Condition: good (used), Year of construction: 1999, operating hours: 52,324 h, functionality: fully functional, X working area max.: 1270 mm Y working area max.: 1270 mm Control: Bosch Type 3 Basic Standard equipment: - Robust C-frame - Safety light barriers - Coordinate guide with integrated linear magazine - 2 clamping claws - Automatic tool changer - Automatic repositioning - Tool length compensation - Forming capability - Mono tool holder with 360° rotation for all tools - Programmable hold-down device - Multitool drive - Punch slug extraction - Brush tables - Part chute 200 x 200 mm, sorting of parts into 2 containers - NC-controlled, digital, maintenance-free three-phase drives - Network interface RJ34 - 3.5" floppy disk drive - TOPS 2000 graphical programming - Online diagnostics via modem - Operating manual Kodpfxsylk T Rs Ahwsdh + Vibration-damped installation + Multitool + Thread forming + Start post

Condition: good (used), Year of construction: 2023, operating hours: 5,001 h, functionality: fully functional, X working area max.: 3000 mm Y working area max.: 1500 mm Control: TRUMPF Control based on Rexroth IndraMotion MTX Machine: - Closed machine frame - Hybrid axis system - Linear magazine with 24 slots for clamps and tools - Hydraulic clamps (3 pieces) - Drives with maintenance-free three-phase motors - Repositioning with programmable hold-down device - Foot pedal for clamp closing - Parts chute on the right Punching Head: - Delta Drive - Rotatable mono-tool holder - Programmable hold-down position - Tool length compensation - Punch lubrication spray system - Punch slug extraction - Forming function - Stroke counter for punches Control: - TRUMPF Control based on Rexroth IndraMotion MTX - Touch panel with 19" TFT color display - Touchpoint - Programmable cutting gas pressure - Automatic shut-off - Remote support interface - Program management - Production planning Data Transmission: - USB interface - RJ-45 network interface - Central Link - Online Update Manager Safety: - CE marking and EC Machinery Directive - Dual-beam safety light curtain Extended Standard Equipment: - 1st positioning pin (inside right) + Brush tables + MultiTool + Thread forming with thread counter + Thread-former breakage monitoring + Lubricant level monitoring + Marking/rapid beading + Deburring and rolling technology + Adaptive stroke calibration + Die lubrication spray system + Smart Punch Monitoring + Parts flap on the left + Parts conveyor belt for parts flap left + Collection tray for parts conveyor left + Sensor for parts chute + Parts conveyor for parts chute right + Additional clamp + 4x individually openable clamps + 4x height-adjustable clamps + Automatic clamp closing loading sensor system + Optical loading sensor + Automatic repositioning movement to compensate for loading tolerance + Repositioning device for DeltaDrive + Vibration-dampened installation + Chip conveyor with tilting bin Kodoylk H Depfx Ahwsdh + Machine status light + Warpage detection + Wireless Operation Point SheetMaster Compact 3000 x 1500 (AK05): - Loading station with spreading magnet for sheet separation - Suction frame - Vacuum sensors - Double sheet detection - Unloading cart for residual grids and microjoint sheets - Second operator station for loading and unloading + Compact setup for light grid and reference point system + Peeling system SortMaster Compact: - Machine-integrated automated small part removal - Suction frame for unloading good parts up to 600 x 400 mm (X x Y) - 2 suction bars (each suction cup individually controllable) - Unloading area 600 x 800 mm - Vacuum sensors for the suction circuits + X-axis extension - Extension of the unloading area to 1200 x 800 mm

