50 Hz; machine weight ≈11,000 kg; dims L3255×W2450×H3150 mm. Accessories: high-pressure coolant 60 bar, chip conveyor, electronic handwheel. Achieves tight tolerances; typical in automotive, aerospace, medical, watchmaking and machine tool industries Iodpfey S Dfnsx Adroau

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain 430, workpiece weight (max.): 800 kg, The machine was recently inspected by a technician, and the following minor repairs were carried out: New cable routing, replacement of the display, and replacement of the sensor cable for the tool changer. TECHNICAL DETAILS Iasdpfx Asy Szq Uodreu Travel range X-axis: 800 mm Travel range Y-axis: 700 mm Travel range Z-axis: 600 mm B-axis: Automatic swivel milling head C-axis: NC rotary table (dimensions: 900 x 630 mm) Tool holder: SK40 Number of tool changer positions: 60 Maximum workpiece weight: 800 kg MACHINE DETAILS Control model: Heidenhain 430 EQUIPMENT Chip conveyor Internal cooling system (40 bar operating pressure) Handwheel Heidenhain TS 642 probe

Condition: used, Year of construction: 1997, machine/vehicle number: 11730, CNC control HEIDENHAIN, travel: X-axis 800 mm x Y-axis 600 mm x Z-axis 500 mm, swiveling range A-axis +20/-90 degrees, C-axis 360 degrees, max. spindle speed 18,000 rpm, automatic tool changer with 30 tool positions, rapid traverse 35 m/min, machine weight 7,000 kg, chip conveyor. Iodpsy Sqgljfx Adrsau

Condition: good (used), Year of construction: 2015, operating hours: 26,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 550 mm, controller model: Heidenhain iTNC 530, Equipment: chip conveyor, Posmill C 800 Kompakt Year of manufacture: 2015 Very well maintained condition! The machine was used exclusively for dry machining of plastics! + 4th / 5th axis Lehmann Edition 2 / 500 Kombiflex 4th axis swivels 360° 5th axis tilts 90° + Coolant tank and internal coolant supply (unused) TECHNICAL DETAILS Isdpey Ni U Nsfx Adrjau Travel X-axis: 800 mm Travel Y-axis: 520 mm Travel Z-axis: 550 mm Spindle type: SK40 Spindle speed: 10,000 rpm Tool changer: 24 positions Table size: 950 x 520 mm Control: Heidenhain iTNC 530 Dimensions & Weight Dimensions (LxWxH): approx. 2.60 x 2.60 x 2.70 m Weight: 6,800 kg Operating hours Machine power-on hours: approx. 26,000 hrs Spindle: approx. 16,000 hrs Note: The clamp on the Lehmann rotary table is not included in the offer.

Condition: used, Year of construction: 2002, operating hours: 22,552 h, functionality: fully functional, machine/vehicle number: 11140002063, travel distance X-axis: 1,080 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 710 mm, controller manufacturer: Heidenhain, controller model: TNC 430, table load: 550 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 15,000 W, number of slots in tool magazine: 32, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 5-axis milling machine, SK 40. Drive amplifier and hard disk "new" January 2025, ball screw "new" 2024. Iodpfxsy Ahxts Adreau

Condition: used, Year of construction: 2011, Technical details: x-travel: 800 mm y-travel: 950 mm z-travel: 1020 mm control: Sinumerik 840D sl MDynamics Operate turning speeds: 10.000 1/min Spindle power: 26/20 kW max. torque on the spindle: 340/262 Nm tool taper: HSK-A 100 tool change unit: 120 (2x60) Pos. Pallet changer 2x: 630 x 630 mm table load capacity: 800 kg weight of the machine ca.: 20 t dimensions of the machine ca.: 3,3 x 6,15 x 3,2 m Iaodoyzza Ijpfx Adrju 6-axis simultaneous horizontal machining center with controlled swivel-rotary table (A/B-axis), Swivel table can swing overhead (180°), that means the part is hanging down overhead and chips don’t accumulate on pallet, they can fall free into the chip conveyor CNC controlled U-axis enables radial movement of tool for variable spindling diamenter. twin pallet changer 630 x 630 mm 6 hydraulic couplings for pallet fixture clamping with rotary joint in A and B-axis special hydraulic pump for fixture coolant through spindle (10-80bar), one channel with proportional valve for pressures 10-200 bar, electromech. tool-length measuring device GROB, BLUM laser for tool measuring, tool coding, chip conveyor, 3D touch probe M&H, el. handwheel Siemens HT8 coolant gun, coolant shower, air gun, oilskimmer, automatic door Remote diagnosis A 6th axis MAPAL Tooltronic U-axis system comes with the machine with two heads: 1. LAT125-HSK100 2. LAT160-HSK100 *

