Hommel GmbH

Condition: ready for operation (used), Year of construction: 2008, operating hours: 9,848 h, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, spindle speed (max.): 12,000 rpm, number of axes: 5, This 5-axis EMCO MC 75-50 was manufactured in 2008. It features an X-axis travel of 750 mm and Y-axis travel of 500 mm, providing versatile machining capabilities. The machine is equipped with a Heidenhain iTNC 530 control and a spindle speed of 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the EMCO MC 75-50 vertical machining centre we have for sale. Contact us for further details. • Axes: 4 (standard) + optional 5th axis • Spindle: Kessler • Operating hours: Control ON 36,839 h; Machine ON 21,370 h; Program run 11,122 h; Spindle ON 9,848 h • Electrical: 400 V, 3 phases, 50 Hz, nominal current 50 A, largest load current 30 A, breaking capacity 16 kA • Protection grade: IP54 • Electrical cabinet weight: 220 kg • Cooling: Coolant system with belt filter (MicroMag filtration unit visible) Additional equipment • Chip conveyor • Wired electronic handwheel • Lehmann rotary axis with rocker and counter bearing • Zeroclamp zero-point clamping system • Retrofitted electrical cabinet cooling unit (Rittal) • Nikken rotary table Technical Specification Taper Size SK 40 Lodpfoywyq Djx Ab Ejri

Condition: ready for operation (used), Year of construction: 2018, travel distance X-axis: 762 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, controller manufacturer: HAAS, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 24, number of axes: 3, This 3-axis HAAS VF-2SS-EU was manufactured in 2018. It features an impressive X-axis travel of 762 mm, Y-axis travel of 406 mm, and Z-axis travel of 508 mm. The machine is equipped with a side mount tool changer with a capacity for approximately 24 tools and a spindle speed of up to 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the HAAS VF-2SS-EU vertical machining center we have for sale. Contact us for further details. • Country of origin: USA • Certification: CE • Electrical: 440 V, 3 phase, 50/60 Hz • Full load current: 33 A • Maximum load current: 33 A • Short circuit capacity: 10,000 A • Software version: 100.19.000.1123 • Power on time: 1,056 h • Tool changes: 32,413 • Included machine equipment: coolant system, wash gun, LED work light, fully enclosed working area • Condition: very good condition, low operating hours, well maintained Additional equipment • Machine vise • Touch probe Technical Specification Lodpfxoywv Tne Ab Esri Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, controller manufacturer: FANUC, spindle speed (max.): 24,000 rpm, number of axes: 4, This 4-axis FANUC Robodrill alpha-T21iFL was manufactured in 2008. It features impressive X-axis travel of 700 mm, Y-axis travel of 400 mm, and Z-axis travel of 330 mm. The machine is capable of a spindle speed of 24,000 rpm and a maximum feed rate of 54,000 mm/min. If you are looking to get high-quality machining capabilities, consider the FANUC Robodrill alpha-T21iFL vertical machining centre we have for sale. Contact us for further details. • Max. feedrate: 54,000 mm/min • Spindle distance: 200 mm • Max. workpiece diameter on 4th-axis table: 300 mm Lodoyvupropfx Ab Esri

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, controller manufacturer: FANUC, spindle speed (max.): 24,000 rpm, number of axes: 5, This 5-axis FANUC Robodrill alpha-T21iFL was manufactured in 2008. It features impressive X, Y, and Z travels of 700 mm, 400 mm, and 330 mm respectively, along with a spindle speed of 24,000 rpm. The machine offers a maximum feed rate of 54,000 mm/min and can accommodate a workpiece diameter of up to 300 mm on a 5-axis table. If you are looking to get high-quality machining capabilities, consider the FANUC Robodrill alpha-T21iFL vertical machining centre we have for sale. Contact us for more information about this machine. • Maximum feed rate: 54,000 mm/min • Spindle distance: 200 mm Lredpfx Absyvunbe Eei • Maximum workpiece diameter on 5-axis table: 300 mm