Condition: good (used), Year of construction: 2009, operating hours: 44,287 h, functionality: fully functional, X Working area max.: 2500 mm Y Working area max.: 1250 mm Operating hours: 44,287 hours Control system: Bosch PNC-P Standard equipment: Machine - Stable, easily accessible C-frame - Coordinate guide for high-precision machining - Linear magazine with 18 tool positions including 2 clamps - Drives with maintenance-free three-phase motors - Reloading device with programmable hold-down device - Ball tables - Part chute 180 x 150 mm - Automatic shut-off Punching head - Hydraulic punching head - Rotatable mono-tool holder - Programmable hold-down device - Tool length compensation - Punch spray lubrication - Punch slug extraction - Forming Kodpfxeylk Ems Ahwodh Control system - Open control system based on Bosch PNC-P - Control panel with 15" TFT color screen - Program management - Integrated Technology Data - Teleservice Data Transfer - USB Interface and Network Connection Safety - CE Marking - Multi-Beam Light Barriers - Hydraulic Quick Shutdown + Multitool Function + MultiShear Function + MultiBend Function + Thread Forming Function + Marking/Fast Beading Function + Deburring and Rolling Technology Function + Soft Punch Function + Movable Support Table + Part Slide Sensor + Vibration-Dampened Installation + 2nd Stop Pin + Bow Detection

Condition: used, Year of construction: 2001, punching force: 2,800 t, total length: 2,500 mm, sheet thickness (max.): 8 mm, overall weight: 11,500 kg, table length: 1,250 mm, Offered for sale. Nice Boschert punching nibbling machine. Comes with a large selection of tools. Kjdpoyiz I Tjfx Ahwsdh

Condition: ready for operation (used), Year of construction: 2007, punching force: 31 t, total height: 2,200 mm, total width: 5,165 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, overall weight: 12,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840D CNC, product length (max.): 5,570 mm, number of axes: 2, This 3s Finn-Power C5 + Compact Express CNC punching machine was manufactured in 2007. It features a working area of 2500 × 1250 mm and a punching force of 30 tonnes. With 20 tool stations and a maximum tool diameter of ~89 mm, it offers efficient operation. Consider the opportunity to buy this Finn-Power C5 + Compact Express CNC punching machine. Contact us for further details. • Maximum sheet thickness (steel): 8 mm • Number of tool stations: 20 • Maximum tool diameter: ~89 mm • Table clamps: 3 (typically pneumatic) • Sheet weight capacity: ~200 kg • Traverse speeds: X ~90 m/min; Y ~60 m/min • Table support: vacuum or brush table Additional equipment Kdedoyiz Igjpfx Ahwsh • Automatic loading/unloading system (automatic material handling, loaders/unloaders) • Chip/slug conveyor belt

Condition: used, Year of construction: 2011, Offer: High-Precision and Versatile Punching/Nibbling Machine Boschert Compact 500 CNC Z (Year 2011) – Ideal for Flexible Sheet Metal Processing! We are selling a powerful and reliable punching/nibbling machine from the renowned manufacturer Boschert, which impresses with its advanced features and precision. This machine is the ideal solution for a wide range of punching and nibbling tasks, from one-off pieces to large-scale production. Key Features: • Manufacturer: Boschert • Model: Compact 500 500 x 1000 CNC Z • Year of manufacture: 2011 Kdodpfxex Uxtfs Ahwjh • Intuitive CNC Control: Multi-axis Ladob controller with graphical user interface for easy programming and visualization of machining processes. • Extended work area for greater flexibility: o X-axis: 0–2000 mm (enables processing of long workpieces) o Y-axis: 0–750 mm (offers ample space for wide sheet metal) • Ultra-fast tool change: Trumpf quick-change tool system ensures minimal downtime and maximum productivity. • Universal tool compatibility: Compatible with the full range of Trumpf tools – reduce your tooling costs and expand your capabilities. • Secure and precise material handling: o Collet clamping: Ensures a firm grip of the workpiece during processing. o Non-contact repositioning up to 9999 mm: High-precision repositioning device with 2 sheet holders for efficient processing of even very long sheets without loss of position. • Dynamics and precision at their best: o Maximum positioning speed: 60 m/min for fast processing cycles. o Infinitely variable feed rates: Optimal adjustment of processing speed to the material and task. o Highest positioning accuracy: ± 0.05 mm for precise results on every workpiece. • Robust and durable construction: o Y-axis drive: Two ball screw-driven carriages located left and right beside the machine table ensure maximum stability and torsional stiffness. o X-axis drive: Ball screw and four recirculating ball guides guarantee precise and smooth movement. • Specialized equipment for small parts: Stop plate (L-bracket) for secure processing of small parts that can no longer be safely held by the collets – for maximum flexibility and minimal scrap. Condition: The machine is in very good, well-maintained condition and has been serviced regularly. It is immediately ready for operation and offers excellent performance for your sheet metal processing needs.