Condition: ready for operation (used), Year of construction: 2008, operating hours: 27,167 h, functionality: fully functional, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, controller model: Heidenhain iTNC 530, rotational speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel X-axis: 850 mm Travel Y-axis: 700 mm Travel Z-axis: 500 mm Spindle speed: 18,000 rpm Tool holder: HSK-A63 Table type: NC-SRT 420 mm Table specification: Pallet clamping system Pallet changer: PW160, 400 x 400 mm MACHINE DETAILS Control: Heidenhain iTNC 530 Internal coolant supply: 80 bar Frequency: 50 Hz Operating hours: 27,167 h EQUIPMENT - Heidenhain DNC - DXF import - Kinematic Opt iTNC - Automatic cabin door - Additional magazine: ZM43 - Linear guides: Dynamic version - Rotary table axis: A-axis (not centered) - Manual cabin roof - Laminated safety glass window - Pallet storage - External MQL (minimum quantity lubrication) - Tool breakage monitoring A2 Blum - Heidenhain touch probe - Preparation for additional touch probe - Event Messenger - Tool identification HSK - Machine license TCS-Soflex - Electronic thermal compensation Iajdpoyzyttefx Adreu - Electronic hand control module - Oil mist extraction (prepared & with after-filter) - Flange for oil mist extraction - Sealing air for measuring units - Chip flushing pistol - Machine bed flushing - Internal & external air blast - Signal light - Coolant filter type: Paper band filter for coolant system - Scraper belt conveyor - Test protocol: C 40 iTNC 530 PW160

Condition: used, Year of construction: 2012, x-travel 800 mm y-travel 800 mm z-travel 600 mm Control Heidenhain iTNC 530 spindle tunring speed 30 - 8.000 U/min spindle drive 25 kW torque 244 Nm tool taper SK 40 number of tool places 30+190 Pos. A-axis ° C-Axis 360 ° table surface area 800 x 630 mm table load 600 kg rapid traverse ( x / y / z ) 40 m/min auto power on hours ca. 79.968 h spindle hours ca. 800 h In our assessment, the machine is in good used condition and can be inspected under power by appointment. The spindle has been overhauled. Iajdpfx Aeyzt Dljdrou Technical Features & Accessories: - Additional magazine - Chip conveyor - Infinitely variable speed control - 5-axis simultaneous machining - 70 bar internal coolant supply - Flushing nozzle - Workpiece measuring probe - Blum laser tool control - Heidenhain 410 electronic handwheel Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 2002, travel -x axis 880 mm travel -y axis 630 mm travel -z axis 630 mm control HEIDENHAIN - TNC 426M number of spindle speeds 12.000 U/min numbers of positions in the tool changer (2 x 16) 32 Tool bore SK 40 surface area 1.250 x 700 mm table load 600 kg Milling machining centers - universal | DMG - DMU 80T equipped with B axis Iodpfxoyzt Auj Adrjau The machine is in good condition. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: 80 T | 80-T

Condition: used, Year of construction: 2005, 5-Axis Simultaneous Hermle U740 Travel: X-915 mm, Y-500 mm, Z-500 mm Control: Heidenhain iTNC530 Spindle speed: 18.000 U/min Spindle mount: SK40 tool magazine: 16 seats B-axis: hydraulic clamping –5°/+95° NC rotary table: 630 mm max. table load: 500 kg probe: Heidenhain electric handwheel: Heidenhain table size: 1000 mm x 560 mm Spänewanne: . Iedjyxh Sfopfx Adrsau