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Haas VF4 NGC. Year of installation: 2020. First owner since new. TECHNICAL DATA OF THE VF-4 MACHINE Tool travels Unit Value Travel in X-axis mm 1,270 Travel in Y-axis mm 508 Travel in Z-axis mm 635 Distance from table surface to spindle mm 102–737 Worktable Table size (X x Y) mm 1,321 x 457 Maximum table load kg 1,588 Table design T-slots T-slot width mm 16 Distance between T-slots mm 80 Spindle and Axis Drives Taper / standard DIN 69871 / ISO 40 Maximum spindle speed rpm 8,100 Drive type Direct Maximum torque at 2,000 rpm Nm 122 Max. torque at 450 rpm (with optional 2-speed gearbox) Nm 339 Maximum spindle power kW 22.4 Max. axial force X & Y kN 11.3 Max. axial force Z kN 18.6 Rapid Traverses and Feed Rates Rapid traverse (X, Y, Z) m/min 25.4 Feed rates m/min 16.5 Tool Magazine Number of tools in magazine 20 Maximum tool diameter (all tools) mm 89 Maximum tool weight kg 5.4 Tool change time (tool-to-tool) s 4.2 Lsdsyvlwtepfx Ab Ejri Tool change time (chip-to-chip) s 4.5 Accuracy Machine positioning accuracy mm +/-0.005 Machine positioning repeatability mm +/-0.003 Other Machine weight kg 6,033 Power supply voltage V 3x400 Frequency Hz 50 Coolant tank capacity l 208 Compressed air pressure bar 6.9

Condition: used, Year of construction: 2012, Doosan DNM 400 CNC machining center Year 2011/12 Heidenhain TNC 530 control X-762 mm Lrodpeyvizpjfx Ab Eji Y-435 mm Z-510 mm Table 920x435 mm Spindle max. 12,000 rpm Through-spindle coolant (IKZ) Tool magazine for 30 tools Spindle taper SK40 BLUM workpiece probe Includes toolholders with the machine LNS chip conveyor Machine documentation

Condition: ready for operation (used), Year of construction: 2013, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, total height: 2,600 mm, total width: 1,800 mm, table load: 160 kg, overall weight: 5,600 kg, spindle speed (max.): 12,000 rpm, product length (max.): 2,630 mm, number of axes: 3, This 3-axis Akira Seiki RMV 700 APC was manufactured in 2013. It features an X-axis travel of 700 mm, Y-axis travel of 400 mm, and Z-axis travel of 400 mm. The machine includes a robust table size of 700 mm x 400 mm with a maximum load capacity of 160 kg. If you are looking to get high-quality machining capabilities, consider the Akira Seiki RMV 700 APC vertical machining centre we have for sale. Contact us for further details. • Table: 700 × 400 mm Lredpfx Ajyvip Tsb Eoi • Spindle: 12 HP (max 15 HP); cooling: air, through-spindle coolant (CTS), and external coolant • Rapid traverse (X/Y/Z): 48 / 60 / 72 m/min • Accuracy: positioning 0.012 mm; repeatability ±0.005 mm • Tool changer: 24 + 1 servo-controlled; max tool Ø 75 mm; max tool length 200 mm; max tool weight 4.5 kg • Change times: tool-to-tool 1.9 s; chip-to-chip 3.4 s • Control: AKIRA Mi:845 (compatible with FANUC G-code) • General data: coolant tank 150 L; power requirement 25 kVA; required air pressure 0.5 MPa • Application: suitable for light machining, especially non‑ferrous metals and composite materials Additional equipment • Twin pallet system (APC) Technical Specification Taper Size HSK 63