Condition: ready for operation (used), Year of construction: 1997, Working area: 2500 x 1280 mm Punching force: 220 kN Ksdpfx Ahsx Tr S Sjwodh For sheet thickness up to: 8 mm Weight approx.: 11 t

Condition: excellent (used), Year of construction: 2006, punching force: 28 t, sheet thickness (max.): 10 mm, sheet thickness steel (max.): 6 mm, punching diameter: 105 mm, throat depth: 1,500 mm, Boschert TWIN 1500x3000 Rota-Index Quick-change tool system TRUMPF Station 1: Rotating with indexing option for Boschert Multitool Max. punching diameter 105 mm, infinitely rotatable tool Station 2: Max. punching diameter 105 mm, with option for Boschert Multitool Revotool adapter incl. 8-position tool holder Punching force: 280 kN (28 tons) Travel range: x-axis 2050 mm (repositioning up to 9999 mm) y-axis 1580 mm Throat depth: 1750 mm Tool system: Trumpf Gr1-3 (105 mm) and Boschert Revotool Labod 32060 graphic control / workshop programmable Max. sheet thickness: 6 mm (clamp opening) Max. stroke height: 90 mm, infinitely programmable upwards and downwards Table width left + right: 2250 mm each Table depth: 3250 mm Table height: 900 mm Overall width: 4900 mm Kdedox Tp Rfopfx Ahwoh Overall depth: 4800 mm Overall height: 2080 mm Drive power: 20 kVA Machine weight: 15,000 kg Hydraulic oil capacity: 160 l Color: Blue RAL5017 / Light Grey RAL7035 Year of manufacture: 2006 Ball transfer table Slug extraction system Fast hydraulic system Very well maintained condition Comes with accessories

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Amada CNC-controlled turret punching machine, type VIPROS 368 KING. The machine is equipped with a loading system type PR 300 and an unloading system type MP 300. Kdedex Sq Ipopfx Ahweh

Condition: used, Year of construction: 2022, controller manufacturer: Sonstige, controller model: AMNC-3i, _____ Description: Control : Sonstige AMNC-3i Movement X/Y/Z : 3000/1500 mm Technical data Punching machine:EMK-3612MII (58) Punching force:300 kN Positioning accuracy:± 0.1 mm Number of tool stations:58 Machine frame:Bridge frame Machine table type:Brush table Punching drive:Servo-electric dual drive Travel range (X x Y):1525 x 3050 mm Control:AMNC-3i (21.5" screen size) Features :Punch & forming function :Good parts flap :scrap conveyor system Kjdpfxox I T Dxj Ahwedh Dimensions Length:5436 mm Width:6212 mm Height:2342 mm Weight:21500 kg

Condition: ready for operation (used), functionality: fully functional, punching force: 22 t, sheet thickness (max.): 6 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,270 mm, workpiece weight (max.): 150 kg, Punching and nibbling machine with TRUMALIFT Sheetmaster! TECHNICAL DETAILS Press force: 220 kN Max. sheet thickness: 6.4 mm Travel path X-axis: 2,500 mm Travel path Y-axis: 1,270 mm Positioning speed X-axis: 90 m/min Positioning speed Y-axis: 60 m/min Positioning speed simulation: 108 m/min Positioning speed rotary axis: 360°/sec Punching diameter: 76.2 mm Minimum programmable increment: 0.01 mm or 0.01° Workpiece weight: 150 kg Tool stations: 15 pcs Tool change time: 1.5 - 6.5 sec MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 6,400 x 5,800 x 2,100 mm Machine weight: approx. 11,050 kg EQUIPMENT Multitool control "Softpunch" function Pneumatic follow-up cylinders Small parts sensor for programmable part chute Parts box for finished parts Chip conveyor with container Scratch-reduced processing Air-cushioned mounting Additional clamping bridge Prepared for TRUMALIFT SheetMaster TRUMALIFT Sheetmaster for workpieces up to 2,500 x 1,250 mm Alignment system for loading stack with spreader magnets Manually movable scrap grid system Kdodsx I Hh Rjpfx Ahwjh

