Kohlbecker GmbH & Co KG

Condition: good (used), Year of construction: 1976, functionality: fully functional, Technical data : Power 40 to 2 lifting speeds 57 + 86 H/min Projection 250 mm . Further data according to offer Bedpsygv Ezjfx Ac Necu . Delivered with new press test incl. new test report. .

Condition: refurbished (used), pressure 40 t throat 225 mm stroke 8 - 84 mm table surface area 580 x 450 mm ram adjustment 55 mm no. of strokes 130 Hub/min ram surface 185 x 180 mm Bcjdoyf N Dzspfx Ac Nsu ram hole 40 mm hole in the table 210 x 170 mm clamping plate 570 x 450 mm total power requirement 3,5 kW weight of the machine ca. 2,7 t

Condition: good (used), Year of construction: 2012, Condition: 2012 overhauled to the latest UVV Installation height: 800 mm Ram stroke: 500 mm Projection: 360 mm Nominal force: 400 kN Hydraulic pressure: 160 bar Bsdpfeydlx Ssx Ac Njcu Operating hours: 1356 Other: new control from Pilz, electrical circuit diagrams available Video about functionality available

Condition: used, Year of construction: 1990, pressure 125 t throat 360 mm stroke 8 - 140 mm daylight, max. stroke above - ram adjustment above 500 mm ram adjustment 100 mm ram surface 800 x 400 mm table surface area 1000 x 720 mm clamping plate 990 x 670 mm Bsdpfx Ajyatx Eoc Nscu clamping plate thickness 80 mm no. of strokes 60 Hub/min tool shank hole (depth x diameter) 90 x 50 mm total power requirement 23 A weight of the machine ca. 11 t dimensions of the machine ca. BxTxH 2770 x 2520 x 2950 mm - Hydraulically operated Ortlinghaus clutch-brake combination - Belt drive - Hydraulic overload protection - Hydraulic connecting rod clamping - Motorized tappet height adjustment - Semi-automatic stroke adjustment - Manual TDC correction - Fixed table - Reverse switch (return) - Electric stroke counter - Electric preselection counter - Cam switch mechanism The machine is partially overhauled in-house as follows: - Disassembled, cleaned, and completely technically inspected - New paintwork (also available according to customer specifications) - New seals - New control cabinet with touchscreen, including wiring of the machine - Current press inspection

Condition: used, Single-column eccentric press HELMERDING Type EH 25 B Machine No. 5917 Year of manufacture: 1993 Pressing force: 25 tons Bcjdpfxsyath Te Ac Nju Throat depth: 180 mm Table area: 560 x 360 mm Ram area: 315 x 150 mm Table through-hole: 150 x 100 mm Stroke adjustment: 8 - 82 mm Ram adjustment travel: 60 mm Installation height max.: 330 mm Clamping pin bore: Ø 40 mm Strokes per minute: 145 Table height adjustment: 150 mm Table height above floor: 630 - 780 mm Motor power: 1.5 kW Power supply: 400 Volt, 50 Hz - Hydraulic clutch-brake combination, manufacturer: ORTLINGHAUS - Electric foot switch and two-hand control - Automatic central lubrication by BEKA lubrication system - Electrical cabinet with 2-channel contactor control - Press table height-adjustable via 2 threaded spindles - UVV [accident prevention regulations] according to VBG 7n 5.1 for manual loading operations - Electrical diagram Space requirements (L x W x H): 1600 x 1100 x 1900 mm Weight: 2 tons Good condition

Condition: good (used), Stock number: 2829 Manufacturer: Eisenwerk Hensel Bayreuth - EBU Machine number: P5044070 Type: SK 25 Press force: 25 t Table: 595 x 410 mm Ram: 170 x 150 mm Passage hole: 210 x 170 mm Throat depth: 200 mm Strokes per minute: 150 Stroke: 4 to 80 mm Bcsdpfx Aex Uwb Isc Neu Ram height adjustment: 70 mm Table adjustment: 240 mm Condition: good Connection: 1.5 HP (1.1 kW) Weight: 1.5 t Dimensions: 800 x 1,300 x 2,000 mm

Condition: excellent (used), safe to handle, with new UVV test: Power 50 to lifting speed 115 /min throat depth 250 mm ram stroke 8 - 120 mm ram adjustment approx. 70 mm , Table, WxD approx. 650 x 500 mm Drop-through hole approx. 250 x 180 mm Max. Max. installation height approx. 380 mm Bjdsx S Hxwspfx Ac Nocu . .