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 730 mm, travel distance Y-axis: 580 mm, travel distance Z-axis: 560 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530 3D, table load: 500 kg, spindle speed (max.): 18,000 rpm, spindle motor power: 15,000 W, number of axes: 5, This 5-axis DMG MORI DMU 60 Monoblock was manufactured in 2016. It features an X-axis travel of 730 mm, Y-axis travel of 560 mm, and Z-axis travel of 560 mm. The machine is equipped with a powerful motor spindle capable of reaching speeds up to 18,000 rpm and includes a 24-pocket tool changer. If you are looking to get high-quality machining capabilities, consider the DMG MORI DMU 60 Monoblock vertical machining centre we have for sale. Contact us for further details. Lodpfxoyvfpbe Ab Eori • Working area / travel: • Modification: X-axis travel reduced by 100 mm (effective X travel 630 mm) • Main drive & spindle: • Motor spindle SK40 with active cooling • Power: 15 kW (40% duty) / 10 kW (100% continuous) • Tooling system: • Tool holder: SK40 (DIN 69871) • Tool clamping: DIN 69872 • Tool changer: Pick-up system • Magazine: 24 pockets (SK40) • Work table: • Integrated NC rotary table in rigid table • Rotary table Ø 600 mm; total table 1,000 x 600 mm • T-slots: 1x 14 H7 (alignment, centered) + 8x 14 H12 (clamping) • T-slot spacing: 63 mm • Permissible load: 500 kg • Milling head: • Controlled NC-swivel B-axis with hydraulic clamping • Spindle offset: 100 mm • Swivel range: -120° to +30° • Control system: • Electronic handwheel iTNC 530 • Control language: German Additional equipment • Workpiece measurement: Heidenhain TS 640 infrared probe (SK40) • Tool measurement: Blum laser (in-machine vertical tool length and diameter) • Chip conveyor • Flushing gun with pump (1 bar / 40 l/min theoretical capacity) • Networking: DMG Netservice Basic Package Euro ISDN (Netservice Box, Cisco Euro ISDN Router, license) Technical Specification Taper Size SK 40

Condition: used, TECHNICAL DETAILS - Number of axes : 3 MILLING SPINDLE - Tool holder type : BT30 - Spindle power : 20 [kW] - Spindle speeds : 24000 [rpm] - Number of spindle hours : 4877 [h] LINEAR AXES - Travels on X/Y/Z axes : 700/420/380 [mm] - Rapid traverses rates (X/Y/Z) : 60 [m/min] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 25 - Tool exchange time : 0.9 [sec] TABLE - Table dimensions : 840/420 [mm] - Maximum weight upon table : 400 [kg] - Distance table / spindle nose (min./max.) : 200-580 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 16 [kW] WEIGHT & DIMENSIONS - Machine floor space : 1650/2950 [mm] - Machine height : 2550 [mm] - Machine weight : 3400 [kg] MACHINE HOURS - Number of hours under power : 18761 [h] - Number of working hours : 7667 [h] EQUIPMENT - CNC : Siemens 840D SL - Interface : Ethernet / RS232 / USB / PCMCIA - Rigid tapping - 3 colors status lamp - Coolant tank * with high-pressure pump * with paper filtering unit - Coolant through spindle - Chips conveyor - Tool probe - Workpiece probe Lredpoyu U E Ajfx Ab Esi - Electric transformer

Condition: ready for operation (used), The machine is ready for operation. Please refer to the video: The machine can be dismantled, loaded, and transported to your location for an additional charge. Basic Specifications Travel paths: X 710 / Y 520 / Z 520 mm Weight: approx. 5,500 kg Tool holder: SK40 or HSK-E50 Tool magazine: 24 positions (optionally 60) Spindle Lrjdpfx Ajyu Tlzob Eoi Standard: 12,000 rpm Option: 30,000 rpm Power: 10–15 kW (standard) / 15–20 kW (option) Axes & Feed Rapid traverse: 30 m/min Feed rate: up to 10,000 mm/min Resolution: 0.001 mm Positioning accuracy: 0.010 mm Tool Data Max. tool length: 315 mm (SK) Max. tool weight: 6 kg Magazine total weight: 80 kg (optionally 180 kg) If you have further questions, please feel free to send a message here, or contact us via WhatsApp or phone. The price is net, no warranty or returns, liability for defects is excluded, subject to prior sale and errors.