Condition: ready for operation (used), Year of construction: 2001, operating hours: 62,769 h, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 8 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, TECHNICAL DETAILS Sheet thickness: 8 mm Punching force: 220 kN Travel X-axis: 3,000 mm Travel Y-axis: 1,500 mm MACHINE DETAILS Control: Siemens Machine weight: approx. 17,500 kg Kodpfex I E Ezjx Ahwsdh Operating hours: 62,769 h EQUIPMENT Scraper position change monitoring Thread forming Marking – quick beading Slitting Multishear Multibend Backgauge repositioning Roller tools Setup cassettes Ball transfer table

Condition: ready for operation (used), Year of construction: 2012, punching force: 18 t, total height: 2,252 mm, sheet thickness (max.): 6 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, controller manufacturer: BOSCH, controller model: MTX CMP70, product length (max.): 6,500 mm, This TRUMPF TruPunch 3000 S11 was manufactured in 2012. It features a Bosch MTX CMP70 control system, with X/Y-axis travels of 2500 / 1250 mm, and can handle sheet weights up to 160 kg. The machine includes a linear tool magazine with 18 stations and offers functions like MultiTool, MultiBend, and thread forming. Consider the opportunity to buy this TRUMPF TruPunch 3000 S11 CNC punching machine. Contact us for more information about this machine. • Maximum sheet weight: 160 kg • Performance: • Punching strokes (E = 1 mm): 1000 strokes/min • Marking strokes: 2500 strokes/min Ksdpfx Aex D Dklohwjdh • MultiTool tool-change time: 0.3 s • Power consumption: • Standby with auto-shutdown: 0.3 kW (average) • During production: 5.6 kW (average) • Equipment & features: • MultiTool function • MultiBend function • Thread forming function with tool breakage monitoring • Surface marking/embossing function • Deburring and roller technology • Tool magazine: Linear, 18 stations • Documentation: TruPunch 3000 documentation

Condition: ready for operation (used), Year of construction: 2011, punching force: 31 t, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,525 mm, overall weight: 21,000 kg, table load: 160 kg, controller manufacturer: FANUC, number of axes: 2, This AMADA EMZ 3610 NT CNC punching machine was manufactured in 2011. It features a Fanuc control system, a punching force of 300kN, and a working area of 2500 x 1525 mm, extendable to 5000 x 1525 mm with repositioning. The machine can handle sheet thicknesses up to 4.5 mm and supports a maximum table load of 160 kg. If you are looking to get high-quality punching capabilities, consider the AMADA EMZ 3610 NT machine we have for sale. Contact us for more information. • Working area with repositioning: 5000 x 1525 mm • Max. sheet thickness: 4,5 mm (mild steel) • Feed rate X/Y: 100 / 80 m/min (128 m/min simultaneous) • Positioning tolerance: +/- 0,1 mm • Z-turret stations: 45 • AutoIndex stations: 4 (2 x B, 2 x C) • Turret feed rate: 30 1/min • Max. number of hits: 1000/min • Machine frame: Bridge frame • Punching drive: Servo-electric Twin Drive • Drives (turret + table): AC-Servo motors • Clamps: Pneumatical • Electrical connection: 400V / 50Hz • Electrical consumption: 1 kW – 7 kW • Air consumption (machine): 250 l/min • Air consumption (Air Jet Vakuum): 250 l/min Additional equipment • Loading unit: Loader L III 300 • Sheet size min.: 1000 x 300 mm • Sheet size max.: 3000 x 1500 mm • Material thickness: 0,5 – 8,0 mm • Max. loading weight: 300 kg • Max. stack height: 300 mm • Max. pallet weight: 4000 kg (2x2000 kg) • Max. feed rate (traverse): 70 m/min • Number of suction cups: 34 pieces • Double sheet control: Yes, with sheet thickness detector • Air consumption: 510 l/min, 6 bar inlet pressure • Electrical connection: 400V • Unloading unit with Parts Remover: PR 3 UL 300 P Kdjdpfxex D Hpqs Ahwsh • Part size min./max.: 150 x 150 mm / 2500 x 1000 mm • Sheet thickness: 0,5 – 3,0 mm (4 mm for EM-Serie) • Max. part weight: 50 kg • Storage table size: 3400 x 1400 mm • Max. part size for unloading clamps: 3000 x 1500 mm • Max. stack height skeleton table: 450 mm • Max. weight skeleton table: 2000 kg • Max. stack height storage table: 450 mm • Max. weight storage table: 4000 kg • Max. feed rate X-/Y-direction: 180 / 90 m/min • Air consumption: 1000 l/min, 6 bar inlet pressure • Electrical connection: 400V