Condition: good (used), Year of construction: 1990, In good technical condition, fully functional. Year of manufacture: 1990. Nominal press force: 63 tons. Table working surface dimensions: 800 x 630 mm. Machine weight approx. 6 tons. Bcjdpfex Sqtfex Ac Nou

Condition: good (used), Year of construction: 1978, Pressing force 45 t Bcsdpex Rvbxjfx Ac Nsu

Condition: new, Year of construction: 2025, table width: 400 mm, table length: 600 mm, stroke adjustment: 45 mm, overall weight: 1,500 kg, pressing force: 35 t, stroke length: 70 mm, power: 3 kW (4.08 HP), punching force: 35 t, warranty duration: 24 months, Equipment: safety light barrier, An eccentric press is a type of mechanical press powered by force generated via an eccentric mechanism, used for cold forming operations such as punching, cutting, and die forming. Thanks to its high production speed and repeatability, it offers an efficient and reliable solution for mass production lines. The CRONOSSTECH C-Type Eccentric Press 35 Ton is designed for stable performance in cold forming applications. Its rigid steel frame, pneumatic clutch-brake system, and CE-compliant safety infrastructure provide reliable performance suitable for serial production. Key Advantages - Consistent stroke performance and high repeatability in mass production - Operator safety-focused design (light curtain + safety systems) - Low maintenance requirement thanks to centralized automatic lubrication - Production-ready operation with PLC control and dual-hand/foot pedal controls Applications - Cold cutting and punching operations - Cold cropping applications - Metal die forming - High-volume production lines ✅ STANDARD FEATURES • Steel construction frame • Four-sided guideways • Spheroidal cast iron connecting rods and gear bearings • Crankshaft and transmission shafts made from 4140 tempered steel • Fully automatic central grease lubrication system • Pneumatic clutch and brake combination • Conforms to CE safety directives Bedpfex N Nd Rjx Ac Njcu • Dual-coil safety valve • Manually adjustable stroke • Light curtain finger–hand safety system • PLC control system • Dual-hand/foot pedal control system • Mechanical safety lock system • Emergency reverse motor operation • Compliant with occupational safety regulations • CE compliant ✅ OPTIONAL FEATURES • Anti-vibration mounts • Touchscreen LCD (standard for 150–300 ton) • Hydraulic safety system (standard for 200–300 ton) • Spare bolster plate • Decoiler, feeder, and straightener • One set of dies tailored to your specifications • 8-sided slide guide ✅ TECHNICAL SPECIFICATIONS (35 TON) Capacity: 35 Ton Usable bolster size: 400×600 mm Stroke length: 0–70 mm Nominal material thickness: 2.5 mm SPM (strokes per minute): 120 Bolster–ram distance: 330 mm Adjustment (ram adjustment): 45 mm Bolster hole diameter: Ø130 mm Ram die shank diameter: Ø35 mm Safety lock: Mechanical safety lock Lubrication system: Automatic lubrication PLC: Included Safety barrier: Included Operation system: Pneumatic clutch–brake system Mounting type: Floor-standing Frame type: C-type steel construction Motor power: 3 kW Motor speed (RPM): 1450 Approximate machine dimensions (L×W×H): 1100×1400×1800 mm Approximate weight: 1500 kg Note: Please contact us for any modifications required in technical specifications. ✅ PRODUCTION / SUPPLY NOTE This machine is manufactured by CRONOSSTECH in Turkey. Sales, commissioning, and after-sales services are managed by CRONOSSTECH.