Condition: ready for operation (used), Year of construction: 1998, travel distance X-axis: 762 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 560 mm, controller manufacturer: HAAS, table load: 1,360 kg, overall weight: 4,200 kg, spindle speed (max.): 7,500 rpm, number of axes: 4, This 4-axis MIKRON VCE 750 was manufactured in 1998. It features impressive travels of 762 mm in the X-axis, 510 mm in the Y-axis, and 560 mm in the Z-axis. The machine includes a tool magazine with 20 positions and a maximum table load capacity of 1,360 kg. If you are looking to get high-quality machining capabilities, consider the MIKRON VCE 750 vertical machining centre we have for sale. Contact us for further details. • Tool magazine: 20 positions • Rapid traverse: 25 m/min • Feed rate: 16 m/min • Table size: 600 x 865 mm • Condition: Ready for operation Lrodpfxoyu S Ube Ab Eoi Additional equipment • Chip conveyor Technical Specification Taper Size ISO 40

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, HAAS VF-3SS Super Speed – 2014 The machine is in good working condition and can be inspected under power. Please note: The rotary table shown in the photos is part of the current production setup and is not included in the sale. Manufacturer: HAAS Model: VF-3SS Year of manufacture: 2014 Travels: X-axis: 1016 mm Y-axis: 508 mm Z-axis: 635 mm Ljdpfxjyuytfs Ab Ejri Table size: 1219 × 457 mm Maximum table load: 794 kg Spindle: Speed: 12,000 rpm Spindle taper: CT40 / BT40 Motor power: 22.4 kW Tool changer: Side-mount tool changer (SMTC) Capacity: 24 + 1 tools Rapid traverse rates: X/Y/Z: 35.6 m/min Machine weight: approx. 5,670 kg Excellent opportunity – attractive price for a HAAS Super Speed machine. Machine available immediately.

Condition: ready for operation (used), Year of construction: 2014, operating hours: 5,327 h, travel distance X-axis: 762 mm, spindle speed (max.): 12,000 rpm, number of axes: 3, This 3-axis HAAS VF-2SS was manufactured in 2014. It features advanced capabilities including tool measuring and a probe for enhanced precision. With a feed cutting time of 5327 hours, this vertical machining centre is designed for efficient operations. If you are looking to get high-quality machining capabilities, consider the HAAS VF-2SS machine we have for sale. Contact us for further details. Ledpsyux Sasfx Ab Ejri • IKZ • Probe • Tool measuring • Axis configuration: 3 axes (X/Y/Z) • Frequency: 50 / 60 Hz • Short circuit interrupting capacity: 10,000 A • Short circuit current: 5,000 A RMS symmetrical • Arc flash rating: • 208-240 VAC models: HRC-1 • 360-480 VAC models: HRC-2 • Feed cutting time: 5327 h

Condition: used, Year of construction: 2004, Hurco VMX24S Vertical Machining Centre with Hurco Ultimax Control, Table size 760mm x 510mm, 24 ATC, BT 40 Tooling, 8000rpm, Travel X=610mm Y= 508mm Z= 610mm, Coolant Tank. S/No. H-2S061 (2004) Lrsdpfxjyuvt Ie Ab Eei Location: This lot is located in Burton-on-Trent. A charge of £350 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser.

