Condition: good (used), x-travel 300 mm y-travel 350 mm z-travel 350 mm taper in main spindle ISO 40 table surface area 625 x 380 mm T-slots 8 Stk. turning speeds 40.0 - 2.000 U/min transmission ratio 18 Stk. feed stepless 0 - 500 mm/min quill stroke 60.0 mm distance spindle nose and table min 50 / max 400 mm voltage 400 V total power requirement 5.1 kW weight of the machine ca. 800 kg range L-W-H 1400 x 1100 x 1700 mm from a training workshop (vocational school) Well maintained (!!) Features: - Robust electric motor universal milling machine Dksdpjxl E Stjfx Aamou - HEIDENHAIN 3-axis digital display - Rotatable universal milling head (right/left = 90°) - Manual milling spindle feed, with lock - Stable T-slot angle/clamping table * Swiveling +/- 30 degrees - Axis feed with rapid traverse in X+Z+Y axis * Rapid traverse continuously adjustable - Swiveling machine light - Control cabinet, installed on the left - Coolant device

Condition: good (used), x-travel 315 mm y-travel 180 mm z-travel 320 mm taper in main spindle ISO 40 table surface area 600 x 250 mm T-slots 5 Stk. turning speeds 45.0 - 1950 U/min feed stepless 10 - 170 mm/min voltage 400 V total power requirement 5.1 kW weight of the machine ca. 1300 kg range L-W-H 1000 x 1400 x 1800 mm From a training workshop (vocational school) Well maintained (!!) Features: - Robust electric motor universal milling machine - HEIDENHAIN 3-axis digital display - Rotatable universal milling head (right/left = 90°) - Manual milling spindle feed, with lock Djdpfx Aajxl E Smomsku - Stable T-slot clamping table - Axis feed with rapid traverse in X+Z+Y axis * Rapid traverse continuously adjustable - Swiveling machine light - Control cabinet, installed on the left - Coolant device

Condition: good (used), x-travel 315 mm y-travel 180 mm z-travel 320 mm taper in main spindle ISO 40 table surface area 600 x 250 mm T-slots 5 Stk. turning speeds 45.0 - 1950 U/min feed stepless 10 - 170 mm/min voltage 400 V total power requirement 5.1 kW weight of the machine ca. 1300 kg range L-W-H 1000 x 1400 x 1800 mm From a training workshop (vocational school) Dksdpfx Asxl E Sgjameu Well maintained (!!) Features: - Robust electric motor universal milling machine - HEIDENHAIN 3-axis digital display - Rotatable universal milling head (right/left = 90°) - Manual milling spindle feed, with lock - Stable T-slot clamping table - Axis feed with rapid traverse in Y-axis * Rapid traverse continuously adjustable - Manual axis adjustment in Z+X axis - Control cabinet, installed on the left - Coolant device

Condition: excellent (used), functionality: fully functional, Speeds: Row 1, stepless 150 – 1000 rpm Row 2, stepless 300 – 2000 rpm Mount: ISO 30 Feed rate in X approx.: Row 1, stepless 15 - 60 mm/min Row 2, stepless 50 – 250 mm/min Travel range approx.: in X 280 mm in Y 170 mm in Z 250 mm Dodpfjxcyzwex Aameku

Condition: used, Year of construction: 1986, table size cross table 490 x 400 mm axis stroke (X,Y,Z) 320x385x430 mm reus 560 - 14000 U/min tool taper SK 30 table load max. 100 kg Weight ca. 500 kg Djdpfxoxbh E Uo Aamjku

Condition: ready for operation (used), Year of construction: 2010, x-travel 280 / 300 mm y-travel 250 / 270 mm z-travel 300 / 310 mm turning speeds 45 - 2240 U/min turning speeds 18 Stufen spindle taper ISO 40 quill stroke 60.0 mm table: 670 x 320 mm table load 150 kg feed range 12.5 - 630 mm/min feed 18 Stufen rapid traverse 1.200 mm/min workpiece weight max. 150 kg T-slots 5x 12 x 63 mm total power requirement 1.6 kW weight of the machine ca. 1100 kg range L-W-H 1265 x 1080 x 1620 mm Dsdpfx Ajxabqnoamjku New price ~ 25.000 Euro (!!) Special price upon request - in checked conditions - machinevideo - ?v=7IsC5cg9WlI Features: - Robust electric-driven universal milling machine - ACURITE 3-axis digital display * with pivoting control panel, front right * including emergency stop button - Electric adjustment of all axes (X/Y/Z axes) * Rapid traverse in all 3 directions - Pivoting milling spindle guard - Coolant system - Lower chip tray - Vertical milling head with quill adjustment * Milling head rotation 90° * Tool holder ISO / DIN 40 / 2080 - Fixed angle table 670 x 320 mm * T-slot width x spacing 12 x 60 mm * Minimum distance between base table and spindle axis - 4 machine feet - Electrical diagram