Condition: used, Year of construction: 2001, x-travel 800 mm y-travel 400 mm z-travel 350 mm Control SIN840D A - axis 360 x 0,001 ° B - axis -30 - +90 x 0,001 ° workpiece diameter 15 - 80 mm workpiece length - max. 800 mm tool taper SK40 Iedpeyu U Ahofx Adroau spindle turning speed - stepless 36 - 12.000 U/min power capacity - milling spindle 14 / 21 kW feed X/Y/Z/-axis 1 - 10.000 mm/min rapid traverse X/Y/Z 45,00 m/min toolpiece magazine: chain magazine 60 Stück tool length - max. 250 mm tool diameter 88 mm wotkpiece diameter with 2 vacant positions 125 mm weight of tools max. 12,00 kg total power requirement 37,00 kW weight of the machine ca. 11,00 t dimensions of the machine ca. 6,00 x 5,00 x H3,50 m 5-axis machining center with Siemens SINUMERIK 840D control, IRCO RBK7212 bar feeder, chip conveyor, coolant system, coolant through the spindle (70bar).

Condition: used, Year of construction: 2001, x-travel 880 mm y-travel 630 mm z-travel 630 mm Control Heidemhain type 426/430 spindle speed: 18000 spindle taper HSK 63 surface area 1250x700 mm Rotary table 700 mm Table load 1000 kg b-axis Schwenkopf 0,001 ° Ijdpoyqukdofx Adreau c-axis 0-360° Rundtisch 0 B-axis C-axis Air blow through the spindle HSK 63 Electronic handwheel The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, x-travel . mm y-travel . mm z-travel . mm Control . type . spindle speed: . spindle taper . surface area . mm Rotary table . mm Table load . kg b-axis . ° Iajdpoyqtdcofx Adrsu c-axis . 0 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 2002, CNC Machining Center DECKEL MAHO DMU 80 T Year of manufacture: 2002 Control: Heidenhain iTNC 530 Iaedpfxeylk Syo Adrju Spindle: replaced on 14.11.2018, approx. 17,000 hours Technical data: Travel paths: X: 880 mm Y: 630 mm Z: 630 mm Controlled B-axis in milling head: -15° to 90° Spindle speed: 12,000 rpm Tool changer capacity: 32 positions Tool holder: SK 40 Coolant system: available

Condition: ready for operation (used), Year of construction: 2003, operating hours: 27,804 h, functionality: fully functional, machine/vehicle number: 16165, travel distance X-axis: 915 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller model: HEIDENHAIN iTNC 530, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS X-axis travel: 915 mm Y-axis travel: 500 mm Iodpfx Adsyhnudjreau Z-axis travel: 500 mm Number of axes: 5 Maximum spindle speed: 12,000 rpm Table length: 900 mm Table width: 500 mm Number of T-slots: 8 T-slot spacing: 65 mm T-slot width: 14 mm Maximum workpiece weight on table: 700 kg Maximum workpiece length: 900 mm Maximum workpiece width: 500 mm Maximum workpiece height: 500 mm Number of tools: 16 Maximum tool diameter: 125 mm Diameter with adjacent pockets empty: 180 mm Maximum tool length: 300 mm Maximum tool weight: 6 kg Tool holder: SK 40 Milling head swiveling range: -5° to +95° Rapid traverse: Longitudinal: 30 m/min Cross: 30 m/min Vertical: 20 m/min MACHINE SPECIFICATIONS Compressed air connection: 6 bar Electrical connection: 50 Hz, 3 x 400 Volt Spindle drive power: 32 kW Total power requirement: 26 kVA Noise level: 78 dB (A) Dimensions & Weight Dimensions (L x W x H): 2,760 x 2,390 x 2,370 mm Machine weight: approx. 7,300 kg Operating Hours Power-on time: 86,672 h Operating time: 34,362 h Spindle run time: 27,804 h EQUIPMENT 3-jaw chuck Ø 200 mm Workpiece probe HEIDENHAIN TS 640 Rotary table 4th axis HOFMANN type RW/NC-160 Rinsing gun RS 232 interface Ethernet interface Electrical cabinet air conditioning unit