Condition: used, Year of construction: 1999, Press Model: T50 CNR4 Year of construction: 1999 Nominal force: kN 500 Mass: Kg. 3,500 Shots per minute: N° 90 Max. insertions per minute: N° 41 Min./max. operating air pressure: BAR 4÷5.5 Stopping time: 0.117 s Safety distance: 187 mm Energy: KJ 2000 Adjustable min./max. stroke: 8÷100 mm Hammer adjustment: 70 mm High adjustment P.M.I: mm.280 Maximum extraction stroke: mm. 30 Worktop surface: 770x530x58 mm Mallet surface size: mm. 450x300 Shank diameter: mm. 45 Protrusion from the centre: 270 mm Max. size mould: mm. 450x300 Upper mold mass: 84 kg Bcjdpfxox Nhbno Ac Neu Voltage: V 400

Condition: used, Year of construction: 2007, pressure 125 t stroke 12 - 140 mm daylight, max. stroke above - ram adjustment above 495 mm ram adjustment 100 mm ram surface 800 x 400 mm table surface area 1000 x 720 mm clamping plate 990 x 670 mm Bcjdpfjxx A Dtox Ac Nou clamping plate thickness 80 mm total power requirement 70 A weight of the machine ca. 11 t dimensions of the machine ca. BxTxH 2770 x 2520 x 2950 mm - Hydraulically operated multi-disc wet multi-plate clutch and spring-loaded safety brake - Hydraulic overload protection - Hydraulic connecting rod clamping - Motorized ram height adjustment - Semi-automatic stroke adjustment - Ram weight compensation - Manual TDC correction - Belt drive - Press force measuring device - hanging control panel - reverse switch (return) - electric stroke counter - electric preselection counter - electronic cam switch - clamping plate - two-hand control panel, swiveling, height-adjustable - Operating hours counter - 1 set of swing elements - with feed The press is technically inspected at our premises and undergoes a current safety inspection.

Condition: good (used), Brand: WMW Model series: Ruckmarsdorf / Biberitz Manufacturer: VEB Maschinen- und Anlagenbau Country of origin: GDR (former East Germany) Total weight: 2,700 kg Bcodpoxw Nncsfx Ac Nju Power type / Frequency: 3 PEN – 50 Hz Mains voltage: 380 V Control voltage: 110 V Power: 3.0 kW Rated current: 12.5 / 7.2 A Technical specifications: Pressing force: 400 kN Torque: 6080 Nm Shearing area: 1000 mm² (at Ta = 392 MPa) Single stroke working energy: 3530 J Continuous working energy: 1765 J Stroke: 8 – 84 mm Tool installation height: 308 mm Ram adjustment: 55 mm Strokes per minute: 130 Note: The information on this page has been obtained and compiled to the best of our knowledge, but accuracy cannot be guaranteed. Accordingly, it does not constitute representation or contract and we recommend verifying all relevant details. Financial information VAT/margin: Margin: The displayed price includes VAT (VAT not deductible for businesses).

Condition: good (used), Year of construction: 1999, 1 used eccentric press, Ambold make Model: PEEV 40/2 Press force: 40 t Throat depth: 225 mm Stroke: 8 – 84 mm Table size: 580 x 450 mm Ram adjustment: 55 mm Bjdpfx Acsxvqlto Nocu Strokes per minute: 130 spm Ram area: 185 x 180 mm Ram bore: 40 mm Drop-through opening in table: 210 x 170 mm Clamping plate: 570 x 450 mm Total power requirement: 3.5 kW Machine weight: approx. 2.7 t Dimensions (LxWxH): approx. 1.4 x 1.1 x 2.1 m