Condition: good (used), functionality: fully functional, A rare find is up for sale. Condition is excellent, very little used, works perfectly. Dedpfxow U Eryo Aamsku

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 211031, Country of manufacture: Switzerland Voltage: 380/50/3 Net weight: 740 kg Overall dimensions: 155 x 110 x 160 cm Installed power: 2.10 kW Customs tariff number: 8459.6930 TECHNICAL SPECIFICATIONS Vertical rectangular table: - usable surface: 740 x 200 mm - number of T-slots: 2 - width of T-slots: 12-H7 - distance between slots: 120 mm Fixed right-angle table: - usable surface: 700 x 250 mm - number of T-slots: 5 - width of T-slots: 12-H7 - distance between slots: 40 mm - possible lateral movement: 250 mm total Universal tilting table: - usable surface: 600 x 210 mm - number of T-slots: 4 - width of T-slots: 12-H7 - distance between slots: 40 mm - possible lateral movement: 350 mm total Adjustable in 3 planes, on either side: 30°-45°-30° Spindle internal taper: - horizontal spindle head: ISO 30 (40) - vertical spindle head: ISO 30 (40) - universal rapid head: SV E20+ES20 Swivel in vertical plane: vertical spindle head: 360° Longitudinal travel, hand/automatic: 320/300 mm Vertical travel, hand/automatic: 375/355 mm Cross travel, adjustment handle: 150 mm Quill stroke: 60 mm Readout accuracy on micrometer verniers: 0.02 mm Main motor power/speed: 1.5 kW/1500 rpm Rapid feed motor power/speed: 0.45 kW/3000 rpm Coolant device motor power/speed: 0.15 kW/3000 rpm Spindle speed range: - 1st range: 58-375 rpm - 2nd range: 330-2000 rpm Feed rates (longitudinal or vertical): 12-400 mm/min - 10 feed rates, mm/min: 12-18-26-38-57-85-125-185-270-400 Dedpfsw Uc Npjx Aamoku Rapid traverse speed (longitudinal or vertical): 1200 mm/min All technical data is given without obligation and subject to errors or omissions.

Condition: used, Year of construction: 1999, Weight 3 to x-travel 750 mm milling-head swivable +/- ja Dkedpsw Sydrefx Aamou ja

Condition: used, Macmon M100 Universal Milling Machine - Feed range in steps: 9–450 mm/min - Horizontal spindle speed: 40–2000 rpm - 21 vertical spindle speeds: 50–2500 rpm Dsdow Rn Ipepfx Aamoku - Spindle taper: SK40 - Quill overhang: approx. 100–320 mm - Clearance under spindle: 350 mm - Vertical head quill diameter: 70 mm - Vertical head swivels 360° - Fixed angle table: 215 x 600 mm - Cross travel (manual): 170 mm - Vertical travel motor/manual: 310/340 mm - Longitudinal travel motor/manual: 290/310 mm - X-axis travel: 310 mm - Y-axis travel: 340 mm - Z-axis travel: 170 mm - Automatic feed and rapid traverse on all 3 axes - Total power requirement: 2.5 kW - Spindle drive: 2.2 kW - Total drive: 2.5 kW, 380V, 50Hz - 3-axis digital readout - Dimensions (LxWxH): 1.5 x 0.7 x 1.5 m - Weight: 900 kg

Condition: good (used), Digital read-out With milling and drilling head Working travels 330 x 400 x 475mm Table size 650 x 245 mm Spindle taper for collets ISO 40 Spindle speeds 63-2'800 rpm Misc.accessories MARCELS MASCHINEN CH Dkedsw Nnutspfx Aameu

Condition: as good as new (ex-display), Universal milling machine Make: OPTImill Model: MZ 4 SV Item No.: 3346245 Dedpfx Ajw I Efysameku Year of manufacture: 2019 - Demonstration machine Serial No.: 1910591 Travel distances: - X-axis: 600 mm (automatic: 560 mm) - Y-axis: 480 mm (automatic: 440 mm) - Z-axis: 390 mm (automatic: 350 mm) Standard equipment includes: - 3-axis digital readout - Automatic feed on all 3 axes stepless from 10 to 600 mm/min - Fixed table 900 x 500 mm (T-slot 14 mm) - Vertical milling head SK 40 with drawbar thread M16 - Splash guard enclosure - Machine lamp - Centralized lubrication, electric - Support with counter-bearing for horizontal milling - Coolant system - Operating tools - Operating manual Including the option: pneumatic tool clamping Including the option: Vario conversion with Siemens inverter drive Sinamics G 110M Stepless speed from 48 to 3,045 rpm via 2 x 6 gear stages