Condition: excellent (used), Year of construction: 2002, Data XYZ: 508 x 406 x 508 mm Control: Haas Magazine: 20 stations / SK 40 Lrjdpfx Asyupmuob Eji Chip conveyor Coolant system Machine has low operating hours

Condition: used, FANUC ROBODRILL ALPHA T21 i FIa is a Vertical machining center delivering precision, high accuracy and reliable performance. Working capacities: table 850 x 400 mm, table load max 300 kg, travels X700 mm, Y400 mm, Z330 mm, total 5 axes, spindle nose-to-table 250–580 mm, tool magazine 21 positions, max tool weight 23 kg. Main technical specs: stepless spindle 100–24,000 t/min, rapid traverse 54 m/min, spindle power 5.5 kW, supply 3x 400 V 50 Hz, total installed power 11 kVA; machine weight ~2200 kg; footprint L2140 x W2000 x H2350 mm. Achieves tight tolerances; suited for automotive, watchmaking, machine tool, aerospace and medical applications. Ljdpfxoyugyrs Ab Eori

Condition: ready for operation (used), Year of construction: 2016, operating hours: 3,112 h, travel distance X-axis: 760 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, table load: 1,000 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 13,000 W, number of axes: 3, This 3-axis Hurco VMX30i vertical machining centre was manufactured in 2016. It features a spindle speed range of 10 – 12,000 rpm and a spindle motor power of 13 kW. The machine offers an X-axis travel of 760 mm, Y-axis travel of 510 mm, and Z-axis travel of 610 mm, along with a table size of 1020 × 510 mm and a maximum table load of 1,000 kg. If you are looking to get high-quality machining capabilities, consider the Hurco VMX30i machine we have for sale. Contact us for further details. • Control: WINMAX (MAX 5), dual-screen • Table size: 1020 × 510 mm Lredpfoyufcfjx Ab Eoi • Tool changer: 30 positions • Design: New design Additional equipment • Chip conveyor • Water cooling system • Main spindle cooling • Full machine enclosure / chip protection guard • Machine work light • Machine base • Machine status indicator • DXF option • ULTIMONITOR Ethernet Kit • Materials and Tools Library • WINMAX PC Software • External spindle blower

Condition: excellent (used), Year of construction: 2020, Unique opportunity to purchase this high quality CHIRON 5-axis machining center for profiles. Built and first use in 2020. The spindle was replaced in June 2022 and currently has 4500 operation hours. Machine is in very good condition and it can be inspected under power upon appointment. Availability: on request Including: Chip conveyor (scraper type) Profile bar feeder for bar lengths up to 6 m, for guiding profiles up to Ø 212 mm Coolant system TPF 350 / FKA 900 Coolant through the spindle Fixed 3D probe Type TS 27 R – RENISHAW Renishaw RLP40Q probe system Cnc control SIEMENS 840D X-axis 730 mm Y-axis 400 mm Lredpfxsyt I Uhe Ab Eji Z-axis 425 mm Maximum spindle speed 15,000 rpm Maximum torque 140 Nm Drilling capacity Ø 42 mm Thread tapping M30 Tool magazine capacity 20 tools Tool taper DIN 69893 HSK A63 Maximum tool diameter 65 mm Milling capacity 500 cm³/min in E355 steel Full technincal specifications in the attached document. Optional: ARMIN automatic robot cell (2024)

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 760 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 13 m/min, rapid traverse Y-axis: 13 m/min, rapid traverse Z-axis: 13 m/min, feed length X-axis: 5,000 mm, feed length Y-axis: 5,000 mm, feed length Z-axis: 5,000 mm, spindle speed (max.): 7,500 rpm, VERTICAL MACHINING CENTER MIKRON VCE 750 TRAVELS 760X400X500 SPINDLE ISO 40, 7500 RPM Lredpfoyt Il Hjx Ab Eei TOOL CHANGER WITH 20 POSITIONS

Condition: good (used), Year of construction: 2018, Traverses X Y Z: 762 x 305 x 406mm, Table 1213 x 267mm, Spindle speed 6,000 rpm, Spindle taper BT40, Spindle Motor 5.6Kw Hp, 10 station toolchanger, HAAS Control, low volt light, coolant Lrjdpfoyt Hbtox Ab Eoi