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, CNC punching machine with only approx. 11,600 operating hours, immediately available Manufacturer: TRUMPF Model: TruPunch 3000 - 1600(S11) Year of manufacture: 11/2013 Operating hours, approx.: only 11,600 h Sheet format: Large format TECHNICAL DATA: Working area: 3,000 x 1,500 mm, with repositioning Max. workpiece weight: 160 kg Kdodjxn Tywopfx Ahwoh Punching and hold-down force: 180 kN and 20 kN Max. stroke rate: Punching: 800 1/min, Marking: 2,500 1/min Dimensions (L x W x H): 6,500 x 6,203 x 2,252 mm SPECIAL EQUIPMENT: - MultiTool function - MultiShear function - Marking / Fast embossing function - Deburring and roller technology - Adaptive stroke calibration - Punch slug breakage monitoring - Lowerable die - Spray degreasing for dies with fill level monitoring - Additional clamp - Sheet collision detection - Stop pin, outer side, left position outside STANDARD EQUIPMENT: Machine: - Working area 3,000 x 1,500 mm (with repositioning) - Rigid C-frame for easy access - Coordinate guidance for high-precision machining - Linear magazine with 17 tool stations and 3 clamps - Drives with maintenance-free 3-phase servo motors - Repositioning device with programmable hold-down - Ball tables - Parts chute - Programmable support table - Good parts container - Scrap container - Automatic shut-off mechanism - Transport and installation device - Stop pin (right side, inside) - Foot switch for closing the clamps Punching head: - Servo-electric punching head - Rotatable single-tool adapter - Programmable hold-down - Tool length compensation - Spray degreasing for punch - Punch slug extraction - Forming - Manually adjustable pressing force - Stroke counter for punch - Monitoring of fill level for thread-cutting and tool lubrication Control: - Control system based on Bosch MTX CMP 70 - Operating panel with 17" touchscreen - NC program management - Integrated technology data - Teleservice via Internet - Integrated e-shop - Production planning - Programming - Advanced workshop programming - Data transmission - USB interface Safety: CE marking (ex works) Dual-beam light barriers

Condition: ready for operation (used), Year of construction: 1998, operating hours: 30,430 h, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 6 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, punching diameter: 76 mm, TECHNICAL DETAILS Pressing force: 220 kN Kdsdpfjxhfu Hox Ahwoh Maximum sheet thickness: 6.4 mm Punching diameter: 76.2 mm X-axis travel: 2,500 mm Y-axis travel: 1,250 mm Positioning speed X-axis: 90 m/min Positioning speed Y-axis: 60 m/min Positioning speed (simulation): 108 m/min Positioning speed rotary axis: 360 °/sec Workpiece weight: 150 kg Smallest programmable increment: 0.01 mm or 0.01° Tool stations: 15 units Tool change time: 1.5 - 6.5 sec MACHINE DETAILS Dimensions & Weight Dimensions: 6,400 x 5,800 x 2,100 mm Approx. machine weight: 11,050 kg Operating hours: 30,430 h