Condition: new, Year of construction: 2022, functionality: fully functional, machine/vehicle number: EEP-30.22070 A.D, throat depth: 180 mm, ram adjustment: 60 mm, table height: 700 mm, total height: 2,150 mm, drop-through hole in table: 150 mm, table width: 580 mm, table length: 360 mm, total width: 1,500 mm, total length: 1,250 mm, overall weight: 1,900 kg, pressing force: 45 t, distance table to ram: 350 mm, stroke length: 90 mm, power: 4 kW (5.44 HP), compressed air connection: 6 bar, input voltage: 380 V, stroke rate (max.): 145 1/min, Equipment: CE marking, documentation/manual, safety light barrier, For Sale: ELMALI EEP-PK45 C-Type Eccentric Press – Like New Condition (+ gratis compressor) We are offering a nearly unused ELMALI EEP-PK45 eccentric press machine, manufactured in 2022 in Turkey. This robust C-frame press delivers a 45-ton pressing force, making it ideal for precision metal forming applications. The machine has never been used in production and is in excellent condition — ready for immediate operation. - Steel frame construction body - Ram and similar pieces steel casting - Pneumatic clutch and brake combination - 4 guide ram - Ram adjustment - Main and extra table with T slots - Single or continous stroke Bodpfx Acsxq Sbfe Njcu - Foot pedal or double hand control - Centralized lubrication system - Gear in oil bath - Photocell safety guard - Die Adjustment and Reverse turn mode For the machine we are offering a KÄSER Premium 200/24W type compressor as a gratis.

Condition: used, Manual folding machine Schuller MAH 2-2000, working width 2030 mm, sheet thickness 2.0 mm Bcjdpfx Asxn Avnoc Nsu

Condition: good (used), – Capacity 25 tons – Table 525 x 405 mm Bodpfx Acoxk Tm No Nocu – Stroke 75 mm – 120 strokes/min. – Foot control or two-hand operation – Central lubrication system – 380V

Condition: used, Year of construction: 1986, pressure 35 t throat 240 mm stroke 12-84 mm no. of strokes 135 Hub/min ram - range of adjustment 70 mm table surface area 600x450 mm ram surface 360x180 mm hole in the table 220x130 mm table height 630 mm Bcsdpfx Ajxh Sx Ejc Nou tool hole in ram Ø35 mm weight of the machine ca. 2,5 t dimensions of the machine ca. BxTxH 1500x2000x2600 mm

Condition: new, Year of construction: 2025, throat depth: 175 mm, table width: 375 mm, table length: 570 mm, stroke adjustment: 60 mm, pressing force: 25 t, An eccentric press is a type of mechanical press driven by a force generated through an eccentric mechanism, used in cold forming operations such as punching, shearing, and die forming. Thanks to its high production speed and repeatability, it provides an efficient and reliable solution for mass production lines. CRONOSSTECH C-Type Eccentric Press 25 Ton is designed for stable operation in cold forming applications. Its rigid steel frame, pneumatic clutch-brake system, and CE-compliant safety infrastructure deliver reliable performance suited for mass production. Key advantages: - Stable stroke performance and high repeatability in series production - Operator safety-focused design (light curtain + safety systems) - Low maintenance requirement with centralized automatic lubrication - Production-ready usage with PLC control + dual hand/foot operation Areas of use: - Cold shearing and punching operations - Cold blanking applications - Metal die forming - High-volume production lines STANDARD FEATURES • Steel fabricated body • Four-sided guided ram • Spheroidal cast iron connecting rod and gearboxes • Crankshaft and transmission shafts made of 4140 normalized steel • Centralized fully automatic grease lubrication system • Pneumatic clutch and brake combination • Compliant with CE safety directives • Dual coil safety valve • Manually adjustable stroke • Light curtain finger–hand protection safety system • PLC control system • Dual hand/foot operation system • Mechanical safety system • Emergency reverse motor function • Conforms to occupational safety regulations • Meets CE standards OPTIONAL FEATURES • Anti-vibration pads • Touchscreen LCD panel (standard for 150–300 tons) • Hydraulic safety system (standard for 200–300 tons) • Spare bolster plate • Decoiler, feeder, and straightener • One die set customized to requirements • Eight-sided slide guidance TECHNICAL SPECIFICATIONS (25 TON) Capacity: 25 Ton Throat depth: 175 mm Bed-to-ram distance: 300 mm Slide-to-table distance: 310 mm Distance between uprights: 290 mm Ram adjustment (stroke regulation): 50 mm Approx. press width: 870 mm Approx. press depth: 1380 mm Approx. press height: 1870 mm Front anchorage dimension: 490 mm Side anchorage dimension: 670 mm Table hole diameter: Ø145 mm Table size: 375×570 mm Die mounting slot diameter: Ø35 mm Ram size: 260×170 mm Floor to table height: 710 mm Stroke adjustment: 10–60 mm Strokes per minute: 120 spm Motor power: 3 kW Bsdexg R Ucopfx Ac Njcu Motor speed: 1000 rpm Approx. weight: 1300 kg Note: Please inform us if you require any modifications to the technical specifications. PRODUCTION / SUPPLY NOTE This machine is manufactured by CRONOSSTECH in Turkey. Sales, commissioning, and after-sales processes are managed by CRONOSSTECH.