Condition: like new (used), Year of construction: 2021, Traverses X Y Z: 710 x 400 x 430mm, Table 800 x 400mm, table load 300kgs, Spindle speed 12,000rpm, Spindle taper CAT40, 5.5kW Spindle motor, FANUC Oi , 20 Station ATC, Coolant, Low Volt light, swarf conveyor Lsdpfxsyt E Uxo Ab Eeri

Condition: used, MIKRON HSM 800 ProdMod is a Vertical machining center engineered for precision, high accuracy and reliability. Working capacities: table 900×600 mm, max table load 800 kg; travels X800 × Y600 × Z500 mm. Main specs: spindle motor 12.5/22 kW, total power 26 kW, 3x 400 V 50 Hz, noise 75 dB(A), machine weight ≈8300 kg, dimensions L4000×W3700×H2500 mm. Equipment: 50‑position tool magazine (tool Ø max 75 mm, length 210 mm, max tool weight 2.5 kg). Delivers tight tolerances; typical applications: automotive, aerospace, medical, machine tools and watchmaking. Ljdpeytu Hkefx Ab Ejri

Condition: ready for operation (used), Year of construction: 2001, travel distance X-axis: 750 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 500 mm, controller manufacturer: HAAS, total height: 2,700 mm, total width: 2,400 mm, table load: 700 kg, overall weight: 5,000 kg, spindle speed (max.): 7,500 rpm, product length (max.): 2,400 mm, number of axes: 4, This 4-axis HAAS VCE 750 was manufactured in 2001. It features an X-axis travel of 750 mm, Y-axis travel of 400 mm, and Z-axis travel of 500 mm. The machine includes a table size of approximately 900 x 350 mm and a maximum table load of 700 kg. If you are looking to get high-quality machining capabilities, consider the HAAS VCE 750 vertical machining centre we have for sale. Contact us for further details. • Table size: approx. 900 × 350 mm • Tool magazine: 20 positions (carousel) • Included options: 4th axis; through-spindle cooling Technical Specification Lredpfxeytqvhj Ab Esi Taper Size ISO 40

Condition: good (used), Year of construction: 2004, operating hours: 6,679 h, functionality: fully functional, machine/vehicle number: H-30459, travel distance X-axis: 760 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, total height: 2,800 mm, total length: 3,200 mm, total width: 2,200 mm, table width: 510 mm, table length: 1,020 mm, table load: 1,000 kg, overall weight: 4,700 kg, spindle speed (max.): 10,000 rpm, Equipment: documentation/manual, HURCO VMX 30 Vertical Machining Center - Spindle nose to clamping table: 152 – 762 mm - Table T-slots (DIN 650): 5 - For further technical data, see photos - With technical documentation Lodpeytny Defx Ab Ejri - Important note: The machine vices visible on the work table are not included in the scope of supply! - A tool holder package is included in the delivery. Attention: The item must be collected bindingly between 27.04. and 30.04.2026 on a date to be agreed. FCA D-39126 Magdeburg – loaded onto truck

Condition: used, Year of construction: 2015, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, controller manufacturer: Haas, workpiece weight (max.): 1,588 kg, total height: 3,023 mm, total length: 4,089 mm, total width: 3,353 mm, rotational speed (min.): 40 rpm, rotational speed (max.): 8,100 rpm, overall weight: 6,033 kg, Equipment: documentation/manual, CNC Vertical Machining Centre CNC Control Haas CNC Table size 1.321 x 457 mm Lsdpfx Abeytb Sys Eori Table load 1.588 kg Number of pallets: 1 x Movement X-axis 1.270 mm Movement Y-axis 508 mm Movement Z-axis 635 mm Spindle taper MAS BT40 Spindle speed 40 - 8.100 1/min Spindle motor 22,4kW Magazin capacity 24 + 1 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.