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 6 mm, workpiece length (max.): 3,000 mm, workpiece width (max.): 1,500 mm, TECHNICAL DETAILS Kdedexhfnajpfx Ahwsh Working area: 3,000 x 1,500 mm Max. punching force: 220 kN Max. sheet thickness: 6 mm MACHINE DETAILS Dimensions & Weight Dimensions: 7,500 x 7,500 x 2,500 mm Approx. machine weight: 17,500 kg

Condition: used, Year of construction: 2004, functionality: fully functional, machine/vehicle number: 11.22-LP6122804, The Finn-Power LP6 SWT is a combined laser and punching CNC machine designed for high-efficiency sheet metal processing. Manufactured in 2004, this model integrates hydraulic punching and CO₂ laser cutting technologies, making it suitable for complex and versatile manufacturing tasks. Kodexcnipopfx Ahwsdh

Condition: ready for operation (used), Year of construction: 2000, operating hours: 20,000 h, functionality: fully functional, workpiece length (max.): 3,000 mm, workpiece width (max.): 1,500 mm, TECHNICAL DETAILS Kdodpfjw Swdijx Ahweh Sheet size: 1,500 x 3,000 mm MACHINE DETAILS Operating hours: 20,000 h EQUIPMENT Material handling Tools Grinding machine

Condition: good (used), Year of construction: 1999, functionality: fully functional, Product Description FINN POWER TP 250 CNC Kdedpfx Ajwxw Uiehwsh Travel distances: X: 1020 mm Y: 1020 mm Control System: Sinumerik 3N Punching force: 250 kN Max. punching diameter: 85 mm Max. sheet thickness: 8 mm Machine dimensions: 3500 x 2300 x 2300 mm Machine weight: 5800 kg

Condition: refurbished (used), Year of construction: 2014, operating hours: 35,418 h, functionality: fully functional, punching force: 18 t, sheet thickness (max.): 6 mm, feed length X-axis: 2,500 mm, feed length Y-axis: 1,250 mm, HIGHLIGHTS - Last maintenance in February - Punch head: stripper holder and seals replaced - Lower clamping piston replaced - C1K encoder and needle bearing renewed - All wear parts and maintenance items serviced TECHNICAL DETAILS Max. punching force: 180 kN Working area: 2,500 x 1,250 mm Max. sheet thickness: 6.4 mm Control: Bosch MTX CMP70 Tool system: 18 tool stations, with 2 clamps Part chute: 500 x 500 mm Hydraulic single tool holder: 360° rotation Programmable hold-down device: active / passive / re-track MACHINE DETAILS Operating hours: 35,418 h (28.02.2025) Space requirements: 6,500 x 6,000 x 2,230 mm Machine weight: 9,800 kg Total connected load: 18 kVA EQUIPMENT - Rigid, easily accessible C-frame - Linear magazine for tool stations - Foot switch for clamp closing - Servo-electric punching head - Punch lubricator (spray lubrication) - Punch slug extraction - Adjustable hold-down force - 17" touch screen - Teleservice via Internet - Automatic shutdown - USB interface - CE marking - Multi-beam safety light barriers - Hydraulic quick shut-off Ksdpfx Ahswu Evyowodh - Multitool function - Deburring and roller technology function - Thread forming function - Engraving tool function - Marking/fast bead forming function - Sensor for part chute - Vibration-dampened installation