Condition: good (used), For sale: Optimum OPTImill MF 2 Vario universal milling machine from training workshop – very well maintained, with low operating hours Manufacturer: Optimum Model: Universal Milling Machine OPTImill MF 2 Vario Year of manufacture: 2007 Dksdsw A Rg Tspfx Aamju Condition: used, good Technical specifications: - Motor: 1.5 kW, 400V ~50Hz - Drilling capacity in steel (St.37): Ø 24 mm - Continuous drilling capacity in steel (St.37): Ø 20 mm - Spindle taper: ISO 40 (DIN 2080, DIN 69871) - Cutter head size: Ø 76 mm - End mill size: Ø 18 mm - Quill travel: 127 mm - Throat: 213–533 mm - Spindle head tilting range: 45° - Variable speed range: 10 – 5100 rpm - Spindle speed: 6 steps, infinitely variable - Automatic quill feed: 0.04 / 0.08 / 0.15 mm/rev - Table size (LxW): 1244 x 230 mm - Manual Z-axis travel: 406 mm - Manual Y-axis travel: 305 mm - Automatic X-axis travel: 800 mm - Table load capacity: 230 kg - T-slot size/spacing: 16 mm / 63 mm - Spindle – table distance: 57 – 463 mm - Dimensions (L x W x H): 1400 x 1450 x 2150 mm - Total weight: 950 kg Included in delivery: – Coolant system – Chip tray – Automatic table feed, X-axis – Operating tools – Machine vice

Condition: used, Year of construction: 1973, Weight 3 t Dkedpfowzyt Tsx Aameu x-travel 1000 mm 110 milling-head swivable +/- ja

Condition: refurbished (used), Digital display: 3-axis Spindle mount: SK40 Spindle speed: 40-2000 rpm Dkodswx Nqcspfx Aameu Travel: X 300 mm, Y 160 mm, Z 340 mm

Condition: good (used), functionality: fully functional, DECKEL FP1 Active milling machine Manufacturer: Deckel Type: FP1 Active Condition: very good Control type conventional Dodpfx Ajwp Hiksamsku Control active HEIDENHAIN TNC X-path 300 mm Y-path 160 mm Z-path 340 mm Tool holder SK40 Speed 40-2000 rpm. Control Active HEIDENHAIN TNC Total power requirement 2 kW Machine weight approx. 0.73 t Space requirement approx. TBH 1200x1100x1600 mm

Condition: used, Year of construction: 2007, reus 8000 min-1 U/min Weight 5500 kg Year 2007 Control Siemens 840D Dimensions (L/W/H) 3600 x 2800 x 2400 mm Dsdswm Rqaspfx Aamsku travel -x axis 1035 mm travel -y axis 560 mm travel -z axis 510 mm

Condition: used, Year of construction: 1968, Second-hand milling machine The milling machine is still functional, but a few control elements no longer operate smoothly. A final examination for a machining mechanic was last taken on this machine 3 years ago. -Clamping table: rotatable/tilting/swiveling -Travel X/Y/Z: 550/340/420 mm Weight: approx. 1780 kg Clamping jaws and tools are also included. Important note: Dkodpfx Ajwl I Adjamju The milling machine is only available for pickup. We do not have a forklift; only standard pallet trucks are available. This means that all transport, including loading, must be undertaken by the buyer.

Condition: used, Year of construction: 2004, gebraucht 2004 4540 prompt, Zwischenverkauf v Österreich 23700 € 1 19900 € 63 - 3150 (18) U/min 700 x 500 x 500 mm 900 x 500 mm 6.6 kW 2150 mm 2220 mm 2120 mm 2550 kg 500 kg 100 mm CNCHeidenhain TNC 410 18. mech. feeds with rapid travel in X,Y,Z axes ball screw spindles toolmaker accuracyDIN 8615 hyd. tool clamping with holdersSK40 vertical und horizontal vertical spindle+/- 30° swiveling swing out device digital 3D edge finder work area protection coolant equiptment aut. central lubrication fixed angle table with 10 t-slots Dkedpfxewirmno Aamju chip collecting tray machine lamp users manual in GERMAN + CE COMPLIES WITH THE CURRENT INDUSTRIAL SAFETY REGULATIONS (AMVO & UVV)