Condition: good (used), pressing force: 25 t, – Capacity 25 tons – Table 360 x 350 mm – Foot control – 380V Bcedoxc N Tcopfx Ac Neu

Condition: used, Russian manufacturing, Max. pressing force: 25 t Bodpfjxbf Sfex Ac Nocu Table size: 550 x 400 mm

Condition: new, Safety valve for presses IMI HERION / NORGREN PSV valve, twin valve, directional control valve Type: XSz 10 V ID No. 2492982 Serial No. 2608 Equivalent to order no.: 2492951 Pressure: 3 to 10 bar Compressed air connection thread (A)+(B)+(P)+(S): 1/2" Compressed air outlet (R): flange connection Supply voltage: 2x 24 Volt (DC) - Base plate hole spacing 115 x 63 mm, 4x mounting holes Ø 6.5 mm - Equipped with silencer on compressed air outlet (R) Valve body dimensions L x W x H: 105 x 90 x 220 mm Dimensions with silencer L x W x H: 180 x 165 x 220 mm Weight: 3.0 kg New, unused, from stock Bcodpew T U A Sofx Ac Nsu

Condition: used, Year of construction: 1978, machine/vehicle number: 4788, Capacity: 35 ton Throat depth: 225 mm Ram stroke: 8 - 80 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 325 mm Table surface area : 600 x 450 mm Slide area: 300 x 225 mm Number of strokes: 160 s.p.m. Required power: 2,2 kW Dimensions L x W x H: 1000 x 1600 x 2200 mm Weight of machine approx.: 1,9 ton Bjdpow Tukijfx Ac Nocu

Condition: used, Year of construction: 2004, functionality: fully functional, total height: 2,810 mm, total width: 1,240 mm, total length: 200 mm, overall weight: 3,200 kg, pressing force: 50 t, year of last overhaul: 2025, DESCRIPTION Heavy-duty eccentric press with pneumatic clutch, supplementary counter table, centralised lubrication, and impact protection guards with a front methacrylate door. CE compliant. SPECIFICATIONS Maximum pressing force: 50t Upper work table length: 450 mm Upper work table width: 310 mm Lower work table length: 750 mm Lower work table width: 440 mm Central bore, scrap ejection: 160 mm Minimum closed die height: 290 mm Maximum closed die height: 340 mm Maximum strokes per minute (variable): 72 to 180 x min Minimum slider stroke length: 12 mm Maximum slider stroke length: 110 mm Spindle adjustment: 70 mm Machine height: 2,810 mm Machine length: 2,000 mm Machine width: 1,240 mm Power: 4 kW Machine weight: 3,200 kg Bcodpfx Acsw S Igbe Neu Year of manufacture: 2004

Condition: used, Year of construction: 2000, functionality: fully functional, total height: 2,810 mm, total width: 1,240 mm, total length: 1,500 mm, overall weight: 4,300 kg, pressing force: 60 t, year of last overhaul: 2025, MODEL PE-63 Maximum force (pressing): 63 t Upper work table length: 450 mm Upper work table width: 310 mm Lower work table length: 900 mm Lower work table width: 560 mm Bedpfxsw S Icvo Ac Nscu Central hole for scrap ejection: 250(280) mm Usable vertical daylight between tables: 430 mm Max. admissible closed die height: 340 mm Maximum strokes per minute: 38-100 /min Minimum slide stroke length: 8 mm Maximum slide stroke length: 92 mm Ram adjustment: 80 mm Machine height: 2810 mm Machine length: 1500 mm Machine width: 1240 mm Power: 5.5 kW Machine weight: 4,300 KG Year of manufacture: 2000