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, punching force: 28 t, travel distance X-axis: 1,500 mm, travel distance Y-axis: 3,000 mm, punching diameter: 105 mm, TECHNICAL DETAILS Punching force: 280 kN Working area: 1500 x 3000 mm Sheet thickness: 6.4 mm Workpiece weight: 200 kg Punching diameter: 105 mm X-axis: 60 m/min Y-axis: 30 m/min Kedpfxswuryls Ahwodh MACHINE DETAILS Machine weight: approx. 16,000 kg EQUIPMENT No further information available.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 5820387, punching force: 30 t, sheet thickness steel (max.): 8 mm, working range: 3,000 mm, travel distance X-axis: 2,500 mm, CNC punching machine with fully automatic loading system TECHNICAL DETAILS Control: CNC AMADAN 04 P-C Automation & Safety Loading system: LKI L III 250 automatic loader Unloading system: PR III automatic unloader Sorting: Automatic part sorting on pallets possible Noise protection: Noise protection hood Safety equipment: SICK photoelectric sensors, original safety fences Processing capacity Punching force: 30 t Max. material thickness (steel): 8 mm Working area: 3,000 mm X-axis travel: 2,500 mm Table system Table type: Brush table for quiet operation and scratch-free processing Repositioning: Automatic sheet repositioning Tool lubrication: Air Blow automatic lubrication Punching Pneumatic punches: 2 pieces MACHINE DETAILS Power supply: Three-phase Overall length: 15,000 mm Total width: 5,000 mm Total height: 2,000 mm Punching machine weight: 16 t Loader weight: 2.3 t EQUIPMENT - Automatic loader LKI L III 250, built in 2011 - Automatic unloader PR III - Noise protection hood - SICK photoelectric sensors - Original safety fences - Brush table - Automatic sheet repositioning - Air blow lubrication - Two pneumatic punches Further technical details according to the manufacturer - without guarantee Ram stroke: 31.9 mm Max. hole diameter: 114.3 mm Punching frequency (X/Y direction) Kodpfswc S R Hsx Ahwjdh Stroke length: 8.0 mm – Pitch: 25.4 mm – Stroke frequency: 300 / 375 strokes/min Stroke length: 4.5 mm – Pitch: 25.4 mm – Stroke rate: 375 / 375 strokes/min Stroke length: 4.5 mm – Pitch: 2.0 mm – Stroke rate: 600 / 600 strokes/min Tool turret Tool type: Amada Thick Turret Turret speed: 25 rpm Turret capacity: 58 stations (4 of which are auto-indexable) Accuracies Punching accuracy: ± 0.10 mm Positioning accuracy: ± 0.025 mm Repeat accuracy: ± 0.025 mm

Condition: ready for operation (used), Year of construction: 2001, operating hours: 62,433 h, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 8 mm, travel distance X-axis: 2,585 mm, travel distance Y-axis: 1,250 mm, workpiece weight (max.): 200 kg, TECHNICAL DETAILS Control: Siemens Sinumerik 840 D Punching force: 220 kN Max. sheet thickness: 8 mm Max. Sheet thickness for stainless steel: 8 mm Max. Punching diameter: 76.2 mm Working area and workpiece Working area: 2,585 x 1,250 mm Max. Workpiece weight: 200 kg Kdedpfx Ahewcqf Nsweh Speed and precision Max. Speeds: 100 / 60 / 116 m/min Accuracy: 0.1 mm MACHINE DETAILS Operating hours: 62,433 h Length: 6,100 mm Width: 6,760 mm Height: 2,500 mm Weight: 13,000 kg

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, punching force: 22 t, sheet thickness (max.): 8 mm, travel distance X-axis: 3,085 mm, travel distance Y-axis: 1,650 mm, workpiece weight (max.): 230 kg, TECHNICAL DETAILS Cutting force: 220 kN Working area: 3,085 x 1,650 mm Max. sheet thickness: 8 mm Max. workpiece weight: 230 kg Kedpfewcqfpjx Ahwedh Control Control: Bosch Trumagraph CC 220 MACHINE DETAILS Machine weight: 13,800 kg Space required: approx. 7,900 x 6,300 x 2,200 mm Electrical specifications Mains connection: 400 V, 50 Hz Connection power: 19 kVA Supply voltage: 400 V Control voltage: 24 V Required fuse: 3 x 35 A Compressed air Compressed air connection: 6 bar