Condition: used, Year of construction: 2023, gebraucht 2023 4546 prompt, Zwischenverkauf v Taiwan 32800 € 1 65 - 2600 U/min ISO 40 420 x 220 x 380 mm 840 x 390 mm 2.2 kW 1600 mm 1700 mm 2000 mm 1145 kg 840 x 390 mm 1000 mm/min 5 14 x 63 mm 200 kg 420 mm 220 mm 380 mm 0 - 600 mm/min. 0 - 600 mm/min. 65 - 2600 90 - 310 mm 65 - 2600 +/- 90° ° 100 mm manuell 2,2 kW 950 x 250 mm 90 - 310 mm 100 - 480 mm demo machine / mint condition net price (price for new machine € 41.100,00) swiveling operating panel 3 axes digital read out Fagor 40i Innova motor for horizontal- and vertical spindle: 2,2 kW feed motors with inverter for X/Y/Z: 0,35 / 0,35 / 0,75 kW ball screw spindles for X/Y/Z axes manual gear box for spindle speeds 1 pc. long milling arbor 27 mm 3 pcs. recustion sleeves (MK1, MK2, MK3) 1 pc. drawing bar ISO40 for horizontal or vertical spindle spindle protection with switch Dkedpfxewirdgo Aameu table safety guard with doors with switches outer arbor support for horizontal spindle LED work lamp automatic lubrication for X/X/Z guidways safety hand wheels for X/Y/Z axes coolant equipment with chip tray covers for X/Z axes level pads and bolts tool box with tools operating manual in English or German according to CE rules

Condition: excellent (used), functionality: fully functional, feed length X-axis: 300 mm, feed length Y-axis: 160 mm, feed length Z-axis: 320 mm, overall weight: 860 kg, Ruhla Type 58 Universal Toolroom Milling Machine Thiel Duplex 58 like Deckel FP1 Compact machine with drilling spindle and automatic feed in all 3 axes includes vice New digital display with 1 measuring rod included Swivel table +/- 0-30° Table 715 x 260mm X 300mm Y 160mm Z 320mm Dsdpfx Aswf Agdjameku Dimensions (LxDxH) approx. 110 x 110 x 170cm Inspection and testing are welcome

Condition: excellent (used), Year of construction: 2013, functionality: unexamined, machine/vehicle number: 1803007, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, mount diameter: 40 mm, total height: 2,000 mm, total width: 1,300 mm, total length: 2,100 mm, table width: 400 mm, table length: 800 mm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, overall weight: 1,500 kg, input voltage: 400 V, input current: 16 A, input frequency: 50 Hz, Connected load: 3 kW Dksdjwdn Anepfx Aamsu EQUIPMENT: Three-axis digital display (SINO)

Condition: excellent (used), Year of construction: 2017, functionality: unexamined, machine/vehicle number: 173902, travel distance X-axis: 300 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 300 mm, total height: 1,500 mm, total width: 1,100 mm, total length: 1,400 mm, table width: 200 mm, table length: 600 mm, rotational speed (max.): 2,200 rpm, rotational speed (min.): 80 rpm, overall weight: 800 kg, input current: 16 A, - Operating voltage: 3 x 400 V - Frequency: 50 – 60 Hz - Number of table slots: 4 Djdpfx Aaowdnz Domoku - Tool holder: SK 30 EQUIPMENT: - Three-axis digital readout (Heidenhain) - Collet set included

Condition: used, Universal Milling Machine MAHO MH 800 Travel X: 700 mm Dodpsv U U S Sjfx Aameku Travel Y: 450 mm Travel Z: 450 mm Spindle SA 40 Spindle exit : 125 mm Spindle speed: from 32 to 1600 RPM Table size: Length 1050 mm x Width 620 mm Manual table travel: 225 mm Table rotation at 360° Swivel table at +/- 30° Scale 3 axes ACU-RITE Sensory drilling Feeds spindle not working Clutch speed used Lubricant pump Voltage: 380 V Width: 2000 mm Depth: 2100 mm Height: 2500 mm Weight: 3 T

Condition: used, Year of construction: 1986, x-travel 390/410 mm Dksdevylkcopfx Aamju y-travel 290/310 mm z-travel 380/400 mm total power requirement 4 kW weight of the machine ca. 1,25 t dimensions of the machine ca. 2100x2100x1700 m technical data please see attachment!
